AEG BSS18CB3 User manual
Important!
It is essential that you read the instructions in this manual
before assembling, operating and maintaining the product.
Subject to technical modifications.
4
4
8
10
START
STOP
12
Remove the battery pack before starting any work on the machine.
11
55
9
13
9
6
123
6
6
Remove the battery pack before
starting any work on the machine.
1
2
2
1
click
77
75-100 %
50-75 %
25-50 %
0-25 %
8
8
2
1
1
2
click
99
123
123
123
1
2
Remove the battery pack
before starting any work
on the machine.
10
10
START
STOP
START
STOP
11 11
LOCK
12
12
13 13
1
2
click
14
14
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric
VKRFN¿UHDQGRUVHULRXVLQMXU\
Save all warnings and instructions for future reference.
IMPACT SCREWDRIVER SAFETY WARNINGS
Wear ear protectors. Exposure to noise can cause hearing loss.
Hold power tool by insulated gripping surfaces, when
performing an operation where the fastener may contact
hidden wiring. Fasteners contacting a “live” wire may make
exposed metal parts of the power tool “live” and could give the
operator an electric shock.
Sawdust and splinters must not be removed while the machine
is running.
:KHQ ZRUNLQJ LQ ZDOOV FHLOLQJ RU ÀRRU WDNH FDUH WR DYRLG
electric cables and gas or waterpipes.
Remove the battery pack before starting any work on the
machine.
Do not dispose of used battery packs in the household refuse
or by burning them. AEG Distributors offer to retrieve old batteries
to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
Use only System GBS chargers for charging System GBS
battery packs. Do not use battery packs from other systems.
Battery acid may leak from damaged batteries under extreme
load or extreme temperatures. In case of contact with battery
acid wash it off immediately with soap and water. In case of eye
contact rinse thoroughly for at least 10 minutes and immediately
seek medical attention.
SPECIFIED CONDITIONS OF USE
The cordless impact driver may be used to tighten and loosen
nuts and bolts for independent use away from mains supply.
Do not use this product in any other way as stated for normal
use.
BATTERIES
New battery packs reach full loading capacity after 4 - 5 chargings
and dischargings. Battery packs which have not been used for
some time should be recharged before use.
Temperatures in excess of 50°C reduce the performance of the
battery pack. Avoid extended exposure to heat or sunshine (risk
of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
after used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C
and away from moisture.
Store the battery packs in a 30% - 50% charged condition.
Every six months of storage, run battery down by minimum 20%
then charge the pack as normal.
BATTERY PACK PROTECTION LI-ION BATTERY
The battery pack has overload protection that protects it from being
overloaded and helps to ensure long life. Under extreme stress the
battery electronics switch off the machine automatically. To restart,
TECHNICAL DATA Cordless Impact Screwdriver BSS18CB3
Rated voltage 18 V
Tool reception ´PP
No load speed (low) 0 - 750 min-1
No load speed (medium) 0 - 2000 min-1
No load speed (high) 0 - 2750 min-1
Impact rate 0 - 3500 min-1
Max torque with battery (6.0 Ah) 220 Nm
0D[GLDPHWHUEROWQXW M14
Weight - not including battery pack 1.09 kg
BATTERY AND CHARGER
Compatible battery pack
(not included)
Compatible charger
(not included)
L1815R
L1820R
L1825R
L1830R
L1840R
L1850R
L1860R
BL1218
AL1218G
Use AEG 18V battery and charger only
15 15
switch the machine off and then on again. If the machine does not
start up again, the battery pack may have discharged completely. In
this case it must be recharged in the battery charger.
THERMAL OVERLOAD PROTECTION
Overheated cells will reduce performance, run time and life.
Overheating can occur from battery packs being exposed to very
hot environments or from the tool they are powering being over-
worked. The control electronics will automatically shut down the
battery pack to protect the cells which in turn protects the electronics
and motor within the tool. The battery pack will automatically shut
itself down again should the temperature condition remain high
when the trigger is pulled again. The system will continue to shut
the battery pack down until the temperature is returned to a safe
operating level.
CURRENT OVERLOAD PROTECTION
The control electronics will instantly shut down the battery back
when excessive current draw is detected - protecting both the
battery cells and the motor of the tool. Releasing the trigger will
reset the battery pack each time.
INDIVIDUAL CELL MONITORING
The control electronics constantly check each individual cell
and automatically adjust its charge and discharge requirements
accordingly.
This systems maximises individual cell life whilst ensuring that the
battery pack is delivering peak performance to the tool at all times.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
Use only AEG accessories and AEG spare parts. Should
components need to be replaced which have not been described,
please contact one of our AEG service agents (see our list of
JXDUDQWHHVHUYLFHDGGUHVVHV
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the machine type printed on the label and
order the drawing at your local service agents or directly at:
Techtronic Industries (Australia) Pty. Ltd.
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 361 505
Australia
Techtronic Industries N.Z. Ltd.
PO Box 12-806
Penrose AUCKLAND 1642
Tel no. 0800 279 624
New Zealand
SYMBOLS
Safety alert
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Please read the instructions carefully before
starting the machine.
Remove the battery pack before starting any work
on the machine.
Do not dispose of electric tools together with
household waste material! In observance of
(XURSHDQ'LUHFWLYH(&RQZDVWHHOHFWULFDO
and electronic equipment and its implementation
in accordance with national law, electric tools that
have reached the end of their life must be collected
separately and returned to an environmentally
compatible recycling facility.
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
Techtronic Industries (Australia) Pty. Ltd.
31 Gilby Road,
Mount Waverley VIC 3149,
Australia
Techtronic Industries N.Z. Limited
2 Landing Drive, Mangere,
Auckland, New Zealand 2022
961004169-01B
