AEMC 701 User manual

Clamp-On Multimeters
Models 701 and 703
USER MANUAL
Chauvin Arnoux, Inc. d.b.a. AEMC® Instruments
99-MAN-100071 Rev 03 01/98

Clamp-On Multimeters
Models 701 and 703
USER MANUAL
600V
OFF
A
~
V
~
~
!
COM +
Model 703
TRMS CLAMP-ON METER
AEMC
INSTRUMENTS
HOLD
MAX
V
Ω
ΩHz
MAX
+
-
¯¯¯
¯¯¯
¯¯
HOLD
A
V
RMS
kHz
600V
OFF
A
~
V
~
~
!
COM +
Model 701
CLAMP-ON METER
AEMC
INSTRUMENTS
HOLD
MAX HOLD
A
V
Ω
+
_
–
V
Ω
Ω
~
MAX

Owner’s Record
The serial number for the Clamp-On Multimeters Models 701 or 703 is
located inside the battery compartment of your instrument. Please
record this number and purchase date for your records.
CLAMP-ON MULTIMETER MODEL 701
CATALOG #1207.51
SERIAL #:
PURCHASE DATE:
DISTRIBUTOR:
CLAMP-ON MULTIMETER MODEL 703
CATALOG #1207.53
SERIAL #:
PURCHASE DATE:
DISTRIBUTOR:
AEMC®Instruments
by Chauvin Arnoux, Inc.
99-MAN-100071
3rd Revision
Printed 01/98

Table of Contents
Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
International Electrical Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Receiving Your Shipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Controls, Model 701 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls, Model 703 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Digital Display Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
AC Current Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
AC and DC Voltage Measurements . . . . . . . . . . . . . . . . . . . . . . . . 16
Max Value Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Resistance Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Continuity Sound Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Diode Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Frequency Measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Repair and Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Technical and Sales Assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . Inside back cover

2Clamp-on Multimeters Models 701 & 703
Warning
These safety warnings are provided to ensure the safety of person-
nel and proper operation of the instrument.
•Read this instruction manual completely before attempting to use
or service this instrument and follow all the safety information.
•Use caution on any circuit: Potentially high voltages and cur-
rents may be present and may pose a shock hazard.
•The instrument must not be operated beyond its specified oper-
ating range.
• Safety is the responsibility of the operator.
•Never open the back of the instrument while connected to any
circuit or input.
•Always make connections from the instrument to the circuit
under test.
•Always inspect the instrument and accessory leads for service-
ability prior to use, and replace defective parts immediately.
•Do not use the meter or any test leads, connectors, probes or
clips if they look damaged.
•Never use the clamp-on meters on electrical conductors rated
above 600 Vrms.
• Never make resistance measurements on a live circuit.
• Never make diode tests on a live circuit.
•Do not have voltage or current inputs connected at the same time.

Clamp-on Multimeters Models 701 & 703 3
International Electrical Symbols
This symbol signifies that the Models 701 and 703 are protect-
ed throughout by double or reinforced insulation. Only use
specified replacement parts when servicing the meter.
This symbol signifies CAUTION! and requests that the user
refer to the user manual before using the meter.
Receiving Your Shipment
Upon receiving your shipment, be sure that the contents are consistent
with the packing list. Notify your distributor of any missing items. If the
equipment appears to be damaged, file a claim immediately with the
carrier and notify your distributor at once, giving a detailed description
of any damage.
Packaging
Clamp-On Multimeter Model 701 (Cat. #1207.51) and Model 703
(Cat. #1207.53) include a 9 V battery, two 4-ft (1.2 m) test leads, a user
manual and a soft carrying case.
!

4Clamp-on Multimeters Models 701 & 703
Description
The AEMC®Instruments Clamp-on Multimeter Models 701 and 703 are
general purpose professional clamp-ons. A strong mechanical case
design, quality materials (GE Lexan®), full ranges and compliance to
international safety and quality standards insure a professional and reli-
able measuring tool. Both models are autoranging, and provide AC
amperes and AC volts, plus DC volts, ohms, continuity with a beeper,
and a diode test function. The Model 703 also has a frequency function.
Both models are equipped with a large and complete 4000 count LCD
with annunciator symbols such as HOLD, Low Battery, Max etc. for easy
operation.
The Model 701 is average sensing RMS calibrated and designed for the
traditional average responding electrical systems. The Model 703 is a
True RMS clamp-on that provides RMS measurements for today’s non-
linear electrical environments. Both clamp-ons are supplied with test
probe terminated test leads, a soft carrying case, a 9 V battery and a
user manual.
We designed and built the Models 701 and 703 for reliability: the right
size; the right functions, display and performance; the right single-hand-
ed operation; the right professional tool.
Specifications
ELECTRICAL SPECIFICATIONS
Reference Conditions for following tables:
Accuracies are provided under the following reference conditions:
Temperature 18° to 28° C, 45 to 75% RH; battery voltage 9 V ± 0.1 V;
conductor centered in the probe jaws, earth’s magnetic field; no exter-
nal AC magnetic or electrical field; sine wave 45 to 450 Hz.

Clamp-on Multimeters Models 701 & 703 5
Model 701 Model 703
AC Current*
Range 1 to 100 A 1 to 100 Arms
Resolution 0.1 A 0.1 A
Basic Accuracy ± 2% R ±5 cts ± 2% R ±5 cts(1)
Range 100 to 399.9 A 100 to 399.9 Arms
Resolution 0.1 A 0.1 A
Basic Accuracy ± 2% R ± 2% R(1)
Range 400 to 600 A 400 to 600 Arms
Resolution 1 A 1 A
Basic Accuracy ± 2% R ± 2% R(1)
AC Volts*
Range 1 to 40 V 1 to 40 Vrms
Resolution 0.1 V 0.1 V
Basic Accuracy ± 1%± 2 cts ± 1%± 2 cts(2)
Input Impedance 1 MΩ1 MΩ
Range 40 to 399.9 V 40 to 399.9 Vrms
Resolution 0.1 V 0.1 V
Basic Accuracy ± 1%R ± 1%R(2)
Input Impedance 1 MΩ1 MΩ
Range 400 to 600 V 400 to 600 Vrms
Resolution 1 V 1 V
Basic Accuracy ± 1%R ± 1%R(2)
Input Impedance 1 MΩ1 MΩ
1. Additional error with CF
CF from 1.5 to 2.5: 5% R
CF from 2.5 to 5: 8% R
2. Additional error with CF
CF from 1.5 to 3: 3% R
CF from 3 to 5: 8% R
* A residual value of 7 counts may be displayed in the AC range.

6Clamp-on Multimeters Models 701 & 703
Model 701 Model 703
DC Volts
Range 1 to 40 V ± 2 count 1 to 40 V ± 2 count
Resolution 0.1 V 0.1 V
Basic Accuracy ± 0.5% ± 0.5%
Input Impedance 1 MΩ1 MΩ
Range 40 to 399.9 V 40 to 399.9 V
Resolution 0.1 V 0.1 V
Basic Accuracy ± 0.5% ± 0.5%
Input Impedance 1 MΩ1 MΩ
Range 400 to 600 V 400 to 600 V
Resolution 1 V 1 V
Basic Accuracy ± 0.5% ± 0.5%
Input Impedance 1 MΩ1 MΩ
Ohms
Range 1 to 40 1 to 40
Resolution 0.1Ω0.1Ω
Basic Accuracy ± 1% R± 3 cts ± 1% R± 3 cts
Open Voltage 4.4 V 4.4 V
Short Circuit Current 1.2 mA 1.2 mA
Range 40 to 399.9Ω40 to 399.9Ω
Resolution 0.1Ω0.1Ω
Basic Accuracy ± 1% R ± 1% R
Open Voltage 4.4 V 4.4 V
Short Circuit Current 1.2 mA 1.2 mA
Range 400 to 4 kΩ400 to 4 kΩ
Resolution 1Ω1Ω
Basic Accuracy ± 1% R ± 1% R
Open Voltage 4.4 V 4.4 V
Short Circuit Current 1.2 mA 1.2 mA

Clamp-on Multimeters Models 701 & 703 7
Model 701 Model 703
Frequency
Range NA 0 to 4 kHz
Basic Accuracy NA ± 0.1% R ± 1 count
Hz pick-up NA from A or V
Continuity
Range 0 to 40Ω0 to 40Ω
Beeper below 20Ωbelow 20Ω
Basic Accuracy ± 10ΩR ± 10ΩR
Open Voltage 4.4 V 4.4 V
Short Circuit Current 1.2 mA 1.2 mA
Diode Test
Range (DC) 0 to 4 V 0 to 4 V
Resolution 0.001 V 0.001 V
Open Voltage 4.4 V 4.4 V
Short Circuit Current 1.2 mA 1.2 mA
Additional Functions Max Display Hold Max Display Hold

8Clamp-on Multimeters Models 701 & 703
General Specifications
Ranging:
Model 701: 6-position switch, autoranging
Model 703: 7-position switch, autoranging
Jaw size: Accommodates two 500 MCM (1.25" or 32 mm) or one 750
MCM (0.77" or 20 mm)
Battery: 9 V alkaline battery; automatic low battery indicator
Life:
Model 701: 180 hr typical
Model 703: 100 hr typical
Typical consumption:
Model 701: 2.5 mA without buzzer
Model 703: 3.5 mA without buzzer
Buzzer:
Continuous beep for the continuity sound test below 20Ω
Frequency: 2.5 kHz
Dimensions: 10 x 3.8 x 1.7” (252 x 97 x 44 mm)
Weight: 17 oz (500 g)
Operating Temperature:
32° to 122°F (0° to 50°C), 0 to 90% RH (@ 31°C)
Storage Temperature: - 40° to 158°F (- 40° to 70°C)

Clamp-on Multimeters Models 701 & 703 9
Safety Specifications
Protection Level: Double insulation
IEC 1010-1, 600 V category III, Pollution degree 2
Electromagnetic Compatibility: (CE mark)
EN 50081-1 Class B
EN 50082-2 Electrostatic discharge IEC 1000-4-2
Radiated Field IEC 1000-4-3
Fast transients IEC 1000-4-4
Magnetic Field
at 50/60 Hz IEC 1000-4-8
Working Voltage: 600 Vrms
Dielectric Test: 6 kV between terminals and case
Overload Protection:
Voltage: 1000 Vrms
Current: 700 Arms(@ 500 Hz @ 50°C)
Ohms: 600 Vrms
Continuity/Diode: 600 Vrms
Frequency: see voltage and current
Warranty: One year

10 Clamp-on Multimeters Models 701 & 703
Controls for Model 701
1. Jaw Assembly
Transformer jaws open to 1.7" (43 mm)
Accepts two 500 MCM or one 750 MCM
2. Cable Positioning
The three markings indicate the position of the conductor inside
the magnetic core for best accuracy.
3. Anti-Slip Guard
4. Hold/Data Hold
HOLD button freezes the measurement on the display; the “HOLD”
symbol will be displayed.
5. MAX
The MAX button displays the maximum value of the signal
measured.
6. Rotary Selector Switch
6-position rotary switch selects the main functions for Model 701.
7. Display
Digital 4000-count
Measurement function and control function symbols
8. Jacks
Two input terminals for the measurement of DC and AC voltages,
resistance, continuity, and diode tests
COM : black
+ : red
9. Lever/Trigger
Trigger opens and closes the clamp jaws.

Clamp-on Multimeters Models 701 & 703 11
600V
OFF
A
~
V
~
~
!
COM +
Model 701
CLAMP-ON METER
AEMC
INSTRUMENTS
HOLD
MAX HOLD
A
V
Ω
+
_
–
V
Ω
Ω
~
2
5
6
3
1
7
8
9
4
MAX
Model 701

12 Clamp-on Multimeters Models 701 & 703
Controls for Model 703
1. Jaw Assembly
Transformer jaws open to 1.7" (43 mm)
Accepts two 500 MCM or one 750 MCM
2. Cable Positioning
The three markings indicate the position of the conductor inside
the magnetic core for best accuracy.
3. Anti-Slip Guard
4. Hold/Data Hold
HOLD button freezes the measurement on the display;
the “HOLD” symbol will be displayed.
5. MAX
The MAX button displays the maximum value of the signal
measured.
6. Rotary Selector Switch
7-position rotary switch selects the main functions for Model 703.
7. Display
Digital 4000-count
Measurement function and control function symbols
8. Jacks
Two input terminals for the measurement of DC and AC voltages,
resistance, continuity, diode tests and frequency
COM : black
+ : red
9. Lever/Trigger
Trigger opens and closes the clamp jaws.

Clamp-on Multimeters Models 701 & 703 13
600V
OFF
A
~
V
~
~
!
COM +
Model 703
TRMS CLAMP-ON METER
AEMC
INSTRUMENTS
HOLD
MAX
V
Ω
Ω
1
5
6
3
2
7
8
9
4
Hz
MAX
+
-
¯¯¯
¯¯¯
¯¯
HOLD
A
V
RMS
kHz
Model 703

14 Clamp-on Multimeters Models 701 & 703
Digital Display Features
The digital display gives measurements on a large, 4000-count LCD
MAX Displays maximum measurement value
HOLD Displayed when Hold function is activated
Indicates that battery requires replacement
OL Overload indication
A Displayed when instrument is measuring amperes
V Displayed when instrument is measuring volts
~ Displayed when measuring AC volts or amperes
Displayed when measuring DC volts
ΩDisplayed when measuring resistance
Displayed when performing the diode test
For the Model 703 only:
RMS Displayed when performing a RMS measurement
kHz Displayed when performing a frequency measurement
Displayed when performing the continuity with sound test
+
–
HOLD
▼
Model 701 Model 703
MAX
+
-
---
–––
HOLD
A
V
RMS
kHz
MAX HOLD
A
V
Ω
+
_
–
---
–––

Clamp-on Multimeters Models 701 & 703 15
!
AC Current Measurements
1. Turn the rotary switch to the current measurement function A~.
2. Press the trigger to open the instrument jaws. Clamp the jaws
around the conductor. For the most accurate readings, align the con-
ductor with the centering marks on the jaws.
3. Take the reading from the display. Current measurements are pos-
sible from 1 A to 700.0 A.
4. If you have the instrument positioned so that you cannot read the
display, press the HOLD button on the side of the instrument to
freeze the reading. Remove the clamp-on and read.
600V
OFF
A
~
V
~
~
!
COM
+
Model 701
CLAMP-ON METER
AEMC
INSTRUMENTS
HOLD
MAX
A
V
Ω
Ω
~
WARNING: Do not exceed operating voltage specifications!
!

16 Clamp-on Multimeters Models 701 & 703
AC and DC Voltage Measurements
1. Turn the rotary switch to the voltage measurement function to mea-
sure AC or DC volts.
2. Insert the red test lead into the + jack and the black test lead into
the COM jack. Select the appropriate termination (test probes or
clips).
3. Touch or connect the voltage test leads to the circuit under test.
4. Take the reading from the display. Voltage measurements are pos-
sible from 0.0 to 600 V.
600V
OFF
A
~
V
~
~
!
COM
+
Model 701
CLAMP-ON METER
AEMC
INSTRUMENTS
HOLD
MAX
V
V
Ω
Ω
~
WARNING: Do not exceed operating voltage specifications!
!

Clamp-on Multimeters Models 701 & 703 17
MAX Value Measurements
1. With the switch in theAAC, VAC or V DC function, push and release
the MAX button (positive MAX value will be displayed).
2. Take the reading.
For the Model 703
There is approximately a 2-second delay before the MAX indication is
shown on the display.
When taking repetitive MAX measurements, wait approximately 5 sec-
onds between measurements.
Resistance Measurements
1. Turn the switch to the Ωfunction.
2. Connect the red lead to the + terminal and black to the COM
terminal.
3. Take the reading from the display. Resistance measurements are
possible from 0 to 4 kΩ.
WARNING: Check that the circuit is not live. Do not test
resistance on a live circuit.
600V
OFF
A
~
V
~
~
!
COM
+
Model 701
CLAMP-ONMETER
AEMC
INSTRUMENTS
HOLD
MAX
Ω
V
Ω
Ω
!
