AES global 705 DECT User manual

RELAY 1 R2
8.000
12.000
N/C | C | N/O N/C | C | N/O
THE AES KEYPAD IS AN
OPTIONAL EXTRA.
PLEASE SEE
‘KPX1200 GUIDE’
FOR FULL INSTRUCTIONS ON
PROGRAMMING AND
EXTENSIVE FEATURES.
N/O
C
N/C
OPTIMAL RANGE
705 DECT
WIRING DIAGRAM
TIP: For longer range installations, locate the handset closest to the front of the
property and near a window if possible. Also ensure the antenna is mounted
pointing towards the handset.
Concrete walls can reduce the normal open-air range of up to 450 metres by
30-50% per wall.
TIP: Most technical calls received are due to installers using CAT5 or alarm cable
to power the unit.
NEITHER are rated to carry enough power! ( 1.2amp peak )
Please use the following cable:
Up to 2 metres ( 6 feet ) –Use minimum 0.5mm2( 18 gauge )
Up to 4 metres ( 12 feet ) –Use minimum 0.75mm2 ( 16 gauge )
Up to 8 metres ( 24 feet ) –Use minimum 1.0mm2( 14 / 16 gauge )
POWER CABLE
Code
Button
SPK
Normally Open
Common
Normally Closed
RELAY CONNECTIONS
RELAY 1
TRANSMITTER
Transmitter Module
WARNING:
ESD SENSITIVE
DEVICE
AES 24v Power Supply
* ALWAYS RANGE TEST THE UNIT ON SITE BEFORE INSTALLATION *
- Radio Intercom System
MAGNETIC LOCK EXAMPLE
TRANSMITTER AES KEYPAD
NEED MORE ASSISTANCE?
Please scan this QR Code to be
brought to our Resources page
where you can find all of our
guides and available resources.
LIGHTNING PRONE AREAS
MUST USE SURGE PROTECTION
FOR POWER SUPPLY!
AES KEYPAD
Follow this method when using a magnetic lock. If the relay in either the
Transmitter or optional AES Keypad is triggered it will temporarily lose power
and allow the door/gate to release.
For installs without the optional AES Keypad; connect the POSITIVE of the
Magnetic Lock PSU to N/C terminal on Transmitter Relay.
12vO
UT
Link both Relay 1’s to
allow either to release
the same door / gate.
24v IN
CALL
MIC
AES KEYPAD
DECT ANTENNA
Both leads of the
antenna are
required as the
audio and video
signals are
transmitted over
separate
frequencies.
STILL HAVING TROUBLE?
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALONLINE.COM
Please only use power supply provided. Do NOT power any additional devices from this power supply.
SYSTEM INCOMPATIBLE WITH FOIL INSULATION.
KEEP POWER SUPPLY AS CLOSE AS POSSIBLE.
SITE SURVEY RESTOCKING FEES MAY APPLY IF RETURNED AFTER INSTALL DUE TO SITE
ISSUES. PLEASE SEE FULL T&C’S ON OUR WEBSITE.
With our 705 DECT video system you can add
up to a max of 4 portable handsets or wall
mounted versions.
( 1 VIDEO HANDSET MAX. )
Did you know?
TIP: It is recommended that the system be fully tested on site BEFORE installation.
You must test to ensure that the system is capable of operating across the desired
range. Power the system on and place the handsets in their expected locations
around the property to ensure that the system is fully functional and suitable for
the site.
Pre-wired MIC connection
Pre-wired
SPEAKER
connection
N/C | C | N/O
N/C | C | N/O
Programming LED will
illuminate on the
undersideof the PCB
MAX 24 VOLTS!
POWER ADAPTER
MAINS
POWER
MAGNETIC LOCK
+
-
-
+* MAGNETIC LOCK PSU SOLD SEPARATELY *
EXIT

Handsets will be
displayed in
order of H1, H2,
H3 & H4.
ON/OFF
RECEPTION
INDICATOR
BATTERY
LEVEL
RED PAIRING
LED
CODE BUTTON
OKOK
MONITORING GATE/DOOR
TRIGGER
VIBRATE
ON/OFF
OKOK
1. Brightness
2. Language
3. Messages
4. Bell
5. Colour
Access menu by holding monitoring
button for 3 seconds
1. Adjusts brightness.
2. English, French or German.
3. Listen or delete Voicemail.
4. Change the ring tone.
5. Change screen colour.
RE-CODING/ADDING EXTRA HANDSETS
INFORMATION ABOUT YOUR DECT HANDSET
The handset should ideally be charged for at least 8 hours before use. It is recommended to give it at least 60 minutes of charge
before performing the range test between the transmitter module and the handset inside.
If re-pairing the video handset it must be the first device paired to receive both video & audio channels.
* ALWAYS RANGE TEST THE UNIT ON SITE BEFORE INSTALLATION *
Occasionally the system may need to be re-coded once installed.
If the handset does not ring when the call button is pressed,
the system may need to be re-coded.
( ●= FULL RE-CODE : STEP 1-5 )
(●= ADDING A HANDSET : STEP 3-5 )
●Step 1) Press and hold the CODE BUTTON inside on the Transmitter PCB for 5 seconds
until the audible tone is heard from the Intercom speaker.
●Step 2) Then press the CODE BUTTON 14 times and proceed to wait until the melody is
heard or the LED turns off. Performing this step will remove ALL handsets currently synced
(or partially synced) to the system.
●●Step 3) Press and hold the CODE BUTTON inside on the Transmitter PCB for 5 seconds
until the audible tone is heard from the Intercom.
●●Step 4) Then press and hold the CODE BUTTON on the handset until the red LED at the
top begins to flash. After a few seconds you will hear a melody play to let you know it has
successfully connected.
●●Step 5) Finally you should test the kit to ensure that everything is working as expected
by pressing the Call Button on the CallPoint to ensure the handset and/or wall mounted unit
receives the call and that the two way speech is functioning correctly.
8.000
TRANSMITTER
CODE BUTTON
Example shows the
location of the CODE
BUTTON that can be found
on the back of the wall
mounted unit.
CODE BUTTON
Can be found on
reverse side.
OKOK
AC/DC STRIKE LOCK
WIRING EXAMPLE
Follow this method when using a Strike Lock with
the system. If used it will mean that if a relay in
either the Transmitter or optional AES Keypad is
triggered it will temporarily allow the door/gate
to release.
MAINS
POWER
Do you require a custom wiring diagram for your site? Please send all
requests to [email protected] and we will do our best to
provide you with a supplementdiagram suitable for your chosen
equipment.
We are constantly using your customer feedback to enhance all of our
guides / learning material for installers.
If you have any suggestions regarding this please send any
suggestions to [email protected]om
1. When the intercom is being called, identify the visitor on the screen.
2. Press the OK button to answer the incoming call.
3. Speak clearly into the top of the handset at a distance of 10-20cm.
4. During the call press < or > to increase or decrease the volume.
5. Press the button to release the door/gate and press OK to end the call.
CHANGING
SETTINGS
Note : The video will remain active for 1 minute after the audio call has ended.
The following settings can be
changed on the handset at any
time.
Use up and down arrows to
navigate, press OK to select. Press
right arrow at any time to exit or
cancel change. ( HANDSET BATTERY INCLUDED )
705 DECT - Radio Intercom System STILL HAVING TROUBLE?
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALONLINE.COM
( Note: Doing this step will also clear ALL voicemails after reset. )
( Repeat Steps 3 & 4 for each new handset. )
( Video Handsets must be added first and 1 MAX )
N/C | C | N/O
N/C | C | N/O
STRIKE
LOCK
MAX 24 VOLTS!
POWER ADAPTER
+
-
TRANSMITTER
AES KEYPAD
* STRIKE LOCK PSU SOLD SEPARATELY *
MICROPHONE
