AES global StylusCOM Audio User manual

N/C | C | N/ON/O | C | N/C
OPTIMAL RANGE
StylusCOM Audio
STYLUSCOM - WIRING DIAGRAM
TIP: To get the most range out of the system we would recommend keeping the
separate power supply as close as possible to the audio monitor. If chaining
multiple monitors together use the SLAVE inputs and outputs - see supplement
wiring diagram which will provide more information on the specific requirements
and max distances.
TIP: Most technical calls received are due to installers using CAT5 or alarm cable
to power the unit.
NEITHER are rated to carry enough power! ( 1.2amp peak )
Please use the following cable:
Up to 2 metres ( 6 feet ) –Use minimum 0.5mm2( 18 gauge )
Up to 4 metres ( 12 feet ) –Use minimum 0.75mm2 ( 16 gauge )
Up to 8 metres ( 24 feet ) –Use minimum 1.0mm2( 14 / 16 gauge )
POWER CABLE
Shield/Filter
Drain Cable
Pairing
LEDs
- Hardwired System
MAX 24 VOLTS!
POWER ADAPTER
MAINS
POWER
MAGNETIC LOCK
MAGNETIC LOCK EXAMPLE
CALL STATION AES KEYPAD
+
-
-
+* MAGNETIC LOCK PSU SOLD SEPARATELY *
EXIT
STILL HAVING TROUBLE?
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALONLINE.COM
SHIELDED CABLE IS ALWAYS RECOMMENDED
KEEP POWER SUPPLY AS CLOSE AS POSSIBLE.
SITE SURVEY
TIP: It is recommended that the system be fully tested on site BEFORE installation.
You must test to ensure that the system is capable of operating on the desired site.
Power the system on and place the monitors in their expected locations around
the property and then test that everything is working BEFORE mounting any items
to the walls.
RESTOCKING FEES MAY APPLY IF RETURNED AFTER INSTALL DUE TO SITE
ISSUES. PLEASE SEE FULL T&C’S ON OUR WEBSITE
RELAY 1
Optional Programmable Keypad
THE AES KEYPAD IS AN OPTIONAL EXTRA.
IF KEYPAD PRESENT, PLEASE SEE THE
‘KPX1200 GUIDE’ ON OUR WEBSITE
FOR FULL INSTRUCTIONS ON PROGRAMMING
AND EXTENSIVE FEATURES. NEED MORE ASSISTANCE?
PLEASE SCAN THIS QR CODE TO BE
BROUGHT TO OUR RESOURCES PAGE
WHERE YOU CAN FIND ALL OF OUR
GUIDES AND AVAILABLE RESOURCES.
RELAY 1 R2
12.000
24v IN EGRESS
RELAY 3
GROUND
+ - N.C. COM N.O. N.C. / N.O.
DATA
I/O
EG
IN
N.C. COM N.O. K or A
O/P
DU
OU T
DO OR
SENS
(-)
GN D
O/P 1
INH IB.
INT
LOCK
TAMPER
N.C.
MODEL: Stylus V2
N/O
C
N/C
Normally Open
Common
Normally Closed
RELAY CONNECTIONS
PLEASE USE ADDITIONAL POWER
SUPPLY (NOT PROVIDED) FOR
DISTANCES GREATER THAN 130m.
CHECK FURTHER INFORMATION FOR
MAX MONITOR DISTANCES AND
POWER REQUIREMENTS, OR IF YOU
NEED TO CHAIN MULTIPLE MONITORS
TOGETHER.
PLEASE USE THE 24v POWERSUPPLY
PROVIDED WITH THE STYLUSCOM KIT.
RELAY 1 R2
12.000
24v IN EGRESS
RELAY 3
GROUND
+ - N.C. COM N.O. N.C. / N.O.
DATA
I/O
EG
IN
N.C. COM N.O. K or A
O/P
DU
OU T
DO OR
SENS
(-)
GN D
O/P 1
INH IB.
INT
LOCK
TAMPER
N.C.
MODEL: Stylus V2
RELAY 1 R2
12.000
24v IN EGRESS
RELAY 3
GROUND
+ - N.C. COM N.O. N.C. / N.O.
DA TA
I/O
EG
IN
N.C. COM N.O. K or A
O/P
DU
OU T
DO OR
SENS
(-)
GN D
O/P 1
INH IB.
INT
LOCK
TAMPER
N.C.
MODEL: Stylus V2
Power for keypad will come
already pre-wired.
300m MAX
DISTANCE
(SHIELDED CAT5)
AUD1
GND
CMD1
AUD2
GND
CMD2
24v
0v
24v
0v
N/A N/A
CMD
AUD
GND
N/C
COM
N/O
N/C
COM
N/O
RELAY 2
RELAY 1
STATION 1
STATION 2
SLAVE IN
SLAVE OUT
DATA
AUDIO
GND
DATA
AUDIO
GND
* ALWAYS FULLY TEST THE UNIT ON SITE BEFORE INSTALLATION TO AVOID RESTOCKING FEES *
CONNECTIONS WILL GO TO GATE
CONTROLLER/DOOR LOCK ETC.
PLEASE SEE ADDITIONAL DIAGRAMS
FOR RELAY CONNECTIONS FOR THE
REQUIRED TYTPE.
(300m MAX DISTANCE)
Follow this method when using a magnetic lock. If the relay in either the
Call Station or optional AES Keypad is triggered it will temporarily lose
power and allow the door/gate to release.
For installs without the optional AES Keypad; connect the POSITIVE of the
Magnetic Lock PSU to N/C terminal on Call Station Relay.

N/C | C | N/O
N/O | C | N/C
HOW TO USE THE STYLUSCOM MONITOR
INFORMATION ABOUT YOUR AUDIO MONITOR
STRIKE
LOCK
AC/DC STRIKE LOCK
WIRING EXAMPLE
Follow this method when using a Strike Lock with
the system. If used it will mean that if a relay in
either the Call Station or optional AES Keypad is
triggered it will temporarily allow the door/gate
to release.
MAX 24 VOLTS!
POWER ADAPTER
MAINS
POWER
+
-
CALL STATION
AES KEYPAD
* STRIKE LOCK PSU SOLD SEPARATELY *
Do you require a custom wiring diagram for your site? Please send all
requests to [e-mail] and we will do our best
to provide you with a supplement diagram suitable for your chosen
equipment.
We are constantly using your customer feedback to enhance all of
our guides / learning material for installers.
If you have any suggestions regardingthis please send any
suggestions to feedbac[email protected]
STILL HAVING TROUBLE?
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALONLINE.COM
TOP
S
I
D
E
FRONT
INCREASE IN CALL VOLUME
DECREASE IN CALL VOLUME
TRANSFER THE CALL
MONITORING MODE
ACTIVATE RELAY 1
ACTIVATE RELAY 2
1
2
ANSWER CALL BUTTON
180mm
130mm
Front depth
Tap to answer incoming call.
Tap to increase volume of monitor.
Tap to decrease volume of monitor.
Tap to transfer the call to other monitor(s).
Tap to listen to the intercom microphone.
Tap to activate Relay 1.
Tap to activate Relay 2.
16mm
CUT DIMENSIONS
165mm
115mm
9mm
25mm
Rear depth
Total depth
* ALWAYS FULLY TEST THE UNIT ON SITE BEFORE INSTALLATION TO AVOID RESTOCKING FEES *
(tap again to hang up call)
StylusCOM Audio - Hardwired System

StylusCOM Monitor
TOP
S
I
D
E
FRONT
MAX
DISTANCES
Call Station
See ‘POWER CABLE’ section on Quick
Start Guide for power supply
requirements for Call Station power
supply.
StylusCOM –Power Options
1x 2x Dual Power Supply :
CAT5 Cable –300m
Poly/Poly Underground –150m
Multi pair telephone wire –50m
Single Power Supply :
CAT5 Cable –130m
Poly/Poly Underground –30m
Multi pair telephone wire –30m
TIP:
To achieve greater distances shown in ‘2x
Dual Power Supply’ a separate power
supply is required (sold separately).

OUT IN
OUT IN
OUT IN
MASTER
SLAVE IN
DATA
AUDIO
GND
SLAVE IN
DATA
AUDIO
GND
SLAVE OUT
SLAVE OUT
DATA
AUDIO
GND
SLAVE IN
SLAVE OUT
SLAVE
SLAVE
24v
0v
24v
0v
24v
0v
StylusCOM –Slave Monitor Wiring Guide
MASTER
SLAVE
SLAVE
PSU #2
Wire the SLAVE OUT terminals to the SLAVE IN
terminals of the next monitor.
SLAVE OUT can also be split 2-ways as shown
in the diagram below.
TO MONITOR 4
DATA
AUDIO
GND
PSU #2
Second power supply is used to power all
of the monitors indoors. Power between
monitors will be shared using 1.0mm
cable.
MONITOR 4
4MONITORS
IN TOTAL :
1MASTER
3SLAVES
KEEP POWER CABLE BETWEEN MONITORS AS SHORT AS POSSIBLE –SEE POWER CABLE ON PAGE 1
Monitor Power Supply Distances:
CAT5 Cable –8m
1.5mm Cable –15m
(MAX DISTANCE BETWEEN MONITORS)
(THE MASTER MONITOR MUST ALREADY BE SET UP BEFORE TESTING SLAVES)
