Agilent 1260 Infinity Micro
Degasser
Service Manual

1260 Infinity Micro Degasser Service Manual
Notices
© Agilent Technologies, Inc. 2006-2008,
2010, 2013
No part of this manual may be reproduced
in any form or by any means (including elec-
tronic storage and retrieval or translation
into a foreign language) without prior agree-
ment and written consent from Agilent
Technologies, Inc. as governed by United
States and international copyright laws.
Manual Part Number
G1379-90111 Rev. B
Edition
10/2013
Printed in Germany
Agilent Technologies
Hewlett-Packard-Strasse 8
76337 Waldbronn
This product may be used as a com-
ponent of an in vitro diagnostic sys-
tem if the system is registered with
the appropriate authorities and com-
plies with the relevant regulations.
Otherwise, it is intended only for gen-
eral laboratory use.
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or perfor-
mance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accor-
dance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of a
U.S. Government prime contract or subcon-
tract, Software is delivered and licensed as
“Commercial computer software” as
defined in DFAR 252.227-7014 (June 1995),
or as a “commercial item” as defined in FAR
2.101(a) or as “Restricted computer soft-
ware” as defined in FAR 52.227-19 (June
1987) or any equivalent agency regulation
or contract clause. Use, duplication or dis-
closure of Software is subject to Agilent
Technologies’ standard commercial license
terms, and non-DOD Departments and
Agencies of the U.S. Government will
receive no greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2) (June
1987). U.S. Government users will receive
no greater than Limited Rights as defined in
FAR 52.227-14 (June 1987) or DFAR
252.227-7015 (b)(2) (November 1995), as
applicable in any technical data.
Safety Notices
CAUTION
A CAUTION notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could
result in damage to the product
or loss of important data. Do not
proceed beyond a CAUTION
notice until the indicated condi-
tions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice,
or the like that, if not correctly
performed or adhered to, could
result in personal injury or
death. Do not proceed beyond a
WARNING notice until the indi-
cated conditions are fully under-
stood and met.

1260 Infinity Micro Degasser Service Manual 3
Contents
Contents
1 Introduction 5
Introduction to the Micro Vacuum Degasser 6
2 Site Requirements and Specifications 7
Site Requirements 8
Physical Specifications 11
Performance Specifications 12
3 Installing the Micro Vacuum Degasser 13
Unpacking the Micro Vacuum Degasser 14
Optimizing the Stack Configuration 16
Installing the Micro Vacuum Degasser 19
Flow Connections to the Micro Vacuum Degasser 21
Operational Hints for the Micro Vacuum Degasser 24
Transporting the Micro Vacuum Degasser 27
4 Using the Micro Vacuum Degasser 29
When to Use a Micro Vacuum Degasser? 30
Prevent Blocking of Solvent Filters 32
Solvent Information 34
5 Optimizing Performance 41
Increasing the Degasser Performance and Degassing Level 42
6 Troubleshooting and Diagnostics 43
Overview of the Degasser's Indicators 44
Status Indicators 45
Hardware Symptoms 47
7 Maintenance 51
Introduction to Maintenance and Repair 52

4 1260 Infinity Micro Degasser Service Manual
Contents
8Repairs 63
Exchanging Internal Parts 64
Overview of Repair Procedures 65
Overview of Internal Parts 66
9 Parts and Materials for Maintenance 79
Cover Parts 80
Sheet Metal Kit 81
Power and Status Light Pipes 82
Accessory Kit 83
10 Parts for Repair 85
Micro Vacuum Degasser Parts 86
11 Cable overview 89
Overview 90
Remote Cable 92
12 Hardware Information 95
Operating Principle 96
13 Appendix 97
General Safety Information 98
The Waste Electrical and Electronic Equipment "WEEE) Directive
(2002/96/EC) 101
Radio Interference 102
Sound Emission 103
Agilent Technologies on Internet 104

5
1260 Infinity Micro Degasser Service Manual
Agilent Technologies
1
Introduction
Introduction to the Micro Vacuum Degasser 6

6 1260 Infinity Micro Degasser Service Manual
1Introduction
Introduction to the Micro Vacuum Degasser
Introduction to the Micro Vacuum Degasser
The Agilent 1260 Infinity micro vacuum degasser, model G1379B,
comprises a 4- channel vacuum container, including 4 micro structured
membranes, and a vacuum pump. When the micro vacuum degasser is
switched on, the control circuit turns on the vacuum pump, which is
operated with constant speed and voltage generates a partial vacuum in
the vacuum container. The pressure is measured by a pressure sensor. The
micro vacuum degasser maintains the partial vacuum with the help of a
controlled leak in the degasser’s proportional valve and by varying size of
the controlled leak within the proportional valve, depending on the signal
from the pressure sensor.
The LC pump draws the solvents from their bottles through the special
plastic membranes of the vacuum container. As the solvents pass through
the vacuum chambers any dissolved gas in the solvents permeates through
the membranes into the vacuum container. The solvents will be almost
completely degassed when leaving the outlets of the micro vacuum
degasser.
Figure 1 Overview (only one of the four solvent channels is shown)
Ejbe
HZchdg
HdakZci
KVXjjbXdciV^cZg
)b^XgdhigjXijgZY
hjeedgiZYbZbWgVcZh
KVXjjb
ejbe
8dcigda
X^gXj^i

7
1260 Infinity Micro Degasser Service Manual
Agilent Technologies
2
Site Requirements and Specifications
Site Requirements 8
Physical Specifications 11
Performance Specifications 12

8 1260 Infinity Micro Degasser Service Manual
2Site Requirements and Specifications
Site Requirements
Site Requirements
A suitable environment is important to ensure optimal performance of the
instrument.
Power Considerations
The module power supply has wide ranging capability. It accepts any line
voltage in the range described in Table 1 on page 11. Consequently there
is no voltage selector in the rear of the module. There are also no
externally accessible fuses, because automatic electronic fuses are
implemented in the power supply.
WARNING
Hazard of electrical shock or damage of your instrumentation
can result, if the devices are connected to a line voltage higher than specified.
➔Connect your instrument to the specified line voltage only.
WARNING
The module is partially energized when switched off, as long as the power cord is
plugged in.
Repair work at the module can lead to personal injuries, e.g. electrical shock, when
the cover is opened and the module is connected to power.
➔Always unplug the power cable before opening the cover.
➔Do not connect the power cable to the instrument while the covers are removed.

1260 Infinity Micro Degasser Service Manual 9
Site Requirements and Specifications 2
Site Requirements
Power Cords
Different power cords are offered as options with the module. The female
end of all power cords is identical. It plugs into the power- input socket at
the rear. The male end of each power cord is different and designed to
match the wall socket of a particular country or region.
CAUTION
Inaccessible power plug.
In case of emergency it must be possible to disconnect the instrument from the power
line at any time.
➔Make sure the power connector of the instrument can be easily reached and
unplugged.
➔Provide sufficient space behind the power socket of the instrument to unplug the
cable.
WARNING
Absence of ground connection or use of unspecified power cord
The absence of ground connection or the use of unspecified power cord can lead to
electric shock or short circuit.
➔Never operate your instrumentation from a power outlet that has no ground
connection.
➔Never use a power cord other than the Agilent Technologies power cord designed
for your region.
WARNING
Use of unsupplied cables
Using cables not supplied by Agilent Technologies can lead to damage of the
electronic components or personal injury.
➔Never use cables other than the ones supplied by Agilent Technologies to ensure
proper functionality and compliance with safety or EMC regulations.

10 1260 Infinity Micro Degasser Service Manual
2Site Requirements and Specifications
Site Requirements
Bench Space
The module dimensions and weight (see Table 1 on page 11) allow you to
place the module on almost any desk or laboratory bench. It needs an
additional 2.5 cm (1.0 inches) of space on either side and approximately
8 cm (3.1 inches) in the rear for air circulation and electric connections.
If the bench shall carry a complete HPLC system, make sure that the
bench is designed to bear the weight of all modules.
The module should be operated in a horizontal position.
Condensation
WARNING
Unintended use of supplied power cords
Using power cords for unintended purposes can lead to personal injury or damage of
electronic equipment.
➔Never use the power cords that Agilent Technologies supplies with this instrument
for any other equipment.
CAUTION
Condensation within the module
Condensation will damage the system electronics.
➔Do not store, ship or use your module under conditions where temperature
fluctuations could cause condensation within the module.
➔If your module was shipped in cold weather, leave it in its box and allow it to warm
slowly to room temperature to avoid condensation.

1260 Infinity Micro Degasser Service Manual 11
Site Requirements and Specifications 2
Physical Specifications
Physical Specifications
Table 1 Physical Specifications
Type Specification Comments
Weight 7 kg (16 lbs)
Dimensions (height ×
width × depth)
80 x 345 × 435 mm (3.1 x 13.5 × 17 inches)
Line voltage 100 – 240 VAC, ± 10 % Wide-ranging
capability
Line frequency 50 or 60 Hz, ± 5 %
Power consumption 30 VA / 30 W / 102 BTU Maximum
Ambient operating
temperature
4–45 °C (39–113 °F)
Ambient non-operating
temperature
-40 – 70 °C (-40 – 158 °F)
Humidity < 95 % r.h. at 40 °C (104 °F) Non-condensing
Operating altitude Up to 2000 m (6562 ft)
Non-operating altitude Up to 4600 m (15091 ft) For storing the module
Safety standards: IEC, CSA,
UL
Installation category II, Pollution degree 2 For indoor use only.

12 1260 Infinity Micro Degasser Service Manual
2Site Requirements and Specifications
Performance Specifications
Performance Specifications
Table 2 Performance Specifications Agilent 1260 Infinity Vacuum Degasser
Type Specification
Maximum flow rate 0 - 5 ml/min per channel
Number of channels 4
Internal volume per channel Typically 1 ml per channel
Materials in contact with solvent PTFE, FEP,PEEK
pH range 1 – 14
RS-232 output For diagnostic purposes

13
1260 Infinity Micro Degasser Service Manual
Agilent Technologies
3
Installing the Micro Vacuum Degasser
Unpacking the Micro Vacuum Degasser 14
Accessory Kit Contents 14
Optimizing the Stack Configuration 16
Installing the Micro Vacuum Degasser 19
Flow Connections to the Micro Vacuum Degasser 21
Operational Hints for the Micro Vacuum Degasser 24
General Priming Instructions 24
Priming the Degasser 24
Priming with a Syringe (only recommended if priming with the pump
fails) 25
Transporting the Micro Vacuum Degasser 27

14 1260 Infinity Micro Degasser Service Manual
3Installing the Micro Vacuum Degasser
Unpacking the Micro Vacuum Degasser
Unpacking the Micro Vacuum Degasser
Damaged Packaging
Upon receipt of your micro vacuum degasser, inspect the shipping
containers for any signs of damage. If the containers or cushioning
material are damaged, save them until the contents have been checked for
completeness and the micro vacuum degasser has been mechanically and
electrically checked. If the shipping container or cushioning material is
damaged, notify the carrier and save the shipping material for the carriers
inspection.
Delivery Checklist
Ensure all parts and materials have been delivered with the micro vacuum
degasser. The delivery checklist is shown below. To aid in parts
identification, please see “Parts and Materials for Maintenance” on
page 79. Please report missing or damaged parts to your local Agilent
Technologies Sales and Service Office.
Accessory Kit Contents
Table 3 Vacuum Degasser Delivery Checklist
Description Quantity
Vacuum Degasser 1
Power Cable 1
Service Manual 1
Accessory Kit (“Accessory
Kit Contents” on page 14)
1

1260 Infinity Micro Degasser Service Manual 15
Installing the Micro Vacuum Degasser 3
Unpacking the Micro Vacuum Degasser
Item p/n Description
1 G1379-68706 Connecting tubing (to connect to channels in series for increased
performance) 2x
2 G1322-67300 Kit of 4 solvent tubes including labels
for connection degasser to MCGV (Quaternary Pump)
3 5062-2463 Corrugated tubing, PP, 6.5 mm id, 5 m
4 0100-1710 Mounting Tool for Tubing Connections

16 1260 Infinity Micro Degasser Service Manual
3Installing the Micro Vacuum Degasser
Optimizing the Stack Configuration
Optimizing the Stack Configuration
If your micro vacuum degasser is part of a system, you can ensure
optimum performance by limiting the configuration of the system stack to
the following configuration. This configuration optimizes the system flow
path, ensuring minimum delay volume (from point of solvent mixing to
head of column) and dead volume (from point of injection to detector
outlet).

1260 Infinity Micro Degasser Service Manual 17
Installing the Micro Vacuum Degasser 3
Optimizing the Stack Configuration
Figure 2 Recommended Stack Configuration (Front View)
Ejbe
6jidhVbeaZg
9ZiZXidg
HdakZciXVW^cZi
B^XgdkVXjjbYZ\VhhZg
>chiVcie^adi
6jidhVbeaZgi]ZgbdhiVi
8dajbcXdbeVgibZci

18 1260 Infinity Micro Degasser Service Manual
3Installing the Micro Vacuum Degasser
Optimizing the Stack Configuration
Figure 3 Recommended Stack Configuration (Rear View)
68EdlZg
A6CidA88]ZbHiVi^dcdg
di]ZgXdcigdaa^c\hd[ilVgZ
GZbdiZXVWaZ
86C7jhXVWaZid>chiVciE^adi
Xdbbjc^XVi^dc
6cVad\h^\cVaidgZXdgYZg
86C7jhXVWaZ[dg^ciZg"bdYjaZ

1260 Infinity Micro Degasser Service Manual 19
Installing the Micro Vacuum Degasser 3
Installing the Micro Vacuum Degasser
Installing the Micro Vacuum Degasser
1Place the micro vacuum degasser on the bench.
2Ensure the power switch on the front of the micro vacuum degasser is
OFF (switch stands out).
3Connect the remote cable to the power connector at the rear of the
micro vacuum degasser.
4Option: Connect the interface cable to the micro vacuum degasser. The
remote cable is a one way connection to send a not- ready signal from
Parts required Description
Power cord
Remote Cable, see “Overview” on page 90
Hardware required Micro degasser
Preparations Locate bench space
Provide power connections
Unpack the vacuum degasser module
WARNING
Abnormal conditions
In case of abnormal conditions during operation, the instrument must be
disconnected from line.
➔To disconnect the instrument from line, unplug the power cord.
CAUTION
"Defective on arrival" problems
If there are signs of damage, please do not attempt to install the module. Inspection by
Agilent is required to evaluate if the instrument is in good condition or damaged.
➔Notify your Agilent sales and service office about the damage.
➔An Agilent service representative will inspect the instrument at your site and
initiate appropriate actions.

20 1260 Infinity Micro Degasser Service Manual
3Installing the Micro Vacuum Degasser
Installing the Micro Vacuum Degasser
the degasser to the other modules to shut down the whole system after
an error condition of the degasser.
Figure 4 Rear of the Micro Vacuum Degasser
Figure 5 Front of the Micro Vacuum Degasser
5Press in the power switch to turn ON the micro vacuum degasser.
NOTE
In an Agilent 1260 Infinity stack, the individual modules are connected through a CAN
cable. The Agilent 1260 Infinity micro vacuum degasser is an exception. The micro vacuum
degasser can be connected via the APG remote cable to the other modules of the stack. An
Agilent 1260 Infinity Instant Pilot can be connected to the CAN bus at any of the modules in
the system except for the degasser. The control software can be connected to the system
through one GPIB or LAN cable (via LAN-Card) at any of the modules (except for the
degasser), preferably at the detector.
EdlZghdX`Zi
GZbdiZXVWaZhdX`Zi
GH'('hdX`Zi
;jhZ]daYZg
HiVijh^cY^XVidg
EdlZghl^iX]
HZg^VacjbWZg
LVhiZdjiaZi
NOTE
The power switch stays pressed in and a green indicator lamp in the power switch is ON
when the micro vacuum degasser is turned ON. When the line power switch stands out and
the green light is OFF, the micro vacuum degasser is turned OFF.
