Agilent 5100 and 5110
ICP-OES
Site Preparation Guide

2 Agilent 5100 and 5110 ICP-OES Site Preparation Guide
Notices
© Agilent Technologies, Inc.
2014, 2016, 2017, 2019
No part of this manual may be
reproduced in any form or by any
means (including electronic storage
and retrieval or translation into a
foreign language) without prior
agreement and written consent from
Agilent Technologies, Inc. as governed
by United States and international
copyright laws.
Manual Part Number
G8010-90001
Edition
Fifth edition, February 2019
Agilent Technologies, Australia (M)
Pty Ltd
679 Springvale Road
Mulgrave, Victoria, 3170
Australia
www.agilent.com
Warranty
The material contained in this
document is provided “as is,” and is
subject to being changed, without
notice, in future editions. Further, to
the maximum extent permitted by
applicable law, Agilent disclaims all
warranties, either express or implied,
with regard to this manual and any
information contained herein,
including but not limited to the
implied warranties of merchantability
and fitness for a particular purpose.
Agilent shall not be liable for errors
or for incidental or consequential
damages in connection with the
furnishing, use, or performance of
this document or of any information
contained herein. Should Agilent and
the user have a separate written
agreement with warranty terms
covering the material in this
document that conflict with these
terms, the warranty terms in the
separate agreement shall control.
Technology Licenses
The hardware and/or software
described in this document are
furnished under a license and may be
used or copied only in accordance
with the terms of such license.
Restricted Rights Legend
If software is for use in the
performance of a U.S. Government
prime contract or subcontract,
Software is delivered and licensed as
“Commercial computer software” as
defined in DFAR 252.227-7014 (June
1995), or as a “commercial item” as
defined in FAR 2.101(a) or as
“Restricted computer software” as
defined in FAR 52.227-19 (June 1987)
or any equivalent agency regulation or
contract clause. Use, duplication or
disclosure of Software is subject to
Agilent Technologies’ standard
commercial license terms, and non-
DOD Departments and Agencies of the
U.S. Government will receive no
greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2) (June
1987). U.S. Government users will
receive no greater than Limited Rights
as defined in FAR 52.227-14 (June
1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
A CAUTION notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that, if
not correctly performed or adhered to,
could result in damage to the product
or loss of important data. Do not
proceed beyond a CAUTION notice
until the indicated conditions are fully
understood and met.
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or the
like that, if not correctly performed or
adhered to, could result in personal
injury or death. Do not proceed
beyond a WARNING notice until the
indicated conditions are fully
understood and met.
WARNING
CAUTION

Request for Installation
Agilent 5100 and 5110 ICP-OES Site Preparation Guide 3
Request for Installation
All preparations have been completed. Please arrange for the
installation to be completed as soon as possible. I understand that if
the installation site is not prepared in accordance with the enclosed
instructions, additional installation charges may apply.
Company name:
Company address:
Name:
Position:
Telephone:
Preferred installation date:
Signed:
Date:

Site Preparation Checklist
4 Agilent 5100 and 5110 ICP-OES Site Preparation Guide
Site Preparation Checklist
Your site must meet all requirements before you request installation.
Complete each requirement listed in the table. After completing each
requirement, place a check in the appropriate check box. Ensure you
compare the boxes with the shipping list supplied with the boxes.
Requirements

Principal installation area is in compliance with all relevant safety regulations.

Laboratory temperature is maintained between 15-30°C (59-86°F)

Laboratory is free of excessive particulate matter.

Cooling air system is set up (if required).

Workbench requirements are met.

Sufficient bench space is available for all components.

Bench can support system weight.

Personal computer with Microsoft Windows 7 Professional 64-bit SP1 or Microsoft Windows 10
Professional installed and printer is set up, if purchased separately.

Exhaust system is suitable and installed.

Specified electrical supply and power outlets are installed.

Gas supply (at specified purity), regulator, and gas lines are installed for argon and any allowed optional
gases.

Water cooling/circulation system and power connections are set up, if system is not purchased from
Agilent.

Waste container appropriate for the chemical waste is prepared.

Accessories Purchased
SPS 4 Autosampler

SPS 3 Sample Preparation System

Advanced valve system (AVS) 4, 6, or 7 Switching Valve

SVS 2+ Productivity Package

VGA Vapor Generation Accessory

5 Channel Peristaltic Pump

Air Inlet Duct Filter

External Inlet Duct Adapter

Multimode Sample Introduction System (MSIS)

Argon Saturator Accessory (ASA)

IsoMist™ Programmable Temperature Spray Chamber


Contents
Agilent 5100 and 5110 ICP-OES Site Preparation Guide 5
Contents
Request for Installation 3
Site Preparation Checklist 4
1. Safety Practices and Hazards 7
Heat, Vapors and Fumes 7
Compressed Gas Hazards 7
Electrical Hazards 8
Other Precautions 8
2. Introduction 9
Installation Guidelines 9
3. Laboratory Environment 11
Environmental Conditions 11
Installation category 11
Pollution level 11
Temperature Control 12
Cleanliness 12
Instrument Cooling Air Supply 12
Workbench 13
Location 14
PC Requirements 17
4. Instrument Shipping Information 19
Weights and Dimensions 19

Safety Practices and Hazards
6 Agilent 5100 and 5110 ICP-OES Site Preparation Guide
Seismic Requirements 20
5. Laboratory Facilities 23
Exhaust System 23
Electrical Power Supplies 25
Electrical Requirements 26
Single phase requirement 26
Power plugs and cords 27
Gas Supplies 27
Water Chiller System 30
Location 31
Waste Fluid Container 32
Guidelines for Software Installation 32
6. Accessories and Options 34
Vapor Generation Accessory (VGA) Recommended Gases 34
Important Customer Web Links 35
Appendix A: Power Cords 36

Safety Practices and Hazards
Agilent 5100 and 5110 ICP-OES Site Preparation Guide 7
1. Safety Practices and Hazards
Heat, Vapors and Fumes
Heat, ozone, vapors and fumes generated by the plasma can be
hazardous, and must be extracted from the instrument by means of
an exhaust system. Ensure that an exhaust system of the appropriate
type is fitted (see Page 23). The system must be vented to the outside
air in accordance with local regulations and never within the
building. Regularly check the exhaust system by smoke test to ensure
that the exhaust system is functioning correctly. The exhaust fan
must always be switched on before igniting the plasma.
Compressed Gas Hazards
All compressed gases (other than air) can create a hazard if they leak
into the atmosphere. Even small leaks in gas supply systems can be
dangerous. Any leak (except that of air or oxygen) can result in an
oxygen-deficient atmosphere, which can cause asphyxiation. The
area in which cylinders are stored and the area surrounding the
instrument must be adequately ventilated to prevent such gas
accumulations.
Gas cylinders must be installed, stored and handled strictly in
accordance with local safety codes and regulations. Cylinders must
be used and stored only in a vertical position and secured to an
immovable structure or a properly constructed cylinder stand. Move
cylinders only by securing them to a properly constructed trolley.
Use only approved regulator and hose connectors (refer to the gas
supplier’s instructions).

Safety Practices and Hazards
8 Agilent 5100 and 5110 ICP-OES Site Preparation Guide
Use only ‘instrument grade’ gases with your spectrometer.
If using cryogenic gases (for example, liquid argon), prevent severe
burns by wearing suitable protective clothing and gloves.
Electrical Hazards
Connecting the Agilent ICP-OES to a power source that is not
equipped with a protective earth contact creates a shock hazard for
the operator and can damage the instrument. Likewise, interrupting
the protective conductor inside or outside the Agilent ICP-OES or
defeating the power cord ground creates a shock hazard for the
operator and can damage the instrument.
Other Precautions
Air flow to the cooling fans of the spectrometer and accessories must
be unobstructed. Do not block the ventilation grills on the
spectrometer and accessories. Consult the manuals supplied with
your PC, monitor, printer and water-cooling system for their specific
ventilation requirements.
The spectrometer weighs approximately 106 kg (234 lb). To avoid
injury to personnel or damage to the instrument or property, always
use a forklift or other suitable mechanical lifting device to move the
instrument.

After all safety regulations have been met, check the checklist box: Principal installation
area is in compliance with all relevant safety regulations.

Introduction
Agilent 5100 and 5110 ICP-OES Site Preparation Guide 9
2. Introduction
This publication contains the information required to successfully
prepare a site for an Agilent ICP-OES system installation.
On completion of the site preparation, fill in the checklist on Page 4,
(striking out those entries not applicable), and send this checklist to
your local Agilent agent or Agilent sales and service office. As soon
as it is received, Agilent or its agent will contact you to arrange a
convenient time for installation.
If you have difficulty in preparing for the installation, and for details
of operator training courses, please contact your Agilent sales or
field service representative.
Installation Guidelines
Allow a minimum of one day for the installation of the Agilent
ICP-OES system by an Agilent field service engineer.
The installation will include the following:
Spectrometer installation
Water chiller connection
Instrument software installation and registration
Accessory installation
Spectrometer installation performance tests
Basic customer training
Maintenance overview

Introduction
10 Agilent 5100 and 5110 ICP-OES Site Preparation Guide
This page is intentionally left blank.
