Agilent Technologies 4107 User manual

Agilent 4107 Nitrogen
Generator
User’s Guide

2 Agilent 4107 Nitrogen Generator User’s Guide
Notices
© Agilent Technologies, Inc. 2011,
2013, 2015
No part of this guide may be
reproduced in any form or by any
means (including electronic storage
and retrieval or translation into a
foreign language) without prior
agreement and written consent from
Agilent Technologies, Inc. as governed
by United States and international
copyright laws.
Guide Part Number
G8001-90001
Edition
Third edition, September 2015
Printed in USA
Agilent Technologies, Australia (M)
Pty Ltd
679 Springvale Road
Mulgrave, Victoria, 3170
Australia
Agilent products must only be used in
the manner described in the Agilent
product user guides. Any other use
may result in damage to the product
or personal injury. Agilent is not
responsible for any damages caused,
in whole or in part, by improper use of
the products, unauthorized alterations,
adjustments or modifications to the
products, failure to comply with
procedures in Agilent product user
guides, or use of the products in
violation of applicable laws, rules or
regulations.
Agilent shall not be liable for errors or
damages on products or performance
due to using non-Agilent genuine
parts.
Warranty
The material contained in this
document is provided “as is,” and is
subject to being changed, without
notice, in future editions. Further, to
the maximum extent permitted by
applicable law, Agilent disclaims all
warranties, either express or implied,
with regard to this guide and any
information contained herein,
including but not limited to the
implied warranties of merchantability
and fitness for a particular purpose.
Agilent shall not be liable for errors
or for incidental or consequential
damages in connection with the
furnishing, use, or performance of
this document or of any information
contained herein. Should Agilent and
the user have a separate written
agreement with warranty terms
covering the material in this
document that conflict with these
terms, the warranty terms in the
separate agreement shall control.
Technology Licenses
The hardware and/or software
described in this document are
furnished under a license and may be
used or copied only in accordance
with the terms of such license.
Restricted Rights Legend
If software is for use in the
performance of a U.S. Government
prime contract or subcontract,
Software is delivered and licensed as
“Commercial computer software” as
defined in DFAR 252.227-7014 (June
1995), or as a “commercial item” as
defined in FAR 2.101(a) or as
“Restricted computer software” as
defined in FAR 52.227-19 (June 1987)
or any equivalent agency regulation or
contract clause. Use, duplication or
disclosure of Software is subject to
Agilent Technologies’ standard
commercial license terms, and non-
DOD Departments and Agencies of the
U.S. Government will receive no
greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2) (June
1987). U.S. Government users will
receive no greater than Limited Rights
as defined in FAR 52.227-14 (June
1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
A CAUTION notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that, if
not correctly performed or adhered to,
could result in damage to the product
or loss of important data. Do not
proceed beyond a CAUTION notice
until the indicated conditions are fully
understood and met.
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or the
like that, if not correctly performed or
adhered to, could result in personal
injury or death. Do not proceed
beyond a WARNING notice until the
indicated conditions are fully
understood and met.
CAUTION
WARNING

Contents
Agilent 4107 Nitrogen Generator User’s Guide 3
Contents
1. Safety Practices and Hazards 5
General 5
Air supply 6
Compressed Gas Hazards 6
Electrical Hazards 7
Compressor 7
Other Precautions 7
Warning Symbols 8
CE Compliance 9
Electromagnetic Compatibility 10
EN55011/CISPR11 10
South Korean Class A EMC declaration 11
ICES/NMB-001 11
2. Introduction 13
Site Preparation Requirements 13
User Documentation 13
Notes and Tips 14
3. Installation 15
Overview 16
Installing the Nitrogen Generator 17
Unpacking 17
Connecting the nitrogen generator to the air supply 19

Contents
4 Agilent 4107 Nitrogen Generator User’s Guide
Connecting the nitrogen generator output to the MP-AES
instrument 19
Connecting the nitrogen generator power 20
4. Operation 21
Before Operation 21
Turning on the Nitrogen Generator 21
Selecting the Nitrogen Generator 22
Purging the Nitrogen Generator 23
Turning Off the Nitrogen Generator 23
Depressurizing the Nitrogen Generator 24
5. Maintenance, Spare Parts and Troubleshooting 25
Routine Maintenance 26
Draining Liquid from the Filter Housing 26
Replacing the Gas Filters 27
Checking the Gas Supply Tubing for Leaks 29
Spare Parts 29
Technical Support 30
Troubleshooting 30

Safety Practices and Hazards
Agilent 4107 Nitrogen Generator User’s Guide 5
1. Safety Practices and Hazards
General 5
Air supply 6
Compressed Gas Hazards 6
Electrical Hazards 7
Compressor 7
Other Precautions 7
Warning Symbols 8
CE Compliance 9
Electromagnetic Compatibility 10
ICES/NMB-001 11
General
Operation of an Agilent 4107 Nitrogen Generator involves the use of
compressed gases. Careless, improper or unskilled use of this
nitrogen generator can cause death or serious injury to personnel,
and/or severe damage to equipment and property.
The nitrogen generator covers are designed to prevent inadvertent
contact with any potential hazards. If the nitrogen generator is used
in any manner not specified by Agilent, this protection may be
impaired.
The safety practices described below are provided to help the user
operate the nitrogen generator safely. Read each safety topic
thoroughly before attempting to operate the nitrogen generator and
always operate the nitrogen generator in accordance with these
safety practices.

Safety Practices and Hazards
6 Agilent 4107 Nitrogen Generator User’s Guide
If you are unsure of the effects of any liquid, gas or chemical on the
nitrogen generator, consult your Agilent field service engineer or
approved representative before use.
Air supply
To avoid shortening its life, the nitrogen generator requires a supply
of clean, dry, oil-free air. To assist in achieving this, the nitrogen
generator has integral filters attached to the side of the unit.
Depending on the quality of the air supply and the environmental
conditions, additional driers and filters may be required. Please refer
to the Agilent MP-AES Site Preparation Guide for further details and
read the instructions regarding filters under the Maintenance chapter
of this guide.
CAUTION Under no circumstances should the nitrogen generator be operated without
these filters connected or with the filters in a saturated condition.
CAUTION Under no circumstances should the nitrogen generator be connected to an air
supply containing oil. Permanent damage to the nitrogen generator will occur.
Contamination of the sorbent material with oil will invalidate the
warranty.
Compressed Gas Hazards
Air compressors must be located and connected strictly in
accordance with local safety codes and regulations.
All compressed gases (other than air) can create a hazard if they leak
into the atmosphere. Even small leaks in gas supply systems can be
dangerous. Any leak (except that of air) can result in an oxygen-
deficient atmosphere which can cause asphyxiation. The area in
which cylinders are stored and the area surrounding the instrument
must be adequately ventilated to prevent such gas accumulations. Do
not directly inhale the output gas from the nitrogen generator.

Safety Practices and Hazards
Agilent 4107 Nitrogen Generator User’s Guide 7
Periodically inspect the hoses to make sure they are in good
condition and properly connected. Keep air hoses off the floor where
they can be tripping hazards or become damaged. When
disconnecting or connecting the hoses, make sure the hose is
depressurized first.
Always wear safety glasses when connecting or disconnecting gas
lines.
Electrical Hazards
Panels or covers which are retained by screws on the nitrogen
generator may be opened only by Agilenttrained, Agilent-qualified or
Agilentapproved field service engineers (unless specified otherwise).
The nitrogen generator is powered by an external AC-DC power
supply. If the enclosure of this power supply is damaged it should be
replaced immediately. Check the power cord for damage and replace
it if it is visibly worn or damaged.
If necessary, replace the power cord only with a cord equivalent to
the one specified in the site preparation guide.
Compressor
Consult the manuals or product labels supplied with your air
compressor for safety information and to determine which parts of it
are operator-accessible.
Other Precautions
The nitrogen generator weighs approximately 110 kg (242.5 lb). To
avoid injury to personnel or damage to the instrument or property,
always use a suitable mechanical lifting device to move the nitrogen
generator.
Use only Agilent-supplied spares with your nitrogen generator.

Safety Practices and Hazards
8 Agilent 4107 Nitrogen Generator User’s Guide
Warning Symbols
The following is a list of symbols that appear in conjunction with
warnings in this guide and on the nitrogen generator. The hazard
they describe is also shown. The beginning of the warning text is
noted by a warning icon:
WARNING
A triangular symbol indicates a warning. The meanings of the
symbols that may appear alongside warnings in the documentation
or on the instrument itself are as follows:
Eye hazard
Heavy weight
(danger to feet)
Heavy weight
(danger to hands)
Noxious gases
The following symbol may be used on warning labels attached to the
instrument or in this guide. When you see this symbol, refer to the
relevant operation or service manual for the correct procedure
referred to by that warning label.

Safety Practices and Hazards
Agilent 4107 Nitrogen Generator User’s Guide 9
The following symbols appear on the instrument for your
information.
Direct current
When attached to the rear of the instrument, it indicates that the product
complies with the requirements of one or more EU directives.
When attached to the rear of the product, indicates that the product has
been certified (evaluated) to CSA 61010.1 and UL 61010-1.
When attached to the rear of the product, indicates that the product
complies with the South Korean Electromagnetic Compatibility (EMC) law
applicable to Industrial and scientific use equipment.
When attached to the rear of the instrument, indicates that the product
complies with the requirements of ACMA.
When attached to the rear of the instrument, indicates that the product
complies with the requirements of WEEE ROHS directive.
CE Compliance
Your Agilent 4107 Nitrogen Generator has been designed to comply
with the requirements of the Electromagnetic Compatibility (EMC)
Directive and the Low Voltage (electrical safety) Directive (commonly
referred to as the LVD) of the European Union. Agilent has
confirmed that each product complies with the relevant Directives by
testing a prototype against the prescribed EN (European Norm)
standards.
Proof that a product complies with these directives is indicated by:
 the CE Marking appearing on the rear of the product, and
 the documentation package that accompanies the product
containing a copy of the Declaration of Conformity. The
Declaration of Conformity is the legal declaration by Agilent that
the product complies with the directives listed above, and shows
the EN standards to which the product was tested to
demonstrate compliance.

Safety Practices and Hazards
10 Agilent 4107 Nitrogen Generator User’s Guide
Electromagnetic Compatibility
EN55011/CISPR11
Group 1 ISM equipment: group 1 contains all ISM equipment in
which there is intentionally generated and/or used conductively
coupled radio- frequency energy which is necessary for the internal
functioning of the equipment itself.
Class A equipment is equipment suitable for use in all
establishments other than domestic and those directly connected to a
low voltage power supply network which supplies buildings used for
domestic purposes.
This device complies with the requirements of CISPR11, Group 1,
Class A as radiation professional equipment. Therefore, there may be
potential difficulties in ensuring electromagnetic compatibility in
other environments, due to conducted as well as radiated
disturbances.
Operation is subject to the following two conditions:
1This device may not cause harmful interference.
2This device must accept any interference received, including
interference that may cause undesired operation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try one or more of
the following measures:
1Relocate the radio or antenna.
2Move the device away from the radio or television.
3Plug the device into a different electrical outlet, so that the device
and the radio or television are on separate electrical circuits.
4Make sure that all peripheral devices are also certified.
5Make sure that appropriate cables are used to connect the device
to peripheral equipment.
6Consult your equipment dealer, Agilent Technologies, or an
experienced technician for assistance.
