Agilent Technologies 708-DS User manual

Agilent Technologies
708-DS
Dissolution Apparatus
Operator’s Manual

708-DS Operator’s Manual
Notices
© Agilent Technologies, Inc. 2016
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or transla-
tion into a foreign language) without prior
agreement and written consent from Agi-
lent Technologies, Inc. as governed by
United States and international copyright
laws.
Manual Part Number
70-9058
Edition
Rev E, February 2016
Agilent Technologies, Inc.
3501 Stevens Creek Blvd.
Santa Clara, CA 95052 USA
Warranty
The material contained in this doc-
ument is provided “as is,” and is
subject to being changed, without
notice, in future editions. Further,
to the maximum extent permitted
by applicable law, Agilent disclaims
all warranties, either express or
implied, with regard to this manual
and any information contained
herein, including but not limited to
the implied warranties of mer-
chantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connec-
tion with the furnishing, use, or
performance of this document or of
any information contained herein.
Should Agilent and the user have a
separate written agreement with
warranty terms covering the mate-
rial in this document that conflict
with these terms, the warranty
terms in the separate agreement
shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license.
Restricted Rights Legend
U.S. Government Restricted Rights. Soft-
ware and technical data rights granted to
the federal government include only those
rights customarily provided to end user
customers. Agilent provides this custom-
ary commercial license in Software and
technical data pursuant to FAR 12.211
(Technical Data) and 12.212 (Computer
Software) and, for the Department of
Defense, DFARS 252.227-7015 (Techni-
cal Data - Commercial Items) and DFARS
227.7202-3 (Rights in Commercial Com-
puter Software or Computer Software
Documentation).
Safety Notices
CAUTION
A CAUTION notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in damage to the product or loss
of important data. Do not proceed
beyond a CAUTION notice until
the indicated conditions are fully
understood and met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice,
or the like that, if not correctly
performed or adhered to, could
result in personal injury or
death. Do not proceed beyond a
WARNING notice until the
indicated conditions are fully
understood and met.

708-DS Operator’s Manual 3
Contents
Figures 7
1Safety 11
Electrical Hazards 12
Warning 13
Caution 13
Note 13
Information Symbols 14
2 Introduction 15
Conventions Used in this Manual 17
Serial Number Format 18
3 Setting Up the 708-DS 19
Initial Setup 20
Unpacking Procedure 20
Environmental Requirements for Installation 22
Clearance 22
Equipment, Parts, and Accessories As Shipped 23
Parts and Accessories 23
Tubing / Cable Connections 24
708-DS Heater / Circulator Setup 24
Instrument Level / Water Bath Setup 25
Level Instrument 25
Bath Temperature Probe Installation 28
Handheld Probe Installation 29

4 708-DS Operator’s Manual
Contents
Power Cord Connections 29
708-DS Initial Power Up 29
Filling the Water Bath 30
Level Instrument - Re-verification 31
Heater / Circulator Power-up 31
Agilent 708-DS Setup 32
Vessel Installation 32
Sample Manifold Installation 32
Accessory Installation 36
Setting Basket (Apparatus 1) Heights 42
Setting Paddle (Apparatus 2) Heights 43
4 Operating the 708-DS 45
Main Screen - Options 46
Main Screen - Display Parameters 46
Main Screen - Sample Temperatures 47
Main Screen - Run 48
Main Screen - Stop 55
Main Screen - Drive Unit Up / Down 58
Manual Drive Unit Up / Down 58
Manual Sampling 59
Main Screen - Manifold Up / Down 60
Main Screen - Lock 61
Main Screen - Unlock 62
Main Screen - Remote Control 63
Main Screen - Alarms 64
Main Screen - Maintenance Due Icon 64
Menu Screen - System Menu 65
Menu Screen - Method Editor 66
Menu Screen - Reports 75
Menu Screen - Alarms 78
Menu Screen - Instrument 79

Contents
708-DS Operator’s Manual 5
Menu Screen - Calibration 84
Menu Screen - Diagnostics 87
Menu Screen - User Access 90
General 708-DS Conventions 91
Alphanumeric Data Entry 91
Numeric and Time / Date Entry 92
Parameter Limits / Ranges 93
Agilent 708-DS Notifications 95
Main Screen - Error Conditions 95
Dialog Screens (Green / Blue) 97
Warning Screens (Yellow) 99
Error Screens (Red) 103
5 Maintenance and Troubleshooting 107
Preventive Maintenance 108
Weekly Maintenance 108
Monthly Maintenance 108
Bi-Annual Maintenance 108
Sample Line / Paddle / Basket Care 109
Shafts 109
Baskets 110
Rinsing Sample Lines 111
Rinse Cups (Optional) 112
Vessels and Evaporation Covers 113
Water Bath and Temperature Probes 113
Water Bath Care 113
Water Bath Temperature Probe Accuracy Test 114
Removing or Adjusting Cannulas / Probes 116
Manifold Maintenance 116
Removing the Manifold 116

6 708-DS Operator’s Manual
Contents
Accessing the Top Cover 117
Removing Top Cover 117
Replacing the Top Cover 117
Printer Maintenance 118
Removing a Thermal Paper Roll 118
Inserting a Thermal Paper Roll (5095-0307) 121
Thermal Printer Test 124
Obtaining Warranty and Other Services 124
