1
Software Keypad

10 Advanced User Guide
1Software Keypad
Using the Software Keypad
The Agilent software keypad (remote controller) provides the
ability to program and use the 7820A Gas Chromatograph (GC).
Refer to the Operating Guide for instructions for its installation
and use.
All instructions in this manual assume the use of the software
keypad unless otherwise noted.
Figure 1 Software keypad (remote controller)

11
Agilent 7820A Gas Chromatograph
Advanced User Guide
FINAL DRAFT - 8 AUG 2016
Agilent Technologies
2
Programming
Run Time Programming 12
Using run time events 12
Programming run time events 13
The run table 13
Adding events to the run table 13
Editing events in the run table 14
Deleting run time events 14
Clock Time Programming 15
Using clock time events 15
Programming clock time events 15
Adding events to the clock table 15
Editing clock time events 16
Deleting clock time events 16
Post Run Programming 17

12 Advanced User Guide
2Programming
FINAL DRAFT - 8 AUG 2016
Run Time Programming
Run time programming during a method allows certain
setpoints to change automatically during a run as a function of
the chromatographic run time. Thus an event that is
programmed to occur at 2 minutes will occur 2 minutes after
every injection.
Its uses include:
•Controlling column switching or other valves
•Changing analog signal definition, zero, or range
•Controlling an auxiliary pressure channel
•Changing polarity of a thermal conductivity detector (TCD)
•Turning the hydrogen flow to a nitrogen-phosphorus
detector (NPD) on or off
•Switching digital signal output (requires an Agilent data
system)
•Pausing (“freezing”) and resuming digital signal output
(requires an Agilent data system)
The changes are entered into a run table that specifies the
setpoint to be changed, the time for the change, and the new
value. At the end of the chromatographic run, most setpoints
changed by a run time table are returned to their original
values.
Valves can be run time programmed but are not restored to
their starting position at the end of the run. You must program
the reset operation in the run table if this action is desired. See
“From the run or clock time tables” on page 115.
Using run time events
The [Run Table] key is used to program the following timed
events.
•Valves (1-2)
•Analog signal definition, zero, and range
•TCD negative polarity (on/off)
•Detector gas flow (on/off), including NPD H2fuel gas

Programming 2
Advanced User Guide 13
FINAL DRAFT - 8 AUG 2016
Programming run time events
1Press [Run Table].
2Press [Mode/Type] to see the available run time events.
3Scroll to the event to be programmed. Press [Enter].
4Enter values for the Time: and the other parameter. Press
[Enter] after each entry.
5Press [Mode/Type] to add another event. Press [Status] to
terminate entries.
The run table
The programmed events are arranged in order of execution time
in the Run Table. This is a brief example:
RUN TABLE (1 of 3) Event 1 rotates a valve.
Time: 0.10
Valve #2 On
RUN TABLE (2 of 3) Event 2 adjusts the signal
Time: 3 range.
Analog signal 2 range 2
RUN TABLE (3 of 3) Event 3 resets Valve #2 to its
Time: 4.20 original position in preparation
Valve #2 Off for another run. Valves do not
reset automatically.
Adding events to the run table
1To add new events to the run table, press [Mode/Type] while
on the Time: line of any entry.
2Select the event type.
3Set appropriate Time: and other parameters. Some require
numbers; others require [On/Yes] or [Off/No].
4Repeat until all entries are added. Events are automatically
placed in order by execution time.

14 Advanced User Guide
2Programming
FINAL DRAFT - 8 AUG 2016
Editing events in the run table
1Press [Run Table].
2Move the cursor to the event you want to change.
3To edit the time for an event, move the cursor to the line
labeled Time:. Type the desired time and press [Enter].
4To edit a setpoint value, scroll to the setpoint line. Press
[On/Yes] or [Off/No] or enter a numeric value for the
setpoint. Press [Enter].
Deleting run time events
1Press [Run Table].
2From within this table press [Delete] to delete events from
the run time table. You will be asked to confirm the deletion.
3Press [On/Yes] to delete the current timed event; press
[Off/No] to cancel this operation.
4To delete the entire table, press [Delete][Run Table].

Programming 2
Advanced User Guide 15
FINAL DRAFT - 8 AUG 2016
Clock Time Programming
Clock time programming allows certain setpoints to change
automatically at a specified time during a 24-hour day. Thus, an
event programmed to occur at 14:35 hours will occur at 2:35 in
the afternoon. A running analysis or sequence has precedence
over any clock table events occurring during this time. Such
events are not executed.
Possible clock time events include:
•Valve control
•Method and sequence loading
•Starting sequences
•Initiating blank and prep runs
•Column compensation changes
•Adjustments of the detector offset
Using clock time events
The Clock Table function allows you to program events to occur
during a day based on the 24-hour clock. Clock table events that
would occur during a run or sequence are ignored.
For example, the clock table could be used to make a blank run
before you even get to work in the morning.
Programming clock time events
1Press [Clock Table].
2Press [Mode/Type] to see the available clock time events.
3Scroll to the parameter to be programmed.
4Edit Time: and the setpoints for this event.
5Press [Mode/Type] to add another event. Press [Status] to
terminate entries.
When the clock event is executed, a confirming message
appears.
Adding events to the clock table
1Press [Clock Table].
2Press [Mode/Type]. When entries are added, they are
automatically ordered chronologically.

16 Advanced User Guide
2Programming
FINAL DRAFT - 8 AUG 2016
3Select the event type.
4Set appropriate parameters.
5Repeat this process until all entries are added.
Editing clock time events
1Press [Clock Table] to view all events programmed.
2Scroll to the event you want to change.
3To edit the time for an event, move the cursor to the line
labelled Time: and type the desired time.
4To edit a setpoint value, scroll to the setpoint item. Press
[On/Yes] or [Off/No], or enter a numerical value for the
setpoint.
Deleting clock time events
1Press [Clock Table].
2Use [Delete] to remove events from the clock time table. You
will be asked to confirm the deletion.
3Press [On/Yes] to delete the current timed event; press
[Off/No] to cancel this operation.
To delete the entire table, press [Delete][Clock Table].

Programming 2
Advanced User Guide 17
FINAL DRAFT - 8 AUG 2016
Post Run Programming
This function can be used with both isothermal and
programmed methods. Post run is a period that begins at the
end of the normal run. The parameters include:
•Time—How long is the post run period?
•Oven Temperature—What is the oven temperature during the
post run period?
•Column npres—For a column controlled in a pressure mode,
enter the pressure for this column during the post run
period.
•Column nflow—For a column controlled in a flow mode, enter
the flow rate for this column during the post run period.
Post run may be used to clean out a column in preparation for
the next run, backflush a column to eliminate high-boilers, and
other functions.
When the Post run Time elapses, the GC returns to the initial
state defined in the current method.
To enable a post run program
1Press [Post Run].
2Type a non-zero time for the post run duration and press
[Enter]. The post run parameters available for the current GC
configuration appear.
3Scroll to each desired parameter, type the value for the post
run period, and press [Enter].
To disable a post run program
1Press [Post Run].
2Type a 0 as the post run time and press [Enter].
NOTE EPR (electronic pneumatics regulation) equipped GCs do not support post
run parameters for Column n pres and Column n flow since column
pressure and flow are set manually.

18 Advanced User Guide
2Programming
FINAL DRAFT - 8 AUG 2016

19
Agilent 7820A Gas Chromatograph
Advanced User Guide
Agilent Technologies
3
Inlets
Using Hydrogen 20
Inlet Overview 21
Carrier Gas Flow Rates 22
About Gas Saver 23
Pre Run and Prep Run 25
Auto Prep Run 26
About the Split/Splitless Inlet 27
Split/Splitless inlet split mode overview 28
Split/Splitless inlet splitless mode overview 29
The S/SL inlet pulsed split and splitless modes 30
Split/Splitless inlet split mode minimum operating pressures 31
Selecting the correct S/SL inlet liner 32
Vapor Volume Calculator 34
Selecting parameters for the S/SL splitless mode 36
About the Purged Packed Column Inlet 39
Setting parameters 40
About the Packed Column Inlet 41
Setting parameters 40
About the Cool On-Column Inlet 43
Retention gaps 44
COC inlet temperature control
44
Setting COC inlet flows/pressures 45

20 Advanced User Guide
3Inlets
Using Hydrogen
WARNING When using hydrogen (H2), as the carrier gas, be aware that
hydrogen (H2) gas can flow into the oven and create an explosion
hazard. Therefore, be sure that the supply is off until all
connections are made, and ensure that the inlet and detector
column fittings are either connected to a column or capped at all
times when hydrogen (H2) gas is supplied to the instrument.
WARNING Hydrogen (H2) is flammable. Leaks, when confined in an enclosed
space, may create a fire or explosion hazard. In any application
using hydrogen (H2), leak test all connections, lines, and valves
before operating the instrument. Always turn off the hydrogen
(H2) supply at its source before working on the instrument.
