Agilent Technologies PR02 User manual

DRAFT 2/13/14
OPERATION MANUAL
Vacuum Products Division
VS Series Helium
Mass Spectrometer
Leak Detectors
MODELS: PR02, MR15, MD30, BR15, BD30 AND
PD03
Manual No. 699909942
Revision J
January 2014

DRAFT 2/13/14
Copyright 2014
Agilent, Inc
VS Series Helium Mass Spectrometer
Leak Detector
Contra-Flow is a trademark or registered trademark of Agilent, Inc.
Alconox is a registered trademark of Alconox, Inc.
Apiezon is a registered trademark of M&I Materials Ltd.

VS Series Helium Mass Spectrometer Leak Detectors
DRAFT 2/13/14
Warranty
Products manufactured by Seller are warranted against defects in materials and workmanship for
twelve (12) months from date of shipment thereof to Customer, and Seller’s liability under valid war-
ranty claims is limited, at the option of Seller, to repair, to replace, or refund of an equitable portion of
the purchase price of the Product. Items expendable in normal use are not covered by this warranty. All
warranty replacement or repair of parts shall be limited to equipment malfunctions which, in the sole
opinion of Seller, are due or traceable to defects in original materials or workmanship. All obligations of
Seller under this warranty shall cease in the event of abuse, accident, alteration, misuse, or neglect of
the equipment. In-warranty repaired or replaced parts are warranted only for the remaining unexpired
portion of the original warranty period applicable to the repaired or replaced parts. After expiration of
the applicable warranty period, Customer shall be charged at the then current prices for parts, labor,
and transportation.
Reasonable care must be used to avoid hazards. Seller expressly disclaims responsibility for loss or
damage caused by use of its Products other than in accordance with proper operating procedures.
Except as stated herein, Seller makes no warranty, express or implied (either in fact or by operation of
law), statutory or otherwise; and, except as stated herein, Seller shall have no liability under any war-
ranty, express or implied (either in fact or by operation of law), statutory or otherwise. Statements made
by any person, including representatives of Seller, which are inconsistent or in conflict with the terms of
this warranty shall not be binding upon Seller unless reduced to writing and approved by an officer of
Seller.
Warranty Replacement and Adjustment
All claims under warranty must be made promptly after occurrence of circumstances giving rise thereto,
and must be received within the applicable warranty period by Seller or its authorized representative.
Such claims should include the Product serial number, the date of shipment, and a full description of
the circumstances giving rise to the claim. Before any Products are returned for repair and/or adjust-
ment, written authorization from Seller or its authorized representative for the return and instructions as
to how and where these Products should be returned must be obtained. Any Product returned to Seller
for examination shall be prepaid via the means of transportation indicated as acceptable by Seller.
Seller reserves the right to reject any warranty claim not promptly reported and any warranty claim on
any item that has been altered or has been returned by non-acceptable means of transportation. When
any Product is returned for examination and inspection, or for any other reason, Customer shall be
responsible for all damage resulting from improper packing or handling, and for loss in transit, notwith-
standing any defect or non-conformity in the Product. In all cases, Seller has the sole responsibility for
determining the cause and nature of failure, and Seller’s determination with regard thereto shall be
final.
If it is found that Seller’s Product has been returned without cause and is still serviceable, Customer will
be notified and the Product returned at Customer’s expense; in addition, a charge for testing and exam-
ination may be made on Products so returned.

VS Series Helium Mass Spectrometer Leak Detectors
This page intentionally left blank.
DRAFT 2/13/14

VS Series Helium Mass Spectrometer Leak Detectors
DRAFT 2/13/14
v
Table of Contents
Preface ...............................................................................................................................................xi
Documentation Standards ...........................................................................................................xi
Hazard and Safety Information ...................................................................................................xii
Agilent Services .........................................................................................................................xxi
Contacting Agilent ......................................................................................................................xxi
Section 1. Introduction to the VS Series Leak Detector ..................................................................1-1
1.1 The VS Series Leak Detector .............................................................................................1-1
1.2 Unpacking the Leak Detector...............................................................................................1-5
1.2.2 Removing the Leak Detector from the Skid ................................................................1-6
1.3 Installation............................................................................................................................1-8
1.3.2 Recommended Additional Services..........................................................................1-12
1.3.3 Storage......................................................................................................................1-12
1.4 Front Panel Display and Controls......................................................................................1-13
1.5 Display Panel Controls.......................................................................................................1-17
1.6 Rear Panel.........................................................................................................................1-19
1.7 Features.............................................................................................................................1-23
Section 2. Operating the Leak Detector ..........................................................................................2-1
2.1 Initial Startup, High Pressure Test Setup, and Shutdown ...................................................2-1
2.1.2 High Pressure Test Set-Up Procedure........................................................................2-3
2.1.3 Shutdown....................................................................................................................2-4
2.2 Screens................................................................................................................................2-5
2.2.2 Home Screen..............................................................................................................2-7
2.2.3 Control Panel Screen................................................................................................2-12
2.2.4 Menus Screen...........................................................................................................2-16
Section 3. Set-Up ............................................................................................................................3-1
3.1 Set-Up Menu .......................................................................................................................3-1
3.1.2 Manual Tuning ............................................................................................................3-7
3.1.3 Manual Valve Control................................................................................................3-10
3.1.4 Output Control...........................................................................................................3-13
3.1.5 Units..........................................................................................................................3-15
3.1.6 Languages ................................................................................................................3-16
3.1.7 Gauge Calibration.....................................................................................................3-17
3.1.8 Maintenance..............................................................................................................3-19
3.1.9 Password ..................................................................................................................3-24
3.1.10 Fore Pump Set-Up and Exhaust Pump...................................................................3-25
3.1.11 Wireless ..................................................................................................................3-27
3.1.12 System Defaults......................................................................................................3-29
Section 4. Maintenance ..................................................................................................................4-1
4.1 Daily Maintenance ..............................................................................................................4-5

VS Series Helium Mass Spectrometer Leak Detectors
vi
DRAFT 2/13/14
4.2 Dry Nitrogen Vent ................................................................................................................4-5
4.3 Spare Parts List ...................................................................................................................4-6
4.4 Leak Detector Accessory Item List ......................................................................................4-8
Appendix A. Communications Protocol ..........................................................................................A-1
A.2 Communicating with RS-232...............................................................................................A-2
A.2.1 Windows HyperTerminal Set-Up Instructions ............................................................A-2
A.2.2 Printing with HyperTerminal ......................................................................................A-4
A.3 Customer Accessible Inputs and Outputs .........................................................................A-14
A.3.1 Serial Connector ......................................................................................................A-14
A.3.2 I/O Connector ..........................................................................................................A-14
Appendix B. Introduction to Leak Detection ....................................................................................B-1
B.2 Agilent's Helium Leak Detection Technologies ...................................................................B-1
B.3 Methods of Leak Testing.....................................................................................................B-3
B.3.1 Vacuum Testing Method (Outside-in) ........................................................................B-4
B.3.2 Pressure Testing Method (Inside-out) .......................................................................B-5
B.3.3 System Leak Test Methods .......................................................................................B-6
B.4 Typical Leak Detection Applications....................................................................................B-8
B.4.1 Quality Control of Production Parts and Assemblies .................................................B-8
B.4.2 Maintenance of Systems ...........................................................................................B-8
B.4.3 System Integrated Leak Detection ............................................................................B-9
B.4.4 Mass Produced Parts ................................................................................................B-9
Appendix C. Specifications .............................................................................................................C-1

VS Series Helium Mass Spectrometer Leak Detectors
DRAFT 2/13/14
vii
List of Figures
Figure Title Page
1-1 Portable Leak Detector with Internal DS42 Wet Rotary Vane Pump, Model VS PR02, and
Portable Leak Detector with Internal IDP-3 (PD03) Dimensions ........................................1-3
1-2 Mobile Leak Detector with External DS302 Wet Rotary Vane Pump on a Cart, Model VS
MR15, Dimensions..............................................................................................................1-3
1-3 Mobile Leak Detector with External TS620 Dry Scroll Pump on a Cart, Model VS MD30,
Dimensions.........................................................................................................................1-4
1-4 Location of Rear Cover Screws..........................................................................................1-9
1-5 Bench Mount Leak Detector with External DS302 Wet Rotary Vane Pump, Model VS BRI5 .
1-11
1-6 Bench Mount Leak Detector with External TS620 Dry Scroll Pump, Model VS BD30......1-11
1-7 Front Panel Displays and Controls ...................................................................................1-13
1-8 Screen Flow......................................................................................................................1-16
1-9 VS Series Rear Panel.......................................................................................................1-19
1-10 Optional I/O PCB Rear Panel ...........................................................................................1-20
1-11 Rear Panel (with Discrete I/O PCB)..................................................................................1-22
2-1 Helium Background Timer ..................................................................................................2-2
2-2 Home Screen......................................................................................................................2-7
2-3 Gross Test Screen..............................................................................................................2-9
2-4 Control Panel....................................................................................................................2-12
2-5 20 Minute Warm-up Dialog...............................................................................................2-14
2-6 Graphical Display..............................................................................................................2-15
2-7 Menus Screen...................................................................................................................2-16
2-8 Calibration Set-Up.............................................................................................................2-17
2-9 Helium Background Timer ................................................................................................2-18
2-10 Reject and Audio Setpoints...............................................................................................2-19
2-11 Auto Sequencer................................................................................................................2-23
2-12 Leak Rate Ranging...........................................................................................................2-25
2-13 Transfer Points..................................................................................................................2-28
2-14 Transfer Points with Stabilization Wait Timer ...................................................................2-29
2-15 System Information...........................................................................................................2-30
2-16 Control Panel Access........................................................................................................2-32
3-1 Set-Up Screen - Initial.........................................................................................................3-1
3-2 Set-Up Screen - Second.....................................................................................................3-2
3-3 Advanced Parameters ........................................................................................................3-3
3-4 Manual Tuning....................................................................................................................3-7
3-5 Manual Valve Control........................................................................................................3-10
3-6 Manual Valve Control - PD03 ...........................................................................................3-11
3-7 Leak Detector Vacuum System Diagram..........................................................................3-12
3-8 Output Control...................................................................................................................3-13
3-9 Leak Detector Linear Output Voltage................................................................................3-14
3-10 Leak Detector Logarithmic Output Voltage.......................................................................3-14
3-11 Units..................................................................................................................................3-15

VS Series Helium Mass Spectrometer Leak Detectors
viii
DRAFT 2/13/14
3-12 Languages........................................................................................................................3-16
3-13 Gauge Calibration.............................................................................................................3-17
3-14 Maintenance .....................................................................................................................3-19
3-15 Vent Turbo Dialog.............................................................................................................3-20
3-16 Current Date & Time Set-Up.............................................................................................3-21
3-17 Internal Calibrated Leak....................................................................................................3-22
3-18 Cal Leak Expiration Set-Up ..............................................................................................3-23
3-19 Password Screen..............................................................................................................3-24
3-20 Fore Pump Set-Up............................................................................................................3-25
3-21 Exhaust Pump ..................................................................................................................3-25
3-22 Date Serviced ...................................................................................................................3-26
3-23 Wireless............................................................................................................................3-27
3-24 System Defaults Screen ...................................................................................................3-29
A-1 Serial Connector Map.......................................................................................................A-14
A-2 Optically Isolated Output Circuit Sketch ...........................................................................A-17
A-3 Optically Isolated Input Circuit Sketch..............................................................................A-18
B-1 Magnetic Separation Principle............................................................................................B-2
B-2 Selective Ion Pump Detector..............................................................................................B-3
B-3 Locating Leaks: Outside In.................................................................................................B-4
B-4 Measuring Leaks: Outside In..............................................................................................B-4
B-5 Measuring Leaks: Inside Out..............................................................................................B-5
B-6 Locating Leaks: Inside Out.................................................................................................B-5
B-7 Accumulation: Inside Out....................................................................................................B-6
B-8 Vacuum System..................................................................................................................B-7

VS Series Helium Mass Spectrometer Leak Detectors
DRAFT 2/13/14
ix
List of Tables
Table Title Page
1-1 VS Series Leak Detector Configurations and Part Numbers............................................. 1-2
1-2 Installation Requirements ................................................................................................ 1-10
1-3 Screens – General Description........................................................................................ 1-17
1-4 VS Series Features.......................................................................................................... 1-23
2-1 Screen Basic Functional Items .......................................................................................... 2-5
2-2 On-Screen Icons................................................................................................................ 2-6
2-3 Leak Detector Operating States......................................................................................... 2-9
2-4 Leak Detector Condition States....................................................................................... 2-10
2-5 Range Stop/Sensitivity Requirements ............................................................................. 2-26
2-6 System Information Screen Conditions............................................................................ 2-30
3-1 Leak Detector Valve State Table - Single Mechanical Pump System ............................. 3-12
4-1 Scheduled Maintenance .................................................................................................... 4-3
4-2 As-Required Maintenance ................................................................................................. 4-3
4-3 Fuses and Circuit Breakers................................................................................................ 4-4
4-4 Leak Detector Spare Parts................................................................................................. 4-6
4-5 Leak Detector Accessory Item List .................................................................................... 4-8

VS Series Helium Mass Spectrometer Leak Detectors
This page intentionally left blank.
DRAFT 2/13/14

VS Series Helium Mass Spectrometer Leak Detectors
DRAFT 2/13/14
xi
Preface
Documentation Standards
This manual uses the following documentation standards:
NOTE Notes contain important information.
CAUTION Cautions appear before instructions, which if not followed,
could cause damage to the equipment or data loss.
WARNING Warnings appear for a particular procedure or practice which, if
not followed correctly, could lead to serious injury or death.
Text
Hard buttons are depicted in text in bold text.
Soft key screen buttons are depicted in bold text when part of an action.
Italics is used for emphasis or to indicate screen text.

VS Series Helium Mass Spectrometer Leak Detectors
xii
DRAFT 2/13/14
Hazard and Safety Information
OFF Supply (Power) Earth (Ground) Terminal
ON Supply (Power) Caution, Hot Surface
AC – Alternating Current Caution, Risk of Electrical
Shock
Warning, Risk of danger Protective Conductor
Termin al
Frame or chassis Terminal Do Not Place in Trash
Indoor, Dry Location Use
Only
Caution, Radio
Restriction
The common international symbols used in this manual and on the equipment are defined
below.
Operators and service personnel must be aware of all hazards associated with this
equipment. They must know how to recognize hazardous and potentially hazardous
conditions, and know how to avoid them. The consequences of unskilled, improper, or
careless operation of the equipment can be serious. Every operator or service person must
read and thoroughly understand operation/maintenance manuals and any additional
information provided by Agilent. All warning and cautions must be read carefully and
strictly observed. Consult local, state, and national agencies regarding specific requirements
and regulations. Address any safety, operation, and/or maintenance questions to your
nearest Agilent office.
°
l

VS Series Helium Mass Spectrometer Leak Detectors
DRAFT 2/13/14
xiii
Solvents
WARNING The mechanical components of leak detectors are typically
cleaned with alcohol, methanol, or other solvents.
When heated, sprayed, or exposed to high-temperature
equipment, these solvents become flammable and explosive,
causing serious injury or death. Do not use these solvents near
a high-temperature source. Ventilate the working area with a
blower and work in a large, well-ventilated room.
Alcohol, methanol, or other solvents are irritants, narcotics,
depressants and/or carcinogens. Their inhalation and/or
ingestion may produce serious side effects. Prolonged or
continued contact with the skin results in absorption through
the skin and moderate toxicity. Always ensure that cleaning
operations are carried out in large, well-ventilated rooms, and
wear eye shields, gloves, and protective clothing.
To clean the leak detector plastic enclosure, the LCD display
and Front Panel buttons, use only a soft cloth slightly
dampened with water or a mild soap.
Do NOT use excess water or cleaning solvents of any kind.
Avoid splashing any cleaning solvents into the unit through the
ventilation openings or Front Panel buttons. Wipe the surface
with a dry lint-free cloth.
CAUTION Do not clean any aluminum parts with Alconox®. Alconox is
not compatible with aluminum and will cause damage.
Vacuum Equipment and Cleanliness
Cleanliness is vital when servicing the leak detector or any vacuum equipment. There are
some techniques that are more important in leak detector servicing than in general vacuum
work:
CAUTION Do not use silicone oil or silicone grease.
Use powder-free butyl or polycarbonate gloves to prevent skin
oils from getting on vacuum surfaces.
NOTE Agilent does not recommend the use of vacuum grease.
Vacuum grease absorbs helium tracer gas and releases this
slowly resulting in helium background during leak test
operations. If it must be used, use it sparingly and avoid
silicone types. Apiezon®L grease is recommended (Agilent Part
No. 695400004).

VS Series Helium Mass Spectrometer Leak Detectors
xiv
DRAFT 2/13/14
O-ring Care
When removing, checking or replacing O-rings, keep in mind the following:
NOTE Agilent recommends replacing all O-rings during routine
maintenance or during any maintenance procedure requiring
that O-rings be removed.
NOTE Due to the effective cleaning nature of VacuSolv solvent and
its residue-free properties, Agilent’ Component and
Spectrometer Cleaning Kit (Part Number 670029096), used in
accordance with the kit instructions, is recommended for
cleaning spectrometer components. The kit can also be used for
fine cleaning of other parts in the leak detector’s vacuum
system such as valves and fittings. No rinsing steps or
high-temperature drying are required following cleaning with
VacuSolv. Although appropriate precautions are advised,
VacuSolv is compatible with most materials and does not
contain toxic chemicals or CFCs (chlorofluorocarbons). Other
acceptable solvents are isopropyl alcohol (IPA) or Dow
Corning®OS-20.
CAUTION Remove O-rings carefully with your fingers. Do not use metal
tools for this task; this prevents scratching of any sealing
surfaces.
❑Wipe all O-rings clean with a lint-free cloth before
installation to ensure that no foreign matter is present to
impair the seal.
❑Do not use grease or any other substance on O-rings that
will come in contact with the spectrometer.
❑Do not use alcohol, methanol or other solvents on O-rings.
Doing so causes deterioration and reduces their ability to
hold a vacuum.
❑Agilent does not recommend the use of vacuum grease. If
applicable, apply a small amount of Apiezon®L grease and
wipe the O-rings shiny dry.

VS Series Helium Mass Spectrometer Leak Detectors
DRAFT 2/13/14
xv
Metal Seal Care
CAUTION Metal Seals must be replaced during routine maintenance or
during any maintenance procedure required. All fasteners must
be installed and torqued per assembly procedure specifications.
Remove Metal Seals carefully with your fingers. Do not use
metal tools for this task, this prevents scratching of any sealing
surfaces. Wear non-powdered, ESD safe Nitride or equivalent
gloves prior to removing or replacing Metal Seals.
❑All Metal Seals come in clean room condition packages. No
cleaning is required If necessary, Metal Seals can be cleaned
using alcohol or methanol. Wipe all Metal Seals clean with a
lint free cloth before installation to ensure that no foreign
matter is present to impair the seal.
❑Do not use grease or any other substance on Metal Seals that
will come in contact with the spectrometer.
Equipment, General
Environment of intended use:
❑Indoors use in an industrial and laboratory installation only.
❑Altitude up to 2000m
❑POLLUTION DEGREE 2, Material group III
❑Operating Temperature: +12 °C to +45 °C, Relative
Humidity (RH) up to 90% max.
❑Storage ambient conditions: RH from 0% to 95%,
non-condensing, temperature: -20°C to +60°C
WARNING ❑Do not use in presence of flammable or explosive gas.
❑Do not attempt to disassemble or modify the equipment.
Such action could lead to electric shock or injury. Agilent's
authorized technician will do any repair work.
❑If there is smoke or unusual smell or noise, stop the using the
equipment immediately, and contact the Agilent Service
Center.
WARNING The leak detector is not designed for use with hazardous gases.
Verify that the system to be tested has been purged of all
hazardous gases prior to using the leak detector. When testing a
system that contained hazardous gases, connect the exhaust of
the leak detector to a scrubbed or toxic containment exhaust.
Exposure to hazardous gases could result in serious injury or
death.

VS Series Helium Mass Spectrometer Leak Detectors
xvi
DRAFT 2/13/14
WARNING Equipment tightness is guaranteed for normal operating
conditions when the equipment leaves the factory. It is the
user’s responsibility to maintain the level of tightness,
particularly when pumping dangerous products.
CAUTION The performance and operating safety of this equipment can
only be guaranteed if it is operated according to normal
conditions of use.
Allow at least 4" of clearance adjacent to the ventilation slots at
the front, sides and back of the equipment enclosure.
Allow sufficient room for the operator to safely maneuver to
perform testing.
LCD Display
WARNING If the LCD display breaks, avoid getting any liquid crystal in mouth
or eyes. If it gets on the operator hands, feet or clothing, wash it
immediately with soap and water.
CAUTION Do not apply excessive pressure to the LCD display as this may
cause smears.
In general, the lower the temperature, the longer it takes the LCD
display to turn on. Performance of the LCD display may deteriorate
in low temperature.
Radio The Wireless Remote Control is built around an Aerocomm, model
AC4424-100, RF transceiver module operating in 2.4 GHz ISM
band. The same type of the RF module is built in a VS Series Leak
Detector Wireless Base Station PCB and Wireless Remote unit (see
VS Series Leak Detector Wireless Remote Operational Manual
(6999099945A)).
Agency Identification Numbers for Aerocomm, Model
AC4424-100:
❑US/FCC ID: KQL-AC4424
❑CAN/IC: CAN2268C391190A
❑EUR/EN: CE
are also applied to the Agilent's Wireless Remote and VS Series
Leak Detector Wireless Base Station, when the units are used the
approved antennas.

VS Series Helium Mass Spectrometer Leak Detectors
DRAFT 2/13/14
xvii
WARNING The Wireless Remote complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that
may cause undesired operation.
To satisfy FCC RF exposure requirements for mobile type transmit-
ting devices, maintain a separationdistance of 20 cm or more
between the antenna of the Wireless Remote and persons during
operation, with exception of hands wrist, feet, and ankles. To
ensure compliance, operations at closer distance than this distance
are prohibited.
Maintain a separation distance of 20 cm or more between the oper-
ator and the RF antenna of the VS Series leak detector with a wire-
less base station.
CAUTION Use only approved type of antennas for:
❑Wireless Remote: Centurion, Model WCP2400-MMCX2,
www.centurion.com.
❑VS Series Leak Detector Wireless Base Station, Nearson,
Model S181FL-5-RMM- 2450S, www.nearson.com
Power and Static Sensitivity
WARNING Depending on the unit configuration ordered, the mains power
supply requirements for VS Series leak detectors are:
❑100 VAC, 50 Hz, 20 A
❑115 VAC, 60 Hz, 20 A or
❑230 VAC, 50/60 Hz, 12 A
Before powering the unit for the first time, verify that the unit is
configured to operate for the local mains supply voltage.

VS Series Helium Mass Spectrometer Leak Detectors
xviii
DRAFT 2/13/14
CAUTION Use surge protection to improve the immunity of the leak
detector against unidirectional transients caused by the
following phenomena:
❑Switching phenomena in the power network 
(e.g., switching of capacitor banks, inductive loads,
electrical motors, etc.)
❑Faults in the power network
❑Indirect lightning strokes
CAUTION Many components of the leak detector are static sensitive.
Wear a grounding device when performing any maintenance
on the leak detector, especially when performing maintenance
of static sensitive parts, such as circuit boards and the
spectrometer.
CAUTION This equipment has been tested and found to comply with the
limits for Class A digital device, pursuant to Part 15 of FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference when it is operated in a
commercial environment.
This equipment generates, uses, and can radiate RF energy,
which if not installed and used in accordance with the
instructional manual, can cause harmful interference to
radio communications.
When this equipment is operated in a commercial
environment, operation is subject to the following two
conditions:
❑This equipment must not cause harmful interference.
❑This equipment must accept any interference received,
including interference (RF and ESD) that may cause
undesired operation.
The equipment may need to be reset after RF and/or ESD events
by cycling the Power Switch/Circuit Breaker on the back panel
of the unit.
Operation of this equipment in a residential area is also likely to
cause harmful radio communications interference, in which
case, the users will be required to correct the interference at
their expense.

VS Series Helium Mass Spectrometer Leak Detectors
DRAFT 2/13/14
xix
WARNING This equipment is designed to meet current EEC regulations:
LVD (Low Voltage Directive, 73/23/EEC:1993) and EMC
(Electromagnetic Compatibility Directive, 89/336/EEC:1993) for
Material Group III, Pollution Degree 2 environment for
Industrial, Scientific, Measuring and Process Control Electrical
Equipment and R&TTE (Radio and Telecommunications
Terminal Equipment Directive, 199915/EC:1999)
❑Any modifications on the part of the user are liable to cause
non-compliance with regulations or affect the EMC
performance and the safety of the product. Agilent cannot
be held responsible for consequences resulting from such
intervention.
❑Before powering the unit the first time, verify that the unit is
configured to operate for the local mains supply voltage.
❑The equipment can be damaged by:
❑Incorrect mains AC supply voltages
❑Radio Frequency (RF) and Electrostatic Discharge (ESD)
energy inputs that exceed the maximum ratings
❑Operating in very high temperatures or without adequate
ventilation
❑Immersion in liquids
❑Physical abuse
❑All electrical connections must be performed by a qualified
electrician and must comply with national and local codes.
❑Opening the enclosure may expose hazardous voltages.
Always disconnect the power cord and interface cables
before opening the enclosure. Do not touch the power
inlet’s contacts for at least 10 seconds after disconnecting
the power cord.
❑Electrical installation must include the appropriate branch
circuit (20 A maximum), with a long time delay and a
reliable earth ground.
❑Use only the power cord that was provided with your leak
detector. The use of extension cords is not recommended
and could result in damage to the equipment and loss of
warranty.
❑To avoid electric shock, connect the product power cord to
a grounded power receptacle. A power cord with a
grounding conductor is required.

VS Series Helium Mass Spectrometer Leak Detectors
xx
DRAFT 2/13/14
Spectrometer
WARNING Store the Ion Source/Preamplifier sub-assembly in a cool, dry
area in a tightly sealed, ESD protected container. Wear lint-free
gloves when handling the spectrometer. Wash hands
thoroughly after handling the spectrometer filaments and
especially before smoking or eating.
CAUTION The spectrometer operates at a very high vacuum produced by
the high vacuum pump. Service of the spectrometer requires
that this vacuum be vented to the atmosphere.
CAUTION Do not use grease or any other substance on O-rings or metal
seals that will come in contact with the spectrometer.
CAUTION If the spectrometer magnet comes in contact with a magnetic
surface, the magnet can become degraded causing the
spectrometer to lose sensitivity.
Pumps
WARNING To avoid injury, use proper lifting techniques when moving
pumps. Two people may be required to move pumps safely.
WARNING The vacuum pumps are also compressors; incorrect operation
may be dangerous. Study the Mechanical Pump Operation
Manual enclosed with your pump before starting pumps.
The pumps are designed to prevent any thermal risk for user
safety. However, specific operating conditions may generate
temperatures >70 C.
Hot oil burns the skin. Service of the pumps in this area must be
performed by authorized personnel only. Stand back from a
mechanical pump before starting it.
