Agilent Technologies Labware MiniHub G5584A User manual


G5584A
Labware MiniHub
User Guide
For Research Use Only. Not for use in
diagnostic procedures.
Original Instructions

Notices
© Agilent Technologies, Inc. 2017
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or
translation into a foreign language) without
prior agreement and written consent from
Agilent Technologies, Inc. as governed by
United States and international copyright
laws.
User Guide Part Number
G5584-90000
Edition
Revision A, July 2017
Contact Information
Agilent Technologies Inc.
Automation Solutions
5301 Stevens Creek Blvd.
Santa Clara, CA 95051
USA
Technical Support: 1.800.979.4811 (US) or
+1.408.345.8011 (rest of world)
[email protected]om
Customer Service: 1.800.227.9770 (US and
Canada)
By country: http://www.agilent.com/en-
us/contact-us/page
Documentation feedback:
[email protected]
Web:
http://www.agilent.com/en-us/products/
automation-solutions
Acknowledgments
Microsoft and Windows are registered
trademarks of the Microsoft Corporation in
the United States and other countries.
Adobe and Acrobat are trademarks of
Adobe Systems Incorporated.
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or perfor-
mance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of
a U.S. Government prime contract or sub-
contract, Software is delivered and
licensed as “Commercial computer soft-
ware” as defined in DFAR 252.227-7014
(June 1995), or as a “commercial item” as
defined in FAR 2.101(a) or as “Restricted
computer software” as defined in FAR
52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use,
duplication or disclosure of Software is
subject to Agilent Technologies’ standard
commercial license terms, and non-DOD
Departments and Agencies of the U.S. Gov-
ernment will receive no greater than
Restricted Rights as defined in FAR 52.227-
19(c)(1-2) (June 1987). U.S. Government
users will receive no greater than Limited
Rights as defined in FAR 52.227-14
(June1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or the
like that, if not correctly performed or
adhered to, could result in personal
injury or death. Do not proceed
beyond a WARNING notice until the
indicated conditions are fully
understood and met.
A CAUTION notice denotes a hazard. It
calls attention to an operating procedure,
practice, or the like that, if not correctly
performed or adhered to, could result in
damage to the product or loss of important
data. Do not proceed beyond a CAUTION
notice until the indicated conditions are
fully understood and met.

iiiG5584A Labware MiniHub User Guide
Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
About this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Accessing Agilent Automation Solutions user guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
About the Labware MiniHub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Hardware overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Software overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Quick start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2. Setting up the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setup workflow for the VWorks software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Turning on and off the Labware MiniHub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Creating a VWorks device file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Adding and deleting a Labware MiniHub in the device file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting Labware MiniHub properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3. Configuring profiles and setting teachpoints. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Configuration workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Opening Labware MiniHub Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Creating Labware MiniHub profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Editing and managing profiles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Initializing the Labware MiniHub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Setting the home position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setting robot teachpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4. Using device diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
About Labware MiniHub Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Checking the current position of the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Enabling and disabling the motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Changing the rotation speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Rotating the MiniHub to a specific position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Checking the fault indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Viewing the log area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
5. Maintenance and troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Cleaning the shelves. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Troubleshooting hardware problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Troubleshooting error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Reporting problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
A. Quick reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Contents
iv G5584A Labware MiniHub User Guide
Profiles tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Controls tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
B. Labware MiniHub ActiveX control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
About the Labware MiniHub ActiveX control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Methods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
C. Orderable spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Spare parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

v
G5584A Labware MiniHub
User Guide
Agilent Technologies
Preface
This preface contains the following topics:
•“About this guide” on page vi
•“Accessing Agilent Automation Solutions user guides” on
page viii

Preface
About this guide
vi G5584A Labware MiniHub User Guide
About this guide
Who should read this guide
This user guide is for people with the following job roles:
Installers, integrations, lab managers, and administrators are users who must
have technical expertise. In addition, lab managers and administrators are
individuals or groups responsible for the use and maintenance of the Labware
MiniHub and for ensuring that operators are adequately trained.
What this guide covers
This guide describes the G5584A Labware MiniHub, the operation of the
hardware components, and the use of the diagnostics software and ActiveX
control.
Software version
The G5584A Labware MiniHub requires the following software versions at a
minimum:
• Microsoft Windows 10 64- bit operating system
• One of the following:
– VWorks Automation Control software v13.1.0 and MySQL 5.7
– Labware MiniHub ActiveX control v13.1.0
This guide documents Labware MiniHub Diagnostics v13.1.0, which can be
invoked from either the VWorks software or Labware MiniHub ActiveX control.
Note: The Labware MiniHub ActiveX control is included in the VWorks ActiveX
Controls installer.
Job role Responsibilities
Installer Unpacks, installs, and tests the device before it is used.
Integrator Configures hardware and writes software.
Lab manager,
administrator,
or technician
• Manages the automation system that contains the
device
• Develops the applications that are run on the system
• Develops training materials and standard operating
procedures for operators
Operator Performs the daily production work on the device and
solves routine problems.

vii
Preface
About this guide
G5584A Labware MiniHub User Guide
Related guides
The G5584A Labware MiniHub User Guide should be used in conjunction with
the following documents, if applicable:
•G5584A Labware MiniHub Safety and Installation Guide. Presents the
safety precautions, emergency stop procedure, site preparation information,
and installation instructions.
•Automation Solutions Products General Safety Guide. Describes the
general safety precautions, intended product use, and the list of safety
labels for the Automation Solutions products.
•Applicable robot user guide. Explains how to set up the robot and set
teachpoints at integrated devices. For example, see the BenchCel
Microplate Handler User Guide for details on how to set the BenchCel
teachpoints at the Labware MiniHub.
•Applicable automation control software user guide. Explains how to
create and run protocols. If you are using the VWorks software, see the
VWorks Automation Control Setup Guide and VWorks Automation Control
User Guide.
Related information
For information about... See...
Accessing related user guides “Accessing Agilent Automation
Solutions user guides” on page viii
Reporting problems “Reporting problems” on page 60

Preface
Accessing Agilent Automation Solutions user guides
viii G5584A Labware MiniHub User Guide
Accessing Agilent Automation Solutions user guides
About this topic
This topic describes the different formats of user information and explains how
to access it for the Agilent Automation Solutions products.
Where to find user information
The Automation Solutions user information is available in the following
locations:
•Knowledge base. The help system that contains information about all the
Automation Solutions products is available from the Help menu within the
VWorks software.
•PDF files. The PDF files of the user guides are installed with the VWorks
software and are on the software CD that is supplied with the product. A
PDF viewer is required to open a user guide in PDF format. You can
download a free PDF viewer from the Internet. For information about using
PDF documents, see the user documentation for the PDF viewer.
•Agilent website. You can search the online knowledge base or download the
latest version of any PDF file from the Agilent website at www.agilent.com/
chem/askb.
Accessing safety information
Safety information for the Agilent Automation Solutions devices appears in the
Automation Solutions Products General Safety Guide and in the
corresponding device safety guide or user guide.
You can also search the knowledge base or the PDF files for safety information.
Using the knowledge base
Knowledge base topics are displayed using web browser software such as
Microsoft Internet Explorer and Mozilla Firefox.
Note: If you want to use Internet Explorer to display the topics, you might
have to allow local files to run active content (scripts and ActiveX controls). To
do this, in Internet Explorer, open the Internet Options dialog box. Click the
Advanced tab, locate the Security section, and select Allow active content to run in
files on my computer.
To open the knowledge base, do one of the following:
• From within VWorks software, select Help > Knowledge Base or press F1.
• From the Windows 10 desktop, select Start > All apps > Agilent Technologies >
VWorks Knowledge Base.

ix
Preface
Accessing Agilent Automation Solutions user guides
G5584A Labware MiniHub User Guide
Opening the help topic for an area in the VWorks window
To access the context-sensitive help feature:
1In the main window of the VWorks software, click the help button .
The pointer changes to . Notice that the different icons or areas are
highlighted as you move the pointer over them.
2Click an icon or area of interest. The relevant topic or document opens.

Preface
Accessing Agilent Automation Solutions user guides
xG5584A Labware MiniHub User Guide
Features in the Knowledge Base window
Item Feature
1Navigation area. Consists of four tabs:
•Contents. Lists all the books and the table of contents of the
books.
•Index. Displays the index entries of all of the books.
•Search. Allows you to search the Knowledge Base (all products)
using keywords. You can narrow the search by product.
•Favorites. Contains bookmarks you have created.
2Navigation buttons. Enable you to navigate through the next or
previous topics listed in the Contents tab.
3Content area. Displays the selected online help topic.
4Toolbar buttons. Enable you to print the topic or send documentation
feedback by email.

1
G5584A Labware MiniHub
User Guide

1
Introduction
This chapter contains the following topics:
•“About the Labware MiniHub” on page 2
•“Safety information” on page 4
•“Hardware overview” on page 4
•“Software overview” on page 8
•“Quick start” on page 11

1 Introduction
About the Labware MiniHub
2G5584A Labware MiniHub User Guide
About the Labware MiniHub
Description
The Labware MiniHub is a rotating random- access labware storage device. Up
to four labware can be placed on each shelf. Spacing blocks, also called
spacers, can be added or removed to adjust the distance between shelves,
accommodating different labware types (microplates, tip boxes, or tube racks).
The following options of the G5584A Labware MiniHub are available:
Option Description
BenchCel Configuration
(option 010)
This option permits the following basic
configurations:
•10 shelves, with single spacers between
shelves, accommodate a maximum of
40 microplates
•5 shelves, with two spacers between
shelves, accommodate a maximum of
20 deepwell microplates or tube racks
•3 shelves, with three spacers between
shelves, accommodate a maximum of 12 tip
boxes
Other configurations can be created using
different combinations of shelves and spacers.
The option is typically installed on risers, as
the figure shows.
Integration Configuration
(option 020)
BenchBot Robot
The Integration Configuration is for
workstations or systems that have the
BenchBot Robot or Direct Drive Robot (DDR).
For the BenchBot, this option enables the
following basic configurations:
•13 shelves, with single spacers between
shelves, accommodate a maximum of
52 microplates
•7 shelves, with two spacers between
shelves, accommodate a maximum of
28 deepwell microplates or tube racks
•5 shelves, with three spacers between
shelves, accommodate a maximum of 20 tip
boxes
Other configurations can be created using
different combinations of shelves and spacers.

3
1 Introduction
About the Labware MiniHub
G5584A Labware MiniHub User Guide
Related information
Integration Configuration
(option 020)
Direct Drive Robot
For the DDR, this option enables the following
basic configurations:
•16 shelves, with single spacers between
shelves, accommodate a maximum of
64 microplates
•9 shelves, with two spacers between
shelves, accommodate a maximum of
36 deepwell microplates or tube racks
•6 shelves, with three spacers between
shelves, accommodate a maximum of 24 tip
boxes
Other configurations can be created using
different combinations of shelves and spacers.
Option Description
For information about... See...
Labware MiniHub safety G5584A Labware MiniHub Safety and
Installation Guide
Preparing the lab for the Labware
MiniHub installation
G5584A Labware MiniHub Safety and
Installation Guide
Installing the Labware MiniHub G5584A Labware MiniHub Safety and
Installation Guide
Hardware components “Hardware overview” on page 4
Software overview “Software overview” on page 8

1 Introduction
Safety information
4G5584A Labware MiniHub User Guide
Safety information
Before you operate the Labware MiniHub, ensure you have read the following
guides and are trained in the safe operation of the device.
•Automation Solutions Products General Safety Guide
•G5584A Labware MiniHub Safety and Installation Guide
Related information
Hardware overview
About this topic
This topic describes the following Labware MiniHub features:
•Main components
•Power supply
•Status lights
Main components
The following figure and table describe the main components of the Labware
MiniHub.
For information about... See...
Safety precautions G5584A Labware MiniHub Safety and
Installation Guide
Labware MiniHub description “About the Labware MiniHub” on
page 2
Hardware components “Hardware overview” on page 4
Software overview “Software overview” on page 8

5
1 Introduction
Hardware overview
G5584A Labware MiniHub User Guide
Figure Main components: Integration Configuration (left) and BenchCel Configuration (right)
Labware MiniHub
Labware MiniHub
1
2
4
3
5
6
4
Item Name Description
1Base White structure at the bottom of the MiniHub that
attaches the MiniHub to the target surface. The base
contains the electronics and hosts the connection panel
and the indicator lights.
The base for the MiniHub BenchCel Configuration
attaches to an integration- plate assembly (ikit) for
integration with the BenchCel Microplate Handler.
2Shelves Flat area on which you can place labware. Locating
pins at the edges of the shelves hold the labware
securely in place.
3Spacers Metal spacing blocks that you can add or remove at the
center of the MiniHub to adjust the distance between
shelves.
Two types of spacers are available:
•25.1- mm spacers. Stacked between shelves to
accommodate different labware heights.
•8.4- mm spacers. Stacked above the top- most shelf
to fill the space between the top- most 25.1- mm
spacer and the cassette cap. These spacers ensure
a tight assembly and are only necessary when a
subset of the shelves are used.
4Cassettes Columns of shelves. The MiniHub consists of four
cassettes, each identified by the number on the
cassette cap.
5Cassette cap Metal label with numerical identification of each
cassette. The numbers are used in Labware MiniHub
Diagnostics and in VWorks software.

1 Introduction
Hardware overview
6G5584A Labware MiniHub User Guide
Power supply
The power supply is the component that supplies electrical power to the
Labware MiniHub.
Figure Power supply
6Black knob Component at the top of the MiniHub that locks the
spacers and shelves in place.
Item Name Description
1
2
3
Item Name Description
1Labware MiniHub
cable connector
Connects the Labware MiniHub to the power
supply unit.
2Power inlet Connects the power supply unit to the power
source. Use only the supplied power cord.
3On/off switch Turns on (I) and off (o)the power supply.

7
1 Introduction
Hardware overview
G5584A Labware MiniHub User Guide
Status lights
On the base of the Labware MiniHub are two status lights, as the following
figure shows.
Figure Status lights on Labware MiniHub base (front view)
Related information
Power Motor enabled
Motor disabled
Status light Description
Power Indicates whether the power is on or off:
•Green light is illuminated when the power is on.
•Green light is off when the power is off.
Motor status Indicates whether the motor is enabled or disabled.
•Red light indicates the motor is disabled.
When you turn on the Labware MiniHub, the red light
turns on.
•Green light indicates that the motor is enabled.
When you initialize the Labware MiniHub, the green light
turns on.
For information about... See...
Labware MiniHub description “About the Labware MiniHub” on
page 2
Labware MiniHub safety “Safety information” on page 4
Software overview “Software overview” on page 8

1 Introduction
Software overview
8G5584A Labware MiniHub User Guide
Software overview
About this topic
This topic describes the software components you use to operate the Labware
MiniHub:
•Labware MiniHub Diagnostics
•Laboratory automation software
Labware MiniHub Diagnostics
The following figure shows the Labware MiniHub Diagnostics dialog box.
The Labware MiniHub Diagnostics software allows you to:
•Create and manage profiles. A profile allows you to set up communication
between the Labware MiniHub and the controlling computer, configure the
Labware MiniHub (tell the software the number of shelves you are using),
and set the rotation speed. For instructions, see “Creating Labware
MiniHub profiles” on page 26.
•Set the home position. The home position is the starting position of the
Labware MiniHub relative to the robot in the laboratory automation system
or BenchCel Configuration. For instructions, see “Setting the home
position” on page 32.

9
1 Introduction
Software overview
G5584A Labware MiniHub User Guide
•Diagnose problems. For information on diagnosing and troubleshooting
problems, see “Using device diagnostics” on page 39 and “Maintenance and
troubleshooting” on page 55.
Access to Labware MiniHub Diagnostics depends on the automation software
you are using.
Laboratory automation software
You can use either the VWorks software or third- party automation software to
operate the Labware MiniHub in protocol runs. The Labware MiniHub ActiveX
control permits third- party automation software to interface with the Labware
MiniHub.
VWorks software
The following figure shows the VWorks window.
The VWorks software allows you to:
•Set up the Labware MiniHub. During setup, you create a device file for the
Labware MiniHub. For setup information, see “Setting up the device” on
page 13.
•Set up user accounts and privileges. You can set up different user
accounts to enforce access policies. For instructions, see the VWorks
Automation Control Setup Guide.
•Define labware. Labware definitions describe the labware you will use
during protocol runs. For instructions, see the VWorks Automation Control
Setup Guide.
•Create protocols. Protocols determine the sequence of tasks you want to
automate in a run. For example, you can use a protocol to unload
60 microplates from the Labware MiniHub, apply barcode labels to the
microplates, and then reload the microplates to the Labware MiniHub. For
protocol- writing instructions, see the VWorks Automation Control User
Guide.

1 Introduction
Software overview
10 G5584A Labware MiniHub User Guide
•Run, pause, monitor, and stop protocols. You can start, pause, monitor,
and stop a protocol run from the controlling computer. For instructions,
see the VWorks Automation Control User Guide.
For a full description and instructions on how to use the VWorks software, see
the VWorks Automation Control User Guide.
Labware MiniHub ActiveX control
The Labware MiniHub ActiveX control allows automation control software
other than the VWorks software to interface with the device. For more
information, see “Labware MiniHub ActiveX control” on page 67.
Related information
For information about... See...
Labware MiniHub description “About the Labware MiniHub” on
page 2
Labware MiniHub safety “Safety information” on page 4
Hardware components “Hardware overview” on page 4
Labware MiniHub ActiveX control “Labware MiniHub ActiveX control” on
page 67
