Agilent Technologies BenchCel Microplate Handler User manual

Original Instructions
This guide contains the following topics:
•“About this guide” on page 2
•“Safety guidelines” on page 3
•“Emergency stops” on page 4
•“Hardware components and axes of motion” on page 7
•“Labware considerations” on page 11
•“Starting up and shutting down” on page 12
•“Handling labware racks safely” on page 14
•“Filling and emptying the labware racks” on page 14
•“Installing and uninstalling labware racks” on page 17
•“Using BenchCel Diagnostics” on page 20
•“Cleaning up after use” on page 29
G5580A BenchCel Microplate Handler
Quick Guide

About this guide
2G5580A BenchCel Microplate Handler Quick Guide
About this guide
This guide summarizes the operator instructions in the BenchCel Microplate Handler
User Guide.
This guide assumes the following:
•The BenchCel Microplate Handler is installed correctly. For details, see the
BenchCel Microplate Handler User Guide.
•The device profile for the specific BenchCel Microplate Handler configuration is
already created and the teachpoints are already set. For setup instructions, see the
BenchCel Microplate Handler User Guide.
•You are familiar with the VWorks Automation Control software. See the VWorks
Automation Control Quick Start. For detailed instructions, see the VWorks
Automation Control User Guide.
Where to find the user documentation
To access the user guides for Agilent Automation Solutions products, do one of the
following:
•From within VWorks software, select Help > Knowledge Base or press F1.
•From the Windows desktop, select Start > Agilent Technologies >
VWorks Knowledge Base.
•Go to the online VWorks Knowledge Base at www.agilent.com/chem/askb.
Contacting Agilent Technologies
Web: https://www.agilent.com
Contact page: https://www.agilent.com/en/contact-us/page
Documentation feedback: [email protected]

3
Safety guidelines
G5580A BenchCel Microplate Handler Quick Guide
Safety guidelines
WARNING
Using controls, making adjustments, or performing procedures other than those
specified in the user documentation can expose you to moving-parts hazards and
hazardous voltage. Before using the BenchCel Microplate Handler, make sure you
are aware of the potential hazards and understand how to avoid being exposed to
them.
Ensure that you are trained in the safe operation of the device and that you have read
the Agilent Automation Solutions Products General Safety Guide and the safety section
of the BenchCel Microplate Handler User Guide.
Figure Safety label location on BenchCel Microplate Handler (front and side view)
For a description of the moving parts, see “Hardware components and axes of motion”
on page 7.
For the emergency-stop procedure, see “Emergency stops” on page 4.
WARNING
If you touch any of the moving parts or attempt to move labware while the BenchCel
Microplate Handler is in operation, the device could pinch, pierce, or bruise you. Keep
your fingers, hair, clothing, and jewelry away from the device while it is in motion.

Emergency stops
4G5580A BenchCel Microplate Handler Quick Guide
Emergency stops
The BenchCel Microplate Handler is equipped with an interlock circuit and emergency-
stop pendant. When the BenchCel Microplate Handler is integrated with other devices
in a third-party system, Agilent Technologies recommends that you install a main
emergency-stop button to safely stop the robot and all devices simultaneously.
CAUTION
You might not be able to resume a protocol after an emergency stop. Do not use an
emergency stop to pause a run. To pause and continue a run, use the appropriate
commands in the automation software.
Stopping in an emergency
WARNING
After pressing the emergency-stop button, the robot arm might have momentum and
continue to move until it comes to the end of its travel in the x-axis, z-axis, or theta-
axis or until it bumps into an obstacle. Stay clear of the robot until it stops moving.
To perform an emergency stop:
Press the red button on the pendant. The safety interlock circuit is interrupted, disabling
the robot motors. The BenchCel Microplate Handler operation stops.
Recovering from an emergency stop
After you press the button on the emergency-stop pendant, the robot stops. One of the
following occurs:
•If you stopped a protocol run, a dialog box opens in the VWorks software.
•If you stopped the robot while diagnosing problems in BenchCel Diagnostics, a
motor-disable message opens.
Use the following procedure to recover in either case.

5
Emergency stops
G5580A BenchCel Microplate Handler Quick Guide
To recover the BenchCel device after an emergency stop:
1If the robot dropped labware before or during the emergency stop, remove the
labware that was dropped. Also remove labware at teachpoints or other locations.
2If the BenchCel robot attempted to place labware at a location that was not free, a
collision might have occurred resulting in misalignment of the robot gripper. Check
the robot gripper alignment:
aMove the robot arms so that they are perpendicular to the x-axis.
bMake sure the bottom of the robot gripper pads are perpendicular to the robot
arms. If they are not, contact Agilent Technical Support.
Figure Gripper alignment: (A) Correct, (B) Incorrect
3At the emergency-stop pendant, turn the button clockwise to restore power to the
motors.
4If you stopped a protocol run in an emergency, select one of the following in the
VWorks message dialog box:
AB
Selection Description
Diagnostics Opens the BenchCel Diagnostics dialog box. See step 5.
Note: This selection is available only when you are in the
middle of a protocol run and not while you are in
BenchCel Diagnostics.
Retry Attempts to restart the current command or task in the
run.
Ignore and continue Ignores the current command or task and continues to
the next command or task in the protocol sequence.
Abort Aborts the current command or task in the run. Select
Abort if you have determined that the protocol run is not
recoverable.

Emergency stops
6G5580A BenchCel Microplate Handler Quick Guide
For a full description of the selections, see the VWorks Automation Control User
Guide.
5Optional. In BenchCel Diagnostics, use the available commands to manually move
the robot or other components, including:
•Release the microplate that the robot is currently holding.
•Upstack the microplate that the robot is currently holding.
•Replace the lid on the microplate.
•Home the robot.
•Verify teachpoints.
If a physical crash occurred, always start BenchCel Diagnostics to home the robot and
verify teachpoints.

7
Hardware components and axes of motion
G5580A BenchCel Microplate Handler Quick Guide
Hardware components and axes of motion
Front view
The following figure and table describe the primary hardware components and axes of
motion.
Figure BenchCel Microplate Handler components (front view)
1
2
3
4
5
6
7
8
9
Item Feature Description
1Labware
rack (with
labware)
The accessory that stores labware to be processed in a run.
2Stacker
head
The structure at which:
•A labware rack is loaded. Two sensors inside of each stacker head detect the
presence of the racks.
•A microplate is checked for type and orientation using a plate-presence sensor and
four plate-orientation sensors.
•A microplate is lowered into the stacker grippers to begin a run.

Hardware components and axes of motion
8G5580A BenchCel Microplate Handler Quick Guide
3Air pressure
regulator
The knob that adjusts the air pressure inside the device. Compressed air is used to
move the components inside the stacker heads. Each regulator controls the air
pressure to the two adjacent stacker heads. For details, see the BenchCel Microplate
Handler User Guide.
4Safety
shield
The clear panel that is installed on the front of the BenchCel device to prevent access
while it is in operation.
5Pendant The component that is part of the safety interlock circuit, which must be closed for the
BenchCel device to operate. Pressing the raised button on the pendant interrupts the
interlock circuit and stops the robot motors. Use this method of stopping the robot for
emergencies only.
6Rack
release
button
The button that unlocks the rack for removal. The rack-release button (1) at the top of
each stacker head displays different colors to indicate the state of the stacker head.
•Green. The labware rack is installed correctly on the BenchCel device and the
microplates are unloaded. The stack of microplates are ready for processing or you
can unlock and remove the labware rack.
•Flashing green. The labware rack is unlocked and can be removed.
•Blue. The stack of microplates is loaded. You cannot unlock and remove the
labware rack.
•Red. The clamps are open without a rack installed. Do not install a rack until the
clamps are closed.
7Robot head The component that moves (1) horizontally along the x-axis and (2) vertically along the
z-axis.
Item Feature Description

9
Hardware components and axes of motion
G5580A BenchCel Microplate Handler Quick Guide
8Robot arms The two parallel structures that are attached to and rotate about the robot head along
the theta-axis.
9Robot
grippers
The structures inside the robot arms that close and open to hold and release a
microplate. Using the provided software, you can adjust the distance between the
grippers (1) to hold a microplate loosely or tightly.
Item Feature Description

Hardware components and axes of motion
10 G5580A BenchCel Microplate Handler Quick Guide
Back view
Figure BenchCel connection panel (Back view)
Item Part Description
1Air-input fitting Connects the air tubing to the BenchCel device.
Compressed air is used to actuate components inside the
stacker head.
2Power switch Turns on or off the power to the BenchCel device.
3AC power entry Connects the power cord to the BenchCel device.
4Ethernet port Connects the Ethernet cable from the controlling
computer to the BenchCel device to allow communication
between the computer and the device. Use this port as an
alternative to the serial connection.
5Serial port Connects the serial cable from the controlling computer to
the BenchCel device to allow communication between the
computer and the device. Use this port as an alternative to
the Ethernet connection.
6Pendant port Connects the pendant to the safety interlock circuit.
1
2
3
4
5
6
