Agri-Fab 45-0424 User manual

10
rePaIr ParTs For 25 Gallon sPraYer moDel 45-0424
28
25
65
40
43
46
51
27
23
42
49
56
C
40
24
51
28
45
44
44 52
39
19
20
31
21
37
30
36
33
35
34 51
63
21
21
32
21
30
37 36
21
33
35
34
63
21
57
58
59
B
C
38
40
29
1
A
7
53 655
54
18
17
2
14
3
8
15
4
9
10
55
B
16
61
5
13
7
50
48 47
60
50 48
15
22
55 721
B
63
26
11
26
41
A
64
62
62

11
11
rePaIr ParTs lIsT For 25 Gallon sPraYer moDel 45-0424
the fastest way to purchase parts
www.speedepart.com
reF
no.
ParT
no.
QTY. DesCrIPTIon
1 46283 1 Tank (25 Gal.)
2 45015 1 Pump and Motor
3 46278 1 Hose, 1/2" ID (24" Lg.)
4 45021 1 Hose, 1/2" ID (20" Lg.)
5 45024 1 Strainer, Cap Type 1"
6 45031 1 Adapter, 1/2" NPT x Hose
7 45032 3 Nut, Swivel 3/4" Garden Hose
8 45033 1 Hose Barb, 1/2"
9 45069 4 Screw, Ph. Pan Hd. 10-24 x 1"
10 43910 4 Flat Washer, #10 SAE
11 46980 4 Nut, Hex 5/16-18 (SEMS)
12 45085 2 Terminal, .25 Male Tab (not shown)
13 46276 1 Adapter, 3/4" GH x 1/2" Barb
14 46277 1 Elbow, 3/8 NPT x 1/2" Barb
15 45025 2 Clamp, 1/2" Hose (For Black Hose)
45026 2 Clamp, 3/8" Hose (For Clear Hose)
16 49754 1 Switch and Wire Assembly
17 45049 1 Nipple, (Nylon) 1/2" x 3/8" Red.
18 45050 1 Tee, 1/2" x 1/2" x 1/2" (1/4" Port)
19 47406 1 Spray Gun
20 49761 1 Hose, 1/4" ID (15' Lg)
21 45026 6 Clamp, 3/8" Hose (For Black Hose)
47405 6 Clamp, 1/4" Hose (For Clear Hose)
22 45034 1 Hose Barb, 3/8"
23 40166 1 Frame Tube (RH)
24 40167 1 Frame Tube (LH)
25 24192 2 Hitch Bracket
26 25896 2 Axle Clamp
27 25898 1 Axle
28 48511 2 Wheel
29 46700 1 Lid
30 24122 2 Boom Bar
31 24585 1 Bracket, Boom Mount
32 47394 1 Tee, Plastic 3/8" Hose
reF
no.
ParT
no.
QTY. DesCrIPTIon
33 45028 2 Nozzle, SS Floodjet
34 45029 2 Strainer, Screen Type
35 45037 2 Nut, Screen Body
36 47396 2 Elbow, Plastic 11/16" Thd.
37 726-0178 2 Nylon Tie
38 44180 2 Bolt, Hex 5/16-18 x 2"
39 46782 2 Bolt, Hex 5/16-18 x 3"
40 47810 6 Nut, Nylock 5/16-18
41 44947 4 Bolt, Curved Head 5/16-18 x 1-5/8"
42 43086 4 Lock Washer, 5/16"
43 43343 1 Pin, Hair Cotter #4 (1/8")
44 43009 4 Washer, 3/4"
45 43093 2 Cotter Pin, 1/8" x 1-1/2"
46 47623 1 Hitch Pin
47 45180 1 Hose Clip, Small
48 736-0722 2 Lock Washer, #10
49 44695 4 Washer, Bowed
50 46677 2 Screw, Phillips Hd. #10-24 x 3/8"
51 43081 6 Washer, 5/16" Std. Wrt.
52 25897 1 Axle Support Tube
53 45017 1 Hose "Y" W / Valves 3/4"
54 45071 1 Gauge, Pressure 2" 100 PSI
55 45072 3 Gasket, 3/4" Garden Hose
56 43085 4 Bolt, Hex 5/16-18 x 1-1/2"
57 712-0421 2 Knob
58 43682 2 Bolt, Carriage 5/16-18 x 1-1/4"
59 44732 2 Washer, Tooth Lock 5/16"
60 47397 1 Hose Clip (Large)
61 47390 1 Adapter, 1/2" NPT x 1/4" Barb
62 49779 2 Clamp, Coiled Hose
63 47392 3 Hose, 3/8" ID (20" Lg.)
64 48719 1 Drain Cap
65 43224 2 Bolt, Hex 5/16-18 x 2-1/4"
40165 1 Owners Manual
