Agri-Fab Tow Sprayer 45-0292 Use and care manual

10
REPAIR PARTS FOR 15 GALLON SPRAYER MODEL 45-0292
31
44
45
66
66
48
48
49
52
34
34
51
50
50
32
33
29
30
31
48
46
32
46
48
48
55
62
47
62
55
48
A
25
70
26
A
71
7
28
59 661
60
24
23 2
20
3
61
8
7
21
4
9
10
37
63
27
43
36
42
39
41
40 57
71
27
27
38
27
36
43
42
27
39
41
40
71
27
64
65
67
61
B
B
C
C
22
5
19
7
72
61
73
74
75
76
68
56 54
56 54 53
35
21
18
11
12
13
14
15
1
58
69

11
REPAIR PARTS LIST FOR 15 GALLON SPRAYER MODEL 45-0292
REF. PART QTY. ESCRIPTION
NO. NO.
40 45029 2 Strainer, Screen Type
41 45037 2 Nut, Screen Body
42 47396 2 Elbow, Plastic 11/16" Thd.
43 726-0178 2 Nylon Tie
44 43224 2 Bolt, Hex 5/16-18 x 2-1/4"
45 46782 2 Bolt, Hex 5/16-18 x 3"
46 43083 6 Nut, Hex 5/16-18 Thread
47 44947 4 Bolt, Curved Head 5/16-18 x 1-5/8"
48 43086 16 Lock Washer, 5/16"
49 43343 1 Pin, Hair Cotter #4 (1/8")
50 R19171616 4 Washer, 17/32" x 1"
51 44663 2 Hub Cap (1/2" Push Nut)
52 47623 1 Hitch Pin
53 45180 1 Hose Clip, Small
54 736-0722 2 Lock Washer, #10
55 44695 4 Washer, Bowed
56 45040 2 Screw, Phillips Hd. #10-24 x 1/2"
57 43081 2 Washer, 5/16" Std. Wrt.
58 46578 2 Spacer
59 45017 1 Hose "Y" W / Valves 3/4"
60 45071 1 Gauge, Pressure 2" 100 PSI
61 45072 4 Gasket, 3/4" Garden Hose
62 43085 4 Bolt, Hex 5/16-18 x 1-1/2"
63 44215 2 Bolt, Carriage 5/16-18 x 1-3/4"
64 712-0421 2 Knob
65 43682 2 Bolt, Carriage 5/16-18 x 1-1/4"
66 43064 4 Nut, Hex Lock 5/16-18 Thd.
67 44732 2 Washer, Tooth Lock 5/16"
68 47397 1 Hose Clip (Large)
69 47390 1 Adapter, 1/2" NPT x 1/4" Barb
70 47405 1 Clamp, 1/4" Hose
71 47392 3 Hose, 3/8" I (20" Lg.)
72 47399 1 rain Body
73 47398 1 Washer, Nylon
74 47402 1 Nut, Nylon 11/16" Thd.
75 47400 1 O-Ring, 5/8" O
76 47403 1 Cap, Nylon 11/16" Thd.
47628 1 Owners Manual
REF. PART QTY. ESCRIPTION
NO. NO.
1 47752 1 Tank (15 Gal.)
2 45015 1 Pump and Motor
3 46278 1 Hose, 1/2" I (24" Lg.)
4 45021 1 Hose, 1/2" I (20" Lg)
5 45024 1 Strainer, Cap Type 1"
6 45031 1 Adapter, 1/2" NPT x Hose
7 45032 3 Nut, Swivel 3/4" Garden Hose
8 45033 1 Hose Barb, 1/2"
9 45069 4 Screw, Ph. Pan Hd. 10-24 x 1" Lg.
10 43910 4 Washer, Flat #10 SAE
11 45084 1 Switch, On - Off
12 45082 1 Boot, Rubber Switch
13 45080 1 Plate, On - Off Switch
14 45048 1 Nut, Hex 15/32-32 Thd.
15 45087 1 Bushing, Strain Relief
16 45085 1 Terminal, .25 Male Tab (not shown)
17 45086 1 Terminal, .25 Female Tab (not shown)
18 23889 1 Bracket, Switch Mounting
19 46276 1 Adapter, 3/4" GH x 1/2" Barb
20 46277 1 Elbow, 3/8 NPT x 1/2" Barb
21 45025 2 Clamp, 1/2" Hose
22 45018 1 Connector with Wire
23 45049 1 Nipple, (Nylon) 1/2" x 3/8" Red.
24 45050 1 Tee, 1/2" x 1/2" x 1/2" (1/4" Port)
25 47406 1 Spray Gun
26 47393 1 Hose, 1/4" I (12' 6" Lg)
27 45026 6 Clamp, 3/8" Hose
28 45034 1 Hose Barb, 3/8"
29 47624 1 Hitch Tube, R.H.
30 47625 1 Hitch Tube, L.H.
31 23014 2 Hitch Bracket
32 24586 2 Clamp, 1/2" Axle
33 24584 1 Axle, 1/2"
34 47052 2 Wheel
35 46700 1 Lid
36 24122 2 Boom Bar
37 24585 1 Bracket, Boom Mount
38 47394 1 Tee, Plastic 3/8" Hose
39 45028 2 Nozzle, SS Floodjet
