Aiwa LCX-137 User manual

DATA
SERVICE MANUAL
BASIC CD MECHANISM : DA11T3C
COMPACT DISC STEREO
SYSTEM
LCX-137
S/M Code No. 09-003-340-2T1
LH(S) K(S)
SIMPLE
MODEL CODE : 86HR8-0117(B)
86HR8-1111(W)
86HR8-4444(L)
86HR8-8888(ST)
このサービスマニュアルはシンプル版です。改定版発行時に差し替えて使用してください。
• Replace this Service Manual with ”Revision Publishing” when it is issued.
EZ(S)
BASIC TAPE MECHANISM : TN-21ZSC-2003

2
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
ELECTRICAL MAIN PARTS LIST -1
IC
87-A20-734-010 IC,TDA2007A
87-A21-443-040 C-IC,M62495AFP
8A-CLB-602-010 IC,LC867240A-5P15
87-A21-245-010 IC,RPM6938-V4
87-A21-145-040 C-IC,BA4560F-E2
87-A20-446-010 C-IC,LA9241ML
87-A20-459-010 C-IC,LC78622ED
87-A21-093-010 IC,LA6541D
87-070-127-110 IC,LC72131 D
87-A20-913-010 IC,LA1837NL
TRANSISTOR
87-026-610-080 TR,KTC3198GR
89-213-702-010 TR,2SB1370 (1.8W)
87-A30-185-010 TR,2SD1381FQR
87-026-313-080 TR,DTC343TS
87-026-237-080 CHIP-TR,DTC124XK
87-026-223-080 TR,DTC143TK
89-320-011-080 TR,2SC2001 (15W)
87-CD7-603-080 TR,SS8050<KS,EZS>
89-318-154-080 TR,2SC1815 (0.4W)
87-026-291-080 TR,DTC124XS
89-112-965-080 TR,2SA1296 (0.75W)
87-A30-227-080 TR,2SB1010Q
87-026-463-080 TR,2SA933S (0.3W)
87-026-239-080 TR,DTC114TK (0.2W)
87-026-210-080 CHIP-TR,DTC144EK
87-A30-196-080 TR,2SC4115SRS
89-327-143-080 TR,2SC2714 (0.1W)
87-A30-072-080 C-TR,RT1P 144C
89-505-434-540 C-FET,2SK543
(4/5)<KS,EZS>
87-A30-257-080 C-TR,2SD1306E<KS,EZS>
87-A30-074-080 C-TR,RT1P
141C<KS,EZS>
DIODE
87-020-465-080 DIODE,1SS133 (110MA)
87-A40-393-090 DIODE,1N5402GW(F20)
87-070-334-080 ZENER,MTZJ10B
87-017-932-080 ZENER,MTJ6.2B
87-A40-347-080 ZENER,MTZJ2.2B
87-070-136-080 ZENER,MTZJ5.1B
87-020-027-080 CHIP-DIODE 1SS184
87-027-825-080 ZENER,HZ9A3L
87-A40-291-080 DIODE,1N4148 (CPT)
87-A40-234-080 ZENER,MTZJ5.6A
<KS,EZS>
87-A40-270-080 C-DIODE,MC2838
<KS,EZS>
MAIN C.B
C101 87-010-190-080 S CHIP F 0.01
C102 87-010-190-080 S CHIP F 0.01
C103 87-010-190-080 S CHIP F 0.01
C104 87-010-404-080 CAP, ELECT 4.7-50V
C105 87-010-403-080 CAP, ELECT 3.3-50V
C106 87-010-192-080 C-CAP,S 0.022-50 F
C107 87-010-192-080 C-CAP,S 0.022-50 F
C108 87-010-192-080 C-CAP,S 0.022-50 F
C109 87-010-192-080 C-CAP,S 0.022-50 F
C110 87-010-190-080 S CHIP F 0.01
C111 87-016-658-090 CAP,E 4700-35 SMG
C112 87-012-140-080 CAP 470P
C113 87-010-190-080 S CHIP F 0.01
C114 87-010-408-080 CAP, ELECT 47-50V
C115 87-010-112-080 CAP, ELECT 100-16V
C116 87-010-101-080 CAP, ELECT 220-16
C118 87-010-263-080 CAP, ELECT 100-10V
C119 87-010-197-080 CAP, CHIP 0.01 DM
C120 87-010-401-080 CAP, ELECT 1-50V
C122 87-010-213-080 C-CAP,S 0.015-50 B
C123 87-010-404-080 CAP, ELECT 4.7-50V
C124 87-010-402-080 CAP, ELECT 2.2-50V
C126 87-010-408-080 CAP, ELECT 47-50V
C127 87-010-248-080 CAP, ELECT 220-10V
C132 87-010-237-080 CAP, ELECT 1000-16V
C136 87-010-197-080 CAP, CHIP 0.01 DM
C137 87-010-197-080 CAP, CHIP 0.01 DM
C138 87-010-197-080 CAP, CHIP 0.01 DM
C139 87-010-197-080 CAP, CHIP 0.01 DM
C143 87-010-401-080 CAP, ELECT 1-50V
C144 87-010-401-080 CAP, ELECT 1-50V
C147 87-010-190-080 S CHIP F 0.01
C148 87-010-190-080 S CHIP F 0.01
C149 87-010-190-080 S CHIP F 0.01
C150 87-010-263-080 CAP, ELECT 100-10V
C151 87-010-263-080 CAP, ELECT 100-10V
C152 87-010-182-080 C-CAP,S 2200P-50 B
C153 87-010-166-080 C-CAP,S 100P-50 SL
C154 87-010-545-080 CAP, ELECT 0.22-50V
C155 87-010-545-080 CAP, ELECT 0.22-50V
C157 87-010-404-080 CAP, ELECT 4.7-50V
C158 87-010-545-080 CAP, ELECT 0.22-50V
C159 87-010-545-080 CAP, ELECT 0.22-50V
C161 87-010-404-080 CAP, ELECT 4.7-50V
C162 87-010-405-080 CAP, ELECT 10-50V
C163 87-010-405-080 CAP, ELECT 10-50V
C164 87-010-405-080 CAP, ELECT 10-50V
C165 87-010-405-080 CAP, ELECT 10-50V
C166 87-010-404-080 CAP, ELECT 4.7-50V
C167 87-010-404-080 CAP, ELECT 4.7-50V
C169 87-010-197-080 CAP, CHIP 0.01DM
<KS,EZS>
C170 87-010-197-080 CAP, CHIP 0.01 DM
<KS,EZS>
C171 87-010-404-080 CAP, ELECT 4.7-50V
C175 87-010-237-080 CAP, ELECT 1000-16V
C301 87-010-322-080 C-CAP,S 100P-50 CH
C302 87-015-951-080 CAP,E 1-50 LL
C304 87-010-406-080 CAP, ELECT 22-50
C306 87-010-405-080 CAP, ELECT 10-50V
C307 87-010-248-080 CAP, ELECT 220-10V
C308 87-010-405-080 CAP, ELECT 10-50V
C309 87-010-322-080 C-CAP,S 100P-50 CH
C311 87-010-406-080 CAP, ELECT 22-50
C312 87-015-951-080 CAP,E 1-50 LL
C314 87-010-426-080 C-CAP,S 0.012-25 B
C315 87-010-404-080 CAP, ELECT 4.7-50V
C316 87-010-404-080 CAP, ELECT 4.7-50V
C319 87-010-426-080 C-CAP,S 0.012-25 B
C320 87-010-197-080 CAP, CHIP 0.01 DM
<KS,EZS>
C322 87-010-112-080 CAP, ELECT 100-16V
C325 87-010-178-080 CHIP CAP 1000P
C326 87-010-178-080 CHIP CAP 1000P
C327 87-010-178-080 CHIP CAP 1000P
C329 87-015-695-080 CAP,E 1-50 7L
C330 87-012-140-080 CAP 470P<KS,EZS>
C701 87-010-381-080 CAP, ELECT 330-16V
C702 87-010-404-080 CAP, ELECT 4.7-50V
C703 87-012-286-080 CAP, U 0.01-25
C704 87-012-286-080 CAP, U 0.01-25
C709 87-012-195-080 C-CAP,U 100P-50CH
C711 87-010-263-080 CAP, ELECT 100-10V
C712 87-010-196-080 CHIP CAPACITOR,0.1-25
C713 87-012-286-080 CAP, U 0.01-25
<KS,EZS>
C714 87-012-286-080 CAP, U 0.01-25
C715 87-012-195-080 C-CAP,U 100P-50CH
<KS,EZS>

3
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
ELECTRICAL MAIN PARTS LIST -2
1 8A-HC7-007-010 WINDOW,CD
2 8A-HC7-005-010 WINDOW,DISPLAY
3 8A-HC7-040-010 LID ASSY,CD311<LHB,LHS>
3 8A-HC7-037-010 LID ASSY,CD 311(LL)<LHLL>
4 85-HC6-205-110 SHAFT,LID(300) HK
5 8A-HC7-204-010 SPR-T,OPEN
6 8A-HC7-018-010 LEVER,OPEN
7 8A-HC7-015-010 CABI
ASSY,CENTER<LHB,LHS>
7 8A-HC7-035-010 CABI ASSY,CENTER
(LL)<LHLL>
8 8Z-HC1-225-010 DMPR,MECHA(SP)
9 8A-HC7-201-010 GUIDE,LCD
10 8Z-HC7-205-010 BAT-CONTACT,(-)
11 8A-HC7-202-010 BAT-CONTACT,(+)
12 87-HC8-205-010 BAT-CONTACT,(+)(-)
13 8A-HC7-012-010 KNOB,SL HOLD
14 8A-HC7-016-010 CABI ASSY,BOTTOM
<LHB,LHS>
14 8A-HC7-036-010 CABI ASSY,BOTTOM
(LL)<LHLL>
15 88-HC6-021-010 FOOT, DIA10
A 87-067-869-010 V+1.7-8 HL BLK
B 87-067-868-010 V+1.7-4 HL BLK
C715 87-012-195-080 C-CAP,U 100P-
50CH<KS,EZS>
C717 87-012-286-080 CAP, U 0.01-25
C719 87-012-286-080 CAP, U 0.01-25
C720 87-012-195-080 C-CAP,U 100P-50CH
C721 87-012-176-080 CAP 15P
C722 87-012-176-080 CAP 15P
C723 87-012-274-080 CHIP CAP,U 1000P-50B
C725 87-018-131-080 CAP, CER 1000P-50V
C727 87-010-196-080 CHIP CAPACITOR,0.1-25
C728 87-010-248-080 CAP, ELECT 220-10V
C729 87-012-274-080 CHIP CAP,U 1000P-50B
C731 87-012-286-080 CAP, U 0.01-25
C752 87-012-284-080 CAP, U 6800P-
50<KS,EZS>
C753 87-012-195-080 C-CAP,U 100P-
50CH<KS,EZS>
C755 87-012-286-080 CAP, U 0.01-
25<KS,EZS>
C756 87-012-286-080 CAP, U 0.01-25
C757 87-012-188-080 C-CAP,U 47P-50 CH
C758 87-012-167-080 C-CAP,U 5P-50 CH
C761 87-010-196-080 CHIP CAPACITOR,0.1-
25<KS,EZS>
C762 87-012-286-080 CAP, U 0.01-
25<KS,EZS>
C763 87-010-829-080 CAP, U 0.047-16
C764 87-012-337-080 C-CAP,U 56P-50
CH<LHS>
C765 87-012-286-080 CAP, U 0.01-25
C766 87-010-197-080 CAP, CHIP 0.01
DM<KS,EZS>
C768 87-012-286-080 CAP, U 0.01-25
C769 87-010-260-080 CAP, ELECT 47-25V
C770 87-010-829-080 CAP, U 0.047-16
C771 87-010-383-080 CAP, ELECT 33-25V
C772 87-010-829-080 CAP, U 0.047-16
C773 87-010-196-080 CHIP CAPACITOR,0.1-25
C774 87-010-263-080 CAP, ELECT 100-10V
C775 87-010-404-080 CAP, ELECT 4.7-50V
C776 87-012-286-080 CAP, U 0.01-25
C777 87-010-400-080 CAP, ELECT 0.47-50V
C778 87-010-401-080 CAP, ELECT 1-50V
C779 87-010-401-080 CAP, ELECT 1-50V
C780 87-010-196-080 CHIP CAPACITOR,0.1-25
C781 87-010-405-080 CAP, ELECT 10-50V
C782 87-010-405-080 CAP, ELECT 10-50V
C783 87-012-286-080 CAP, U 0.01-25
C784 87-012-286-080 CAP, U 0.01-25
C785 87-010-401-080 CAP, ELECT 1-50V<LHS>
C785 87-010-405-080 CAP, ELECT 10-
50V<KS,EZS>
C786 87-010-401-080 CAP, ELECT 1-50V<LHS>
C786 87-010-405-080 CAP, ELECT 10-
50V<KS,EZS>
C787 87-012-287-080 C-CAP,U 0.015-25
F<KS,EZS>
C788 87-012-287-080 C-CAP,U 0.015-25
F<KS,EZS>
C789 87-012-275-080 C-CAP,U 1200P-50 B
C789 87-012-275-080 C-CAP,U 1200P-50 B
C790 87-012-275-080 C-CAP,U 1200P-50 B
C791 87-010-405-080 CAP, ELECT 10-50V
C793 87-012-275-080 C-CAP,U 1200P-50
B<KS,EZS>
C793 87-012-273-080 C-CAP,U 820P-50
B<LHS>
C794 87-010-406-080 CAP, ELECT 22-50
C795 87-010-596-080 CAP, S 0.047-16
C796 87-010-403-080 CAP, ELECT 3.3-50V
C797 87-012-276-080 CAP, CHIP SS 1500 PBK
C798 87-012-276-080 CAP, CHIP SS 1500 PBK
C799 87-010-829-080 CAP, U 0.047-16
C803 87-018-047-080 CAP, CER 0.01-
16V<KS,EZS>
C812 87-012-286-080 CAP, U 0.01-25
C814 87-012-286-080 CAP, U 0.01-
25<KS,EZS>
C820 87-010-260-080 CAP, ELECT 47-25V
C821 87-012-286-080 CAP, U 0.01-25
C822 87-012-286-080 CAP, U 0.01-25
C823 87-012-286-080 CAP, U 0.01-25
C824 87-012-172-080 CAPACITOR CHIP U 10P
CH<KS,EZS>
C828 87-010-196-080 CHIP CAPACITOR,0.1-25
C829 87-010-196-080 CHIP CAPACITOR,0.1-25
C909 87-012-286-080 CAP, U 0.01-
25<KS,EZS>
C910 87-012-286-080 CAP, U 0.01-
25<KS,EZS>
C940 87-012-286-080 CAP, U 0.01-
25<KS,EZS>
C942 87-012-172-080 CAPACITOR CHIP U 10P
CH<KS,EZS>
C947 87-012-286-080 CAP, U 0.01-
25<KS,EZS>
C949 87-A10-039-080 C-CAP,U 470P-50 J
CH<KS,EZS>
C952 87-012-286-080 CAP, U 0.01-
25<KS,EZS>
C958 87-010-197-080 CAP, CHIP 0.01
DM<KS,EZS>
C959 87-010-831-080 C-CAP,U,0.1-16F
C960 87-010-196-080 CHIP CAPACITOR,0.1-25
C961 87-012-170-080 C-CAP,U 8P-50 CH<LHS>
C962 87-010-401-080 CAP, ELECT 1-
50V<KS,EZS>
C963 87-010-196-080 CHIP CAPACITOR,0.1-
25<LHS>
CF801 87-008-423-010 CERAMIC FILTER,
SFE10.7<KS,EZS>
CF801 87-008-261-010 FILTER, SFE10.7MA5-
A<LHS>
CF802 82-785-747-010 CF MS2 GHY R<KS,EZS>
CF802 87-008-261-010 FILTER, SFE10.7MA5-
A<LHS>
CN301 87-009-036-010 CONNECTOR, 8P PH V
WHT
!F101 87-A91-217-010 FUSE,3.15A 250V T 50T
!FC1 87-033-213-080 CLAMP, FUSE
!FC2 87-033-213-080 CLAMP, FUSE
FFE801 A8-6ZA-19C-170 6ZA-1 YFEENC<KS,EZS>
FFE801 A8-8ZA-193-070 8ZA-1 YFEUNC<LHS>
J101 87-A60-354-010 JACK,PIN 2P MSP -

4
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
1 87-B30-285-010 AC ADAPTOR,AC-D603HRNC
2 87-B30-326-010 HEADPHONE,HP-M048
3 8A-HC7-914-010 IB,LH(3L)C F
4 87-A90-312-010 PLUG,CONVERSION
WTN-1157R1
ELECTRICAL MAIN PARTS LIST -3
242V-05
J102 87-A60-754-010 TERMINAL,SPK 4P MSP-
154V-05
J103 87-A60-420-010 JACK,3.5 ST (MSC)
J104 87-099-608-010 JACK, DC
HEC3800<KS,EZS>
J801 87-A60-202-010 TERMINAL,ANT 4P MSP-
154V-02<LHS>
J801 87-A60-880-010 TERMINAL,ANT-PAL 2P
MSP-313V-0<KS,EZS>
L101 87-005-366-010 COIL, 1UH
L102 87-005-366-010 COIL, 1UH
L104 87-005-676-080 COIL,2.2UH K LF5.0S
L301 88-CL6-609-010 COIL,BIAS 8CL6
L771 87-A50-266-010 COIL,FM DET-2N(TOK)
L772 87-A90-733-010 FLTR,PCFAZH-450 (TOK)
L781 87-005-847-080
COIL,2.2UH(CECS)<KS,EZS>
L832 87-005-847-080
COIL,2.2UH(CECS)<KS,EZS>
L941 87-A50-020-010 COIL,ANT
LW(COI)<KS,EZS>
L942 87-A50-019-010 COIL,OSC
LW(COI)<KS,EZS>
L981 87-NF4-650-010 COIL,AM PACK
4N(TOK)<LHS>
PR100 87-A90-091-080 PROTECTOR,2A 491
PR101 87-026-689-080 PROTECTOR,1A 60V 491
TC942 87-011-164-010 CAPACITOR,TRIMMER
30P<KS,EZS>
WH101 87-099-043-010 CONN 2P EH
X721 87-A70-061-010 VIB,XTAL 4.500MHZ
CSA-309
FRONT C.B
C201 87-010-375-080 CAP,E 330-10 SME
C202 87-012-350-080 C-CAP,1-25 F
C203 87-010-197-080 CAP, CHIP 0.01 DM
C205 87-010-178-080 CHIP CAP 1000P
C208 87-010-197-080 CAP, CHIP 0.01 DM
C209 87-010-196-080 CHIP CAPACITOR,0.1-25
C210 87-010-196-080 CHIP CAPACITOR,0.1-25
C211 87-010-314-080 C-CAP,S 22P-50V
C212 87-010-318-080 C-CAP,S 47P-50 CH
C213 87-010-154-080 CAP CHIP 10P
C214 87-012-149-080 C-CAP,S 30P-50 CH
C215 87-010-312-080 C-CAP,S 15P-50 CH
C216 87-010-400-080 CAP, ELECT 0.47-50V
C217 87-010-196-080 CHIP CAPACITOR,0.1-25
CN201 87-099-720-010 CONN,30P TYK-B(P)
CN202 87-A60-404-010 CONN,3P TKX-P03P-F1
L206 87-003-098-080 COIL,2.2UH
LCD201 8Z-CL8-665-110 LCD,ZCL-8
S200 87-A90-095-080 SW,TACT EVQ11G04M
S201 87-A90-095-080 SW,TACT EVQ11G04M
S202 87-A90-095-080 SW,TACT EVQ11G04M
S203 87-A90-095-080 SW,TACT EVQ11G04M
S205 87-A90-095-080 SW,TACT EVQ11G04M
S207 87-A90-095-080 SW,TACT EVQ11G04M
S208 87-A90-095-080 SW,TACT EVQ11G04M
S213 87-A90-095-080 SW,TACT EVQ11G04M
S214 87-A90-095-080 SW,TACT EVQ11G04M
S216 87-A90-095-080 SW,TACT EVQ11G04M
S217 87-A90-095-080 SW,TACT EVQ11G04M
S218 87-A90-095-080 SW,TACT EVQ11G04M
S220 87-A90-095-080 SW,TACT EVQ11G04M
SW301 8Z-CL8-668-010 SW,RP ZCL8
X201 87-030-364-010 VIB,XTAL 32.768K CT
X202 87-A70-185-080 VIB,CER 5.76MHZ TF21
CD C.B
C500 87-016-459-040 CAP,E 470-10 SMG
C502 87-016-459-040 CAP,E 470-10 SMG
C503 87-016-459-040 CAP,E 470-10 SMG
C505 87-010-196-080 CHIP CAPACITOR,0.1-25
C507 87-010-196-080 CHIP CAPACITOR,0.1-25
C510 87-010-197-080 CAP, CHIP 0.01 DM
C513 87-010-196-080 CHIP CAPACITOR,0.1-25
C514 87-010-196-080 CHIP CAPACITOR,0.1-25
C515 87-012-157-080 C-CAP,S 330P-50 CH
C516 87-010-545-080 CAP, ELECT 0.22-50V
C525 87-010-176-080 C-CAP,S 680P-50 SL
C528 87-012-156-080 C-CAP,S 220P-50 CH
C529 87-010-545-080 CAP, ELECT 0.22-50V
C530 87-012-140-080 CAP 470P
C531 87-010-374-080 CAP, ELECT 47-10V
C532 87-010-401-080 CAP, ELECT 1-50V
C533 87-010-184-080 CHIP CAPACITOR
3300P(K)
C534 87-010-197-080 CAP, CHIP 0.01 DM
C535 87-010-145-080 C-CAP,S 1P-50 CH
C536 87-010-312-080 C-CAP,S 15P-50 CH
C537 87-010-309-080 C-CAP,1000P-50 CH
C538 87-010-196-080 CHIP CAPACITOR,0.1-25
C539 87-010-404-080 CAP, ELECT 4.7-50V
C540 87-010-196-080 CHIP CAPACITOR,0.1-25
C541 87-010-405-080 CAP, ELECT 10-50V
C542 87-010-369-080 C-CAP,S 0.033-25 K B
C543 87-010-405-080 CAP, ELECT 10-50V
C545 87-010-197-080 CAP, CHIP 0.01 DM
C546 87-010-374-080 CAP, ELECT 47-10V
C547 87-010-263-080 CAP, ELECT 100-10V
C548 87-010-263-080 CAP, ELECT 100-10V
C549 87-010-198-080 CAP, CHIP 0.022
C550 87-010-248-080 CAP, ELECT 220-10V
C551 87-010-178-080 CHIP CAP 1000P
C552 87-010-197-080 CAP, CHIP 0.01 DM
C553 87-010-374-080 CAP, ELECT 47-10V
C555 87-010-403-080 CAP, ELECT 3.3-50V
C556 87-010-197-080 CAP, CHIP 0.01 DM
C557 87-010-197-080 CAP, CHIP 0.01 DM
C558 87-010-197-080 CAP, CHIP 0.01 DM
C559 87-010-315-080 C-CAP,S 27P-50 CH
C560 87-010-263-080 CAP, ELECT 100-10V
C561 87-010-196-080 CHIP CAPACITOR,0.1-25
C562 87-010-196-080 CHIP CAPACITOR,0.1-25
C563 87-012-156-080 C-CAP,S 220P-50 CH
C565 87-010-263-080 CAP, ELECT 100-10V
C566 87-010-196-080 CHIP CAPACITOR,0.1-25
C568 87-010-197-080 CAP, CHIP 0.01 DM
C570 87-010-197-080 CAP, CHIP 0.01 DM
C571 87-010-248-080 CAP, ELECT 220-10V
C572 87-010-196-080 CHIP CAPACITOR,0.1-25
C573 87-010-197-080 CAP, CHIP 0.01 DM
C578 87-010-197-080 CAP, CHIP 0.01 DM
C579 87-010-263-080 CAP, ELECT 100-10V
C582 87-010-197-080 CAP, CHIP 0.01 DM
C583 87-010-405-080 CAP, ELECT 10-50V
C587 87-010-166-080 C-CAP,S 100P-50 SL
C589 87-010-166-080 C-CAP,S 100P-50 SL
C590 87-010-166-080 C-CAP,S 100P-50 SL
C591 87-010-166-080 C-CAP,S 100P-50 SL
C592 87-010-166-080 C-CAP,S 100P-50 SL
C593 87-010-197-080 CAP, CHIP 0.01 DM
C594 87-010-263-080 CAP, ELECT 100-10V
C596 87-010-404-080 CAP, ELECT 4.7-50V
C597 87-010-197-080 CAP, CHIP 0.01 DM
C598 87-010-197-080 CAP, CHIP 0.01 DM
C601 87-010-197-080 CAP, CHIP 0.01 DM

5
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
CN501 87-009-345-010 CONN,2P PH H
CN510 87-009-034-010 CONN,6P PH V
CN520 87-A60-248-010 CONN,16P H CFF1416
L501 87-005-647-080 COIL,10UH K LF5S
L502 87-005-659-080 COIL,100UH K LF5.0S
R503 87-029-019-010 RES, FUSEIBLE
1/2W-2.2
SFR501 87-A90-787-080 SFR,100K H HOKU
X501 87-A70-046-010 VIB,XTAL 16.934MHZ
LED C.B
D941 87-A40-365-080 LED,L-1154 SGD
D942 87-A40-365-080 LED,L-1154 SGD
D943 87-A40-365-080 LED,L-1154 SGD
D944 87-A40-365-080 LED,L-1154 SGD
D945 87-A40-365-080 LED,L-1154 SGD
D946 87-A40-365-080 LED,L-1154 SGD
D947 87-A40-365-080 LED,L-1154 SGD
D948 87-A40-365-080 LED,L-1154 SGD
D949 87-A40-365-080 LED,L-1154 SGD
AC C.B
CNA101 8A-CLA-630-010 CONN ASSY,2P PT
SW1 87-A90-178-010 SW SL1-1-2<LHS>
T1 87-A60-317-010 TERMINAL, 1P MSC
T2 87-A60-317-010 TERMINAL, 1P MSC
MOTOR C.B
M2 9X-262-576-910 MOTOR GEAR ASSY
PIN3 91-564-722-110 CONNECTOR 6P
SW1 91-572-085-120 LEAF SW
ELECTRICAL MAIN PARTS LIST -4

6
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
1 8A-CLB-007-010 WINDOW,CASS
2 8A-CLB-005-010 LID,CASS
3 8A-CLB-006-010 BOX,CASS
4 8Z-CL8-209-010 SPR-T,CASS
5 8A-CLB-004-010 WINDOW,DISP<LHS,KS>
6 87-B00-002-010 BADGE,AIWA 30 ABS SIL
7 8Z-CL8-204-010 CUSH,FOOT
8 8A-CLM-002-010 CABI,FRONT EX<LHS,KS>
8 8A-CLM-001-010 CABI,FRONT EZ<EZS>
9 8A-CLB-008-010 KEY,CASS SET
10 8A-CLB-009-010 KEY,CONT
11 8A-CLB-013-010 KEY,RT PTY<EZS>
12 8A-CLB-012-010 KEY,POWER
13 8A-CLB-010-010 KEY,SKIP
14 8A-CLB-011-010 KEY,P/S
15 8Z-CDB-170-010 BASE,CHUCK
16 88-CD9-211-210 RING,CHUCK
17 87-036-368-010 MAGNET
18 8A-CLB-002-010 LID,CD
19 8Z-CL8-683-010 CONN ASSY,2P CD DOOR
20 8Z-CL8-205-010 SPR-T,CD
21 8A-CLB-003-010 CHAS,CD
22 M8-ZZK-E90-070 DA11T3C
23 88-CT6-206-010 CUSHION,CD
24 8Z-CL8-681-010 CONN ASSY,6P CD MOTOR
25 8A-CLB-028-010 CABI,REAR EZ<KS,EZS>
25 8A-CLB-037-010 CABI,REAR H<LHS>
26 8Z-CL8-682-010 FF-CABLE, 16P 1.0
180MM
27 8Z-CL8-201-010 GUIDE,LCD
! 28 87-A80-092-010 AC CORD ASSY,
E BLK SUN FAI
! 29 8A-CLL-621-010 PT,EZ ACL-L<KS,EZS>
! 29 8A-CLL-620-010 PT,H ACL-L<LHS>
30 8Z-CDB-169-010 PANEL,CD SANYO
31 8Z-CL8-206-010 SPR-P,REC
32 8Z-CL8-214-010 DMPR,HLDR BE
33 84-CD5-215-010 GEAR
34 84-CD5-216-010 BRACKET
35 86-NFZ-231-010 DMPR,70
36 87-064-108-110 HLDR,NC LUTCH
A 87-B10-239-010 QT2+3-8 W/O CR
B 8Z-CL8-220-010 W,30-0856-01-01-01
C 87-067-579-010 TAPPING SCREW,
BVT2+3-8
D 87-067-703-010 TAPPING SCREW,
BVT2+3-10
E 87-342-074-010 UT2+2.6-8
F 87-761-096-410 VFT2+3-10 GLD
G 87-B10-230-010 BVT2+3-10 W/O SLOT
SILVER CR
H 87-571-033-410 TAPPING SCREW,
VIT+2-4
MECHANICAL PARTS LIST - 1

7
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
ACCESSORIES LIST-1
1 8A-CLM-906-010 IB,EZ(9L)B<EZS>
1 8A-CLM-905-010 IB,K(E)B<KS>
1 8A-CLM-902-010 IB,LH(ESP)B<LHS>
2 87-A90-030-010 ANT,LOOP AM-NC C
3 87-043-115-010 ANT,FEEDER FM<LHS>
3 87-A90-118-010 ANT,WIRE FM
(Z)<KS,EZS>
! 4 87-A91-017-010 PLUG,CONVERSION
JT-0476<KS,EZS>
5 8A-CLB-961-010 RC UNIT,RC-AAT11

8
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
SPEAKER LIST-1
8A-CLL-600-010 SPKR, 40HM 5W ACL-L
8A-CLB-014-010 CABI,FR SPKR
8A-CLB-016-010 FRAME,SPKR
8Z-CL7-107-010 BADGE,AIWA SILVER
8A-CLL-601-010 CORDASSY,SPKR-BLK
ACL-L/M

2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:[phone]
737004 Printed in Singapore
