SERVICE MANUAL
DATA
COMPACT DISC
STEREO SYSTEM
BASIC TAPE MECHANISM : ZZM-3 PR1NM
BASIC CD MECHANISM : AZG-1 ZD3RDM
NSX-AJ22
U
S/M Code No. 09-008-423-4S1
SUPPLEMENT
NSX-AJ22
SPEAKER
SYSTEM CD
CASSEIVER REMOTE
CONTROLLER
CX-NAJ22 SX-R140
SX-NAJ33 RC-ZAS02
• This Service Manual is the “Supplement” and replaces “Simple Manual”
(S/M Code No. 09-007-423-4T5).
• This Service Manual contains information about the difference between
NSX-AJ22 (U) and NSX-AJ20 (U). If requiring the other information, see
Service Manual of NSX-AJ20/SZ20 (U,LH),
(S/M Code No.09-001-423-4R1).
• If requiring information about the CD mechanism, see Service Manual
of AZG-1, (S/M Code No. 09-001-335-3N8).
All manuals and user guides at all-guides.com
all-guides.com

– 2 –
SPECIFICATIONS
• Design and specifications are subject to change without notice.
• The word "BBE"and the "BBE symbol" are trademarks of BBE
Sound, Inc.
Under license from BBE Sound,Inc.
<FM tuner section>
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity (IHF) 13.2 dBf
Antenna terminals 75 ohms (unbalanced)
<AM tuner section>
Tuning range 530 kHz to 1710 kHz (10 kHz step)
531 kHz to 1602 kHz (9 kHz step)
Usable sensitivity 350 µV/m
Antenna Loop antenna
<Amplifier section>
Power output 60 W + 60 W (50 Hz - 20 kHz,
THD less than 1%, 6 ohms)
75 W + 75 W (1 kHz, THD less than
10%, 6 ohms)
Total harmonic distortion 0.08% (30 W, 1 kHz, 6 ohms,
DIN AUDIO)
Inputs VIDEO/AUX: 500 mV
Outputs SPEAKERS: accept speakers of 6
ohms or more
SURROUND SPEAKERS
accept speakers of 8 ohms to 16 ohms
PHONES (stereo jack): accepts
headphones of 32 ohms or more
<Cassette deck section>
Track format 4 tracks, 2 channels stereo
Frequency response 50 Hz – 15 kHz
Recording system AC bias
Heads Deck 1 : Playback head x 1
Deck 2 : Recording/Playback head x 1,
erase head x 1
<Compact disc player section>
Laser Semiconductor laser (λ =780 nm)
D-A converter 1 bit dual
Signal-to-noise ratio 85 dB (1 kHz, 0 dB)
Harmonic distortion 0.05 % (1 kHz, 0 dB)
<General>
Power requirements 120 V AC, 60 Hz
Power consumption 85 W
Power consumption in standby mode
15 W with power-economizing
mode off
0.9 W with power-economizing
mode on
Dimensions of main unit 260 x 328 x 335 mm
(W xH xD) (101/4x 13 x 131/4in.)
Weight of main unit 6.6 kg (14 lbs 2 oz.)
<Speaker system SX–NAJ33>
Speaker System 3 way, bass reflex (magnetic
shielded type)
Speaker units Woofer:
140 mm (55/8 in.) cone type
Tweeter:
60mm (23/8in.) cone type
Super tweeter:
20 mm (13/16 in.) ceramic type
Impedance 6 ohms
Output sound pressure level 87 dB/W/m
Dimensions (W xH xD) 230 x 324x 256 mm
(91/8x 127/8 x 101/8in.)
Weight 3.8 kg (8 lbs 6 oz.)
All manuals and user guides at all-guides.com

– 3 –
ELECTRICAL MAIN PARTS LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
IC
87-A21-355-010 IC,STK490-140
87-A21-419-040 C-IC,NJM14558MD-TE2
87-A21-401-040 C-IC,M61503FP
87-A21-560-010 IC,LA1844L-A
8A-NF9-604-010 C-IC,UPD780226GF-015-3BA
87-A21-482-010 IC,RPM6938-H4
87-070-127-110 IC,LC72131 D
87-A21-269-010 IC,EW732
TRANSISTOR
87-026-609-080 TR,KTA1266GR
89-213-702-010 TR,2SB1370 (1.8W)
87-026-610-080 TR,KTC3198GR
87-A30-076-080 C-TR,2SC3052F
87-A30-075-080 C-TR,2SA1235F
87-A30-074-080 C-TR,RT1P 141C
87-A30-107-070 C-TR,CMBT5401
87-A30-106-040 C-TR,CMBT5551
87-026-235-080 CHIP-TR,DTC114EK
87-A30-087-080 C-FET,2SK2158
87-A30-091-080 FET,2SJ460
87-A30-090-080 FET,2SK2541
87-A30-318-080 TR,CSA952K
87-A30-329-080 TR,CD1585BC
89-327-143-080 TR,2SC2714 (0.1W)
87-A30-072-080 C-TR,RT1P 144C
87-A30-234-080 TR,CSC4115BC
87-A30-468-080 C-TR,KRC102S-RTK
87-A30-062-080 C-TR,KRC104S
87-A30-495-080 TR,2SA1981Y
87-A30-492-080 TR,2SC5343G
DIODE
87-A40-393-090 DIODE,1N5402GW(F20)
87-A40-553-080 DIODE,1N4003 LES
87-A40-776-080 ZENER,UZ27BSD
87-A40-764-080 ZENER,UZ10BSC
87-A40-313-080 C-DIODE,MC 2840
87-A40-270-080 C-DIODE,MC2838
87-A40-269-080 C-DIODE,MC2836
87-A40-752-080 ZENER,UZ6.2BSC
87-A40-739-080 ZENER,UZ2.7BSA
87-017-149-080 ZENER,HZS6A2L
87-020-465-080 DIODE,1SS133
87-A40-854-080 ZENER,UZ15BSA
MAIN C.B
C3 87-012-368-080 C-CAP,S 0.1-50 F
C4 87-012-368-080 C-CAP,S 0.1-50 F
C5 87-012-368-080 C-CAP,S 0.1-50 F
C6 87-012-368-080 C-CAP,S 0.1-50 F
C9 87-012-368-080 C-CAP,S 0.1-50 F
C10 87-012-368-080 C-CAP,S 0.1-50 F
C11 87-012-368-080 C-CAP,S 0.1-50 F
C12 87-012-368-080 C-CAP,S 0.1-50 F
C19 87-A12-036-000 CAP,E 2200-63 SMG
C20 87-A12-036-000 CAP,E 2200-63 SMG
C21 87-A10-520-000 CAP,E 3300-35 M SMG
C22 87-A10-520-000 CAP,E 3300-35 M SMG
C25 87-010-385-080 CAP, ELECT 220-25V
C26 87-010-247-080 CAP, ELECT 100-50V
C30 87-010-430-080 CAP, ELECT 100-63
C31 87-010-263-080 CAP, ELECT 100-10V
C32 87-010-197-080 CAP, CHIP 0.01-25 K B
C33 87-010-263-080 CAP, ELECT 100-10V
C34 87-010-247-080 CAP, ELECT 100-50V
C35 87-010-380-080 CAP, ELECT 47-16 M
C36 87-010-381-080 CAP, ELECT 330-16V
C38 87-010-197-080 CAP, CHIP 0.01-25 K B
C60 87-010-403-080 CAP, ELECT 3.3-50V
C61 87-010-260-080 CAP, ELECT 47-25V
C97 87-010-196-080 CHIP CAPACITOR,0.1-25
C101 87-010-185-080 C-CAP,S 3900P-50 K B
C102 87-010-185-080 C-CAP,S 3900P-50 K B
C103 87-010-545-080 CAP, ELECT 0.22-50M
C104 87-010-545-080 CAP, ELECT 0.22-50M
C105 87-010-187-080 CHIP CAP 5600P-50 K B
C106 87-010-187-080 CHIP CAP 5600P-50 K B
C107 87-010-404-080 CAP, ELECT 4.7-50V
C108 87-010-404-080 CAP, ELECT 4.7-50V
C109 87-010-179-080 C-CAP,S 1200P-50 K B
C110 87-010-179-080 C-CAP,S 1200P-50 K B
C111 87-010-391-080 CAP,E 10-35 SME
C112 87-010-391-080 CAP,E 10-35 SME
C113 87-010-866-080 CAP, ELECT 10-63
C114 87-010-866-080 CAP, ELECT 10-63
C119 87-A10-801-080 C-CAP,S 0.022-16 J B
C120 87-A10-801-080 C-CAP,S 0.022-16 J B
C125 87-012-368-080 C-CAP,S 0.1-50 F
C126 87-012-368-080 C-CAP,S 0.1-50 F
C127 87-012-368-080 C-CAP,S 0.1-50 F
C128 87-012-368-080 C-CAP,S 0.1-50 F
C129 87-010-191-080 C-CAP,S 0.015-50 F
C130 87-010-191-080 C-CAP,S 0.015-50 F
C131 87-010-197-080 CAP, CHIP 0.01-25 K B
C132 87-010-197-080 CAP, CHIP 0.01-25 K B
C133 87-010-186-080 CAP,CHIP 4700P-50 K
C140 87-010-182-080 C-CAP,S 2200P-50 B
C141 87-010-196-080 CHIP CAPACITOR,0.1-25
C235 87-010-408-080 CAP, ELECT 47-50V
C236 87-010-408-080 CAP, ELECT 47-50V
C239 87-010-196-080 CHIP CAPACITOR,0.1-25
C301 87-010-178-080 C-CAP,S 1000-50 K B
C302 87-010-178-080 C-CAP,S 1000-50 K B
C303 87-010-178-080 C-CAP,S 1000-50 K B
C304 87-010-178-080 C-CAP,S 1000-50 K B
C307 87-010-263-080 CAP, ELECT 100-10V
C308 87-010-263-080 CAP, ELECT 100-10V
C309 87-010-318-080 C-CAP,S 47P-50 CH
C310 87-010-318-080 C-CAP,S 47P-50 CH
C313 87-010-188-080 CAP,CHIP 6800P-50 K
C314 87-010-188-080 CAP,CHIP 6800P-50 K
C315 87-010-263-080 CAP, ELECT 100-10V
C317 87-010-546-080 CAP, ELECT 0.33-50V
C318 87-010-546-080 CAP, ELECT 0.33-50V
C326 87-010-198-080 CAP, CHIP 0.022-25 K
C327 87-012-368-080 C-CAP,S 0.1-50 F
C360 87-010-401-080 CAP, ELECT 1-50V
C399 87-012-140-080 C-CAP,S 470P-50 J
C401 87-010-544-080 CAP, ELECT 0.1-50V
C402 87-010-544-080 CAP, ELECT 0.1-50V
C403 87-010-321-080 CHIP CAPACITOR,82P(J)
C404 87-010-321-080 CHIP CAPACITOR,82P(J)
C405 87-010-197-080 CAP, CHIP 0.01-25 K B
C406 87-010-197-080 CAP, CHIP 0.01-25 K B
C407 87-010-197-080 CAP, CHIP 0.01-25 K B
C408 87-010-197-080 CAP, CHIP 0.01-25 K B
C409 87-010-182-080 C-CAP,S 2200P-50 B
C410 87-010-182-080 C-CAP,S 2200P-50 B
C411 87-010-405-080 CAP, ELECT 10-50V
C412 87-010-405-080 CAP, ELECT 10-50V
C452 87-010-382-080 CAP, ELECT 22-25V
C453 87-010-183-080 C-CAP,S 2700P-50 B
C454 87-010-183-080 C-CAP,S 2700P-50 B
C455 87-010-183-080 C-CAP,S 2700P-50 B
All manuals and user guides at all-guides.com

– 4 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
C456 87-010-197-080 CAP, CHIP 0.01-25 K B
C460 87-010-196-080 CHIP CAPACITOR,0.1-25
C461 87-012-158-080 C-CAP,S 390P-50 CH
C462 87-012-158-080 C-CAP,S 390P-50 CH
C470 87-018-127-080 CAP,TC U 470P-50
C605 87-010-184-080 CAP,CHIP S 3300P-50 K B
C606 87-010-184-080 CAP,CHIP S 3300P-50 K B
C609 87-010-213-080 C-CAP,S 0.015-50 B
C610 87-010-213-080 C-CAP,S 0.015-50 B
C611 87-010-545-080 CAP, ELECT 0.22-50V
C612 87-010-545-080 CAP, ELECT 0.22-50V
C613 87-010-545-080 CAP, ELECT 0.22-50V
C614 87-010-545-080 CAP, ELECT 0.22-50V
C615 87-010-154-080 CAP CHIP 10P-50 CH
C616 87-010-221-080 CAP, ELECT 470-10 M
C617 87-010-221-080 CAP, ELECT 470-10 M
C618 87-010-405-080 CAP, ELECT 10-50V
C630 87-016-669-080 C-CAP,S 0.1-25 K B
C631 87-010-185-080 C-CAP,S 3900P-50 B
C632 87-010-185-080 C-CAP,S 3900P-50 B
C633 87-016-369-080 C-CAP,S 0.033-25 K B
C634 87-016-369-080 C-CAP,S 0.033-25 K B
C669 87-010-322-080 C-CAP,S 100P-50 CH
C670 87-010-322-080 C-CAP,S 100P-50 CH
C677 87-010-197-080 CAP, CHIP 0.01-25 K B
C771 87-010-263-080 CAP, ELECT 100-10V
C772 87-010-197-080 CAP, CHIP 0.01-25 K B
C782 87-010-197-080 CAP, CHIP 0.01-25 K B
C783 87-010-197-080 CAP, CHIP 0.01-25 K B
C784 87-010-197-080 CAP, CHIP 0.01-25 K B
C785 87-010-197-080 CAP, CHIP 0.01-25 K B
C786 87-010-197-080 CAP, CHIP 0.01-25 K B
C788 87-010-149-080 C-CAP,S 5P-50 CH
C789 87-A12-052-080 C-CAP,S 0.033-25 J B
C790 87-A12-052-080 C-CAP,S 0.033-25 J B
C791 87-010-196-080 CHIP CAPACITOR,0.1-25
C792 87-010-197-080 CAP, CHIP 0.01-25 K B
C793 87-010-404-080 CAP, ELECT 4.7-50V
C795 87-010-197-080 CAP, CHIP 0.01-25 K B
C796 87-010-197-080 CAP, CHIP 0.01-25 K B
C797 87-010-405-080 CAP, ELECT 10-50V
C798 87-010-197-080 CAP, CHIP 0.01-25 K B
C799 87-010-407-080 CAP, ELECT 33-50V
C800 87-012-369-080 C-CAP,S 0.047-50F
C801 87-010-403-080 CAP, ELECT 3.3-50V
C802 87-010-194-080 CAP, CHIP 0.047-25 Z F
C803 87-010-198-080 CAP, CHIP 0.022-25 K B
C804 87-010-263-080 CAP, ELECT 100-10V
C807 87-010-400-080 CAP, ELECT 0.47-50V
C808 87-010-401-080 CAP, ELECT 1-50V
C809 87-010-401-080 CAP, ELECT 1-50V
C810 87-010-196-080 CHIP CAPACITOR,0.1-25
C814 87-010-197-080 CAP, CHIP 0.01-25 K B
C815 87-010-400-080 CAP, ELECT 0.47-50 M
C816 87-010-400-080 CAP, ELECT 0.47-50 M
C821 87-010-405-080 CAP, ELECT 10-50V
C823 87-010-177-080 C-CAP,S 820P-50 SL
C824 87-010-404-080 CAP, ELECT 4.7-50V
C825 87-010-596-080 CAP, S 0.047-16
C842 87-010-197-080 CAP, CHIP 0.01-25 K B
C844 87-010-197-080 CAP, CHIP 0.01-25 K B
C850 87-010-260-080 CAP, ELECT 47-25V
C851 87-010-197-080 CAP, CHIP 0.01-25 K B
C852 87-010-197-080 CAP, CHIP 0.01-25 K B
C853 87-010-197-080 CAP, CHIP 0.01-25 K B
C858 87-010-196-080 CHIP CAPACITOR,0.1-25
C859 87-010-196-080 CHIP CAPACITOR,0.1-25
C860 87-010-197-080 CAP, CHIP 0.01-25 K B
C959 87-010-196-080 CHIP CAPACITOR,0.1-25
C960 87-010-196-080 CHIP CAPACITOR,0.1-25
C961 87-010-152-080 C-CAP,S 8P-50 CH
C963 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C971 87-010-381-080 CAP, ELECT 330-16V
C972 87-010-404-080 CAP, ELECT 4.7-50V
C973 87-010-197-080 CAP, CHIP 0.01-25 K B
C974 87-010-197-080 CAP, CHIP 0.01-25 K B
C979 87-010-322-080 C-CAP,S 100P-50 CH
C981 87-010-260-080 CAP, ELECT 47-25V
C982 87-010-196-080 CHIP CAPACITOR,0.1-25
C983 87-010-197-080 CAP, CHIP 0.01-25 K B
C984 87-010-197-080 CAP, CHIP 0.01-25 K B
C987 87-010-197-080 CAP, CHIP 0.01-25 K B
C991 87-010-312-080 C-CAP,S 15P-50 CH
C992 87-010-312-080 C-CAP,S 15P-50 CH
C993 87-010-178-080 CHIP CAP 1000P-50 K B
C995 87-010-178-080 CHIP CAP 1000P-50 K B
C997 87-010-196-080 CHIP CAPACITOR,0.1-25
C998 87-010-260-080 CAP, ELECT 47-25V
C999 87-A11-155-080 CAP,TC U 0.01-16 Z F
CF831 87-008-261-010 FILTER, SFE10.7MA5-A
CF832 87-008-261-010 FILTER, SFE10.7MA5-A
CN301 87-A60-620-010 CONN,3P V 2MM JMT
CN351 87-A60-625-010 CONN,8P V 2MM JMT
CN601 87-099-719-010 CONN,30P TYK-B(X)
CN602 87-A60-131-010 CONN,6P V FE
FC602 88-906-251-110 FF-CABLE,6P 1.25
FFE831 A8-8ZA-190-030 8ZA-1 FEUNM
J202 87-A60-488-010 JACK,DIA6.3 BLK ST W/SW KM16AT
J203 87-A60-238-010 TERMINAL,SP 4P (MSC)
J205 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN
J602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN
J831 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02
L101 87-A50-610-010 COIL,1UH-K(MDEC)
L102 87-A50-610-010 COIL,1UH-K(MDEC)
L451 87-007-342-010 COIL,OSC 85K BIAS
L801 87-A50-608-010 COIL,FM DET-N(TOK)
L802 87-A91-551-010 FLTR,PCFJZH-450 L(TOK)
L811 87-005-847-080 COIL,2.2UH(CECS)
L832 87-005-847-080 COIL,2.2UH(CECS)
L951 8A-NF8-667-010 COIL,AM PACK 4(TOK)
R129 87-A00-669-080 RES,M/F 0.22-2W J RA
R130 87-A00-669-080 RES,M/F 0.22-2W J RA
R131 87-A00-669-080 RES,M/F 0.22-2W J RA
R132 87-A00-669-080 RES,M/F 0.22-2W J RA
R143 87-A00-440-050 RES,220-1/2W J RP
R144 87-A00-440-050 RES,220-1/2W J RP
R145 87-A00-440-050 RES,220-1/2W J RP
R146 87-A00-440-050 RES,220-1/2W J RP
R653 87-A11-144-080 CAP,TC U 0.1-50 K B
R654 87-A11-144-080 CAP,TC U 0.1-50 K B
R790 87-010-197-080 CAP, CHIP 0.01 DM
R991 87-010-322-080 C-CAP,S 100P-50 CH
R993 87-010-322-080 C-CAP,S 100P-50 CH
R995 87-010-322-080 C-CAP,S 100P-50 CH
SFR451 87-A90-432-080 SFR,30K H NVZ6TLTA
SFR452 87-A90-432-080 SFR,30K H NVZ6TLTA
W99 8A-NF9-609-010 F-CABLE,9P 2.5 480MM
WH1 87-A90-510-010 HLDR,WIRE 2.5-9P
X991 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309
FRONT C.B
C101 87-010-196-080 CHIP CAPACITOR,0.1-25
C102 87-010-196-080 CHIP CAPACITOR,0.1-25
C103 87-010-498-040 CAP,E 10-16 M 5L
C104 87-010-196-080 CHIP CAPACITOR,0.1-25
C107 87-010-493-040 CAP,E 0.47-50 M 5L
C108 87-012-393-080 C-CAP,S 0.22-16 K
C153 87-010-198-080 CAP, CHIP 0.022-25 K B
C154 87-010-246-040 CAP,E 47-35 SME
All manuals and user guides at all-guides.com

– 5 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
C155 87-010-404-040 CAP,E 4.7-50 SME
C156 87-010-404-040 CAP,E 4.7-50 SME
C361 87-010-178-080 CHIP CAP 1000P-50 K B
C362 87-010-178-080 CHIP CAP 1000P-50 K B
C371 87-010-178-080 CHIP CAP 1000P-50 K B
C372 87-010-178-080 CHIP CAP 1000P-50 K B
C601 87-010-382-040 CAP,E 22-25 SME
C801 87-010-195-080 C-CAP,S 0.068-25 F
C802 87-010-195-080 C-CAP,S 0.068-25 F
C803 87-010-402-040 CAP,E 2.2-50 SME
C804 87-010-402-040 CAP,E 2.2-50 SME
C805 87-010-196-080 CHIP CAPACITOR,0.1-25
C806 87-010-196-080 CHIP CAPACITOR,0.1-25
C810 87-010-379-040 CAP,E 22-16 M
C901 87-010-322-080 C-CAP,S 100P-50 CH
C902 87-010-322-080 C-CAP,S 100P-50 CH
C903 87-010-322-080 C-CAP,S 100P-50 CH
C904 87-010-322-080 C-CAP,S 100P-50 CH
C905 87-010-322-080 C-CAP,S 100P-50 CH
C906 87-010-322-080 C-CAP,S 100P-50 CH
C907 87-010-322-080 C-CAP,S 100P-50 CH
C908 87-010-322-080 C-CAP,S 100P-50 CH
C909 87-010-322-080 C-CAP,S 100P-50 CH
C910 87-010-322-080 C-CAP,S 100P-50 CH
C911 87-010-178-080 CHIP CAP 1000P-50 K B
C912 87-010-196-080 CHIP CAPACITOR,0.1-25
C913 87-010-248-040 CAP,E 220-10 SME
C914 87-010-248-040 CAP,E 220-10 SME
C915 87-010-196-080 CHIP CAPACITOR,0.1-25
C916 87-010-196-080 CHIP CAPACITOR,0.1-25
C917 87-010-196-080 CHIP CAPACITOR,0.1-25
C919 87-010-197-080 CAP, CHIP 0.01-25 K B
C920 87-012-369-080 C-CAP,S 0.047-50 Z F
C921 87-010-186-080 CAP,CHIP 4700P-50 K B
C951 87-010-312-080 C-CAP,S 15P-50 CH
C952 87-012-155-080 C-CAP 180P-50CH
C953 87-012-140-080 CAP 470P-50 CH
C961 87-010-378-040 CAP,E 10-16 M SME
C962 87-012-157-080 C-CAP,S 330P-50 CH
C963 87-010-196-080 CHIP CAPACITOR,0.1-25
CN104 87-A60-057-010 CONN,11P V 9604S-11C
CN701 87-099-720-010 CONN,30P BLK TYK-B(P)
CN731 87-099-015-010 CONN,13P V BLK 6216V
FC104 88-911-101-110 FF-CABLE,11P 1.25
FC731 88-913-301-110 FF-CABLE,13P-1.25
FL901 8A-NF9-605-010 FL,HNA-10SS12
L951 87-A50-434-010 COIL,CLK 4.19M(TOKO)
LED201 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED202 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED204 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED205 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED209 87-A40-317-080 LED,SLR-342VCT31 RED
LED210 87-A40-619-040 LED,SLR-56PT-T31-W GRN
S301 87-A90-164-080 SW,TACT SKQAB(N)
S302 87-A90-164-080 SW,TACT SKQAB(N)
S303 87-A90-164-080 SW,TACT SKQAB(N)
S304 87-A90-164-080 SW,TACT SKQAB(N)
S305 87-A90-164-080 SW,TACT SKQAB(N)
S306 87-A90-164-080 SW,TACT SKQAB(N)
S307 87-A90-164-080 SW,TACT SKQAB(N)
S308 87-A90-164-080 SW,TACT SKQAB(N)
S309 87-A90-164-080 SW,TACT SKQAB(N)
S321 87-A90-164-080 SW,TACT SKQAB(N)
S322 87-A90-164-080 SW,TACT SKQAB(N)
S323 87-A90-164-080 SW,TACT SKQAB(N)
S324 87-A90-164-080 SW,TACT SKQAB(N)
S325 87-A90-164-080 SW,TACT SKQAB(N)
S326 87-A90-164-080 SW,TACT SKQAB(N)
S341 87-A90-164-080 SW,TACT SKQAB(N)
S342 87-A90-164-080 SW,TACT SKQAB(N)
S343 87-A90-164-080 SW,TACT SKQAB(N)
S344 87-A90-164-080 SW,TACT SKQAB(N)
S345 87-A90-164-080 SW,TACT SKQAB(N)
S346 87-A90-164-080 SW,TACT SKQAB(N)
S347 87-A90-164-080 SW,TACT SKQAB(N)
S348 87-A90-164-080 SW,TACT SKQAB(N)
S349 87-A90-164-080 SW,TACT SKQAB(N)
S350 87-A90-164-080 SW,TACT SKQAB(N)
S361 87-A91-633-010 SW,RTRY XRE012103PVB25FINA 1-2
S371 87-A91-632-010 SW,RTRY XRE012103PVB25FINB 1-2
PT C.B
C183 87-010-387-080 CAP,E 470-25 SME
C184 87-010-403-080 CAP, ELECT 3.3-50V
PT1 8A-NF9-612-010 PT,ANF-9 U
PT181 8A-NF8-661-010 PT,SUB ANF-8 (U)
RY181 87-A91-418-010 RELAY,AC12V G5PA-1-M
T181 87-A60-317-010 TERMINAL, 1P MSC
T182 87-A60-317-010 TERMINAL, 1P MSC
WH181 87-A90-510-010 HLDR,WIRE 2.5-9P
DECK C.B
CN1 87-099-753-010 CONN,11P H 9604
SFR1 87-024-581-010 SFR,3.3K DIA6V K0A
SOL1 82-ZM1-618-410 SOL ASSY,27
SOL2 82-ZM1-618-410 SOL ASSY,27
SW1 87-A90-673-010 SW,MICRO ESE11SH1C
SW2 87-A91-500-010 SW,MICRO MPU11470MLB0
SW3 87-A91-500-010 SW,MICRO MPU11470MLB0
SW4 87-A91-500-010 SW,MICRO MPU11470MLB0
SW5 87-A90-673-010 SW,MICRO ESE11SH1C
!
!
!
!
!
TRANSISTOR ILLUSTRATION
E C B
2SA1981Y
2SC5343G
E
B
C
KRC102S-RTK
KRC104S
All manuals and user guides at all-guides.com

WIRING – 1 (MAIN)
– 6 –
101112131415161718192021222324
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
1234567892526272829303132
All manuals and user guides at all-guides.com
all-guides.com

– 7–
SCHEMATIC DIAGRAM – 1 (MAIN 1 / 2 : AMP)
All manuals and user guides at all-guides.com

– 8–
SCHEMATIC DIAGRAM – 2 (MAIN 2 / 2 : TUNER)
All manuals and user guides at all-guides.com

WIRING – 2 (FRONT)
– 9 –
101112131415161718192021222324
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
1234567892526272829303132
All manuals and user guides at all-guides.com

– 10–
SCHEMATIC DIAGRAM – 3 (FRONT)
All manuals and user guides at all-guides.com

WIRING – 3 (PT)
– 11–
123456789101112131415
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
All manuals and user guides at all-guides.com
all-guides.com

– 12–
SCHEMATIC DIAGRAM – 4 (PT)
All manuals and user guides at all-guides.com

– 13 –
IC BLOCK DIAGRAM
All manuals and user guides at all-guides.com

– 14 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
MECHANICAL PARTS LIST 1 / 1
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange GM Metallic Green
YM Metallic Yellow DM Metallic Orange PT Transparent Pink
12 8A-NF9-211-010 HLDR,PWB PT HI
15 8A-NF9-074-010 WINDOW,DISP U J22
24 8A-NF9-010-110 KEY,ASSY OPE 1 WAY
25 8A-NF9-020-110 KEY,CD
27 8A-NF9-026-110 KEY,ENTER
32 86-NF6-211-010 HLDR,IC T1.6
39 8A-NF9-619-010 PT,ANF-9 U HI
43 8A-NF9-073-010 CABI,REAR USM J22
!
All manuals and user guides at all-guides.com

– 15 –
TAPE MECHANISM EXPLODED VIEW 1 / 1
ATERMINAL,LB1
AA
B
TERMINAL,
LB1
1
2
3
4
5
5
6
6
7
8
9
9
10
11
10
11
12
12
13
13
14
14
15
15
16
16
18
18
19
19
20
20
21
21
30
22
23
24
25
26
27
28
22
23
24
25
26
27
28
29
31
32
33
34
35
36
37
37
38
38
39
39
40
41
42
43
44
51
52
45
46
47
48
49
50 53
54
54
17
55
30
35
29
31 32
33
52
51
44
45
43
42
IC, EW732
IC, EW732
b
a
a
b
cc
40
41
46
47
48
49
P.C.B
All manuals and user guides at all-guides.com

– 16 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
TAPE MECHANISM PARTS LIST 1 / 1
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
1 8Z-ZM3-227-010 BELT,MAIN M3
2 8Z-ZM3-235-010 BELT,MAIN L
3 8Z-ZM1-235-010 PULLEY,MOT
4 87-045-347-010 MOT,SHU2L 70
5 8Z-ZM1-232-010 GEAR,IDL FF/REW
6 8Z-ZM3-244-010 GEAR,CAM TD20
7 8Z-ZM3-256-010 FLY-WHL ASSY,M3 R
8 8Z-ZM3-255-010 FLY-WHL ASSY,M3 L
9 8Z-ZM3-231-010 SPR-T,TRIG
10 8Z-ZM3-213-010 CLR,MG
11 82-ZM3-616-010 RING MAGNET 4
12 8Z-ZM3-243-010 LEVER ASSY,HD UP
13 8Z-ZM3-238-010 SPR-T,HD UP
14 8Z-ZM3-219-010 GEAR,CAM M3
15 8Z-ZM3-206-010 LEVER,TRIG
16 8Z-ZM3-209-010 LEVER,CAM FR
17 8Z-ZM3-203-010 CHAS ASSY,M3
18 8Z-ZM1-228-010 GEAR,SLIP T-UP B
19 8Z-ZM1-265-010 FELT,T-UP
20 8Z-ZM1-227-010 GEAR,SLIP T-UP A
21 8Z-ZM1-251-110 SPR-C,T-UP SLIP
22 8Z-ZM1-275-010 W-L,1,47-4-0.25
23 8Z-ZM1-257-010 SPR-C,F/R
24 8Z-ZM1-236-010 CLR,SLIP FF/REW
25 8Z-ZM3-226-010 SPR-C,FR M3
26 8Z-ZM3-250-010 GEAR,SLIP F/R A M3
27 8Z-ZM1-269-010 FELT,FF/REW 2
28 8Z-ZM1-238-110 GEAR,SLIP FF/REW B 2
29 8Z-ZM3-220-010 LEVER,FR M3
30 8Z-ZM3-205-010 LEVER,PLAY M3
31 8Z-ZM3-233-010 SPR-T,BRG M3
32 84-ZM2-227-310 SPR-C,AZIMUTH
33 87-A90-403-110 HEAD,RPH MS15R
34 87-A90-404-010 HEAD,EH LE15B
35 8Z-ZM3-239-010 SPR-E,FR
36 8Z-ZM3-211-010 LEVER,EJECT R
37 8Z-ZM3-225-010 LEVER,STOP
38 8Z-ZM3-221-010 LEVER,CAS
39 8Z-ZM3-234-010 SPR-T,LVR CAS
40 8Z-ZM3-223-010 SPR-C,REEL R M3
41 8Z-ZM1-225-110 GEAR,REEL R
42 8Z-ZM3-240-010 SPR-T,T-UP M3
43 8Z-ZM3-237-010 SPR-T,PINCH M3
44 8Z-ZM3-215-010 LEVER,PINCH M3
45 8Z-ZM1-261-110 ROLLER ASSY,PINCH
46 8Z-ZM1-226-010 GEAR,REEL L
47 8Z-ZM3-222-010 SPR-C,REEL L M3
48 8Z-ZM3-251-010 GEAR,IDL REW M3
49 8Z-ZM3-236-010 SPR-T,PLAY M3
50 82-ZM1-240-110 LVR,REC(*)
51 8Z-ZM3-216-010 LEVER,T-UP M3
52 87-B10-301-010 W-L,1.63-3.2-05 SLIT
53 8Z-ZM3-212-010 LEVER,EJECT L
54 8Z-ZM3-214-010 HLDR,IC
55 86-ZM3-605-110 CONN ASSY,8P -RPB
A 84-ZM2-242-010 S-SCREW,AZ1-2-6.4
B 8Z-ZM2-220-110 V+2.6 ZZM-2
All manuals and user guides at all-guides.com
all-guides.com

– 17 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
ACCESSORIES / PACKAGE LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
1 8A-NF9-913-010 IB,U(ESF)M -AJ22(SUR)
4 87-006-225-010 AM,LOOP ANT NC2
SPEAKER PARTS LIST
SX-NAJ33 (YUSL)
1 8A-NSK-001-010 PANEL,FR
2 8A-NSK-003-010 GRILLE,FRAME ASSY
3 8A-NSK-007-010 PROTECTOR,TWA
4 87-NSH-612-010 SPKR,CERAMIC ASSY
5 87-NS7-611-010 CORD,SPKR
6 8A-NSJ-602-010 SPKR,W 130
7 8A-NSK-604-010 SPKR,TW 60
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
SPEAKER PARTS LIST
SX-R140 (YUSC)
1 8A-YS4-001-010 GRILLE,FRAME ASSY
2 81-VSA-010-010 SPKR,CORD
3 87-010-384-010 CAP,E 100-25 M SME
4 8A-YS4-610-010 CORD,SPKR 3.5
5 8A-YS4-601-010 SPKR,80
All manuals and user guides at all-guides.com

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:[phone]
Printed in Singapore9820543 0251431
All manuals and user guides at all-guides.com
