TECH SPECS
Number of buttons 4
Panic button Yes
Radio signal Up to 1,300 m
(any obstacles absent)
Power supply 1 battery CR2032A, 3 V
Service life from
the battery
Up to 5 years (depending
on the usage frequency)
Operating temperature range From -20°С to +50°С
Overall dimensions 65 х 37 x 10 mm
Operating humidity Up to 90%
Weight
Frequency band 868.0-868.6 mHz
Maximum RF output Up to 20 mW
Modulation FM
13 g
Quick Start Guide EN
Two-way wireless key fob
SpaceControl is a security system control key fob. It can arm and
disarm and can be used as a panic button.
IMPORTANT: This Quick Start Guide contains general
information about the SpaceControl. Before using the
device, we recommend to reviewing the User Manual on the
website:
ajax.systems/support/devices/spacecontrol
Key fob
Model Name: Ajax SpaceControl
FUNCTIONAL ELEMENTS
Assignment of the buttons in
using the key fob with Ajax Hub
and Ajax uartBridge. At the
moment, the feature of
modification of commands of
the fob buttons when using with
the Ajax Hub is not available.
1 - System arming button.
2 - System disarming button.
3 - Partial arming button.
4 - Panic button (activates the
alarm).
5 - Light indicators.
KEY FOB CONNECTION
QR is located on the interior side of the device box cover and
inside the body at the battery attachment.
For the pairing to occur, the key fob and the hub should be located
within the same protected object.
To connect the key fob to a third party security central unit using
the Ajax uartBridge or Ajax ocBridge Plus integration module, follow
the recommendations in the user manual of the respective device.
The key fob is connected and set up via the Ajax Security System
mobile application (the process is supported by prompt
messages). For the key fob to become available for detection, at
the time of adding the device, simultaneously press the arming
button and the panic button .
SpaceControl operates with a single reciever device only (Hub,
bridge).
The fob can:
USING THE KEY FOB
To mute the actuated security system (siren), press the disarming
button on the fob.
Set the system to the armed mode - press the button .
Set the system to the partially armed mode - press the button .
Disarm the system - press the button .
Switch on an alarm - press the button .
The fob has protection against accidental buttons presses. Very
fast pressings are ignored, to operate the button it is necessary to
hold it for a while (less than quarter of a second). The
SpaceControl lights the green light indicator when a hub or
integration module receives a command and red light when
command is not received or not accepted.
For more detailed description of light indication refer to User
Manual.
1. SpaceControl.
2. Battery CR2032 (pre-installed).
3. Quick Start Guide.
COMPLETE SET
WARRANTY
Warranty for the Ajax Systems Inc. devices is valid for 2 years
after the purchase and does not apply to the supplied battery.
If the device does not work correctly, you should first contact
the support service—in half of the cases, technical issues can
be solved remotely!
The full text of the warranty is available on the website:
ajax.systems/ru/warranty
Technical support:
[email protected]
User Agreement:
ajax.systems/end-user-agreement
This product can be used across all EU member states.
CAUTION: RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS
IMPORTANT INFORMATION
This device in compliance with the essential requirements and
other relevant provisions of Directive 2014/53/EU.
All essential radio test suites have been carried out.
Manufacturer: Research and Production Enterprise “Ajax” LLC
Address: Sklyarenko 5, Kyiv, 04073, Ukraine
By request of Ajax Systems Inc.
www.ajax.systems
