alfen Twin 4XL - V2G User manual

EV Charging Stations
Installation and User Manual
-
Twin 4XL - V2G

Table Of Contents1. Safety and usage instructions 3
1.1 Purpose and intended audience 3
1.2 Explanation of text instructions used 3
1.3 General safety 3
1.4 Disclaimer 3
1.5 Copyright 4
1.6 Service 4
1.7 EU Declaration of Conformity 4
2. Product overview 5
2.1 Exterior view 5
2.2 Interior view 6
2.3 Legend product overview 8
2.4 Identification label 8
2.5 Operating conditions 8
2.6 Operation 9
2.6.1 Start and stop charging with charge card 9
2.6.2 Start and stop charging with Plug&Charge 9
2.7 User interface 9
3. Installing and connecting 11
3.1 Safety announcements 11
3.2 Assembly and installation requirements 11
3.3 Preparation prior to installation 12
3.4 Scope of delivery 12
3.5 Accessories 13
3.6 Installation tools 13
3.7 Installation prerequisites 13
3.8 Mechanical installation procedure 13
3.8.1 Foundation for ground mounting 13
3.8.2 Inserting ground cable and earth cable 13
3.8.3 Mounting the charging station onto the
base 14
3.9 Electrical installation procedure 14
4. Commissioning 16
4.1 Safety instructions before use 16
4.2 Commissioning Twin 4XL V2G 16
4.2.1 Testing the socket(s) 16
5. Connectivity 17
5.1 Preparation prior to configuration 17
5.2 Configuring the charging station 17
5.2.1 Wired network connection 17
5.2.2 Back office management systems 17
6. Waste electrical and electronic
equipment (WEEE) 19
I
TABLE OF CONTENTS
EN
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU

Safety and usage instructions1.1 Purpose and intended audience
This manual applies to the Twin 4XL V2G (the charging
station) produced by Alfen ICU B.V., Hefbrugweg 28,
1332AP Almere, the Netherlands, reg. no. 64998363
(“Alfen”). The Alfen Twin 4XL V2G is intended exclusively
for charging electric vehicles and, when installed correctly,
may be used by untrained individuals. Follow this manual to
install and commission the charging station correctly.
Installation, commissioning and maintenance of this
charging station may only be performed by a qualified
electrician. It is essential that the qualified technician has:
•Expertise on all relevant general and specific rules
regarding safety and incident prevention
•Comprehensive knowledge of applicable electrical
regulations.
•The ability to identify risks and avoid potential hazards
•Received and read these installation and operation
instructions
1.2 Explanation of text instructions used
Safety warnings and precautions regarding Twin 4XL V2G
are indicated in this document as follows:
DANGER
Signal word used to indicate an imminently hazardous
situation which, if not avoided, will result in death or serious
injury.
WARNING
Signal word used to indicate a potentially hazardous
situation which, if not avoided, could result in death or
serious injury
CAUTION
Signal word used to indicate a potentially hazardous
situation which, if not avoided, could result in minor or
moderate injury.
NOTE
Signal word used to provide additional information or
information on possible product damage.
1.3 General safety
Make sure to follow the stated safety aspects at all times:
DANGER
Do not use the charging station in the vicinity of explosive
or highly flammable substances.
DANGER
Do not use the charging station if it is partially submerged
in water.
DANGER
Do not use the charging station if it is damaged or plugs
and cables are defective. Contact the charge point operator
to repair the defects immediately.
DANGER
Keep away children or individuals who are not able to
assess the risks associated with using this product.
More extensive safety information is available in the
relevant sections of this document.
1.4 Disclaimer
This document has been subjected to rigorous technical
review before being published. It is revised at regular
intervals, and any modifications and amendments are
included in the subsequent issues. Although Alfen has
made its best efforts to keep the document as precise and
up-to-date as possible, Alfen does not assume any liability
for defects and damage which results from the use of the
information contained herein.
NOTE
This manual is subject to updates and changes. The latest
version will always be available for download on https://
knowledge.alfen.com or Alfen.com. Errors and omissions
excepted.
Any deviation to the products as assembled by
Alfen including, but not limited to, customer-specific
modifications to the product such as the placement of
stickers, SIM cards or the usage of different colors (all
referred to as 'Customization') may affect the final product,
its experience, appearance, quality and / or lifespan (the
Customized Product). Alfen is not liable for any damage
to, or caused by, the Customized Product if this damage is
caused by this applied Customization.
EN
3
1. SAFETY AND USAGE INSTRUCTIONS
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU

Alfen ICU B.V. shall not be liable in any way, for any kind of
damage, and the (carry in) warranty for the product and the
accessories shall not apply in the following cases:
•Failure to comply with the instructions in this manual in
general and with the operating conditions specifically.
•Improper use.
•External damage.
•Installation, commissioning or faulty repair or
maintenance by unqualified persons.
•Failures from the grid or the GPS / GPRS provider.
•Modification or configuration of the product or
accessories without the knowledge of Alfen ICU B.V..
•Use of spare parts not approved or manufactured by
Alfen.
•The charging station is used outside its operating
conditions as stated in this manual.
•Situations have occurred that are beyond the control of
Alfen ICU B.V. (force majeur).
•Malfunction of an open charge point back office.
•Damage to the electrical vehicle.
1.5 Copyright
Copyright ©2022 Alfen ICU B.V. All rights reserved. The
disclosure, duplication, distribution and editing of this
document, or utilization and communication of the content
are not permitted, unless authorized in writing by Alfen.
All rights, including rights created by a patent, grant or
registration of a utility model or a design, are reserved.
The English version of this manual is the original source
document. Manuals in other languages are translations of
this source document.
Twin 4XL V2G is a trade mark by Alfen ICU B.V. Any
unauthorized use of the trade mark is therefore illegal.
1.6 Service
The Alfen Twin 4XL V2G charging stations are serviced by
the local charge point supplier. Your charge point supplier
provides support to you. When contacting your charge
point supplier, always have the serial number of your
charging station available to facilitate quick support.
Optionally you can find support for all our products on
https://knowledge.alfen.com.
1.7 EU Declaration of Conformity
The Twin 4XL V2G complies to the following directives:
•Low Voltage Directive 2014/35/EU
•EMC Directive 2014/30/EU
•Harmonized standards: IEC 61851-1 ed. 3 (2017) -
Electric vehicle conductive charging system - General
requirements, on national level implemented under:
AT: ÖVE/EN 61851-1
BE: NBN EN 61851-1
DE: DIN-EN 61851-1
FIN: SFS-EN 61851-1
FR: NF-EN 61851-1
NL: NEN-EN-IEC 61851-1
NO: NEK-EN-61851-1
UK: BS-EN 61851-1
NOTE
The EU declaration of conformity can be requested from
Alfen. Please refer to the contact data on the backpage of
this manual.
1. SAFETY AND USAGE INSTRUCTIONS
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU
4
EN

Product overview2.1 Exterior view
5
5
1
2
3
4
5
5
5
6
7
8
Figure 2.1: Overview of the exterior (legend see following pages)
EN
5
2. PRODUCT OVERVIEW
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU

2.2 Interior view
4
7
1
2
3
4
5
4
3
1
6
Figure 2.2: Overview of the interior (variant A) (legend see following pages)
2. PRODUCT OVERVIEW
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU
6
EN

4
10
1
1
33
8
8
9
7
Figure 2.3: Overview of the interior with grid connection box (variant B) (legend see following pages)
EN
7
2. PRODUCT OVERVIEW
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU

2.3 Legend product overview
Exterior view
1 Charge point Identifier (customer specific label)
2 LED / charge card (RFID) interface
3 Charge card reader
4 Quick start instructions
5 Type 2 socket
6 Door handle
7 Cylinder for grid operator
8 Cylinder for end customer
Interior view
1 Power meter
2 Identification label
3 Type B residual current device (RCD)
4 Fuses
5 Main switch
6 Space for installation of grid connection box
7 Strain relief
8 Miniature circuit breaker (MCB)
9 Residual current circuit breaker (RCCD)
10 Grid connection box
123
Figure 2.4: Detailed illustration of component location
No. Description
1 SIM card holder
2 External power meter connection (RS-485)
3 UTP / Ethernet connections
2.4 Identification label
The identification label shows the following information:
IP54 IK10
Hefbrugweg 28
1332 AP Almere
Nederland
www.Alfen.com
Made in the Netherlands by
Warning! before providing access to electrical components
all power supplies must be disconnected
AHWP01-52599
RATING: 400V.50Hz 64A 3F+N+PE -25°C +40°C
TYPE: 934452599
ACE0180026
Class I
1
2
3
4
Figure 2.5: Identification label
No. Description
1 Type number (consisting of the platform name
and the last five digits of the article number)
2 Article number
3 Unique number (per charging station)
4 Technical specifications (such as the number of
phases, maximum charging current and voltage)
NOTE
When contacting your charge point supplier / operator,
always have your serial number available to facilitate quick
support.
2.5 Operating conditions
Operating temperature -25°C tot 40°C
Relative atmospheric hu-
midity
5 - 95%
Protection category I
2. PRODUCT OVERVIEW
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU
8
EN

Degree of protection (cas-
ing)
IP54
IK protection IK10
2.6 Operation
2.6.1 Start and stop charging with charge card
4
3
2
1
Figure 2.6: Starting the charging process with user authorization. Symbols shown
on the user interface
No. Description
1 Plug the charging cable into the car
2 Plug the charging cable into the charge
point
3 Scan the charge card on the charging sta-
tions RFID-interface
4 Charging in progress
4
3
2
1
Figure 2.7: Stopping the charging process. Symbols shown on the user interface
No. Description
1 Scan the charge card on the charging sta-
tions RFID-interface
2 Remove the charging cable from the charge
point
3 Remove the charging cable from the car
4 Leave the charging place
2.6.2 Start and stop charging with Plug&Charge
Figure 2.8: Starting the charging process without charge card. Symbols shown on
user interface
No. Description
1 Plug the charging cable into the car
2 Plug the charging cable into the charge
point
3 Charging in progress
3
2
1
Figure 2.9: Stopping the charging process without charge card. Symbols shown
on user interface
No. Description
1 Remove the charging cable from the car
3 Remove the charging cable from the charge
point
4 Leave the charging place
2.7 User interface
8
7
6
5
4
3
2
1
Figure 2.10: Display of with LED’s (left socket active in this illustration)
EN
9
2. PRODUCT OVERVIEW
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU

No. Description
1 Charging station indication
2 Charge card accepted, cable connected
3 Communication with vehicle or charging com-
pleted
4 Charging in progress
5 Error message
6 Operating steps to start the charging process
7 Charge card reader (RFID interface)
8 Operating steps to stop the charging process
2. PRODUCT OVERVIEW
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU
10
EN

Installing and connecting3.1 Safety announcements
DANGER
Installing the charging station incorrectly may result in
fatal injury! When working with electricity, failure to comply
with relevant regulations can lead to dangerous and life-
threatening situations.
DANGER
The electrical system must be disconnected from every
power source before performing any installation or
maintenance work!
DANGER
The charging station contains electrical components that
still contain a charge after being disconnected from the
system. Always wait 10 seconds after powering down
before commencing to work.
DANGER
Never install in a potentially explosive atmosphere.
DANGER
Never install in areas prone to flooding without
implementing compensatory measures.
WARNING
This work may not be carried out during rain or if air
humidity exceeds 95%.
WARNING
The installation must be performed by a qualified
electrician who has read this manual and will execute the
installation in accordance with the IEC 60364 (Electrical
Installations for Buildings) standard.
WARNING
A charging station must always be installed on separate
power circuit.
WARNING
Local conditions may influence the installation
requirements. Your installation must comply with the
standards and regulations of the location (country) where it
is installed.
WARNING
The installer is always responsible for choosing the correct
cable diameter and complying with the relevant standards
and legislation.
WARNING
The installation and cables should be installed to match
the maximum charging current to the input of the charging
station. This should assume continual load.
WARNING
Protect Alfen products installed in public areas and car park
sites from mechanical impact and/or collisions which can
cause damage to the equipment.
WARNING
Adapters or conversion adapters are not allowed to be
used.
CAUTION
Installation, commissioning and maintenance of the
charging station may only be performed by a qualified
electrician.
3.2 Assembly and installation requirements
When selecting a location to install the charging station,
the following criteria must be met:
•Always fully comply with local technical requirements
and safety regulations
•An on-site connection has been prepared that complies
with the specifications of the charging station.
•The installation site must have a leveled and solid
foundation or, if the charging station is installed into
the ground, preparing the foundation is part of the
installation process.
•A maximum temperature difference within 24 hours of
< 35 °C
EN
11
3. INSTALLING AND CONNECTING
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU

Please refer to the following table for safety options and
cable cross-sections advised.
Power supply cable: minimum advised cable cross-section
(based on assumed max. 50m cable length)
•11kW charging, 16A selected per phase: 5 x 4mm2
•22kW charging, 32A selected per phase: 5 x 6mm2
•Maximum cross-section: 35mm2
Short-circuit protection:
•Integrated in grid connection box (in case of direct
installation to grid), or
•Installation on the local low-voltage distributor:
•With circuit breakers: 80A, 3P, type B or C
•With fuses: 3 x 80A gG. In case of gG fuses it is
possible to apply 64A (minimum)
Earth leakage protection: (possibly in combination with
circuit breaker)
•Integrated in charging station, with grid connection box
(in case of direct installation to grid), or:
•Optional residual current device: 100mA S (Selective),
type A, 4P. Applicable for: 22kW charging: 80A
Nominal input voltage:
•VL1-N: 230V (+/-10%)
•VL2-N: 230V (+/-10%)
•VL3-N: 230V (+/-10%)
•VL1-L2: 400V (+/-10%)
•VL1-L3: 400V (+/-10%)
•VL2-L3: 400V (+/-10%)
•VPE-N: ≈ 0V
Nominal frequency:
•50 Hz
Grounding:
•TN system: PE cable TT system: separately installed
•grounding electrode <100Ohm spreading resistance
•IT system: connected to a shared reference (common
earth) with other metal parts
3.3 Preparation prior to installation
•View the site and determine the installation location.
•Check the scope of delivery and required parts.
•Read this installation manual before hand.
•Download the data sheet on Alfen.com for product-
specific information.
•Download the Smart Charging Implementation Guide
on knowledge.alfen.com for detailed information on
configuring Smart Charging options.
3.4 Scope of delivery
The scope of delivery provides:
•charging station
•Installation manual and assembly supplies
•Charge cards (depending on selected options).
•Charge point password
8
7
6
5
4
3
2
1
Figure 3.1: Bottom plate with mounting material
3. INSTALLING AND CONNECTING
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU
12
EN

No. Description Quantity
1 Cable clamp 1
2 Grommet for ground cable 1
3 Connection nut 1
4 Grommet for Ethernet Smart
Charging network cable
1
5 Grommet for main power supply 3
6 Grommet for power supply Smart
Charging Network
1
7 Base plate gasket 2
8 Base plate 1
3.5 Accessories
Item / Article no. Dimensions Weight
Concrete base
833829300-ICU
570x350x220mm 42 kg
Metal base
803828601-ICU
598x204x300mm 7.8 kg
Extra RFID-card
203120010-ICU
3.6 Installation tools
•Level
•Shovel
•Stanley knife
•Phillips screwdriver
•Wire stripper
•Socket set / spanners
3.7 Installation prerequisites
Verify the delivery scope regarding the locks:
The door handle of the charging station is provided with 2
locks:
•the left lock is for the owner of the charging station,
•the right lock is for the grid operator.
1. Slide the protection from the lock: the charging station
may contain 1, 2 or no cylinder lock(s).
2. Open the lock with the key(s) (or passkey provided if no
cylinders are installed).
3. Pull out the handle.
4. Turn the handle counter-clockwise to open the door.
3.8 Mechanical installation procedure
3.8.1 Foundation for ground mounting
1. Dig a hole of approx. 500 x 500 mm and 550 mm deep
and level out horizontally.
2. Position the base and level it.
3. Place the supplied cable glands and cutting glands on
the sealing plate. Place the whole assembly on the
bottom of the charging station
4. Provide an earth electrode or earth pin, depending on
the local regulations.
3.8.2 Inserting ground cable and earth cable
1. Make a provision in the form of a main grounding rail
right at the bottom of the charging station to ground
the charging station. (This applies to both: a PE cable
and an earthing pin)
2. Pass the ground cable through the conduit, concrete
base and tulle in the sealing plate.
3. Leave an overhang from the top of the base of at least
250 mm. Due to the mounting of the strain relief it is
recommended to cut the cable only when the charging
station is mounted on the base.
4. Pass the earthing cable, coming from the earthing pin,
through the base and swivel into the sealing plate (see
position 3 in figure 3.2).
EN
13
3. INSTALLING AND CONNECTING
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU

3.8.3 Mounting the charging station onto the base
3
2
1
1
2
3
Figure 3.2: Exploded view of charging station to be mounted on base
1. Insert the four threaded M10x80 mm rods supplied
into the sockets on the base (see position 1 in figure
3.2).
2. Place the gasket over the threaded ends and the
sealing plate (see position 2 in illustration).
3. Place the charging station on the base over the wire
ends and over the power supply cable and ground
cable.
4. Cut the cable grommet to size, so that the power
supply cable is firmly clamped in place.
5. Guide the power supply cable through the bottom
plate. Pull the power supply cable to the outside of the
charging station to fit the strain relief provided.
6. Mount the strain relief.
7. Guide the power supply cable back into the charging
station / base. Make sure that 250 mm cable length
remains in the charging station.
8. Fasten the charging station to the base as shown in
figure with the provided 4 M10 nuts including lock and
V-rings.
9. Secure the charging station to the base with 4
M10x80 mm studs.
3.9 Electrical installation procedure
1. Remove the sheath from the power cable with a
Stanley knife and remove the sheaths from the loose
wires with a wire stripper.
2. Connect the earth pin.
3. The earthing sleeve / earthing wire of the distribution
system operator may only be used as an earthing
device with the written consent of the system
operator;
4. According to your installation requirements, make sure
the grounding resistance of the system is set to one of
the following values:
a. <100Ohm (requirement by EV/ZE Ready 1.4I
certification);
b. <167Ohm (requirement Dutch NEN1010
directive);
c. according to the values stated in the legal
regulations of your country.
5. According to product variant disconnect the charging
station from voltage source:
a. Make sure the main switch is in the OFF (0)
position, or
b. Make sure the main residual current circuit breaker
(RCCB) is in the OFF (0) position
6. According to product variant disconnect the charging
station from voltage source:
a. Remove the fuses in the distribution system
operator cabinet of the charging station, or
b. Switch the circuit breakers (MCB) to the OFF (0)
position;
7. According to product variant:
a. Connect the wires of the phases to the fuse
holders, or
b. to the circuit breakers (MCB) in the distribution
system operator cabinet of the charging station
including standard grid connection. (PE on
separate rail)
8. Connect the provided cable clamp to the plate provided
at the back wall inside of the charging station (see
figure 2.2 and 2.3 position 7) ensuring strain relief on
the cable.
3. INSTALLING AND CONNECTING
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU
14
EN

9. According to product variant connect the charging
station to voltage source:
a. Place fuses (if supplied) in the fuse holders and
close the holders, or
b. Switch the circuit breakers (MCB) to the ON (I)
position.
10. According to product variant connect the charging
station to voltage source:
a. Make sure the main switch is in the ON (I)
position, or
b. Make sure the main residual current circuit breaker
(RCCB) is in the ON (I) position.
11. If a transparent cover is supplied for the internal
components, fit it with the bolts supplied.
12. Close the door and make sure it is securely locked.
EN
15
3. INSTALLING AND CONNECTING
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU

Commissioning4.1 Safety instructions before use
Carry out the following safety instructions before
commissioning your charging station:
1. Make sure the charging station is properly connected
to the power supply as described in this manual.
2. Make sure the distribution of the power supply
is separately protected by an appropriate breaker
(automatic or fuse cartridges)
3. Make sure the charging station is installed in
accordance with this manual.
4. Make sure the casing is always closed during normal
operation.
4.2 Commissioning Twin 4XL V2G
1. Turn on the local power supply.
The charging station will now run self diagnostics.
All interface LED’s will flash briefly. The following
background operations will occur within a few seconds:
-The sockets are tested one by one (locking and
unlocking).
-The internal relays are tested: audible by clicking
noise.
-The symbols will flash twice.
The charging station is now ready for testing.
4.2.1 Testing the socket(s)
1. Put the test charging cable in one of the sockets.
The symbol illuminates. The hourglass symbol
flashes.
2. Hold the charge card in front of the (RFID) card reader
to start charging.
The symbol flashes. Then the hourglass symbol
illuminates and the charging symbol illuminates.
The socket is now functional.
3. Hold the charge card in front of the (RFID) card reader
to stop charging.
The hourglass symbol illuminates. The symbol
illuminates.
4. Pull out the test charging cable.
The socket is now ready for use.
5. Do the same procedure for the other socket.
4. COMMISSIONING
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU
16
EN

Connectivity5.1 Preparation prior to configuration
1. Make sure the charging station is equipped with the
newest firmware.
2. Download the MyEve app in Google Play, Apple Store
or Windows Store to your laptop, tablet or smartphone.
Google Play Apple Store Microsoft Store
3. Create an account.
4. If you have the MyEve app already installed, make sure
you have the latest version. Use the above QR-codes
to see if your app needs to be updated.
5. Make sure the Firewall settings on your laptop, tablet
or smartphone are not blocking the MyEve app.
5.2 Configuring the charging station
The charging station can be accessed and configured
with the MyEve app via a wireless or a wired network
connection.
NOTE
Currently the communication between the MyEve app and
the charging station is only possible via a wired connection.
The MyEve app will guide you step-by-step through the
configuration process.
5.2.1 Wired network connection
How to establish a wired network connection by
connecting the charging station to your laptop, tablet or
smartphone using an UTP (Ethernet) cable:
The minimum requirement is a CAT5 UTP (Ethernet) cable
NOTE
For the use of a smartphone or tablet an adapter such as a
USB-C to Ethernet or Lightning to Ethernet is required.
1. Log into the MyEve app.
2. According to product variant disconnect the charging
station from voltage source:
a. Make sure the main switch is in the OFF (0)
position, or
b. Make sure the main residual current circuit breaker
(RCCB) is in the OFF (0) position
3. Connect the UTP (Ethernet) cable to your router or
directly to the charging station.
4. Connect the UTP (Ethernet) cable with the
corresponding port.
5. Connect your laptop, tablet or smartphone to the
switch or router or directly to the charging station.
6. According to product variant connect the charging
station to voltage source:
a. Make sure the main switch is in the ON (I)
position, or
b. Make sure the main residual current circuit breaker
(RCCB) is in the ON (I) position.
7. Select your charging station from the list in the MyEve
app.
NOTE
If the charging station(s) is (are) not detected
automatically, the MyEve app might be blocked by the
Firewall on your laptop, tablet or smartphone. Check
the settings and try again.
8. Enter the provided password.
The network connection has now been established.
Via the MyEve app you can configure the settings
9. After finishing the configuration, hand over the card
with password (recovery) information to the customer.
5.2.2 Back office management systems
If additional services by a back office provider have been
purchased, the charging station has been configured
ex-factory to connect to the selected back office
management system.
NOTE
A connection with a backoffice management system can
only be established if arrangements with the supplier of
this system have been made. The service of third parties is
not provided by Alfen.
EN
17
5. CONNECTIVITY
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU

NOTE
If the charging station is set to connect with a
backoffice management system, it will do so directly and
automatically.
NOTE
Manually configurating and connecting to a backoffice
management system can be done with the MyEve. A SIM
card needs to be installed during installation. If you do not
have a SIM card, please contact your backoffice provider.
NOTE
If a mobile communication (SIM card) Internet connection
has been purchased, the charging station is already
equipped with a SIM card and will automatically connect,
once the charging station is being commissioned.
5. CONNECTIVITY
Alfen ICU B.V. | Installation and User Manual | Twin 4XL - V2G | EV Charging Stations | V1.2 | EN | October 2022 | 203130172-ICU
18
EN
