8Eve model 2017 (2.0) manual | Version 1.0 | July 2017
ENGLISH
2. PRODUCT
2.1 The charging station
Pages 2 and 3 of this manual contain corresponding
images of the charging station. This section provides more
information about the content of the product and how use
it to charge your vehicle.
The charging station (outside, ref. page 2)
1
2Colour display
3RFID card reader and authorisation indicator
4Type 2 plug connection
5Cable gland(s) for power cable(s), entry
6Grommets for outgoing cables
7Port for Service Installer/ UTP cable
8
The charging station (inside, ref. page 3)
9Threaded holes for wall mounting
10 SIM card holder (ref. image 7 for
detailed location)
11 UTP (Ethernet) connection
12 Connector P1 port
13 Connector for the display
14
(model 904461002: 8-pole)
8
date and serial number. This label is located on the bottom
of your charging station. Please have your serial number
available while contacting Alfen to enable quicker support.
2.2 Display status indications
The Alfen Eve is equipped with a colour display to visualise
the status of the charging station and inform the user
about the charging progress.
23-10-2017 12:30
Please hold card over
reader below
To stop charging, please hold
card over reader below
Charging in progress
22kW
01:23h
11.0kW 22.67kWh
1
2
3
7
4
5
8
9
6
Image 1: Eve display during charging (on the left).
General charging station information
1
administration system, or during installation with the
remains invisible.
Status and information screen
The charging station informs the user about its actual
status and provides feedback on input and actions. The
following information is available:
2Status information
3Status indicator, options
Charge card
accepted, cable
connected
Communicating with
vehicle or charging
completed
Charging Error
--kW
--,--h
--kW --,--kWh
4Maximum charging capacity of the socket
5Current charging capacity for the connected vehicle
6Currently consumed energy during the current
transaction
7Duration of the current transaction
8Logo: shown across the entire width of the display if
both sockets are available, or smaller on the available
side if one socket is being used.
Instruction box
9User instructions for each user are shown here. In case
of an error, an error code is shown (ref. Appendix 1 for
more information).
