Allen + Roth 1138-2 User manual

ITEM #0147672
MODEL #1138-2
Français p. 8
Español p. 15
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
1
40 IN. ROUND BAR TABLE
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Friday.

PACKAGE CONTENTS
2
B
B
B
BC
D
E
F
A
G
PART DESCRIPTION QUANTITY
A Slate Table Top 1
B
Table Leg 4
C
Body Ring 1
D
Foot Ring 1
E
Glass Top 1
F
Lighting Unit 1
G
Lighting Unit Top Ring 1

HARDWARE CONTENTS (shown actual size)
3
Big washer
Qty. 4
EE
Small washer
Qty. 8
DD
Long bolt
Qty. 4
AA
Short bolt
Qty. 4
BB
Medium bolt
Qty. 8
CC FF
Bolt cap
Qty. 12
GG
Allen key
Qty. 1
SAFETY INFORMATION
WARNING
• Do not mix old and new batteries. Do not mix alkaline, standard (Carbon-Zinc), or rechargeable
(Nickel-Cadmium) batteries.
• If you find any noise, excessive temperature or leakage from a battery, please discard.
• When not using the unit for a considerable period of time, disconnect the batteries from the unit
for storage.
• If battery power is weak during use, switch off the device and dispose of batteries.
Please read and understand this entire manual before attempting to assemble, operate or install
the product.

ASSEMBLY INSTRUCTIONS
4
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not attempt
to assemble the product.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly:Allen key (included).
1. Attach the table legs (B) to the foot ring (D)
with the long bolts (AA) using the Allen key
(GG).
Hardware Used
x 4 B
AA D
AA
1
Long bolt
CAUTION
• Assemble on a soft, non-abrasive surface.
• Don’t fully fasten the bolts until all bolts are in place.
• Changes or modifications not approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures：
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.

5
3. Place the slate table top (A) face down on
a non-abrasive surface and attach the
table leg assembly using the short bolts
(BB) and big washers (EE). When all bolts
are in place, tighten them fully. Cover the
long bolts (AA) and the medium bolts (CC)
with bolt caps (FF).
Hardware Used
x 4
x 12
x 4
3
BB
EE
FF
BB
EE
B
A
A
G
4
A
B
D
F
E
G
4. Place the glass top (E) with the smooth
surface facing upward on the slate table
top (A). Insert the lighting unit (F) under
the glass top (E) through the central hole
and fix with the lighting unit top ring (G).
Adjust feet to level the table.
C
Short bolt
Big washer
Bolt cap
Hardware Used
x 8
x 8
2
CC
DD
B
C
CC
DD
2. Fasten the body ring (C) to the table legs
(B) with the medium bolts (CC) and small
washers (DD).
Medium bolt
Small washer

6
CARE AND MAINTENANCE
Ring
• Immediately remove any spot or stain.
• To clean, wash with a mild soap, rinse with water
and let air dry.
• Do not use strong solvents or bleach as they
may damage the surface.
• Use an outdoor cover to extend the life of your
patio set.
• Disassemble the lighting unit for storage to
extend its working life.
• To install new batteries (sold separately) into
lighting unit, open the battery cover according
to the label on the battery compartment. Put
the batteries on top of the band according to
the inside labeling. Note: Remove the batteries
by pulling on the band.
• Switch the lighting unit on/off by turning the top
ring of the lighting unit.
TROUBLESHOOTING
Can't align the bolt
holes.
Other components are overtightened. Loosen the other bolts and
realign the holes before screw-
ing again.
POSSIBLE CAUSE CORRECTIVE ACTIONPROBLEM

Printed in China
LIMITED WARRANTY
This warranty is for the original purchaser and applies to defects in materials and workmanship of
your patio furniture, provided your unit is maintained with care and used only for personal, resi-
dential purposes.
Frames are warranted to be free from defects in material or workmanship for five (5) years.
Lighting unit is covered for one (1) year against defects in material or workmanship.
Exclusions: Items used for commercial, contract or other non-residential purposes, display
models, items purchased “as is,” or items damaged due to acts of nature, vandalism, misuse or
improper assembly are not covered. Discoloration or fading of the finish or fabrics as a result of
exposure to the elements, chemicals or spills is not covered. Tabletop breakage, corrosion or
rusting of hardware and damages to frames or welds caused by improper assembly, misuse or
natural causes are not covered.
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m.,
EST, Monday - Friday.
7
Glass rest (H) is pre-assembled by factory to slate table top (A).
*
EEDD
AA BB CC FF GG
PART #DESCRIPTIONPART
AA Long Bolt 1138-1-AA
BB Short Bolt 1138-1-BB
CC Medium Bolt 1138-1-CC
DD Small Washer 1138-1-DD
EE Big Washer 1138-1-EE
FF Bolt Cap 1138-1-FF
GG Allen Key 1138-1-GG
H Glass Rest 1138-1-HH

ARTICLE #0147672
