Allen + Roth WSWS-CS1C User manual

1
COMPLETE CLOSET KIT
MODEL #WSWS-CS1C, #WSWS-CS1W
#WSWS-CS1P, #WSWS-CS1S
ITEM #0339203, #0339204, #0339205, #0339206
ATTACH YOUR RECEIPT HERE
Serial Number______________________ Purchase Date _______________________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Friday.
Español p. 47
Français p. 24

2
TABLE OF CONTENTS
Safety Information ………………………………………………………..……...……………...…...
Preparation.…………………...………………………………………..…………………...………..
Warranty …………………………………….……………………………………….…………...….
Hardware Contents ………………………….………………………………………………....…....
Package Contents………………………………………………………………………………….....
Replacement Parts List ……………………………………………………………………....…….
Troubleshooting …………….………………………………………………………………....…….
Care and Maintenance …………………………………….………………….………………...….
Assembly Instructions ……...…………………….…………….……………………...…...…..…..
1. Screw cam bolt into the predrilled small holes on panel.
2. Insert cam lock into predrilled large hole on panel.
3. Make sure the arrow on the cam lock is pointed toward the cam bolt.
4. Connect both panels together, making sure cam bolt goes into predrilled hole on
the end of panel with cam lock.
5. Once cam bolt is connected inside cam lock, take Phillips screwdriver and tighten
cam lock clockwise.
CAM LOCK
PANEL
CAM BOLT
THREADED
INSERT PANEL
LOCKED POSITION
CAM LOCK SYSTEM OPERATION
DETAIL A DETAIL B
Cam Lock System Operation…………………………………………………………………..….... 2
3
4
6
6
7
20
20
21
21

3
PACKAGE CONTENTS
R
U
T
Q
P
S
PART DESCRIPTION QUANTITY
AHutch Panel Left 1
BHutch Panel Right 1
CHutch Panel Top 1
DHutch Panel Back 1
EFront Curved Stretcher 1
FFront Straight Stretcher 1
GAdjustable Shelf 1
PART DESCRIPTION QUANTITY
HBase Panel Left 1
IBase Panel Right 1
JBase Panel Top 1
KBase Panel Back 1
LBase Panel Bottom 1
MPartition Panel 2
NShoe Shelf 2
OWall Hanging Cleat 2
PART DESCRIPTION QUANTITY
PDrawer Front 1
QDrawer Panel Left 1
RDrawer Panel Right 1
SDrawer Back 1
TDrawer Bottom 1
USelf Closing Slides 2
V
PART DESCRIPTION QUANTITY
VLong Shelf 2
WInstallation Template 1
C
H
B
E
D
F
G
A
IM
K
J
L
N
O
W

4
5-Minicam(24)
HARDWARE CONTENTS
NN
LL
AA
JJ
KK
I I
M4 x 38 mm
Wood Screw
Qty. 8
BB CC DD
FF
EE
M8 x 2-1/2 in.
Lag Bolt
Qty. 4
HH
GG
OO
1/4 x 1-1/4 in.
Bolt
Qty. 12
Lock
Washer
Qty. 12
Flat
Washer
Qty. 12
Large
Cam Lock
Qty. 34
Small
Cam Lock
Qty. 4
Medium
Cam Bolt
Qty. 30
Small
Cam Bolt
Qty. 4
Large
Wood Dowel
Qty. 34
Small
Wood Dowel
Qty. 8
M6 x 10 mm
Screw
Qty. 4
M4 x 25 mm
Wood Screw
Qty. 4
M3.5 x 12 mm
Wood Screw
Qty. 6
Large Flat
Washer
Qty. 4
PP QQ
Shelf Pin
Qty. 4
Wall Anchor
Qty. 8
RR
MM
M4 x 14 mm
Wood Screw
Qty. 24

5
HARDWARE CONTENTS
SS
YO
L Bracket
Qty. 8
YC
Drawer Handle
and Bolts
Qty. 1
Open Pole
Holder
Qty. 3
Closed
Pole Holder
Qty. 3
(3)
TT
ww
M4 Allen
Wrench
Qty. 1
Z Z
M4 x 15 mm
Self-tapping Screw
Qty. 6
Y
PACKAGE CONTENTS ( Pole Kit )
KK
M4 x 38 mm
Wood Screw
Qty. 18
MM
M4 x 14 mm
Wood Screw
Qty. 9
X
HARDWARE CONTENTS ( for Pole Kit )
PART DESCRIPTION QUANTITY
X22 mm Metal Pole 3
Y25 mm Metal Pole 3
Touch Up Pen(1)
xx
Touch-up Pen
Qty. 1
(not included for
Item #0339205)
UU V V
Barrel
Nut
Qty. 4
Large
Cam Bolt
Qty. 4

6
SAFETY INFORMATION
Tools Required for Assembly (not included): Phillips Screwdriver, Power Drill, 3/16 in. Drill Bit,
3/8 in. Drill Bit, 1/2 in. Socket Wrench, Level, Stud Finder, Marking Pencil, Tape Measure, Step
Ladder, and Hammer
MAXIMUM LOAD: 30 lbs. (13.6 kg)
MAXIMUM LOAD: 40 lbs. (18.14 kg)
MAXIMUM EXPANDABLE LENGTH:
60 in. (1.52 m)
Please read and understand this entire manual prior to assembling the product.
1. Do not allow children to climb or play in or around this product.
2. Use this unit for its intended purpose only. Do not use shelves as step ladder.
3. To avoid damage, assemble the product on a sturdy, level and protective surface.
4. Two or more persons must work together to install the unit onto the wall.
5. Make sure all bolts/screws are tightly fastened before the unit is used.
6. Check bolts/screws periodically and tighten them if necessary.
PREPARATION
Before beginning assembly of this product, make sure all parts are present. Compare parts with
package contents list and hardware contents above. If any part is missing or damaged, do not
attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 120 minutes
THIS UNIT IS INTENDED FOR USE ONLY WITH THE MAXIMUM WEIGHTS INDICATED. USE
WITH PRODUCTS HEAVIER THAN THE MAXIMUM WEIGHTS INDICATED MAY RESULT IN
INSTABILITY CAUSING POSSIBLE INJURY. DISTRIBUTE WEIGHT EVENLY.
WARNING
!
