Alliance Laundry Systems HC125BYV Troubleshooting guide

Operation/Maintenance
www.comlaundry.com
Washer-Extractor
Cabinet Hardmount
B-Series Microcomputer
Variable-Speed
HC125BYV and SC125BYV
B004C
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Part No. F232215R1
September 2008

F232215
© Copyright 2008, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
1
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table of
Contents
Safety Information.............................................................................. 2
Explanation of Safety Messages........................................................... 2
Important Safety Instructions ............................................................... 2
Safety Decals ........................................................................................ 4
Operator Safety..................................................................................... 5
Introduction......................................................................................... 6
Introduction........................................................................................... 6
Electronic Control Unit......................................................................... 6
Control Output Fuse Board................................................................... 6
Harnessing........................................................................................ 6
Communications ................................................................................... 6
Nameplate Location.............................................................................. 7
Replacement Parts ................................................................................ 7
Customer Service.................................................................................. 7
Operation............................................................................................. 9
Control Panel ........................................................................................ 9
Display Indicators................................................................................. 10
Operating Instructions .......................................................................... 12
Maintenance ........................................................................................ 14
Daily ..................................................................................................... 14
Beginning of Day............................................................................. 14
End of Day ....................................................................................... 14
Weekly.................................................................................................. 15
Monthly................................................................................................. 15
Quarterly ............................................................................................... 18
Care of Stainless Steel .......................................................................... 19

F232215
2© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual for the proper
grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, kerosene, waxes, cooking oils, dry-
cleaning solvents, or other flammable or
explosive substances as they give off vapors that
could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. The gas is
flammable; do not smoke or use an open flame
during this time.
6. Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children. This is a safety
rule for all appliances.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
DANGER indicates the presence of a
hazard that will cause severe personal
injury, death, or substantial property
damage if the danger is ignored.
DANGER
WARNING indicates the presence of a
hazard that can cause severe personal
injury, death, or substantial property
damage if the warning is ignored.
WARNING
CAUTION indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions: W023
WARNING

Safety Information
3
F232215 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power source.
13. Use washer only for its intended purpose,
washing textiles.
14. Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
15. ALWAYS disconnect the washer from electrical
supply before attempting any service. Disconnect
the power cord by grasping the plug, not the cord.
16. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and be
made by licensed personnel when required.
17. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc. or anything
containing wax or chemicals such as in mops and
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to catch on fire by itself.
18. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
19. Keep washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have washer checked by a qualified
service person.
20. If supply cord is damaged, it must be replaced by
a special cord or assembly available from the
manufacturer or its service agent.
21. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
22. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT bypass
the loading door switch by permitting the washer
to operate with the loading door open.
23. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of the reach of children at all times
(preferably in a locked cabinet).
24. Always follow the fabric care instructions
supplied by the textile manufacturer.
25. Never operate the washer with any guards and/or
panels removed.
26. DO NOT operate the washer with missing or
broken parts.
27. DO NOT bypass any safety devices.
28. Failure to install, maintain, and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
NOTE: The WARNINGS and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.

Safety Information
F232215
4© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
IMPORTANT: Ensure that the recommended
clearances for inspection and maintenance
are provided. Never allow the inspection and
maintenance space to be blocked.
Safety Decals
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals
could result in injury to the operator or service
technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If
questions regarding safety arise, contact the
manufacturer immediately.
Use manufacturer-authorized spare parts to avoid
safety hazards.
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty. SW004
WARNING
Install the machine on a level floor of
sufficient strength. Failure to do so may
result in conditions which can produce
serious injury, death and/or property
damage. W703
WARNING
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury. SW025
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched. SW014
WARNING

Safety Information
5
F232215 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operator Safety
To ensure the safety of machine operators, the
following maintenance checks must be performed
daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage. SW039
WARNING

F232215
6© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
Introduction
The “B” electronic control is composed of the
electronic control unit and the control fuse board with
wiring harness. Only an authorized person should look
inside the machine. First TURN OFF POWER, open
lid and remove any cover present. The components are
described below.
Electronic Control Unit
This portion of the control contains the “intelligence” –
the micro-controller and the miscellaneous components
on the printed circuit (PC) board. The board has a
metal cover, which MUST be in place at all times
during machine operation. Operation of the machine
without this cover installed will void the warranty.
The control unit monitors and responds to input, gives
information about the status of the washer and
monitors and responds to inputs from the user
interface (keypad). The control provides signals to the
control output unit, which in turn operates the
components that control the machine functions. This is
located behind the machine control panel.
Control Output Fuse Board
This portion of the control contains the power supply
for the control unit, and also the switching devices
which power the components in the machine, all of
which are on the output PC board. The switching
devices are controlled by the control unit, and are solid
state.
Harnessing
Wiring harnesses are modular – harnesses common to
various configurations are similar, while those specific
to a certain configuration can be added. There are
harnesses for inputs to the control unit, for outputs
from the control power/output unit to the machine
components, and for the main incoming power to the
control power/output unit.
Communications
The control will accept communications with a Card
Reader in order to perform vending transactions when
a card is inserted to pay for cycles. The Card Reader
can also allow the owner to program and collect audit
information.
For detailed information on the Card Reader
Communications, refer to the third party Card Reader
manufacturer.

Introduction
7
F232215 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Nameplate Location
The nameplate is located at the rear of the machine and
inside door. Always provide the machine’s serial
number and model number when ordering parts or
when seeking technical assistance.
Figure 1
Replacement Parts
If literature or replacement parts are required, contact
the source from which the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
Customer Service
For technical assistance, call: [phone], Ripon,
Wisconsin U.S.A.
B004C
1Nameplate
1

Introduction
F232215
8© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
* Denotes Brand
Figure 2
Model Number Familiarization Guide
Sample Model Number: *C125BYVQU60001
*C Model Number Prefix
125 Washer-Extractor Capacity (pounds dry weight of laundry)
BType of Electrical Control
YActuation (Y = Prep for Card Reader)
VWasher-Extractor Speed Capability (V = Variable-Speed)
QElectrical Characteristics
U6 Design Series
001 Option Identification (varies from machine to machine)
CHM2012N
CHM2012N
*C125BYVQU6001
00000000000
500000
200 – 240
50 - 60 3 3
0
18
3
125
N/A N/A
470
7
EXAMPLE OF NAMEPLATE

9
F232215 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
Control Panel
Figure 3 shows the control panel.
Figure 3
CHM482R
1Cycle 1 9START Keypad
2Cycle 2 10 “Clean Filter” Indicator LED
3Cycle 3 11 Door Open LED
4Cycle 4/Up Edit 12 Spin Cycle LED
5Cycle 5 13 Rinse Cycle LED
6Cycle 6 14 Add Bleach LED
7Cycle 7 15 Wash Cycle LED
8Cycle 8/Down Edit 16 Main LED Display
CHM482R
WASH
ADD
BLEACH
RINSE
SPIN
DOOR
NORMAL
NORMAL
QUICK AS QUICK WASH
HEAVY SOIL
DELICATE
RM RESS
PERM PRESS
HOT
WARM
HOT
HOT
WARM
COLD
WARM
COLD
START
PE P
WH
1
5
6
7
8
4
10
2
3
16
9
11
12
13
14
15

Operation
F232215
10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Display Indicators
Table 1 lists the various displays and what they
mean. The operator should become familiar with
these machine displays.
Display Meaning
tESt Diagnostic test cycle selected or enabled
SPIn Spin (extract) step
SUP1 Supply signal 1 (“S1” output), normally detergent
SUP2 Supply signal 2 (“S2” output), normally bleach
SUP3 Supply signal 3 (“S3” output), normally softener
SUP4 Supply signal 4 (“S4” output)
SUP5 Supply signal 5 (“S5” output)
SdLY Spin coast (motor coasts after high speed extract)
CFIL Cold Fill
HFIL Hot Fill
bFIL Warm Fill (cold + hot)
bLCH Control will also light “add bleach” indicator
PASS Variable-speed ONLY – balance “PASS” condition; shows in “test” cycle only
FAIL Variable-speed ONLY – balance “FAIL” condition; shows in “test” cycle only
bAL? Variable-speed ONLY – meaning: “Do you wish to enter balance detection test routine?”
CY__ Cycle number (followed by a space and number 1 through highest cycle number)
nornNormal agitation selected
gEnt Gentle (reduced) agitation selected
SPn1 Variable-speed ONLY – low spin speed (the lower of 2 spin speeds)
SPn2 Variable-speed ONLY – high spin speed (the higher of 2 spin speeds)
For Wash speed forward (during test cycle)
rEv Wash speed reverse (during test cycle)
dISt Variable-speed ONLY – distribution speed (during test cycle)
LO Low water level
nEd Medium water level
HI High water level
CEL Display all temperatures in degrees Celsius
FAr Display all temperatures in degrees Fahrenheit
___C The first 3 digits are reserved for temperature reading, C indicates “degrees Celsius”
Table 1 (Continued)

Operation
11
F232215 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Tab l e 1
Table 1 (Continued)
Display Meaning
___F The first 3 digits are reserved for temperature reading, F indicates “degrees Fahrenheit”
FILL “Fill error” – machine did not fill to programmed water level within 10 minutes
dOOr “Door” opened during cycle
SHUt/door Machine user must “shut door” of the washer to allow the cycle to begin
CAnt/OPEn Control cannot unlock the door
CArd Control will interpret the coin 2 input as a START signal from a Card Reader with no timing
max restriction, meaning the signal can last any amount of time once recognized
USH1 “Wash 1” segment
USH2 “Wash 2” segment
USH3 “Wash 3” segment
USH4 “Wash 4” segment
rIn1 “Rinse 1” segment
rIn2 “Rinse 2” segment
rIn3 “Rinse 3” segment
rIn4 “Rinse 4” segment (final rinse)
dOnE Cycle has concluded
drAI Drain selected for segment; also indicates in drain step during 2 speed version test cycle
---- Flashes for a period of time (for safety) after power up while keeping outputs OFF
dEn1 Denomination assigned for coin 1 input (example: .25 would mean a US quarter)
dEn2 Denomination assigned for coin 2 input (example: 100 would mean a US dollar)

Operation
F232215
12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
1. Turn on main power at its source (circuit
breaker).
2. Use left hand to press and hold door unlock
button located on top left of door lock box. Refer
to Figure 4.
3. Turn handle counterclockwise to open. Refer to
Figure 4.
Figure 4
4. Load to capacity whenever possible. DO NOT
OVERLOAD. Refer to Figure 5.
NOTE: Underloading can cause out-of-balance
conditions that can shorten machine life.
Figure 5
5. Close door and turn handle clockwise to
horizontal position. Refer to Figure 6.
Figure 6
6. The default wash cycle will display. Refer to
Figure 7.
NOTE: Perm Press Cold is the default cycle if none
is selected.
Figure 7
7. If desired, select a different cycle at this point or
after satisfying vend. The LED indicator for that
cycle will light.
CHM2013N
U003I
CHM2014N
CHM482R
To avoid personal injury, recommended
inlet water temperature should be no
higher than 125°Fahrenheit (51°Celsius).
W709
WARNING
WASH
ADD
BLEACH
RINSE
SPIN
DOOR
NORMAL
NORMAL
QUICK AS QUICK WASH
HEAVY SOIL
DELICATE
RM RESS
PERM PRESS
HOT
WARM
HOT
HOT
WARM
COLD
WARM
COLD
START
PE P
WH

Operation
13
F232215 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
8. Add liquid and/or powder supplies to supply
dispenser.
9. Insert and remove card. Contact the third party
Card Reader manufacturer for details.
Figure 8
10. When applicable, add bleach when the ADD
BLEACH LED is lit.
11. Press the desired wash cycle keypad. Refer to
Figure 7.
12. Press the START keypad.
13. During first fill, the desired wash cycle can be
changed. After first fill has ended, the wash cycle
active at that moment remains the chosen wash
cycle.
14. When cycle is complete, display shows “dOnE”.
CHM2015N

F232215
14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Maintenance
IMPORTANT: Replace all panels that are removed
to perform service and maintenance procedures.
Do not operate the machine with missing guards or
with broken or missing parts. Do not bypass any
safety devices.
Daily
IMPORTANT: Door lock should be checked daily
to ensure proper operation. Also check that all
safety and instruction stickers are on the machine.
Any missing or illegible safety instructions stickers
should be replaced immediately.
Beginning of Day
1. Inspect water inlet valve hose connections on the
back of the machine for leaks.
2. Inspect steam hose connections for leaks (where
applicable).
3. Check door interlock before starting operation:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door, and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
End of Day
1. Clean the door gasket of residual detergent and
all foreign matter.
2. Clean between the door gasket and the door glass
with a damp cloth.
3. Clean automatic supply dispenser lid and general
area. Flush dispenser with clean water.
4. Clean the machine’s top, front and side panels
with mild detergent. Thoroughly rinse and dry all
surfaces after cleaning them.
5. Leave loading door open at the end of each day to
allow moisture to evaporate.
NOTE: Unload the machine promptly after each
completed cycle to prevent moisture buildup. Leave
loading door open after each completed cycle to
allow moisture to evaporate.
Sharp edges can cause personal injury.
Wear safety glasses and gloves, use
proper tools and provide lighting when
handling sheet metal parts. W366R1
WARNING

Maintenance
15
F232215 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Weekly
1. Clean the AC drive box filter(s) weekly or more
frequently as needed:
NOTE: If fan filter service indicator light is on, fan
filter must be cleaned immediately to prevent
possible damage. Press the thermostat button to
reset the indicator light.
IMPORTANT: If filter indicator is ignored,
repeated resets might shorten life of drive. Clean
filter regularly to avoid indicator prompt.
a. Open the top cover.
b. Grasp the filter handle and pull straight up to
remove filter.
c. Wash the filter with warm water and allow
filter to air-dry. As an alternative, the filter
may be vacuumed clean.
IMPORTANT: The control module cover and fan
filter must be in place for the fan to properly cool
the AC inverter drive. Failure to observe this
warning will void the warranty and could lead to
expensive AC inverter drive repair.
2. Check the machine for leaks.
a. Start an unloaded cycle to fill the machine.
b. Verify that door and door gasket do not leak.
c. Verify that the drain valve is operating and
that the drain system is free from obstruction.
If water does not leak out during the first wash
segment, the drain valve is closed and
functioning properly.
Monthly
NOTE: Disconnect power to the machine at its
source before performing the monthly maintenance
procedures.
1. Use the following procedures to determine if
V-belt(s) require replacement or adjustment. Call
a qualified service technician in either case.
a. Check V-belt(s) for uneven wear and frayed
edges.
b. For groove-pulley drive systems, verify
alignment by placing a straightedge across
both pulley faces. The straightedge should
make contact with the pulleys in four places.
Refer to Figure 9.
Figure 9
H040I
1Motor
2Motor Pulley
3Straightedge
4Basket Pulley
H040I
1
23
4

Maintenance
F232215
16 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
c. Verify that V-belts are properly tensioned by
applying a set force to the belt and measuring
the deflection to determine the belt tension.
Refer to Table 2 for the acceptable belt
tension ranges. Belt tension measurements
should be taken as close to the center of the
belt span as possible. Refer to Figure 10.
Figure 10
NOTE: Hoses and other natural rubber parts
deteriorate after extended use. Hoses may develop
cracks, blisters or material wear from the
temperature and constant high pressure they are
subjected to.
2. Check all hoses for any visible signs of
deterioration. Any hoses showing signs of
deterioration listed above should be replaced
immediately.
NOTE: All hoses should be replaced every five
years.
H039I
1Deflection
2Span Length
1
2
Belt Tension Testing
Model Belt Belt Span Deflection Range Force
Min – Max
125 Motor-Basket 50 in. (1270 mm) .78 in. (20 mm) 5 – 7 lbs. (22 – 31 N)
Ta b le 2

Maintenance
17
F232215 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 11
3. Lubricate bearings and seals each month OR
after every 200 hours of operation. Refer to
Figure 11.
a. Use a premium-grade lithium-based #2
grease. Never mix two types of grease, such
as petroleum and silicone.
b. Pump the grease gun slowly, permitting only
the following number of strokes:
●Bearing grease fitting, 2 strokes
●Seal grease fitting, 1 stroke
IMPORTANT: Do not pump the grease gun until
grease comes out of the bearing housing. This can
result in overlubrication, causing damage to
bearings and seals.
H047I
1Bearing Grease Fitting
2Seal Grease Fitting
H047I
1
2

Maintenance
F232215
18 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
4. Remove back panel and check overflow hose and
drain hose for leaks.
5. Unlock the hinged lid and check the supply
dispenser hoses and hose connections.
6. Clean inlet hose filter screens:
a. Turn water off and allow valve to cool, if
necessary.
b. Unscrew inlet hose and remove filter screen.
c. Clean with soapy water and reinstall. Replace
if worn or damaged.
7. Tighten motor mounting bolt locknuts and
bearing bolt locknuts, if necessary.
8. Use compressed air to clean lint from motor.
9. Use compressed air to ensure that all electrical
components are free of moisture and dust.
10. Verify that the insulation is intact on all external
wires and that all connections are secure. If bare
wire is evident, call a service technician.
Quarterly
NOTE: Disconnect power to the machine at its
source before performing the quarterly
maintenance procedures.
1. Tighten door hinges and fasteners, if necessary.
2. Using a Teflon-based spray lube, lubricate the
door lock by applying the spray to the door lock
pin while turning the door handle.
3. Verify that the drain motor shield is in place and
secure, if so equipped.
4. Check all painted surfaces for exposed metal.
(Matching paint is available from the
manufacturer.)
●If bare metal is showing, paint with primer or
with a solvent-based paint.
●If rust appears, remove it with sandpaper or by
chemical means and then paint the affected
area with primer or with a solvent-based paint.
5. Clean supplied steam filter, where applicable.
Refer to Figure 12.
a. Turn off steam supply and allow time for the
valve to cool.
b. Unscrew Cap.
c. Remove Element and clean.
d. Replace Element and Cap.
Figure 12
6. Measure the out-of-balance switch gap setting
and adjust it as needed. Refer to the Installation
Manual, which is supplied with the machine.
7. Check the bearing mounting bolts to make sure
they are torqued properly. Refer to Tabl e 3 for
specifications.
Table 3
H042I
1Cap
2Filter Element
Machine
Capacity Bearing Torque
125 Front 500 ft.-lbs.
125 Rear 140 ft.-lbs.
H042
I
1
2
