Alliance Laundry Systems HC100 User manual

HC60, HC65, HC75, HC100
HC135, HC165
Instruction manual
Washer Extractors
Technical specications
Installation instructions
Maintenance
for corresponding “CHC” and “IHC” models,
see page 6 for complete model list.
Part No. D0285R10
Code: 249/00306/20
March 2012

1
2
3
4
3
Contents
Contents
Model Numbers .............................................................................................. 6
Safety and Environmental Informations ...................................................... 8
Safety .......................................................................................................... 8
Environmental .............................................................................................. 9
Explanation of Safety Messages ............................................................... 10
Important Safety Instructions ..................................................................... 11
Operator Safety ......................................................................................... 13
Technical data and dimensions ................................................................. 14
Technical data HC60, IHC012, IHC060 ..................................................... 14
Dimensions HC60, IHC012, IHC060 ......................................................... 15
Technical data HC65, IHC014, IHC065 ..................................................... 16
Dimensions HC65, IHC014, IHC065 ......................................................... 17
Technical data HC75, IHC018, CHC018, IHC075 ..................................... 18
Dimensions HC75, IHC018, CHC018, IHC075 ......................................... 19
Technical data HC100, IHC025, CHC025, IHC100 ................................... 20
Dimensions HC100, IHC025, CHC025, IHC100 ....................................... 21
Technical data HC135, IHC030, IHC135 ................................................... 22
Dimensions HC135, IHC030, IHC135 ....................................................... 23
Technical data HC165, IHC035, CHC035, IHC165 ................................... 24
Dimensions HC165, IHC035, CHC035, IHC165 ....................................... 25
Installation and Connection Instructions .................................................. 26
Surface ...................................................................................................... 26
Out of balance switch ................................................................................ 26
Removal of the transport safety ................................................................. 27
Mounting Bolt Hole Locations for machines, HC60, IHC012, IHC060 ....... 28
Mounting Bolt Hole Locations for machines, HC65, IHC014, IHC065 ....... 29
Mounting Bolt Hole Locations for machines, HC75, IHC018, CHC018,
IHC075 ...................................................................................................... 30
Mounting Bolt Hole Locations for machines, HC100, IHC025, CHC025,
IHC100 ...................................................................................................... 31
Mounting Bolt Hole Locations for machines, HC135, IHC030, IHC135 ..... 32
Mounting Bolt Hole Locations for machines, HC165, IHC035, CHC035,
IHC165 ...................................................................................................... 33
Water connection ....................................................................................... 34
Water drain ................................................................................................ 34
Electrical Installation .................................................................................. 35
Main power connection .............................................................................. 37

5
6
7
8
9
4
Electrical Specifications HC60, IHC012, IHC060 ...................................... 39
Electrical Specifications HC65, IHC014, IHC065 ...................................... 40
Electrical Specifications HC75, IHC018, CHC018, IHC075 ...................... 41
Electrical Specifications HC100, IHC025, CHC025, IHC100 .................... 42
Electrical Specifications HC135, IHC030, IHC135 .................................... 43
Electrical Specifications HC165, IHC035, CHC035, IHC165 .................... 44
Liquid soap connection (option) ................................................................. 45
Connection of a central operating panel for coin machines (option) ......... 47
Steam connection ........................................................................................ 48
Technical remarks ....................................................................................... 49
Internal connections of the electrical heating ............................................ 49
Maintenance instruction of the machine ................................................... 50
End of day .................................................................................................. 50
General maintenance ................................................................................ 50
Periodical maintenance ............................................................................. 50
Annual maintenance .................................................................................. 51
Contact Information ..................................................................................... 52
Nameplate ................................................................................................. 52
Repair and after-sales service .................................................................... 54

5

1
6
Model Numbers
xHC060yyHyyyyyy
xHC065yyHyyyyyy
xHC075yyHyyyyyy
xHC100yyHyyyyyy
xHC135yyHyyyyyy
xHC165yyHyyyyyy
xHC012yyHyyyyyy
xHC014yyHyyyyyy
xHC018yyHyyyyyy
xHC025yyHyyyyyy
xHC030yyHyyyyyy
xHC035yyHyyyyyy
Build-up
Model numbers IHC012ANH
IHC012MNH
IHC012MCH
IHC012MDH
IHC012MEH
IHC012MLH
IHC012MXH
IHC012MYH
IHC012SCH
IHC012SDH
IHC012SEH
IHC012SRH
IHC012SLH
IHC012SXH
IHC012SYH
IHC018ANH
IHC018MNH
IHC018MCH
IHC018MDH
IHC018MEH
IHC018MLH
IHC018MXH
IHC018MYH
IHC018SCH
IHC018SDH
IHC018SEH
IHC018SRH
IHC018SLH
IHC018SXH
IHC018SYH
IHC025ANH
IHC025MNH
IHC025MCH
IHC025MDH
IHC025MEH
IHC025MLH
IHC025MXH
IHC025MYH
IHC025SCH
IHC025SDH
IHC025SEH
IHC025SRH
IHC025SLH
IHC025SXH
IHC025SYH
IHC030ANH
IHC030MNH
IHC030MCH
IHC030MDH
IHC030MEH
IHC030MLH
IHC030MXH
IHC030MYH
IHC030SCH
IHC030SDH
IHC030SEH
IHC030SRH
IHC030SLH
IHC030SXH
IHC030SYH
IHC035ANH
IHC035MNH
IHC035MCH
IHC035MDH
IHC035MEH
IHC035MLH
IHC035MXH
IHC035MYH
IHC035SCH
IHC035SDH
IHC035SEH
IHC035SRH
IHC035SLH
IHC035SXH
IHC035SYH
IHC060ANH
IHC060MNH
IHC060MCH
IHC060MDH
IHC060MEH
IHC060MLH
IHC060MXH
IHC060MYH
IHC060SCH
IHC060SDH
IHC060SEH
IHC060SRH
IHC060SLH
IHC060SXH
IHC060SYH
HC60
HC65
HC75
HC100
HC135
HC165
HX25
HX35

1
7
IHC060ZNH
IHC065ANH
IHC065MNH
IHC065MCH
IHC065MDH
IHC065MEH
IHC065MLH
IHC065MXH
IHC065MYH
IHC065SCH
IHC065SDH
IHC065SEH
IHC065SRH
IHC065SLH
IHC065SXH
IHC065SYH
IHC065ZNH
IHC075ANH
IHC075MNH
IHC075MCH
IHC075MDH
IHC075MEH
IHC075MLH
IHC075MXH
IHC075MYH
IHC075SCH
IHC075SDH
IHC075SEH
IHC075SRH
IHC075SLH
IHC075SXH
IHC075SYH
IHC075ZNH
IHC100ANH
IHC100MNH
IHC100MCH
IHC100MDH
IHC100MEH
IHC100MLH
IHC100MXH
IHC100MYH
IHC100SCH
IHC100SDH
IHC100SEH
IHC100SRH
IHC100SLH
IHC100SXH
IHC100SYH
IHC100ZNH
IHC135ANH
IHC135MNH
IHC135MCH
IHC135MDH
IHC135MEH
IHC135MLH
IHC135MXH
IHC135MYH
IHC135SCH
IHC135SDH
IHC135SEH
IHC135SRH
IHC135SLH
IHC135SXH
IHC135SYH
IHC135ZNH
IHC165ANH
IHC165MNH
IHC165MCH
IHC165MDH
IHC165MEH
IHC165MLH
IHC165MXH
IHC165MYH
IHC165SCH
IHC165SDH
IHC165SEH
IHC165SRH
IHC165SLH
IHC165SXH
IHC165SYH
IHC165ZNH
CHC012ANH
CHC012MNH
CHC018ANH
CHC018MNH
CHC025ANH
CHC025MNH
CHC030ANH
CHC030MNH
CHC035ANH
CHC035MNH
CHC060ANH
CHC060MNH
CHC060MCH
CHC060MDH
CHC060MEH
CHC060MLH
CHC060MXH
CHC060MYH
CHC065ANH
CHC065MNH
CHC065MCH
CHC065MDH
CHC065MEH
CHC065MLH
CHC065MXH
CHC065MYH
CHC075ANH
CHC075MNH
CHC075MCH
CHC075MDH
CHC075MEH
CHC075MLH
CHC075MXH
CHC075MYH
CHC100ANH
CHC100MNH
CHC100MCH
CHC100MDH
CHC100MEH
CHC100MLH
CHC100MXH
CHC100MYH
CHC135ANH
CHC135MNH
CHC135MCH
CHC135MDH
CHC135MEH
CHC135MLH
CHC135MXH
CHC135MYH
CHC165ANH
CHC165MNH
CHC165MCH
CHC165MDH
CHC165MEH
CHC165MLH
CHC165MXH
CHC165MYH

8
2
Safety and Environmental Informations
Safety
CAUTION LABELS
Please familiarize yourself with the following standard warning symbols. They are
used throughout this manual and on the equipment to alert you to possible hazards.
Anyone operating or servicing this equipment must understand these symbols and
must follow all safety rules in this manual.
ELECTRICAL HAZARD
This symbol alerts you to the presence of a dangerous voltage, which could cause a
serious shock resulting in personal injury or death.
CONSULT MANUAL
This symbol warns you to consult the manual for important instructions concerning
the machine and possible hazards.
MOVING PARTS HAZARD
This symbol alerts you to the presence of possible dangerous moving parts within
the machine. Guards should always be in place when the machine is in operation. Be
very careful when servicing the drive system.
PINCHING HAZARD
This warning symbol indicates the presence of a pinch point on the machine. This is
a place where your hand might be pinched or crushed, resulting in a severe injury.
Make sure you understand these hazards and keep all body parts clear of them.
HOT SURFACE HAZARD
This symbol indicates the presence of a potentially hot surface. Some machine
surfaces and parts may become extremely hot during normal operation and should
not be touched.
ATTENTION
This symbol identies information about practices or circumstances that can lead to
personal injury or death, property damage, or economic loss.

9
2
Environmental
Disposal of Unit
This appliance is marked according to the European directive 2002/96/
EC on Waste Electrical and Electronic Equipment (WEEE).
This symbol on the product or on its packaging indicates that this
product shall not be treated as household waste. Instead it shall be
handed over to the applicable collection point for the recycling of
electrical and electronic equipment. Ensuring this product is disposed
of correctly, you will help prevent potential negative consequences
for the environment and human health, which could otherwise be
caused by inappropriate waste handling of this product. The recycling
of materials will help to conserve natural resources. For more detailed
information about recycling of this product, please contact your local
distributor resources.

10
Explanation of Safety Messages
Throughout this manual and on machine decals, you will nd precautionary statements (“DANGER,”
“WARNING,” and “CAUTION”) followed by specic instructions. These precautions are intended for the
personal safety of the operator, user, servicer, and those maintaining the machine.
DANGER
Indicates an imminently hazardous situation that, if not
avoided, will cause severe personal injury or death.
WARNING
Indicates a hazardous situation that, if not avoided, could
cause severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided, may
cause minor or moderate personal injury or property
damage.
Safety Decals
Safety decals appear at crucial locations on the machine. Failure to maintain legible safety decals could
result in injury to the operator or service technician.
To provide personal safety and keep the machine in proper working order, follow all maintenance and
safety procedures presented in this manual. If questions regarding safety arise, contact the manufacturer
immediately.
Use manufacturer-authorized spare parts to avoid safety hazards.
Additional precautionary statements (“IMPORTANT” and “NOTE”) are followed by specic instructions.
IMPORTANT: The word “IMPORTANT” is used to inform the reader of specic procedures where
minor machine damage will occur if the procedure is not followed.
NOTE: The word “NOTE” is used to communicate installation, operation, maintenance or servicing
information that is important but not hazard related.
2

11
Important Safety Instructions
WARNING
To reduce the risk of re, electric shock, serious injury or
death to persons when using your washer, follow these
basic precautions:
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in the installation Manual for the proper grounding of the
washer.
3. Do not wash textiles that have been previously cleaned, washed, soaked, or spotted with gasoline,
dry-cleaning solvents, or other ammable or explosive substances as they give off vapors that could
ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or other ammable or explosive substances to the wash
water. These substances give off vapors that could ignite or explode.
5. Under certain conditions, hydrogen gas may be produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been
used for such a period, before using a washing machine or combination washer-dryer, turn on all hot
water faucets and let the water ow from each for several minutes. This will release any accumulated
hydrogen gas. The gas is ammable, do not smoke or use an open ame during this time.
6. Do not allow children to play on or in the washer. This appliance is not intended for use by young
children or inrm persons without supervision. Young children should be supervised to ensure that
they do not play with the appliance.
7. Before the washer is removed from service or discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is moving. This is an imminently hazardous situation
that, if not avoided, will cause severe personal injury or death.
9. Do not install or store the washer where it will be exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer, or attempt any servicing unless specically
recommended in the user-maintenance instructions or in published user-repair instructions that the
user understands and has the skills to carry out.
12. To reduce the risk of an electric shock or re, DO NOT use an extension cord or an adapter to connect
the washer to an electrical power source.
13. Use a washer only for its intended purpose, washing textiles.
14. ALWAYS disconnect the washer from the electrical supply before attempting any service. Disconnect
the power cord by grasping the plug, not the cord.
15. Install the washer according to the INSTALLATION INSTRUCTIONS. All connections for water, drain,
electrical power and grounding must comply with local codes and be made by licensed personnel
when required.
16. To reduce the risk of re, textiles which have traces of any ammable substances such as vegetable
oil, cooking oil, machine oil, ammable chemicals, thinner, etc., or anything containing wax or
chemicals such as in mops and cleaning cloths, must not be put into the washer. These ammable
substances may cause the fabric to catch on re.
17. Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of
the fabric softener or product.
18. Keep washer in good condition. Bumping or dropping the washer can damage safety features. If this
occurs, have washer checked by a qualied service person.
19. Replace worn power cords and/or loose plugs.
20. Be sure water connections have a shut-off valve and that ll hose connections are tight. CLOSE the
shut-off valves at the end of each wash day.
2

12
22
21. Loading door MUST BE CLOSED any time the washer is to ll, tumble, or spin. DO NOT bypass the
loading door switch by permitting the washer to operate with the loading door open.
22. Always read and follow manufacturer’s instructions on packages of laundry and cleaning aids. Heed all
warnings or precautions. To reduce the risk of poisoning or chemical burns, keep them out of the reach
of children at all times (preferably in a locked cabinet).
23. Always follow the fabric care instructions supplied by the textile manufacturer.
24. Never operate the washer with any guards and/or panels removed.
25. DO NOT operate the washer with missing or broken parts.
26. DO NOT bypass any safety devices.
27. Failure to install, maintain, and/or operate this washer according to the manufacturer’s instructions
may result in conditions which can produce bodily injury and/or property damage.
28. It is recommended that the machine be installed by qualied technicians.
29. Before starting repairs or maintenance, shut off all power and water supplies.
30. To prevent re and explosion:
Keep the area around the machine free from inammable or combustible products.
NOTE: The WARNINGS and IMPORTANT SAFETY INSTRUCTIONS appearing in this manual are not
meant to cover all possible conditions and situations that may occur. Common sense, caution, and
care must be exercised when installing, maintaining, or operating the washer.
Any problems or conditions not understood should be reported to the dealer, distributor, service agent, or
the manufacturer.
SAVE THESE INSTRUCTIONS

13
Operator Safety
WARNING
NEVER insert hands or objects into basket until it has
completely stopped. Doing so could result in serious
injury.
To ensure the safety of machine operators, the following maintenance checks must be performed daily:
1. Prior to operating the machine, verify that all warning signs are present and legible. Missing or illegible
signs must be replaced immediately. Make certain that spares are available.
2. Check door interlock before starting operation of the machine:
a. Attempt to start the machine with the door open. The machine should not start with the door open.
b. Close and lock the door and start a cycle. Attempt to open the door while the cycle is in progress.
The door should not open.
If the door lock and interlock are not functioning properly, call a service technician.
3. Do not attempt to operate the machine if any of the following conditions are present:
a. The door does not remain securely locked during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly grounded circuit.
Do not bypass any safety devices in the machine.
WARNING
Never operate the machine with a bypassed or
disconnected balance system. Operating the machine
with severe out-of-balance loads could result in personal
injury and serious equipment damage.
SAVE THESE INSTRUCTIONS
2

14
3
METRIC US
Capacity (dry weight) Ratio [kg/Lit]
1:11 5 kg 11.02 lb.
1:10 5,5 kg 12.13 lb.
1:9 6,1 kg 13.45 lb.
Cylinder
Diameter 530 mm 20.87 inch
Depth 250 mm 9.84 inch
Volume 55 Lit 1.94 ft³
Cabinet
Height 1038 mm 40.87 inch
Width 660 mm 25.98 inch
Depth 575 mm 22.64 inch
Front loading
Diameter door opening 300 mm 11.81 inch
Height under door 279 mm 10.98 inch
To center 505 mm 19.88 inch
Speed
Wash 10 - 50 tr/min - RPM
Distribution 85 tr/min - RPM
Spin 250 - 1250 tr/min - RPM
G-factor
High spin 462
Dynamic bottom load (N/Hz)
570/16
Motor (3-phase)
4p. 1470 tr/min 0,55 kW / 0,74 HP
Drain valve
2"
Water supply
Hard, soft, warm water 3/4"
Heating
Electrical 230/400 V 4,2 kW
Electrical 400V 6 kW
Steam X
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm - inch 1140x740x840 mm - 44.88x29.13x33.07 inch
Weight
Net 184 kg 405.65 lb.
Gross 198 kg 436.52 lb.
Technical data HC60, IHC012, IHC060
Technical data and dimensions

660 [25.98]
530 [20.87]
1011 [39.8]
1038 [40.87]
33 [1.3] 33 [1.3]
65 [2.56] 65 [2.56]
279 [10.98]
622 [24.49]
565 [22.24]
485 [19.09]
69 [2.72]
30 [1.18] 30 [1.18]
163 [6.4]
660 [25.98]
226 [8.9]
75 [2.95]
151 [5.94]
747 [29.41]
791 [31.14]
887 [34.92]
J
J
696.2 [27.41]
180 [7.09]
44 [1.73]
K
70 [2.76]
J
J
109 [4.3]
D
C
A
E
F
IG
B
15
Dimensions HC60, IHC012, IHC060
 A. Ventilation soap dispenser
B. Liquid soap connections
C. Hard water connections 3/4"
D. Warm water connections 3/4"
E. Soft water connections 3/4"
F. Main switch
G.Electrical connections
 I. Ventilation tub
 J. Bolt pattern for fixation of the machine
K. Drain valve
Legend: metric mm [inches]
3

16
3
METRIC US
Capacity (dry weight) Ratio [kg/Lit]
1:11 5,9 kg 13.01 lb.
1:10 6,5 kg 14.33 lb.
1:9 7,2 kg 15.87 lb
Cylinder
Diameter 530 mm 20.87 inch
Depth 295 mm 11.61 inch
Volume 65 Lit 2.30 ft³
Cabinet
Height 1038 mm 40.87 inch
Width 660 mm 25.98 inch
Depth 739 mm 29.09 inch
Front loading
Diameter door opening 300 mm 11.81 inch
Height under door 279 mm 10.98 inch
To center 505 mm 19.88 inch
Speed
Wash 10 - 50 tr/min - RPM
Distribution 85 tr/min - RPM
Spin 250 - 1000 tr/min - RPM
G-factor
High spin 296
Dynamic bottom load (N/Hz)
570/16
Motor (3-phase)
4p. 1470 tr/min 0,75 kW / 1,01 HP
Drain valve
2"
Water supply
Hard, soft, warm water 3/4"
Steam connection
Steam connection 3/8"
Heating
Electrical 230/400 V 4,2 kW - 6 kW - 9 kW
Electrical 400V 12 kW
Steam X
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm - inch 1140x740x840 mm - 44.88x29.13x33.07 inch
Weight
Net 207 kg 456.36 lb.
Gross 229 kg 504.86 Ib.
Technical data HC65, IHC014, IHC065

660 [25.98]
530 [20.87]
1011 [39.8]
1038 [40.87]
33 [1.3] 33 [1.3]
65 [2.56] 65 [2.56]
279 [10.98]
75 [2.95]
887 [34.92]
791 [31.14]
747 [29.41]
485 [19.1]
696.2 [27.41]
70 [2.76]44 [1.73]
180 [7.09]
660 [25.98]
K
151 [5.94]
226 [8.9]
L
C
A
D
E
F
G
I
109 [4.3]
B
69 [2.72] 727 [28.62]
30 [1.18] 30 [1.18]
590 [23.23]
670 [26.38]
220 [8.66]
17
3
Dimensions HC65, IHC014, IHC065
 A. Ventilation soap dispenser
B. Liquid soap connections
C. Hard water connections 3/4"
D. Warm water connections 3/4"
E. Soft water connections 3/4"
F. Main switch
G.Electrical connections
 I. Ventilation tub
K. Drain valve
L. Steam connections
Legend: metric mm [inches]

18
3
METRIC US
Capacity (dry weight) Ratio [kg/Lit]
1:11 6,9 kg 15.21 lb.
1:10 7,6 kg 16.76 lb.
1:9 8,4 kg 18.52 lb.
Cylinder
Diameter 530 mm 20.87 inch
Depth 345 mm 13.58 inch
Volume 76 Lit 2.68 ft³
Cabinet
Height 1038 mm 40.87 inch
Width 660 mm 25.98 inch
Depth 739 mm 29.09 inch
Front loading
Diameter door opening 300 mm 11.81 inch
Height under door 279 mm 10.98 inch
To center 505 mm 19.88 inch
Speed
Wash 10 - 50 tr/min - RPM
Distribution 85 tr/min - RPM
Spin 250 - 1000 tr/min - RPM
G-factor
High spin 296
Dynamic bottom load (N/Hz)
550/16
Motor (3-phase)
4p. 1470 tr/min 0,75 kW / 1,01 HP
Drain valve
2"
Water supply
Hard, soft, warm water 3/4"
Steam connection
Steam connection 3/8"
Heating
Electrical 230/400 V 4,2 kW - 6 kW - 9 kW
Electrical 400V 12 kW
Steam X
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm - inch 1140x740x840 mm - 44.88x29.13x33.07 inch
Weight
Net 211 kg 465.18 lb.
Gross 233 kg 513.68 lb.
Technical data HC75, IHC018, CHC018, IHC075

3
660 [25.98]
530 [20.87]
1011 [39.8]
1038 [40.87]
33 [1.3] 33 [1.3]
65 [2.56] 65 [2.56]
279 [10.98]
69 [2.72] 727 [28.62]
30 [1.18] 30 [1.18]
590 [23.23]
670 [26.38]
220 [8.66]
75 [2.95]
887 [34.92]
791 [31.14]
747 [29.41]
485 [19.1]
696.2 [27.41]
70 [2.76]44 [1.73]
180 [7.09]
660 [25.98]
K
151 [5.94]
226 [8.9]
L
C
A
D
E
F
G
I
109 [4.3]
B
19
3
Dimensions HC75, IHC018, CHC018, IHC075
 A. Ventilation soap dispenser
B. Liquid soap connections
C. Hard water connections 3/4"
D. Warm water connections 3/4"
E. Soft water connections 3/4"
F. Main switch
G.Electrical connections
 I. Ventilation tub
K. Drain valve
L. Steam connections
Legend: metric mm [inches]

20
3
METRIC US
Capacity (dry weight) Ratio [kg/Lit]
1:11 8,6 kg 18.96 lb.
1:10 9,5 kg 20.94 lb.
1:9 10,5 kg 23.15 lb.
Cylinder
Diameter 530 mm 20.87 inch
Depth 440 mm 17.32 inch
Volume 95 Lit 3.35 ft³
Cabinet
Height 1038 mm 40.87 inch
Width 660 mm 25.98 inch
Depth 839 mm 33.03 inch
Front loading
Diameter door opening 300 mm 11.81 inch
Height under door 279 mm 10.98 inch
To center 505 mm 19.88 inch
Speed
Wash 10 - 50 tr/min - RPM
Distribution 85 tr/min - RPM
Spin 250 - 1000 tr/min - RPM
G-factor
High spin 296
Dynamic bottom load (N/Hz)
538/16
Motor (3-phase)
4p. 1470 tr/min 0,75 kW / 1,01 HP
Drain valve
2"
Water supply
Hard, soft, warm water 3/4"
Steam connection
Steam connection 3/8"
Heating
Electrical 230/400 V 4,2 kW - 6 kW - 9 kW
Electrical 400V 12 kW
Steam X
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm - inch 1250x740x950 mm- 49.21x29.13x37.40 inch
Weight
Net 236 kg 520.29 lb.
Gross 258 kg 568.79 lb.
Technical data HC100, IHC025, CHC025, IHC100
