Alpine KCE-G7QI User manual

Installation of KCE-G7QI / Einbau der KCE-G7QI / Installation du KCE-G7QI / Instalación del KCE-G7QI / Installazione di KCE-G7QI
EN
1Inbay®mat
2Inbay®power cable
3Power drill (diameter 10 mm)
4Plastic wedge
5Screwdriver Torx 20
6Wrench SW10
DE
1Inbay®-Auflage
2Inbay®-Anschlusskabel
3Bohrmaschine (Durchmesser 10 mm)
4Kunststoffkeil
5Torx-Schraubendreher 20
6Schraubenschlüssel SW10
FR
1Tapis Inbay®
2Câble d'alimentation Inbay®
3Perceuse électrique (diamètre 10 mm)
4Coin en plastique
5Tournevis Torx 20
6Clé SW10
ES
1Superficie Inbay®
2Cable de alimentación Inbay®
3Taladradora eléctrica (diámetro 10 mm)
4Cuña de plástico
5Destornillador Torx 20
6Llave SW10
IT
1Tappetino Inbay®
2Cavo di alimentazione Inbay®
3Trapano elettrico (diametro 10 mm)
4Cuneo in plastica
5Cacciavite Torx 20
6Chiave SW10
25
4
36
1
Ø10
EN
1. Carefully remove the side cover of the dashboard on the driver‘s side using the plastic wedge.
2. Pull out the air vent as shown.
3. Push the steering wheel to down position.
4. / 5. Pull out the cover located above the steering wheel.
6. Loosen the 2 screws fixing the instrument cluster using screwdriver T20.
7. Carefully loosen the original equipped faceplate to pull out the instrument cluster.
8. Disconnect all plugs.
9. Open the fuse box cover located on the left hand side of the steering wheel.
10. Slightly squeeze the side covers of the fuse box to loosen the fuse box from its fixed position.
11. Carefully pull out the fuse box.
12. Open the compartment.
13. Remove the cover of the climate control.
14. / 15. Carefully remove the compartment below the climate control and disconnect all plugs.
16. Drill a hole on the backside of the compartment with a diameter of 10mm.
17. Route the Inbay®power cable from the fuse box through the instrument cluster opening to
the compartment as indicated.
18. Run the Inbay®power cable 2through the 10mm drilling hole of the compartment.
19. Reinsert the compartment.
20. Connect the plug of the Inbay®power cable 2to the Inbay®mat 1.
21. Position the Inbay®mat 1in the compartment as shown.
DE
1. Entfernen Sie mithilfe des Kunststoffkeils vorsichtig die Abdeckung auf der Fahrerseite des
Armaturenbretts.
2. Ziehen Sie den Luftausströmer gemäß Abbildung heraus.
3. Stellen Sie das Lenkrad ganz nach unten.
4. / 5. Ziehen Sie die Verkleidung über dem Lenkrad heraus.
6. Lösen Sie die beiden Schrauben, die das Kombiinstrument halten, mit einem
Torx-Schraubendreher (T20).
7. Lösen Sie vorsichtig die Original-Frontblende und ziehen Sie das Kombiinstrument heraus.
8. Ziehen Sie alle Stecker.
9. Öffnen Sie die Abdeckung des Sicherungskastens auf der linken Seite des Lenkrads.
10. Drücken Sie leicht auf die seitlichen Abdeckungen des Sicherungskastens, um den
Sicherungskasten aus seiner Befestigungsposition zu lösen.
11. Ziehen Sie den Sicherungskasten vorsichtig heraus.
12. Öffnen Sie das Ablagefach.
13. Entfernen Sie die Abdeckung der Klimaanlage.
14. / 15. Entfernen Sie vorsichtig das Ablagefach unter der Klimaanlage und ziehen Sie alle
Stecker.
16. Bohren Sie in die Rückseite des Ablagefachs ein Loch mit einem Durchmesser von 10 mm.
17. Führen Sie das Inbay®-Anschlusskabel wie dargestellt vom Sicherungskasten durch die
Öffnung des Kombiinstruments zum Ablagefach.
18. Stecken Sie das Inbay®-Anschlusskabel 2durch die 10-mm-Bohrung im Ablagefach.
19. Setzen Sie das Ablagefach wieder ein.
20. Verbinden Sie den Stecker des Inbay®-Anschlusskabels 2mit der Inbay®-Auflage 1.
21. Positionieren Sie die Inbay®-Auflage 1wie dargestellt im Ablagefach.
ES
1. Retire con cuidado la cubierta lateral del salpicadero del lado del conductor con la ayuda de la
cuña de plástico.
2. Extraiga la rejilla de ventilación tal como se muestra.
3. Baje por completo el volante.
4. / 5. Extraiga la cubierta situada sobre el volante.
6. Afloje los dos tornillos que fijan el grupo de instrumentos con un destornillador T20.
7. Afloje con cuidado la placa frontal original con objeto de extraer el grupo de instrumentos.
8. Desconecte todas las tomas.
9. Abra la tapa de la caja de fusibles situada a la izquierda del volante.
10. Apriete ligeramente las tapas laterales de la caja de fusibles para aflojarla y soltarla.
11. Extraiga con cuidado la caja de fusibles.
12. Abra el compartimento.
13. Retire la cubierta del control de climatización.
14. / 15. Retire con cuidado el compartimento situado bajo el control de climatización y
desconecte todas las tomas.
16. Taladre un orificio en la parte posterior del compartimento de 10 mm de diámetro.
17. Lleve el cable de alimentación Inbay®desde la caja de fusibles, a través de la abertura del
conjunto de instrumentos y hasta el compartimento, según lo indicado.
18. Pase el cable de alimentación Inbay®2a través del orificio 10 mm hecho en el compartimento.
19. Vuelva a colocar el compartimento.
20. Conecte la toma del cable de alimentación Inbay®2en la superficie de carga Inbay®1.
21. Coloque la superficie de carga Inbay®1en el compartimento según se muestra en la imagen.
IT
1. Rimuovere con attenzione la copertura laterale del cruscotto sul lato conducente utilizzando il
cuneo di plastica.
2. Estrarre la bocchetta di ventilazione come mostrato.
3. Abbassare il volante.
4. / 5. Sfilare la copertura posta sopra il volante.
6. Allentare le 2 viti che fissano il quadro strumenti col cacciavite T20.
7. Allentare con attenzione il frontalino originale per estrarre il quadro strumenti.
8. Scollegare tutti i connettori.
9. Aprire il coperchio della scatola fusibili ubicata a sinistra del volante.
10. Schiacciare leggermente i coperchi laterali della scatola fusibili per allentarla dalla posizione
in cui è fissata.
11. Estrarre con attenzione la scatola fusibili.
12. Aprire il vano.
13. Rimuovere la copertura del climatizzatore.
14. / 15. Rimuovere con attenzione il vano sotto il climatizzatore e scollegare tutti i connettori.
16. Trapanare un foro di diametro di 10 mm sul retro del vano.
17. Far passare il cavo di alimentazione Inbay®dalla scatola fusibili attraverso l’apertura del
quadro strumenti per farlo arrivare nel vano, come mostrato.
18. Far passare il cavo di alimentazione Inbay®2attraverso il foro da 10 mm appena trapanato
nel vano.
19. Reinserire il vano.
20. Collegare il connettore del cavo di alimentazione Inbay®2al tappetino Inbay®1.
21. Posizionare il tappetino Inbay®1nel vano, come mostrato.
FR
1. Déposez avec précaution le couvercle latéral du tableau de bord côté conducteur en utilisant le
coin en plastique.
2. Déposez l'ouïe d'aération (voir l'illustration).
3. Abaissez le volant de direction.
4. / 5. Retirez le cache situé au-dessus du volant.
6. Desserrez les 2 vis de fixation du tableau de bord à l'aide du tournevis T20.
7. Desserrez délicatement la plaque frontale d'origine afin de déposer le tableau de bord.
8. Déconnectez toutes les fiches.
9. Ouvrez le couvercle du boîtier de fusibles à gauche du volant.
10. Pincez légèrement les côtés du boîtier de fusibles pour le sortir de son logement.
11. Sortez délicatement le boîtier de fusibles.
12. Ouvrez le compartiment.
13. Déposez le cache de la commande de climatisation.
14. / 15. Déposez avec précaution le compartiment sous la commande de climatisation et
déconnectez toutes les fiches.
16.
Percez un trou sur la face arrière du compartiment à l'aide d'un foret de diamètre 10 mm.
17. Faites passer le câble d'alimentation Inbay®entre le boîtier de fusibles et le compartiment,
en passant par l'ouverture du tableau de bord (voir l'illustration).
18. Faites passer le câble d'alimentation Inbay®2dans le trou de 10 mm percé dans le
compartiment.
19. Remettez le compartiment en place.
20. Raccordez la fiche du câble d'alimentation Inbay®2au tapis Inbay®1.
21. Positionnez le tapis Inbay®1dans le compartiment (voir l'illustration).
1 2 3 4
5 6 7 8
9 10 11 12
Ø10
13 14 15 16
17
18 19
20 21
2
1
2
2
2
1
EN
22. Connect the plug of the Inbay®power cable (A) to the socket F48 in the fuse box (consult the
vehicles' troubleshooting guide for details). The PIN GND (B) has to be affixed with the hex nut of
the vehicle as indicated.
DE
22. Verbinden Sie den Stecker des Inbay®-Anschlusskabels (A) mit der Buchse F48 im Sicherungskasten
(Einzelheiten entnehmen Sie bitte der Fehlersuchanleitung des Fahrzeugs). Der Masseanschluss (B)
muss wie dargestellt mit einer Sechskantmutter am Fahrzeug angebracht werden.
FR
22. Raccordez la fiche du câble d'alimentation Inbay®(A) à la cavité F48 du boîtier de fusibles
(voir le guide de dépannage du véhicule pour les détails). La cosse de masse GND (B) doit
être fixée au moyen de l'écrou hexagonal au véhicule (voir l'illustration).
ES
22. Conecte la toma del cable de alimentación Inbay®(A) a la toma F48 de la caja de fusibles (consulte
la guía de resolución de averías del vehículo para obtener detalles al respecto). El PIN GND (B)
debe fijarse con la tuerca hexagonal del vehículo, según lo indicado.
IT
22. Collegare il connettore del cavo di alimentazione Inbay®(A) alla presa F48 nella scatola
fusibili (per maggiori dettagli consultare la risoluzione dei problemi del veicolo). Il PIN GND
(B) deve essere fissato con il dado esagonale del veicolo, come indicato.
15
10
10
10
10
7.5
5
15
25
25
40
20
25
30
30
30
40
5
22
(A)
(B)
2
1
ALPINE ELECTRONICS MARKETING, INC.
1-7, Yukigaya-Otsukamachi, Ota-ku,
Tokyo 145-0067, JAPAN
Phone: 03-5499-4531
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777Supertest Road, Toronto,
Ontario M3J 2M9, Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
ALPINE ELECTRONICS GmbH
Wilhelm-Wagenfeld-Str. 1-3, 80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
ALPINE ELECTRONICS FRANCE S.A.R.L.
Phone 01-48638989
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
184, Allée des Erables
CS 52016 - Villepinte
95 945 Roissy CDG Cedex, France
Designed by Alpine Electronics (Europe) GmbH
Printed in Hungary

Other Alpine Automobile Electronic manuals

Alpine KCE-300BT User manual

Alpine

Alpine KCE-300BT User manual

Alpine VPX-B104R User manual

Alpine

Alpine VPX-B104R User manual

Alpine KTX-100EQ - IMPRINT Sound Tuning User manual

Alpine

Alpine KTX-100EQ - IMPRINT Sound Tuning User manual

Alpine SIRIUS KCA-SC100 User manual

Alpine

Alpine SIRIUS KCA-SC100 User manual

Alpine KTX-100EQ - IMPRINT Sound Tuning User manual

Alpine

Alpine KTX-100EQ - IMPRINT Sound Tuning User manual

Alpine SIRIUS KCA-SC100 User manual

Alpine

Alpine SIRIUS KCA-SC100 User manual

Alpine X009-WRA User manual

Alpine

Alpine X009-WRA User manual

Alpine KCA-620M User manual

Alpine

Alpine KCA-620M User manual

Alpine DPR-RDS1 User manual

Alpine

Alpine DPR-RDS1 User manual

Alpine CXA-B200NK User manual

Alpine

Alpine CXA-B200NK User manual

Alpine SIRIUS KCA-SC100 User manual

Alpine

Alpine SIRIUS KCA-SC100 User manual

Alpine CXA-B200NK User manual

Alpine

Alpine CXA-B200NK User manual

Alpine KCE-300BT User manual

Alpine

Alpine KCE-300BT User manual

Popular Automobile Electronic manuals by other brands

Valeo Light/on&off instruction manual

Valeo

Valeo Light/on&off instruction manual

Axxess AXDSPX-HK4 installation instructions

Axxess

Axxess AXDSPX-HK4 installation instructions

Renault AUDIO CONNECTION BOX installation instructions

Renault

Renault AUDIO CONNECTION BOX installation instructions

PreCise ParkLink Pay-by-License Plate Meters How to use

PreCise ParkLink

PreCise ParkLink Pay-by-License Plate Meters How to use

Toyota Dynamic Laser Cruise Control System Quick training guide

Toyota

Toyota Dynamic Laser Cruise Control System Quick training guide

Soltech ITB-500HD installation guide

Soltech

Soltech ITB-500HD installation guide

Crux RVCMT-69 manual

Crux

Crux RVCMT-69 manual

Tesla G-TECH user manual

Tesla

Tesla G-TECH user manual

Polaroid DS231GSW user guide

Polaroid

Polaroid DS231GSW user guide

flexmedia V737 user manual

flexmedia

flexmedia V737 user manual

Striker Garage Parking Sensor instructions

Striker

Striker Garage Parking Sensor instructions

Axxess AX-JP901 installation instructions

Axxess

Axxess AX-JP901 installation instructions

netvox R719A user manual

netvox

netvox R719A user manual

Perfect Tuning MS3Pro-PNP user manual

Perfect Tuning

Perfect Tuning MS3Pro-PNP user manual

Intermec 1022AD01B Quick manual

Intermec

Intermec 1022AD01B Quick manual

VDO OPERATING HOURS COUNTER installation instructions

VDO

VDO OPERATING HOURS COUNTER installation instructions

Rear view safety RVS-5350-W Product manual installation & instructions

Rear view safety

Rear view safety RVS-5350-W Product manual installation & instructions

Safe Fleet RVS-218627 instruction manual

Safe Fleet

Safe Fleet RVS-218627 instruction manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
