Amantii FS-26-922 Assembly instructions

Repair Guide
12.03.20 -AC

Contents
•Replacing the LED light
•Replacing the flicker motor
•Replacing the heating element
•Replacing the PCB board
•Replacing the signal receiver

Replacing the LED lights
Step 1
To remove the front glass panel,
hold tightly and push upwards

Step 2
Unscrew the two screws on the top of
each side (red dots) to remove inner
side panels and ember bed glass
panel
Left Right

Remove screws → remove side panels → remove ember bed glass panel

Step 3
Replacing the ember bed LED lights
Ember bed LED lights are located here Unplug the red circled socket and
remove the old LED light with a new
one
To change flame light, see step 4

Step 4
Unscrew the 4 screws on both sides (circled in red) to remove the
plastic board

Now you can replace the flame light.

Replacing the flicker motor
Please follow Steps 1 & 2 from the
replacing the LED lights section to arrive
here

Replacing the ember bed flicker motor
Step 1
Unscrew the screw to separate
the motor and the flicker rod

Step 2
Unscrew the four screws circled
In red to remove the motor
Now you can change the motor

Replacing the flame effect flicker motor
Step 1
Unscrew 4 screws on both sides (circled in red) to
remove the plastic board

Step 2
Unscrew the screw to separate the
motor and flicker rod

Step 3
Right Left
Unscrew the four screws
on both side(circled in red,
the larger ones)

Step 4
Unscrew the six screws circled in left
picture, then you can remove the main
body cover

Step 5
Unscrew the screws to remove the flame effect
flicker motor

Replacing the heating element
Please follow steps 1& 2 from replacing the LED light, and steps 3 & 4 in
replacing the flame effect flicker motor
Step 1 Remove the upper cover
Unscrew the four screws circled in pictures,
on right and left sides of the fireplace body,
to remove upper cover
Right Left

Step 2
After the upper cover has been removed, you can see heating element (as shown be
Unscrew 3 screws.

Step 3
In order to remove the heating element, unscrew 4 additional screws that are
beneath the heating element and opposite to the three screws you removed at step 2
Right
Left
In detail

Step 4
Unplug the heating element to remove it
