Amazone UF 1002 User manual
Operating Manual
az
UF 1002 UF 1302
UF 1602 UF 2002
Mounted field sprayer with Comfort Package CP
MG6980
BAG00225.3 09.22
Printed in Germany
Please read this operating man-
ual before commissioning.
Keep it in a safe place fo
r
future use.
en
2 UF02 BAG00225.3 09.22
Reading the instruction
Manual and following it should seem to be incon-
venient and superfluous as it is not
enough to hear from others and to realize that a
machine is good, to buy it and to believe that now
everything should work by itself. The person in
question would not only harm himself but also
make the mistake of blaming the machine for pos-
sible failures instead of himself. In order to ensure
success one should enter the mind of a thing, make
himself familiar with every part of the machine
and get acquainted with how it's handled. Only in
this way could you be satisfied both with the ma-
chine and with yourself. This goal is the purpose o
f
this instruction manual.
Leipzig-Plagwitz 1872.
Identification data
UF02 BAG00225.3 09.22 3
Identification data
Manufacturer: AMAZONEN-WERKE
H. DREYER SE & Co. KG
Machine ID no.:
Tye UF02
Permissible system pressure (bar)
Year of manufacture:
Factory:
Basic weight (kg):
Permissible total weight (kg):
Maximum load (kg):
Manufacturer's address
AMAZONEN-WERKE
H. DREYER SE & Co. KG
Postfach 51
D-49202
Tel.:
E-mail:
Hasbergen, Germany
+ 49 (0)5405 501-0
Spare part orders
Spare parts lists are freely accessible in the spare parts portal at
www.amazone.de.
Please send orders to your AMAZONE dealer.
Foreword
4 UF02 BAG00225.3 09.22
Formalities of the operating manual
Document number: MG6980
Compilation date: 09.22
Copyright AMAZONEN-WERKE H. DREYER SE & Co. KG, 2022
All rights reserved.
Reprinting, even of extracts, is only possible with the approval of
AMAZONEN-WERKE H. DREYER SE & Co. KG.
This operating manual is valid for all versions of the implement.
All of the equipment is described without indicating it as special
optional equipment.
A description may be provided for equipment that is not fitted on the
implement or is only available in certain markets. The sales docu-
ments provide information on the equipment of your implement or
consult your dealer for more detailed information.
All information in this operating manual corresponds to the state
of knowledge at the time of publication. Due to ongoing develop-
ment of the implement, deviations are possible between the im-
plement and the information in this operating manual.
No claims can be made based on differences in the specifica-
tions, figures or descriptions.
Figures serve as a reference and are to be understood as representa-
tions of the principle.
If you want to sell the implement, ensure that the operating manual is
supplied with the implement.
Identification data
UF02 BAG00225.3 09.22 5
Foreword
Dear Customer,
You have chosen one of the quality products from the wide product
range of AMAZONEN-WERKE, H. DREYER SE & Co. KG. We thank
you for your confidence in our products.
On receiving the machine, check to see if it has been damaged during
transport or if parts are missing. Using the delivery note, check that
the machine has been delivered in full, including any special equip-
ment ordered. Damage can only be rectified if problems are signalled
immediately.
Before commissioning, read and understand this operating manual,
and particularly the safety information. Only after careful reading will
you be able to benefit from the full scope of your newly purchased
machine.
Please ensure that all the machine operators have read this operating
manual before the machine is commissioned.
Should you have any questions or problems, please consult this oper-
ating manual or contact your local service partner.
Regular maintenance and timely replacement of worn or damaged
parts increases the lifespan of your machine.
User evaluation
Dear Reader,
We update our operating manuals regularly. Your suggestions for im-
provement help us to create ever more user-friendly manuals.
AMAZONEN-WERKE
H. DREYER SE & Co. KG
Postfach 51
D-49202
Tel.:
E-mail:
Hasbergen, Germany
+ 49 (0)5405 501-0
