Amazone UF 901 User manual

Operating Manual
az
UF 901
UF 1201
UF 1501
UF 1801
Mounted field sprayer
MG3168
BAG0012.11
04.19
Printed in Germany
Please read this operating
manual before commissioning.
Keep it in a safe place for
future use.
en

Reading the instruction
Manual and following it should seem to be in-
convenient and superfluous as it is not
enough to hear from others and to realize that a
machine is good, to buy it and to believe that now
everything should work by itself. The person in
question would not only harm himself but also
make the mistake of blaming the machine for pos-
sible failures instead of himself. In order to ensure
success one should enter the mind of a thing,
make himself familiar with every part of the ma-
chine and get acquainted with how it's handled.
Only in this way could you be satisfied both with
the machine and with yourself. This goal is the
purpose of this instruction manual.
Leipzig-Plagwitz 1872.
2 UF BAG0012.11 04.19

Identification data
Identification data
Manufacturer:
AMAZONEN-WERKE
H. DREYER GmbH & Co. KG
Machine ID no.:
Type:
UF
Permissible system pressure (bar)
Year of manufacture:
Factory:
Basic weight (kg):
Permissible total weight (kg):
Maximum load (kg):
Manufacturer's address
AMAZONEN-WERKE
H. DREYER GmbH & Co. KG
Postfach 51
D-49202
Tel.:
E-mail:
Hasbergen, Germany
+ 49 (0)5405 501-0
[e-mail]
Spare part orders
Spare parts lists are freely accessible in the spare parts portal at
www.amazone.de.
Please send orders to your AMAZONE dealer.
Formalities of the operating manual
Document number:
MG3168
Compilation date:
04.19

Copyright AMAZONEN-WERKE H. DREYER GmbH & Co. KG, 2019
All rights reserved.
Reprinting, even of extracts, is only possible with the approval of
AMAZONEN-WERKE H. DREYER GmbH & Co. KG.
UF BAG0012.11 04.19 3

Foreword
Foreword
Dear Customer,
You have chosen one of the quality products from the wide product
range of AMAZONEN-WERKE, H. DREYER GmbH & Co. KG. We
thank you for your confidence in our products.
On receiving the machine, check to see if it has been damaged during
transport or if parts are missing. Using the delivery note, check that
the machine has been delivered in full, including any special equip-
ment ordered. Damage can only be rectified if problems are signalled
immediately.
Before commissioning, read and understand this operating manual,
and particularly the safety information. Only after careful reading will
you be able to benefit from the full scope of your newly purchased
machine.
Please ensure that all the machine operators have read this operating
manual before the machine is commissioned.
Should you have any questions or problems, please consult this op-
erating manual or contact your local service partner.
Regular maintenance and timely replacement of worn or damaged
parts increases the lifespan of your machine.
User evaluation
Dear Reader,
We update our operating manuals regularly. Your suggestions for
improvement help us to create ever more user-friendly manuals.
AMAZONEN-WERKE
H. DREYER GmbH & Co. KG
Postfach 51
D-49202
Tel.:
E-mail:
Hasbergen, Germany
+ 49 (0)5405 501-0
[e-mail]
4 UF BAG0012.11 04.19

Table of Contents
1User Information..........................................................................................9
1.1 Purpose of the document.........................................................................................................9
1.2 Locations in the operating manual...........................................................................................9
1.3 Diagrams..................................................................................................................................9
2General safety instructions.......................................................................10
2.1 Obligations and liability..........................................................................................................10
2.2 Representation of safety symbols..........................................................................................12
2.3 Organisational measures.......................................................................................................13
2.4 Safety and protection equipment...........................................................................................13
2.5 Informal safety measures.......................................................................................................13
2.6 User training...........................................................................................................................14
2.7 Safety measures in normal operation....................................................................................15
2.8 Danger from residual energy .................................................................................................15
2.9 Maintenance and repair work, fault elimination .....................................................................15
2.10 Design changes .....................................................................................................................15
2.10.1 Spare and wear parts and aids..............................................................................................16
2.11 Cleaning and disposal............................................................................................................16
2.12 User workstation ....................................................................................................................16
2.13 Warning symbols and other signs on the machine................................................................17
2.13.1 Positions of warning symbols and other labels......................................................................18
2.14 Dangers if the safety information is not observed..................................................................26
2.15 Safety-conscious working......................................................................................................26
2.16 Safety information for users...................................................................................................27
2.16.1 General safety and accident prevention information .............................................................27
2.16.2 Hydraulic system....................................................................................................................30
2.16.3 Electrical system....................................................................................................................31
2.16.4 Universal joint shaft operation................................................................................................31
2.16.5 Field sprayer operation..........................................................................................................33
2.16.6 Cleaning, maintenance and repairs.......................................................................................34
3Loading and unloading .............................................................................35
4Product description...................................................................................35
4.1 Overview of the assemblies...................................................................................................36
4.2 Safety and protection equipment...........................................................................................37
4.3 Supply hoses between the tractor and the machine..............................................................38
4.4 Transportation equipment......................................................................................................38
4.5 Intended use ..........................................................................................................................39
4.6 Device inspections.................................................................................................................40
4.7 Consequences of using certain crop protection agents.........................................................40
4.8 Danger areas and danger points ...........................................................................................41
4.9 Rating plate and CE mark......................................................................................................42
4.10 Conformity..............................................................................................................................42
4.11 Technically possible maximum application rate.....................................................................42
4.12 Maximum permissible application rate...................................................................................43
4.13 Technical Data.......................................................................................................................44
4.13.1 Basic machine........................................................................................................................44
4.13.2Payload ..................................................................................................................................45
4.13.3 Spraying technology ..............................................................................................................46
4.13.4 Residual amounts ..................................................................................................................47
4.14 Required tractor equipment ...................................................................................................49
4.15 Noise emissions data.............................................................................................................49
UF BAG0012.11 04.19 5

Table of Contents
5Construction and function of the basic machine................................... 50
5.1 Function................................................................................................................................. 50
5.2 Control panel......................................................................................................................... 52
5.3 Switch tap on the control terminal......................................................................................... 53
5.4 Parking supports ................................................................................................................... 55
5.5 Three-point attachment frame............................................................................................... 56
5.6 PTO shaft.............................................................................................................................. 57
5.6.1 Coupling the PTO shaft......................................................................................................... 59
5.6.2 Uncoupling the PTO shaft..................................................................................................... 60
5.7 Hydraulic connections........................................................................................................... 61
5.7.1 Coupling the hydraulic hose lines ......................................................................................... 62
5.7.2 Uncoupling the hydraulic hose lines...................................................................................... 63
5.8 Operating terminal or manual operation................................................................................ 64
5.8.1 Control terminal..................................................................................................................... 64
5.8.2 AMASPRAY+......................................................................................................................... 65
5.8.3 AMASET+.............................................................................................................................. 65
5.8.4 HB manual operation............................................................................................................. 66
5.9 Spray liquid tank.................................................................................................................... 69
5.9.1 Hinged/screw lid for the filling opening.................................................................................. 69
5.9.2 Filling the spray liquid tank (optional)................................................................................... 69
5.9.3 Fill level indicator................................................................................................................... 70
5.9.4 Step....................................................................................................................................... 70
5.9.5 Agitator.................................................................................................................................. 70
5.9.6 Suction port for filling the spray liquid tank (optional) ........................................................... 71
5.10 Flushing water tank............................................................................................................... 72
5.11 Fresh water tank.................................................................................................................... 73
5.12 Induction bowl with injector and canister flushing................................................................. 74
5.13 Pump equipment................................................................................................................... 75
5.14 Filter equipment..................................................................................................................... 76
5.14.1 Filling sieve............................................................................................................................ 76
5.14.2 Bottom sieve in the induction bowl........................................................................................ 76
5.14.3 Suction filter........................................................................................................................... 76
5.14.4 Self cleaning pressure filter................................................................................................... 77
5.14.5 Nozzle filters.......................................................................................................................... 77
5.15 Quick coupling system (optional).......................................................................................... 78
5.16 Removable transportation device (optional).......................................................................... 79
5.17 Exterior wash down kit (optional).......................................................................................... 80
5.18 Secure container for protective clothing (optional)................................................................ 80
5.19 Work lights............................................................................................................................. 81
5.20 FT 1001 front tank (optional) ............................................................................................. 81
5.21 Camera system..................................................................................................................... 82
5.22 Comfort equipment (optional)................................................................................................ 83
6Construction and function of the sprayer boom.................................... 84
6.1 Q-plus boom.......................................................................................................................... 89
6.1.1 Unlocking and locking the transport safety catch.................................................................. 90
6.1.2 Q-plus boom manually folded ............................................................................................... 91
6.1.3 Q-plus boom, folding via the tractor control unit ................................................................... 93
6.1.4 Working on one side using the right-hand boom .................................................................. 94
6.2 Super-S boom....................................................................................................................... 95
6.2.1 Unlocking and locking the transport safety catch.................................................................. 96
6.2.2 Super-S boom, folding via the tractor control unit........................................................... 97
6.3 Reduction joint on the outer boom (optional)........................................................................ 99
6.4 Boom width reduction (option) ............................................................................................ 100
6.5 Boom extension (option) ..................................................................................................... 101
6.6 Hydraulic tilt adjustment (optional)...................................................................................... 102
6 UF BAG0012.11 04.19

Table of Contents
6.7 Distance Control (optional) ..................................................................................................102
6.8 Spray lines ...........................................................................................................................103
6.9 Nozzles ................................................................................................................................105
6.9.1 Multiple nozzles ...................................................................................................................105
6.9.2 Edge nozzle .........................................................................................................................108
6.10 Automatic single nozzle control (optional)...........................................................................109
6.10.1 Single nozzle control AmaSwitch.........................................................................................109
6.10.2 4-way AmaSelect single nozzle control ...............................................................................109
6.11 Special optional equipment for liquid fertiliser .....................................................................111
6.11.1 Three-ray nozzles ................................................................................................................111
6.11.2 7 hole nozzles / FD- nozzles (optional)................................................................................112
6.11.3 Drag hose unit for liquid fertiliser (optional) .........................................................................113
6.12 Foam marker (optional)........................................................................................................114
7Commissioning........................................................................................115
7.1 Checking the suitability of the tractor...................................................................................116
7.1.1 Calculating the actual values for the total tractor weight, tractor axle loads and tyre load
capacities, as well as the minimum ballast..........................................................................116
7.2 Installing the PTO shaft........................................................................................................120
7.3 Adjusting the length of the PTO shaft to the tractor.............................................................121
7.4 Securing the tractor / machine against unintentional start-up and rolling............................123
7.5 Installing sensor "X" (cardan shaft / wheel) for determining the distance travelled and
operational speed ................................................................................................................124
7.5.1 Installation on a tractor without all-wheel drive....................................................................124
7.5.2 Installation on a tractor with all-wheel drive or an Mb-trac ..................................................125
7.6 Adjusting the hydraulic system with the system setting screw............................................126
8Coupling and uncoupling the machine..................................................128
8.1 Coupling the machine ..........................................................................................................128
8.2 Uncoupling the machine ......................................................................................................131
9Adjustments.............................................................................................132
9.1 Positions of the control elements for the different operation modes....................................132
10 Transportation .........................................................................................133
11 Using the machine...................................................................................135
11.1 Preparing for spraying operation .........................................................................................137
11.2 Preparing the spray liquid....................................................................................................138
11.2.1 Calculating the filling and re-fill quantity ..............................................................................142
11.2.2 Filling table for remaining spray area...................................................................................143
11.3 Filling with water ..................................................................................................................145
11.3.1 Filling the spray liquid tank via the filling opening................................................................146
11.3.2 Filling the spray liquid tank via the suction port on the control terminal ..............................146
11.4 Filling the spray liquid tank / flushing water tank through the pressure connection ............148
11.5 Filling the fresh water tank...................................................................................................148
11.6 Inducting agents...................................................................................................................149
11.6.1 Clean the spray agent canister and induction bowl.............................................................151
11.6.2 Ecofill....................................................................................................................................152
11.7 Spraying operation...............................................................................................................153
11.7.1 Applying the spray liquid......................................................................................................155
11.7.2 Drift reduction measures......................................................................................................157
11.7.3 Dilute the spray liquid with flushing water............................................................................157
11.8 Residues..............................................................................................................................158
11.8.1 Diluting the residue in the spray liquid tank and spraying the diluted residue at the end of
spraying operation ...............................................................................................................159
11.8.2 Draining the spray liquid tank using the pump.....................................................................161
11.9 Cleaning the field sprayer....................................................................................................162
11.9.1 Cleaning the sprayer with the tank empty............................................................................163
UF BAG0012.11 04.19 7

Table of Contents
11.9.2 Draining the final residues................................................................................................... 164
11.9.3 Cleaning the suction filter.................................................................................................... 165
11.9.4 Cleaning the suction filter when tank is full......................................................................... 165
11.9.5 Cleaning the pressure filter when the tank is empty........................................................... 166
11.9.6 Cleaning the pressure filter when the tank is full ................................................................ 166
11.9.7 External cleaning................................................................................................................. 167
11.9.8 Cleaning the sprayer during a critical agent change........................................................... 168
11.9.9 Cleaning the sprayer with a full tank (work interruption)..................................................... 169
12 Faults........................................................................................................ 170
13 Cleaning, maintenance and repairs....................................................... 171
13.1 Cleaning .............................................................................................................................. 173
13.2 Winter storage and long periods out of operation............................................................... 174
13.3 Lubrication instructions........................................................................................................ 178
13.4 Maintenance schedule – overview...................................................................................... 179
13.5 Hydraulic system................................................................................................................. 181
13.5.1 Labelling of hydraulic hose lines......................................................................................... 182
13.5.2 Maintenance intervals ......................................................................................................... 182
13.5.3 Inspection criteria for hydraulic hose lines.......................................................................... 182
13.5.4 Installing and removing hydraulic hose lines....................................................................... 183
13.5.5 Fluid filter............................................................................................................................. 184
13.5.6 Cleaning the solenoid valves .............................................................................................. 184
13.5.7 Clean / exchange the filter in the hydraulic plug ................................................................. 185
13.5.8Hydro-pneumatic pressure reservoir................................................................................... 185
13.6 Adjusting the hydraulic throttle valve................................................................................... 186
13.6.1 Q-plus boom........................................................................................................................ 186
13.6.2 Super-S boom ..................................................................................................................... 187
13.7 Settings on the folded-out sprayer boom............................................................................ 189
13.8 Pump................................................................................................................................... 190
13.8.1 Checking the oil level .......................................................................................................... 190
13.8.2 Changing the oil .................................................................................................................. 190
13.8.3 Checking and replacing the suction and pressure-side valves........................................... 191
13.8.4 Checking and replacing piston diaphragms (workshop work)............................................. 192
13.9 Calibrating the field sprayer ................................................................................................ 194
13.9.1 Determining the actual spray rate by driving a calibration distance.................................... 195
13.10 Setting the volumetric remote control.................................................................................. 197
13.11 Nozzles................................................................................................................................ 198
13.12 Line filter.............................................................................................................................. 199
13.13 Instructions on testing the field sprayer............................................................................... 200
13.14 Electric lighting system........................................................................................................ 201
13.15 Upper and lower link pins.................................................................................................... 201
13.16 Screw tightening torques..................................................................................................... 202
13.17 Disposing of the field sprayer.............................................................................................. 203
14 Liquid circuit............................................................................................ 204
15 Spray table............................................................................................... 207
15.1 Spray tables for flat-fan, anti-drift, injector and airmix nozzles, spraying height 50 cm..... 207
15.2 Spraying nozzles for liquid manure..................................................................................... 211
15.2.1 Spray table for three-ray nozzles, spraying height 120 cm................................................. 211
15.3 Spray table for 7-hole nozzles............................................................................................. 212
15.3.1 Spray table for FD- nozzles................................................................................................. 214
15.4 Spray table for drag hose unit ................................................................................................. 215
15.5 Conversion table for spraying ammonium nitrate / urea solution (AUS) liquid fertiliser...... 218
8 UF BAG0012.11 04.19

User Information
1 User Information
The User Information section provides information on use of the oper-
ating manual.
1.1 Purpose of the document
This operating manual
•describes the operation and maintenance of the machine.
•provides important information on safe and efficient handling of
the machine.
•is a component part of the machine and should always be kept
with the machine or the towing vehicle.
•Keep it in a safe place for future use.
1.2 Locations in the operating manual
All the directions specified in the operating manual are always seen in
the direction of travel.
1.3 Diagrams
Instructions and responses
Activities to be carried out by the user are given as numbered instruc-
tions. Always keep to the order of the instructions. The response to an
instruction is given by an arrow. Example:
1. Instruction 1
→Machine response to instruction 1
2. Instruction 2
Lists
Lists without an essential order are shown as a list with bullets. Ex-
ample:
•Point 1
•Point 2
Item numbers in diagrams
Numbers in round brackets refer to the item numbers in the diagrams.
The first number refers to the diagram and the second number to the
item.
Example: (Fig. 3/6)
•Figure 3
•Item 6
UF BAG0012.11 04.19 9

General safety instructions
2 General safety instructions
This section contains important information on safe operation of the
machine.
2.1 Obligations and liability
Comply with the instructions in the operating manual
Knowledge of the basic safety information and safety regulations is a
basic requirement for safe handling and fault-free machine operation.
Obligations of the operator
The operator is obliged only to let those people work with/on the ma-
chine who
•
are aware of the basic workplace safety information and accident
prevention regulations.
•have been instructed in working with/on the machine.
•have read and understood this operating manual.
The operator is obliged
•to keep all the warning symbols on the machine in a legible
state.
•to replace damaged warning symbols.
•If you still have queries, please contact the manufacturer.
Obligations of the user
Before starting work, anyone charged with working with/on the ma-
chine is obliged
•to comply with the basic workplace safety instructions and acci-
dent prevention regulations.
•
to read and follow the "General safety information" section of this
operating manual.
•to read the section "Warning symbols and other labels on the
machine" (page 17) of this operating manual and to follow the
safety instructions represented by the warning symbols when
operating the machine.
•to get to know the machine.
•to read the sections of this operating manual that are important
for carrying out their work.
If the user discovers that a function is not working properly, then they
must eliminate this fault immediately. If this is not the task of the user
or if the user does not possess the appropriate technical knowledge,
then they should report this fault to their superior (operator).
10 UF BAG0012.11 04.19

General safety instructions
Risks in handling the machine
The machine has been constructed to the state-of-the art and the
recognised rules of safety. However, operating the machine may
cause risks and restrictions to
•the health and safety of the user or third parties,
•the machine,
•other property.
Only use the machine
•for the purpose for which it was intended.
•in a perfect state of repair.
Eliminate any faults immediately which could impair safety.
Guarantee and liability
Our "General conditions of sales and delivery" are always applicable.
These shall be available to the operator, at the latest on conclusion of
the contract. Guarantee and liability claims for damage to people or
property will be excluded if they can be traced back to one or more of
the following causes:
•Improper use of the machine.
•Improper installation, commissioning, operation and mainte-
nance of the machine.
•Operation of the machine with defective safety equipment or
improperly attached or non-functioning safety equipment.
•Non-compliance with the instructions in the operating manual
regarding commissioning, operation and maintenance.
•Unauthorised design changes to the machine.
•Insufficient monitoring of machine parts which are subject to
wear.
•Improperly executed repairs.
•Disasters through the impact of foreign bodies and Acts of God.
UF BAG0012.11 04.19 11

General safety instructions
2.2 Representation of safety symbols
Safety instructions are indicated by the triangular safety symbol and
the highlighted signal word. The signal word (DANGER, WARNING,
CAUTION) describes the gravity of the risk and has the following sig-
nificance:
DANGER
Indicates an immediate high risk which will result in death or
serious physical injury (loss of body parts or long term damage)
if not avoided.
If the instructions are not followed, then this will result in imme-
diate death or serious physical injury.
WARNING
Indicates a medium risk, which could result in death or (serious)
physical injury if not avoided.
If the instructions are not followed, then this may result in death
or serious physical injury.
CAUTION
Indicates a low risk which could cause minor or medium level
physical injury or damage to property if not avoided.
IMPORTANT
Indicates an obligation to special behaviour or an activity re-
quired for proper machine handling.
Non-compliance with these instructions can cause faults on the
machine or disturbance to the environment.
NOTE
Indicates handling tips and particularly useful information.
These instructions will help you to use all the functions of your
machine in the best way possible.
12 UF BAG0012.11 04.19

General safety instructions
2.3 Organisational measures
The operator must provide the necessary personal protective equip-
ment as per the information provided by the manufacturer of the crop
protection agent to be used, such as:
•Chemical-resistant gloves,
•Chemical-resistant overalls,
•Water-resistant footwear,
•A face mask,
•Breathing protection,
•Safety glasses;
•Skin protection agents, etc.
The operating manual
•
must always be kept at the place at which the machine is
operated.
•
must always be easily accessible for the user and mainte-
nance personnel.
Check all safety equipment regularly.
2.4 Safety and protection equipment
Before starting up the machine each time, all the safety and protection
equipment must be properly attached and fully functional. Check all
safety and protection equipment regularly.
Faulty safety equipment
Faulty or disassembled safety and protection equipment can lead to
dangerous situations.
2.5 Informal safety measures
As well as all the safety information in this operating manual, comply
with the general, national regulations pertaining to accident prevention
and environmental protection.
When driving on public roads and routes you should comply with the
statutory road traffic regulations.
UF BAG0012.11 04.19 13

General safety instructions
2.6 User training
Only those people who have been trained and instructed may work
with/on the machine. The operator must clearly specify the responsi-
bilities of the people charged with operation and maintenance work.
People being trained may only work with/on the machine under the
supervision of an experienced person.
Person
Activity
Person special-
ly trained for the
activity1)
Trained opera-
tor2) Person with specialist
training
(specialist workshop*)3)
Loading/Transport X X X
Commissioning -- X --
Set-up, tool installation -- -- X
Operation -- X --
Maintenance -- -- X
Troubleshooting and fault elimina-
tion X -- X
Disposal X -- --
Legend:
X..permitted
--..not permitted
1) A person who can assume a specific task and who can carry out
this task for an appropriately qualified company.
2) Instructed persons are those who have been instructed in their
assigned tasks and in the possible risks in the case of improper
behaviour, have been trained if necessary, and have been in-
formed about the necessary protective equipment and
measures.
3) People with specialist technical training shall be considered as a
specialist. Due to their specialist training and their knowledge of
the appropriate regulations, they can evaluate the work with
which they have been charged and detect possible dangers.
Comment:
A qualification equivalent to specialist training can be obtained
from several years' experience in the relevant field.
If maintenance and repair work on the machine is additionally marked
"Workshop work", only a specialist workshop may carry out such
work. The personnel of a specialist workshop shall possess the ap-
propriate knowledge and suitable aids (tools, lifting and support
equipment) for carrying out the maintenance and repair work on the
machine in a way which is both appropriate and safe.
14 UF BAG0012.11 04.19

General safety instructions
2.7 Safety measures in normal operation
Only operate the machine if all the safety and protection equipment is
fully functional.
Check the machine at least once a day for visible damage and check
the function of the safety and protection equipment.
2.8 Danger from residual energy
Note that there may be residual mechanical, hydraulic, pneumatic and
electrical/electronic energy on the machine.
Use appropriate measures to inform the operating personnel. You can
find detailed information in the relevant sections of this operating
manual.
2.9 Maintenance and repair work, fault elimination
Carry out prescribed setting, maintenance and inspection work in
good time.
Secure all media such as compressed air and the hydraulic system
against unintentional start-up.
Carefully fix and secure larger assemblies to lifting gear when carry-
ing out replacement work.
Regularly check that bolted connections are firmly secured and tight-
en if necessary.
When the maintenance work is completed, check the function of the
safety devices
2.10 Design changes
You may make no changes, expansions or modifications to the ma-
chine without the authorisation of AMAZONEN-WERKE. This also
applies when welding support parts.
Any expansion or modification work shall require the written approval
of AMAZONEN-WERKE. Only use modification and accessory parts
approved by AMAZONEN-WERKE so that the type approval, for ex-
ample, remains valid in accordance with national and international
regulations.
Vehicles with an official type approval or with equipment connected to
a vehicle with a valid type approval or approval for road transport
according to the German road traffic regulations must be in the state
specified by the approval.
WARNING
Risk of crushing, cutting, catching, being drawn in or impact
from the failure of support parts.
It is strictly forbidden to
•drill holes in the frame or on the running gear.
•increase the size of existing holes on the frame or the running gear.
•weld support parts.
UF BAG0012.11 04.19 15

General safety instructions
2.10.1 Spare and wear parts and aids
Immediately replace any machine parts which are not in a perfect
state.
Only use genuine AMAZONE spare and wear parts or those ap
proved
by AMAZONEN-WERKE so that the type approval remains valid ac-
cording to the national and international regulations. The use of spare
and wear parts from third parties does not guarantee that they have
been constructed in a way as to meet the requirements placed on
them.
AMAZONEN-WERKE shall accept no liability for damage caused by
the use of non-approved spare and wear parts or aids.
2.11 Cleaning and disposal
Handle and dispose of any materials used carefully, in particular
•when carrying out work on lubrication systems and equipment
and
•when cleaning using solvents.
2.12 User workstation
The machine may only be operated by one person sitting in the driv-
er's seat of the tractor.
16 UF BAG0012.11 04.19

General safety instructions
2.13 Warning symbols and other signs on the machine
Always keep all the warning symbols on the machine clean and in a
legible state. Replace illegible warning symbols. You can obtain the
warning symbols from your dealer using the order number (e.g. MD
075).
Warning symbols - structure
Warning symbols indicate danger areas on the machine and warn
against residual dangers. At these points, there are permanent or
unexpected dangers.
A warning symbol consists of two fields:
Field 1
is a symbol describing the danger, surrounded by triangular safety
symbol.
Field 2
is a symbol showing how to avoid the danger.
Warning symbols - explanation
The column Order number and explanation provides an explanation
of the neighbouring warning symbol. The description of the warning
symbols is always the same and specifies, in the following order:
1. A description of the danger.
For example: risk of cutting
2. The consequence of non-compliance with the risk avoidance
instructions.
For example: causes serious injuries to fingers or hands.
3. Risk avoidance instructions.
For example: only touch machine parts when they have come to
a complete standstill.
UF BAG0012.11 04.19 17

General safety instructions
2.13.1 Positions of warning symbols and other labels
Warning symbols
The following diagrams show the arrangement of the warning symbols
on the machine.
Fig. 1
Fig. 2
Fig.
3
18 UF BAG0012.11 04.19

General safety instructions
Super-S boom
Fig. 4
Q-Plus boom
Fig. 5
UF BAG0012.11 04.19 19

General safety instructions
Order number and explanation
Warning symbols
MD 078
Risk of crushing fingers or hands due to ac-
cessible moving parts in the machine.
This danger can cause extremely serious injuries
and the loss of body parts.
Never reach into the danger area when the trac-
tor engine is running with PTO shaft / hydraulic /
electronics system connected.
MD 082
Risk of falling due to personnel riding on
treads or platforms.
This danger can cause extremely serious and
potentially fatal injuries.
It is forbidden to ride on the machine or climb the
machine when it is running. This also applies to
machines with treads or platforms.
Make sure that nobody is riding on the machine.
MD 084
Risk of crushing the entire body due to
standing in the swivel range when machine
parts are being lowered.
This danger can cause extremely serious and
potentially fatal injuries.
•
It is forbidden to stand in the swivel range of
the machine when machine parts are being
lowered.
•Instruct personnel to leave the swivel range
of any machine parts which can be lowered
before you lower the parts.
20 UF BAG0012.11 04.19
