AMC MP 02B User manual

User
Manual
MP 02B
Music Player

Safety instructions
USER MANUAL MP 02B Music Player
When using this electronic device, basic precautions
should always be taken, including the following:
1Read all instructions before using the product.
2Do not use this product near water (e.g., near a bathtub, washbowl,
kitchen sink, in a wet basement or near a swimming pool etc).
3 Use this device when you are sure that microphone receiver has
a stable base and it is fixed securely.
4This product, in combination with loudspeakers and amplifier may be
capable of producing sound levels that could cause permanent hearing
loss. Do not operate for a long period of time at a high volume level or at
a level that is uncomfortable. If you experience any hearing loss or ringing
in the ears, you should consult with otorhinolaryngologist.
5The product should be located away from heat sources such as radiators,
heat vents, or other devices that produce heat.
6The product should be connected to a power supply that is described
in the operating instructions or are marked on the product.
7The power supply should be undamaged and never share an outlet
or extension cord with other devices. Never leave device plugged
into the outlet when it is not being used for a long period of time.
8Care should be taken that objects do not fall into liquids and liquids
would not be spilled on the device.
9The product should be serviced by qualified service personnel if:
– The power supply or the plug has been damaged.
– Objects have fallen into or liquid has been spilled on the product.
– The product has been exposed to rain.
– The product has been dropped or the enclosure damaged.
10 There are some areas with high voltage inside, to reduce the risk of electric
shock do not remove cover of the microphone receiver or power supply.
The cover should be removed by the qualified personnel only.

Table of contents
USER MANUAL MP 02B Music Player
Before you start
Introduction......................................................................................................................................................2
Features................................................................................................................................................................2
Operation
Front panel ........................................................................................................................................................3
Rear panel...........................................................................................................................................................3
Remote control...............................................................................................................................................4
CD/USB/SD player functions.................................................................................................................5
FM radio tuner functions.........................................................................................................................6
Bluetooth audio player functions .....................................................................................................7
Specifications
General specifications................................................................................................................................8

USER MANUAL MP 02B Music Player
Before you start
02
MP 02B music player with integrated SD card and USB flash drive readers, CD player, FM radio tuner
and Bluetooth audio player.
FEATURES
• Compressedaudioplayback
• Supportsupto32GBUSBashandSDcards
• ID3informationsupport
• FMradiotuner
• Bluetoothaudioplayer
• IRremotecontrol
• StereoRCAoutput

USER MANUAL MP 02B Music Player
Front Panel
Rear Panel
1. Power switch |2. USB slot |3. CD/USB/SD player display |4. CD slot |5. Program |6. Player controls |7. CD eject |8. Repeat |9. Folder skip
10.A-Brepeat|11. Mute |12. Function |13. SD/MMC card slot |14. Radio tuner display |15. IR receiver |16. Station presets
17. Bluetooth antenna and indicators |18. Bluetooth pair |19. Bluetooth player controls |20. Jump through 5 radio station presets |21. Memory
22. Station search |23. Music source select: CD/TUNER/BLUETOOTH
1. FM antenna connector |2.StereoRCAoutput|3. Mains power input and fuse holder
Operation
1 6 7 13 2
1
9 10 11 20 21 22 23128
4 5
2
19
1715 16 1814
3
3
03

USER MANUAL MP 02B Music Player
Remote control Changing batteries
1. Open the battery cover
2.InserttwoAAAbatteriesas
marked inside the remote control
battery compartment
3. Close the battery cover
1. IR remote buttons which are assigned to control CD/USB/SD player only. |2. IR remote buttons which are assigned to control both CD/USB/SD player and radio
tuner. In white color are marked functions for the CD/USB/SD player, in red – functions for the radio tuner. |3. IR remote buttons which are assigned to control
radio tuner player only. |4. Select CD/USB/SD or Radio tuner for IR remote control. Selected player is indicated by green color LED on the front panel.
04
Operation

USER MANUAL MP 02B Music Player
CD/USB/SD Functions
FUNCT
Selectaudiosource(CD/USB/CARD).
PLAYER CONTROLS
Play/Pause, Stop and skip files.
FOLDER SKIP
Select previous or the next folder.
A - B
Repeat selected place in the file. When file is playing pressing this button one
timesetsstartpointandpressingthesecondtimesetsendpoint.Press“A-B”
button one more time to stop repeating playback.
EJECT
Ejected CD from the player.
PROG
Keyisusedforprogramming.AllprogrammingisclearedwhenSTOPkeyis
pushed in the programming mode.
MUTE
Mute and unmute sound from the output.
REPEAT
InUSB/SDmode,whenpushingthekeyPLAYmodeswitcheslikeshownbelow:
WhilepushingthekeyinCDmode,PLAYmodeischangedinthisorder:
05
Operation

USER MANUAL MP 02B Music Player06
Operation
FM Radio Tuner Functions
MEMORY
Whenradiotunerisonpressing“MEM”buttonstartsashingpresetnumber.Set
thepresetnumberusingnumberkeysandpress“Memory”tosavethepreset.
Thedisplayedfrequencywillbestoredintheselectedpreset(1-30).
After5secondsofinactivityplayerexitsmemorymodeautomatically.
+5 AND +10/--
Thesekeysallowtoselectpresets1-5,6-10...26-30fromthefrontpanelor1-10,
2-20,3-30fromtheremote.Longpressof+10/--keywillalloweneringpreset
number using number keys.
ASM
Thisafunctiontoautosearchandstoreradiostations.Longpressof“ASM”button
will search for all available radio stations and store them in memory presets.
MANUAL TUNING
Longpressof“UP”or“DOWN”ontheremoteor“TUNE-/+”onthefrontpanel
will start auto tuning. Short press adjusts frequency manually in 50kHz steps.
SLEEP
In sleep mode radio tuner automatically turns off after set time. Maximum time
for sleep function is 90 minutes.
DIRECT
Set radio frequency using the number keys. Press this button once, input station
frequency,press“DIRECT”keyagaintoconrmthefrequencyandthetunerwill
jump to this station.
If the input frequency is beyond the range, the tuner will display ERR.
SLEEP
In sleep mode radio tuner automatically turns off after set time. Maximum time
for sleep function is 90 minutes.
MO/ST
Press“MO/ST”buttontosetmonoorstereomodefortheradiotuner.
RDS
Change RDS functions* cyclically: PS →PTY→RT →CT
PS – program service (call letters or station identity name will displayed)
PTY-programtype
RT-radiotext(textualinformation,usuallytitleandartistofthecurrentlyplaying
song)
CT-clocktime
RDSfunctions*-theRDSinformationandfunctionsdependfromradiostationbroadcasting.

USER MANUAL MP 02B Music Player07
Operation
BluetoothAudioPlayerFunctions
CD/TUNER/BT
Select audio source: CD player, FM TUNER or Bluetooth player
PAIR LED INDICATOR
LED is ON with short blinks – searching for the paired device (not connected).
LED is constantly blinking – the Bluetooth module is in pairing mode.
LED is OFF – device is successfully paired and connected.
PAIRING
Pressingthiskeyfor3secondswillenterBluetoothpairingmode(PAIRLEDindi-
cator starts blinking). Connect to the player using your Bluetooth audio device.
BLUETOOTH AUDIO PLAYER CONTROLS
Start or pause connected Bluetooth device audio playback, skip tracks.
MANUAL TUNING
Longpressof“UP”or“DOWN”buttonwillstartautotuning.
Shortpressof“UP”or“DOWN”buttonadjustsfrequencymanuallyin50kHzsteps.

USER MANUAL MP 02B Music Player
General Specifications
MP 02B
Power supply : 230VAC50Hz
Power consumption: 50VA
Weight: 3,8kg
Dimension: 482mm x 44mm x 250mm
Output UnbalancedstereoRCA
CD/USB/SD section
Output level: +4dBu(±2dBu)
Output level difference
between channels 2dB
Frequency response 20 Hz 20 KHz
Audiochannelseparation
@ 1 KHz 60 dB
THD 0,1 %
S/N ration 70 dB
FM radio tuner section
Output level: -5dBu
Tuning Frequency range 87,5 – 108 MHz
Sensitivity 10 μV
S/N ratio 55 dB
Image rejection 45 dB
THD 0,1 %
Audiochannelseparation 35 dB
Antennainput FM 75 ohm unbalanced
Memory 30 presets
8
