AMC MP05 User manual

IMPORTANT SAFETY INSTRUCTIONS
When using this electronic device,
asic precautions should always e
taken, including the following:
1. Read all instructions before using the product.
2. Do not use this product near water (e.g., near a bathtub, washbowl, kitchen sink, in a
wet basement or near a swimming pool etc).
3. Use this device when you are sure that player has a stable base and it is fixed securely.
4. his product, in combination with amplifier and loudspeakers may be capable of
producing sound levels that could cause permanent hearing loss. Do not operate for a
long period of time at a high volume level or at a level that is uncomfortable. If you
experience any hearing loss or ringing in the ears, you should consult with
otorhinolaryngologists. he product should be positioned so that proper ventilation is
maintained.
5. he product should be located away from heat sources such as radiators, heat vents, or
other devices (including amplifiers) that produce heat.
6. he product should be connected to a power supply that is described in the operating
instructions or are marked on the product. Replace the fuse only with one of the
specified type, size and correct rating.
7. he power supply cord should be undamaged and never share an outlet or extension
cord with other devices so that the outlet or extension cord's power rating is exceeded.
Never leave device plugged in to the outlet when it is not being used for a long period
of time.
8. Care should be taken so that objects do not fall into, and liquids would not be spilled
through, the enclosure's openings.
9. he product should be serviced by qualified service personnel if:
•he power supply cord or the plug has been damaged.
•Objects have fallen into or liquid has been spilled on the product.
•he product has been exposed to rain.
•he product has been dropped or the enclosure damaged.
10. here are some areas with high voltage inside, to reduce the risk of electric shock do not
remove cover of the player. he cover should be removed by the qualified personnel only.
No user servicea le parts inside.

CON EN S:
Before you start
What’s in the box 4
Hints on installation 4
Controls and connections
Front panel 5
Rear panel 5
IR remote control 6
Batteries changing 6
Settings and functions
Functions description 7
Remote control pinout 10
RS 232 commands 11
Specifications
General 12

What’s in the ox
he accessories which are included in the MP 05 music player recorder box are:
•Remote control
•Instruction manual
•Power cable
Hints on installation
Do…
•Use in a well-ventilated room.
•Place on a solid, flat, level surface, such as a table, shelf or stereo rack.
Don’t…
•Use in a place exposed to high temperatures or humidity, including near radiators and
other
heat-generating appliances.
•Place on a window sill or a place where the player will be exposed to direct sunlight.
•Use in an excessively dusty or damp environment.
•Place directly on top of an amplifier, or other component that becomes hot in use.
•Use near television or monitor as you may experience interference-especially if the
television
uses an indoor antenna.
•Use in a kitchen or other room where the player may be exposed to smoke or steam.
•Use on a thick rug or carpet, or cover with cloth-this may prevent proper cooling of the
unit.
•Place on an unstable surface, or one that is not large enough to support all four of the
unit’s
feet.
•Do not use or store batteries in direct sunlight or other hot place, such as inside car or
near heater. his can cause batteries to leak, overheat, explode or catch fire. It can also
reduce the life or performance of batteries.

Front Panel
1. ON/OFF switch
2. SD MMC card’s slot
3. rack selection buttons
4. Display
5. USB flash’s slot
6. Find
7. Folder up/down
8. Repeat
9. Record/delete
10. Function
11. Input level indicator
12. Input level potentiometer
13. Eject
14. Play/Pause
15. Stop
16. Down/Rev
17. Prog
18. IR detector
19. CD slot
Rear Panel
1. Serial interface RS 232
2. Remote control trigger
3. Stereo outputs
4. Stereo inputs for recording
5. Mains power socket

IR remote control
1. Play/Pause
2. Stop
3. Prog
4. Find
5. ESP
6. Rev
7. Cue
8. Rec/del
9. Function
10. rack selection buttons
11. Folder up
12. Folder down
13. Display
14. Repeat
15. Mute
16. Eject
Batteries changing
1. Open the battery cover.
2. Insert two AAA batteries in
accordance with marks in the
remote control battery
compartment.
3. Close the battery cover

Functions description
ON/OFF switch.
urns on and off the device.
SD MMC card’s slot
his slot is designed for SD and MMC cards. Please note that maximum supported capacity of
card is up to 32GB.
Track selection uttons
Allows select the sound tracks directly.
Display
Displays the status of the device and main information about the files and folders.
USB flash’s slot
his slot is designed for USB flash disc and it can support up to 32GB capacity.
Find
By pressing this key once search mode is changed into FILE search. By pressing this key twice
search mode is changed into FOLDER search.
Folder up
In stop mode this key skips the starting play folder to next folder, and automatically switches to first folder
if current folder is last.
In the program entry mode this key switches to next folder’s first file, if the folder is last it switches to first
folder.
In normal play mode this key skips the playing file and switches to next folder’s first file.
Folder down
In stop mode this key skips the starting play folder to next previous, and automatically switches to last
folder if current folder is first.
In the program entry mode this key switches to previous folder’s first file, if the folder is first it switches to
last folder.
In normal play mode this key skips the playing file and switches to previous folder’s first file.
Repeat
Pressing this key allows to change sound tracks playing mode like in picture below.

Record/delete
Recording from AUX input
When AUX is selected on the display, press the REC button to start recording audio signal from
the REC input. AUX input must be selected by the “FUNC” button before the start of the
recording. he AUX input level can be adjusted by using input level potentiometer according to
level indicator located in the front panel. o stop the recording, press the REC button again. For
confirmation of successful ending “REC OK” appears on the screen. All records will be named
automatically and placed in M AUX folder, like in the picture below.
Recording from CD
If CD player is selected, and CD with compressed audio files is inserted, after pressing REC button
CD audio signal will be recorded to SD MMC or USB flash. Press REC button again to stop the
recording and the confirmation of successful ending “REC OK” appears on the screen. All records
will be named automatically and placed in CDROM folder, like in the picture below.
If CD player is selected and audio CD is inserted, after pressing REC button CD audio signal will be
recorded to SD MMC or USB flash. Press REC button again to stop the recording and the
confirmation of successful ending “REC OK” appears on the screen. All records will be named
automatically and placed in CD-DA folder, like in the picture below.
Copying
If USB or SD/MMC source are selected you can copy files from one source to another (from USB
to SD/MMC and contrary). Press REC button and by using REV ant CUE keys find the desired
folder. After this you must select the file from this folder by pressing REV or CUE for the long time.
Now you can press REC button one more time and copying will be started. During the copy
procedure display will show “COPY”. If copy is successful “COPY OK” appears on the screen.

Delete
If USB or SD/MMC source are selected you can delete files from memory card or flash. First of all
you must press DEL button to turn on delete function. By pressing REV or CUE keys find the
folder. After this you must select the file from this folder by pressing REV or CUE for the long time.
After file selection press DEL button one more time to delete file.
FUNC
his key allows change music scourge and select AUX input. When this key is pressed device
mode are changed cyclically as in picture below.
Input level indicator
hese LED’s indicates level of the recording signal from the REC input.
Input level potentiometer
his potentiometer is for adjusting the recording audio level from the REC input.
EJECT
By pushing this key CD is ejected.
PLAY/PAUSE
By pressing this key when device is stopped, play starts after track search. When this key is
pressed during playing the mode of the device is changed in to pause. When this key is pressed
during pause, it switches back to play mode.
STOP
When device is playing or is in pause mode, by pressing this you will stop it.
Down/Rev
In stop mode this key changes starting track (file) in descending order, and automatically goes to
the last track if it is in first track.
Single pressed in play mode or program mode changes to previous track (file).
By pressing longer than 0,7 sec switches to fast reverse mode.
Up/Cue
In stop mode this key changes starting track (file) in ascending order, and automatically goes to
first track if it is in the last track.
Single pressed in play mode or program mode changes to next track, in random mode skips to
random track.
By pressing longer than 0,7 sec. switches to fast forward mode..
PROG
his key is used for programming.
All programs are cleared when S OP key is pushed in the programming mode.

IR detector
Receive controls commands from remote control.
CD slot
his slot is designed for CD and it can support compressed audio files.
Serial interface RS 232
D-Sub 9-pin connection for serial interface (RS232). his connector is designed to control device
functions by using external control unit, like Creston or PC etc.
Remote control trigger
Because of this input the device can by controlled by using external push buttons or relays. he
maximum distance between the device and push buttons should be up to 10m. if shielded cable
are used.
Stereo output
his is line level output with balanced stereo XLR and stereo RCA connectors.
Stereo input for recording
his is line level input with balanced stereo XLR and stereo RCA connectors for the audio
recording. Recording audio level can be adjusted by using potentiometer located in the front
panel. o prevent signal clipping please give attentions to signal level indicator located in the
front panel too.
Remote control pinout
D-SUB 25 connector
Remote control connector. Pin’s description. Remote control wiring diagram
Pin
num er
Description
1
GND
2
Play/pause
3
Stop
4
Up
5
Down
6
Folder skip
>>
7
Folder skip
<<
8
Repeat
9
Eje
ct
10
PROG
11
Find
12
Mute
13
Function
14
Record
15
Delete
16
0
17
1
18
2
19
3
20
4
21
5
22
6
23
7
24
8
25
9

RS 232 commands
Baud rate 9600,
8 data bits,
no parity,
1 stop bit,
no flow control.
Byte
1
2
3
4
5
Functions
ASCII ASCII ASCII HEX HEX
Folder skip >>
E A A 0d 0a
Folder skip <<
E A B 0d 0a
Down E A C 0d 0a
Up E A D 0d 0a
Stop E A E 0d 0a
Play/ pause E A F 0d 0a
Eject E A G 0d 0a
PROG E A H 0d 0a
ESP E A I 0d 0a
Find E A J 0d 0a
Mute E A K 0d 0a
Play mode E A L 0d 0a
FUNC E A M 0d 0a
Display E A N 0d 0a
REC E A O 0d 0a
Delete E A P 0d 0a
0 E A 0 0d 0a
1 E A 1 0d 0a
2 E A 2 0d 0a
3 E A 3 0d 0a
4 E A 4 0d 0a
5 E A 5 0d 0a
6 E A 6 0d 0a
7 E A 7 0d 0a
8 E A 8 0d 0a
9 E A 9 0d 0a
Answer from device if OK
+ O K 0d 0a
Answer from device if ERROR
+ E R 0d 0a
Please note: he partition between two orders must exceed 300ms.

General specifications
1. Available sources USB flash, SD/MMC card and CD
2. Maximum compatible USB SD/MMC size up to 32GB
3. Input Stereo RCA and balanced Stereo XLR (REC input)
4. Output Stereo RCA and balanced Stereo XLR
5. Max REC input level +6 dBu
6. Output level 0 dBu
7. HD 0,1 % @ 1 kHz
8. Frequency response 20 Hz – 20 kHz
9. Signal to noise ratio 80 dB
10. Stereo separation 60 dB
11. Recording bit rate 128 kbps
12. Supported audio formats Compressed audio
13. Power supply ~230 V 50 Hz
14. Power consumption 50 VA
15. Weight 3,8 kg
16. Dimension 482 mm*44 mm*250 mm
