AMP Lighting AAL-1012 Series Operating and safety instructions

- 1 -
INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
AMP®Low Voltage Landscape Lighting
AMP®EcoPro MR16 Spotlight
AAL-1012 Series

Package Contents
Product Dimensions
A. (1) Fixture Body
- 2 - - 3 -
3.11”
2.72”
2.9”
1.4”
7”
Install Stake
1
Determine the desired location
for mounting the stake mount.
Hammer the stake into the
ground until ange of stake
is ush to grade. To avoid
damage to the stake, place a
board on top of the stake while
hammering.
Note: If the ground is hard and
the stake is difcult to install,
make a crosscut in the ground
using a at shovel.
Board
Ground
Soil
Stake
AMP®EcoPro MR16 Spotlight
AAL-1012
Important Safety Instructions: Read Before Installation
INSTALLATION & MAINTENANCE GUIDE
!
www.amplighting.com
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL listed wire connectors that are
suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or
tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
Important Safety Instructions
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
[email protected] • 813.978.3900

- 4 - - 5 -
Install Fixture to Stake
2
Clear away an area in the
ground at the wireway slot on
top of the stake. Lay the supply
wires into the wireway slot and
attach the xture on to the
stake. Tighten until snug.
Fixture Body
Ground
Supply Wires
Wireway Slot
Soil
Stake
Wire Connection
3
Strip both leads from the luminaire pigtail. Using two wire connectors
(sold separately), connect the leads from the luminaire to the main
supply cable leads.
Pigtail
Main Supply
Cable
Wire Connectors
Remove the Lens
4
Unlock the set screw and remove
the lens from the xture.
Fixture
Lens
Set Screw
Install MR16 Bulb
5
Insert MR16 bulb with the
correct wattage and type
marked on the xture label
and secure into place.
CAUTION: Do not exceed
maximum wattage marked on
luminaire label.
Fixture
MR16 Bulb
Socket
AMP®EcoPro MR16 Spotlight
AAL-1012
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com [email protected] • 813.978.3900

- 6 - - 7 -
ROTAT E
Install Lens
6
Place the lens back onto the
xture. Align holes on both of
them and secure with previously
removed set screw. Hand tighten
until snug.
Adjust Luminaire Direction
7
Loosen the adjustment screw
at the joint and adjust the
luminaire to the desired
direction. Once the desired
direction is achieved, tighten
the adjustment screw.
ROTAT E
Luminaire
Adjustment Screw
Remove the glare guard and the lens to expose the MR16 lamp and replace it
with the correct wattage and type marked on the xture label. Then,
reinstall the lens and the glare guard.
IMPORTANT: MR16 lamp must be protected from moisture and dust at all
times. Always reinstall the lens and the glare guard when removed.
Install/Replace Lamp
Fixture
Set Screw
Lens
AMP®EcoPro MR16 Spotlight
AAL-1012
INSTALLATION & MAINTENANCE GUIDE
[email protected] • 813.978.3900
www.amplighting.com

- 8 -
IS-AAL-1012
Specications and product details subject to change without notice.
© Copyright 2019, AMP® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3900
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
