AMP Lighting TieredPro Path Light Operating and safety instructions

INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
AMP®Low Voltage Landscape Lighting
AMP®TieredPro Path Light
AAR-3511-B-BZ

AMP®TieredPro Path Light
AAR-3511-B-BZ
Important Safety Instructions: Read Before Installation
INSTALLATION & MAINTENANCE GUIDE
!
www.amplighting.com
–2–
[email protected] • 813.978.3900
Parts Required
–3–
Package Contents
Install Stake
1
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL listed wire connectors that are
suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or
tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
7. If additional lengths of low voltage cable are required, please contact
www.amplighting.com or call 1-813-978-3900.
Important Safety Instructions
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may dam-
age lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
Product Dimensions
A. (1) TieredPro Hat C. (1) Stake
B. (1) 6” Stem
A. (1) Bulb
4.25”
11.5”
4.75”
Board
Stake
Soil
Ground
Determine the desired location for mounting
the luminaire. Hammer the stake into the
ground until ange of stake is ush to grade.
To avoid damage to the stake, place a board on
top of the stake while hammering.
NOTE: If the ground is hard and the stake
is difcult to install, make a crosscut in the
ground using a at shovel.

INSTALLATION & MAINTENANCE GUIDE
–4–
www.amplighting.com
–4–
Wire Connection
3
Install Stem to Stake
2
[email protected] • 813.978.3900
–5–
Install Bulb
4
AMP®TieredPro Path Light
AAR-3511-B-BZ
Install TieredPro
5
Install/Replace Bulb
6” Stem
Socket
Stake
Pigtail
Wireway Slot
Clear away an area in the ground at
the wireway slot on top of the stake.
Lay the luminaire pigtail into the
wireway slot and screw the stem onto
the stake. If the xture does not look
straight, adjust by pushing or pulling
on the stake only. Use a bubble level
against the side of stem to make
sure the stem is perpendicular to the
ground.
Pigtail
Main Supply Cable
Wire Connectors
Strip both leads from the luminaire pigtail. Using two wire connectors
(sold separately), connect the leads from the luminaire to the main low
voltage supply cable leads.
Socket
Bulb
Insert the bulb with the correct wattage
and type marked on the luminaire label.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
NOTE: DO NOT touch bulb with bare
hands. Use soft cloth to handle bulb.
Place the TieredPro hat over the bulb
and thread onto the top end of the
stem. Hand tighten until snug.
TieredPro Hat
Bulb
Stem
Please reverse Step 2 - Step 4 to expose the bulb and replace it with the
correct wattage and type marked on the luminaire label. Reinstall inner
lens and shade.
IMPORTANT: Bi-Pins must be protected from moisture and dust at all times.
Always reinstall shade and lens when moved.

–6–
www.amplighting.com
–6–
[email protected] • 813.978.3900
–7–
INSTALLATION & MAINTENANCE GUIDE
AMP®TieredPro Path Light
AAR-3511-B-BZ
Replace Lens
Remove TieredPro Hat
1
Loosen the TieredPro hat and remove
it from the top end of the stem by
pulling it up and over the bulb.
Stem
TieredPro Hat
Replace Lens
2
Loosen the screws from the bottom of
the TieredPro Hat. Remove the bottom
tier to expose the lens and replace
it with the new replacement shade.
Reinstall the bottom tier to hold the
shade and secure it with the screws
removed previously. Tighten until snug.
Reinstall the TieredPro hat onto the
stem.
Bottom Tier
TieredPro Hat
Lens

IS-AAR-3511-B-BZ.ver1
Specications and product details subject to change without notice.
© Copyright 2019, AMP®Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3900
