AMP Lighting TuscanPro AHT-3517-B-BZ Operating and safety instructions

INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
AMP®Low Voltage Landscape Lighting
AMP® TuscanPro Path & Area Light
AHT-3517-B-BZ

AMP®TuscanPro Path & Area Light
AHT-3517-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com
–2–
Important Safety Instructions: Read Before Installation
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL listed wire connectors that are
suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or
tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
Important Safety Instructions
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS

[email protected] • 813.978.3900
–3–
Package Contents
A. (1) Hat
Parts Sold Separately
A. (1) Decorative Arm
Product Dimensions
3.5”
9.6”
11”
9”
22.15”
Decorative arm
sold separately

INSTALLATION & MAINTENANCE GUIDE
–4–
www.amplighting.com
–4–
2
1
AMP®TuscanPro Path & Area Light
AHT-3517-B-BZ
Remove Stem Top
Loosen the stem top
and remove it from the
top end of the stem.
Stem
To p
Stem
Place the decorative
piece onto the top end
of the stem as shown.
Stem
Decorative Piece
3
Install Lamp
Insert the lamp with the correct
wattage and type marked on the
xture label and push rmly into
place.
CAUTION: Do not exceed maximum
wattage marked on xture label.
Socket
Lamp
Install Decorative Piece (optional)

[email protected] • 813.978.3900
–5–
INSTALLATION & MAINTENANCE GUIDE
4
5
AMP®TuscanPro Path & Area Light
AHT-3517-B-BZ
Remove Washer and Finial
Loosen the nial and remove
the nial, coupler and washer
from the stem top.
Finial
Stem Top
Coupler
Washer
Install Stem Top
Place the stem top over the
lamp and thread the stem
top onto the stem. Hand
tighten until snug.
Stem Top
Stem
6
Install Coupler to Hat
Thread the coupler onto
the hat and hand tighten
until snug.
Hat
Coupler

INSTALLATION & MAINTENANCE GUIDE
–6–
www.amplighting.com
–6–
7
AMP®TuscanPro Path & Area Light
AHT-3517-B-BZ
Install Hat
Thread the hat onto the stem
top and hand tighten until
snug.
Stem To p
Hat
8
Install Stake
Determine the desired location
for mounting the stake mount.
Hammer the stake into the
ground until ange of stake is
ush to grade. To avoid
damage to the stake, place a
board on top of the stake while
hammering.
Note: If the ground is hard and
the stake is difcult to install,
make a crosscut in the ground
using a at shovel.
Stake
Soil
Ground

[email protected] • 813.978.3900
–7–
Install/Replace Bulb
9
Install Stem to Stake
Clear away an area in the
ground at the wireway slot
on top of the stake. Lay the
luminaire pigtail into the
wireway slot and secure the
stem onto the stake. Tighten
until snug.
Stem
Stake
Pigtail
Wireway Slot
10
Wire Connection
Strip both leads from the luminaire. Using two wire
connectors (sold separately), connect the leads from the
xture to the main supply cable leads.
Pigtail
Main Supply Cable
Wire Connectors
Remove the hat and stem top to expose the lamp and replace it
with the correct wattage and type marked on the xture label. Then,
reinstall the stem top and hat.
IMPORTANT: Lamps must be protected from moisture and dust at all
times. Always reinstall the stem top and hat when removed.

IS-AHT-3517-B-BZ-ver1.pdf
Specications and product details subject to change without notice.
© Copyright 2020, AMP®Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3900
