Important Safety Instructions: Read Before Installation
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL listed wire connectors that are
suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or
tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
7. If additional lengths of low voltage cable are required, please contact
www.amplighting.com or call 1-813-978-3900.
Important Safety Instructions
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS

[email protected] • 813.978.3900
Product Dimensions
–3–
Package Contents
A. (1) Fixture Body
10.25”
6”
3”
Estate Size Hat featured
on Estate Size Line
Voltage Stem
36”

INSTALLATION & MAINTENANCE GUIDE
–4–
www.amplighting.com
–4–
2
1
AMP®Estate Size Path & Area Lights
3602 Series
Remove Stem Top
Install Lamp
Loosen the stem top and remove
it from the top end of the stem.
Stem
Stem Top
Insert the lamp with the correct
wattage and type marked on the
xture label and push rmly into
place.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
Socket
Lamp

[email protected] • 813.978.3900
–5–
INSTALLATION & MAINTENANCE GUIDE
3
4
AMP®Estate Size Path & Area Lights
3602 Series
Install Stem Top
Install Stake and Conduit
Thread the stem top onto the
stem and hand tighten until
snug.
Stem Top
Stem
Dig a hole in the ground for the conduit runs and the stake. Install the
conduit. Slide the stabilizer grid onto the stake and secure with the
screws. Place the stake over the conduit runs then backll against the
mounting stake.
Stake
Stabilizer
Grid
Conduit
Ground Level

INSTALLATION & MAINTENANCE GUIDE
–6–
www.amplighting.com
–6–
5
AMP®Estate Size Path & Area Lights
3602 Series
Remove Cap from Stake
Remove the cap from the stake
by loosening the set screws.
Set Screw
Cap
Stake
6
Install Cap to Junction Box
Thread the cap onto the Junction
Box.
Cap
Junction Box
* Junction Box is not
provided

–6––6–
[email protected] • 813.978.3900
–7–
7
Install Fixture to Junction Box
Remove the cover from the junction
box by loosening the screws. Place
the xture supply wires into the
junction box.
Thread the junction box onto the
bottom of the xture and hand
tighten until snug.
Fixture
Junction Box
Supply Wires
Screw
Cover * Junction Box is not
provided®
8
Install Junction Box to Stake
Pass the main supply cable into
the junction box. Place the cap
back onto the stake and secure
with the previously removed
screws. Tighten until snug with a
screwdriver.
Main Supply Cable
Junction Box
Cap
Screw
Stake Conduit * Junction Box is not
provided

INSTALLATION & MAINTENANCE GUIDE
AMP®Estate Size Path & Area Lights
3602 Series
Strip the leads from the xture supply wire and main supply cable. Using
wire connectors (sold separately), connect the leads from the xture
supply wire to the main supply cable leads. Then, connect the ground
wires to the ground screw in the junction box.
After wiring, carefully tuck the slack wires into the junction box. Attach
the cover back onto the junction box and secure with the previously
removed screws. Bury conduits and junction box.
Main Supply Cable
Wire Connectors
Junction Box
Screw
Cover
Fixture Supply Wires
Ground Screw
* Junction Box is not
provided
9
Wire Connection
www.amplighting.com
–8–

Install/Replace Lamp
9
Install Hat
Place the hat onto the stem top and secure it with the nial, or thread
the hat onto the stem top directly. Hand tighten until snug.
Stem Top
Finial
Hat of your choice
Remove the nial, hat and stem top to expose the lamp and replace it
with the correct wattage and type marked on the xture label. Then,
reinstall the stem top, hat and nial.
IMPORTANT: Lamps must be protected from moisture and dust at all
times. Always reinstall the stem top and hat when removed.
[email protected] • 813.978.3900
–9–

–10–
www.amplighting.com
INSTALLATION & MAINTENANCE GUIDE
AMP®Estate Size Path & Area Lights
3602 Series

–11–
[email protected] • 813.978.3900
