AMP Lighting APL-301X-XX-4-B-BZ Series Operating and safety instructions

INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
AMP®Low Voltage Landscape Lighting
AMP® Radix or Helix Bollard
APL-301X-XX-4-B-BZ

AMP®Radix or Helix Bollard
APL-301X-XX-4-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com
–2–
[email protected] • 813.978.3900
–3–
Important Safety Instructions: Read Before Installation
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with wire connectors that are suitable
for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or
tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
7. If additional lengths of low voltage cable are required, please contact
www.amplighting.com or call 1-813-978-3900.
Important Safety Instructions
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
Package Contents
A. (1) Fixture
B. (2) Stakes
C. (2) Threaded Couplers (attaches
stake and xture)
Product Dimensions
8” x 8” 8” x 8”
6.5” x 6.5”
APL-3010-26-4-B-BZ Pictured
APL-3010-42-4-B-BZ Pictured
6.5” x 6.5”
3” 3”
26”
42”

INSTALLATION & MAINTENANCE GUIDE
–4–
www.amplighting.com
–4–
2
1
[email protected] • 813.978.3900
–5–
INSTALLATION & MAINTENANCE GUIDE
3
AMP®Radix or Helix Bollard
APL-301X-XX-4-B-BZ
AMP®Radix or Helix Bollard
APL-301X-XX-4-B-BZ
Install Stakes to Fixture
Install Stakes to Ground
Wire Connection
Lay down the xture body on a at surface. Screw the couplers into the
mounting holes on the bottom of the xture body then thread the stakes
onto the couplers. Hand tighten to secure the stakes onto the xture
body.
Fixture Body
Determine the desired location for
the xture. Clear away an area in
the ground and lay the luminaire
pigtail into the wireway slot. Insert
stakes into the ground until ange
of stakes are ush to grade.
NOTE: If the ground is hard and
stakes are difcult to install, make
a crosscut in the ground using a at
shovel.
Stake
Soil
Ground
Pigtail
Strip both leads from the luminaire pigtail. Using two wire connectors
(not provided), connect the leads from the xture body to the main
supply cable leads.
Pigtail
Main Supply Cable
Wire Connectors

INSTALLATION & MAINTENANCE GUIDE
–6–
www.amplighting.com
–6–
[email protected] • 813.978.3900
–7–
AMP®Radix or Helix Bollard
APL-301X-XX-4-B-BZ

IS-APL-301X-XX-4-B-BZ-ver1.pdf
Specications and product details subject to change without notice.
© Copyright 2019, AMP®Lighting, Lutz FL USA 33549 • All rights reserved.
