AMP Lighting APL-3015-B-BZ Operating and safety instructions

- 1 -
AMP®Low Voltage Landscape Lighting
AMP® Dual Mini PinnaclePro Path Light (Lamp - Ready)
APL-3015-B-BZ
INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com

Package Contents
A. (1) Fixture Body
B. (2) Stake
Product Dimensions
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL Listed wire connectors that
are suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
Parts Required
A. (2) MR11 Lamps
B. (1) Stake Cover (optional)
6”
2.7”
26.2”
4.5”
3.2”
14.65”
- 3 -- 2 -
AMP®Dual Mini PinnaclePro Path Light (Lamp Ready)
APL-3015-B-BZ
INSTALLATION & MAINTENANCE GUIDE
Important Safety Instructions: Read Before Installation
!
Important Safety Instructions: Read Before Installation
!
www.amplighting.com customersuppor[email protected] • 813.978.3900

Install Shield and Glare Guard
4
Glare Guard
Shield
Set Screw
Fixture Body Place the shield over the lamp and
thread onto the xture. Attach the
glare guard back onto the shield
and secure with the set screw.
Tighten until snug.
Install Lamp
3
MR11 Lamp
Socket Insert the lamp with the correct
wattage and type marked on the
xture label.
CAUTION: Do not exceed maximum
wattage marked on luminaire
label.
NOTE: DO NOT touch lamp with
bare hands. Use soft cloth to
handle lamp.
Install Stake
1
Board
Stake
Soil
Ground
Determine the desired location for
mounting the xture. Hammer the stake
into the ground until ange of stake is
ush to grade. To avoid damage to the
stake, place a board on top of the stake
while hammering.
NOTE: If the ground is hard and the
stake is difcult to install, make a
crosscut in the ground using a at
shovel.
Remove Shield and Glare Guard
2
Glare Guard
Shield
Set Screw
Fixture Body Loosen the set screw and remove
the glare guard from the shield.
Remove the shield from the
xture.
- 5 -- 4 -
Install Fixture to Stake
5
Pigtail
Fixture
Wireway Slot
Clear away an area in the ground
at the wireway slot on top of the
stake. Align the wireway slot of
the stake cover and the stake.
Lay the luminaire pigtail into
the wireway slot and attach the
xture onto the stake.
AMP®Dual Mini PinnaclePro Path Light (Lamp Ready)
APL-3015-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com customersuppor[email protected] • 813.978.3900

Adjust Angle of Fixture Body
7
Install/Replace Lamp
Loosen the set screw on glare guard, remove the glare guard and the
shield to expose the lamp. Replace it with the correct wattage and
type marked on the xture label. Then reinstall the shield and glare
guard and tighten with the set screw.
IMPORTANT: Halogen lamps must be protected from moisture and
dust at all times. Always reinstall the shield and glare guard when
moved.
Allen Wrench Using an Allen Wrench, loosen the
adjustment screws and modify
the xture bodies to the desired
angles. Then tighten the
adjustment screws.
Wire Connections
6
Pigtail
Main Supply Cable
Wire Connectors
Strip both leads from the luminaire pigtail. Using two wire
connectors (sold separately), connect the leads from the
luminaire to the main supply cable leads.
Adjustment Screw
- 7 -- 6 -
AMP®Dual Mini PinnaclePro Path Light (Lamp Ready)
APL-3015-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com customersuppor[email protected] • 813.978.3900

- 8 -
