AMP Lighting APL-3032-26-4-B-BZ Operating and safety instructions

INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
AMP®Low Voltage Landscape Lighting
AMP® Customizable Bollard Light
APL-3032-26-4-B-BZ

AMP®Customizable Bollard Light
APL-3032-26-4-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com
–2–
Important Safety Instructions: Read Before Installation
!
Important Safety Instructions
!
This xture is intended for installation in accordance with local codes and
the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing
this xture.
2. Warning: this xture is not intended to be installed within 10 feet [3
meters] of a pool, spa or fountain.
3. This xture is intended to be used only with a power supply
(transformer) rated maximum of 50 watts (25 AMPS) at 12 volts.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm)
in order to connect to the main low voltage cable.
5. Wiring connections must be made with UL listed wire connectors that
are suitable for outdoor use.
6. Position the wire connector so that it is located within 6 inches (15.2
cm) from a building structure, a luminaire, or tting.
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.

[email protected] • 813.978.3900
–3–
Package Contents
A. (1) Fixture Body C. (2) Threaded Couplers
B. (2) Bi-Pin Brass Puck Lights
Sold Separately
A. (4) Side Panels
B. Mounting Accessory
Product Dimensions
8”x8”
6.38”x6.38”
25.87”
3”

INSTALLATION & MAINTENANCE GUIDE
–4–
www.amplighting.com
–4–
1
AMP®Customizable Bollard Light
APL-3032-26-4-B-BZ
Remove Top Cover
Push
Rotate
Remove
Top Cover
Top Cover
Fixture
Push the top cover down and rotate it clockwise to remove it from the
xture.

[email protected] • 813.978.3900
–5–
INSTALLATION & MAINTENANCE GUIDE
2
AMP®Customizable Bollard Light
APL-3032-26-4-B-BZ
Install Side Panels
Insert the side panels of your choice into the slots on the xture body.
Side Panel
Slot
Fixture
OPTIONAL SIDE PANELS

INSTALLATION & MAINTENANCE GUIDE
–6–
www.amplighting.com
–6–
3
AMP®Customizable Bollard Light
APL-3032-26-4-B-BZ
Install Top Cover
4
Push
Rotate
Top Cover
Hole
Bolt
Fixture
Align the bolts on the top cover
to the holes on top of the xture.
Insert the bolts into the holes and
push down. Then rotate the top
cover counter clockwise to secure
it in place.
Install Stakes to Fixture
Lay the xture down on a at surface. Twist the couplers into the mount-
ing holes on the bottom of the xture. Then thread the stakes onto the
couplers. Hand tighten until snug to secure the stakes to the xture.
Fixture Stake
Coupler

–6––6–
[email protected] • 813.978.3900
–7–
INSTALLATION & MAINTENANCE GUIDE
AMP®Customizable Bollard Light
APL-3032-26-4-B-BZ
5
Install Fixture
Fixture
Determine the desired location for
the xture. Insert the stakes into
the ground until ange of stakes
are ush to grade.
NOTE: If the ground is hard and the
stakes are difcult to install, make
a crosscut in the ground using a at
shovel.
Stake
Soil
Ground
Pigtail
6
Wire Connection
Strip both leads from the luminaire pigtail. Using two UL listed wire
connectors (sold separately), connect the leads from the xture to the
main supply cable leads.
Pigtail
Main Supply Cable
Wire Connectors

7
Replace Bi-Pin
12 3
1. Remove the cover off the bottom and top of the xture.
2. Using a screwdriver, remove the two screws from the socket base.
Insert the Bi-pin brass puck light onto the socket and secure with the
two screws.
3. Thread the previously removed cover back onto the socket base.
CAUTION: This xture is for LED use only. Do not exceed maximum watt-
age marked on luminaire label.
NOTE: DO NOT touch the Bi-pin brass puck light with bare hands. Use soft
cloth to handle the puck light.
Cover
Cover
Socket
Base
Socket
Base
Socket
Screw Bi-pin
Puck Light
–8–
www.amplighting.com
–8–
INSTALLATION & MAINTENANCE GUIDE
AMP®Customizable Bollard Light
APL-3032-26-4-B-BZ
