AMP Lighting PolynesianPro AAR-3518-B-BZ Operating and safety instructions

INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
AMP®Low Voltage Landscape Lighting
AMP® PolynesianPro
AAR-3518-B-BZ

AMP®PolynesianPro
AAR-3518-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com
–2–
Important Safety Instructions: Read Before Installation
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL listed wire connectors that are
suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or
tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
Important Safety Instructions
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS

[email protected] • 813.978.3900
Product Dimensions
–3–
1
Package Contents
Install Stake
A. (1) Stem
B. (1) Shade Assembly
C. (1) Stake
7.75”
61”
11”
Board
Stake
Soil
Ground
Determine the desired location for mounting
the luminaire. Hammer the stake into the
ground until ange of stake is ush to grade.
To avoid damage to the stake, place a board on
top of the stake while hammering.
NOTE: If the ground is hard and the stake
is difcult to install, make a crosscut in the
ground using a at shovel.

INSTALLATION & MAINTENANCE GUIDE
–4–
www.amplighting.com
–4–
3
2
AMP®PolynesianPro
AAR-3518-B-BZ
Install Stem to Stake
Wire Connection
Stem
Stake
Pigtail
Wireway Slot
Clear away an area in the ground at
the wireway slot on the top of the
stake. Lay the luminaire pigtail into
the wireway slot and secure the stem
onto the stake. If the xture does not
look straight, adjust by pushing or
pulling on the stake only.
Strip both of the leads from the luminaire pigtail. Using two wire
connectors (sold separately), connect the leads from the luminaire to
the leads of the main supply cable.
Pigtail
Main Supply Cable
Wire Connectors

[email protected] • 813.978.3900
–5–
INSTALLATION & MAINTENANCE GUIDE
4
5
AMP®PolynesianPro
AAR-3518-B-BZ
Install Bulb
Install Shade Assembly
Socket
Bulb
Insert the bulb with the correct wattage
and type marked on the luminaire label.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
NOTE: DO NOT touch bulb with bare
hands. Use soft cloth to handle bulb.
Attach the shade assembly onto the
top end of the stem as shown. Tighten
the set screw until snug to secure both
pieces together.
Set Screw
Shade
Assembly
Stem
Install/Replace Bulb
Please reverse Step 5 - Step 4 to expose the bulb and replace it with the
correct wattage and type marked on the xture label. Then, reinstall the
shade assembly.
IMPORTANT: The Bulb must be protected from moisture and dust at all
times. Always reinstall the shade assembly when removed.

INSTALLATION & MAINTENANCE GUIDE
–6–
www.amplighting.com
–6–
6
AMP®PolynesianPro
AAR-3518-B-BZ
Install Shade
How to Fill Fuel Container
Remove the cap from the top end of
the shade assembly.
Cap
Shade
Assembly
7
Remove Shade
Remove the washer with the cap and
the shade from the fuel container by
unscrewing the lid.
Cap
Wick
Washer
Shade
Fuel Container
Lid

–6––6–
[email protected] • 813.978.3900
–7–
8
Fill Fuel Container
Pour tiki fuel in the xture’s fuel
container as shown. Never use
gasoline, kerosene, or other ammable
fuels.
Fuel Container
Tiki Fuel
9
Reinstall Shade and Cap
Place the shade and the washer back
onto the container. Insert the wick
inside of the fuel container and tighten
the lid until snug. Put the cap back
onto the top end of the xture over
the lid. Before lighting the torch insure
that the wick is completely saturated.
Cap
Wick
Washer
Shade
Fuel Container
Lid

IS-AAR-3518-B-BZ-ver1.pdf
Specications and product details subject to change without notice.
© Copyright 2021 AMP®Lighting, Lutz FL USA 33549 • All rights reserved.
