AMP Lighting Deck-DesignPro Classic Operating and safety instructions

INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
AMP®Low Voltage Landscape Lighting
AMP® Deck-DesignPro Classic
ADL-2010-4-B-XX

AMP®Deck-DesignPro Classic
ADL-2010-4-B-XX
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com
–2–
[email protected] • 813.978.3900
Product Dimensions
–3–
Important Safety Instructions: Read Before Installation
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with wire connectors that are suitable
for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or
tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
7. If additional lengths of low voltage cable are required, please contact
www.amplighting.com or call 1-813-978-3900.
Important Safety Instructions
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
Package Contents
A. (1) Luminaire
B. (1) Lock Screws
2”
3 3/8”
2 1/4”
Pro Technique for Hiding Lead Wire
Determine the location for the xture. Drill a hole straight through the
desired mounting location and run the lead wire out the backside of
the location so that the wires are not visible from the front side. Use a
matching trim piece and cut a groove in the back of trim. Cover the lead
wires with the matching trim piece.
Pro Technique for Hiding Splice Connections
All xtures come with 4’ of lead wire enabling you to hide the splice
connections out of sight. If you must make a splice connection in view, use
an inline heat shrink style connection that is less visible than traditional twist
caps.

INSTALLATION & MAINTENANCE GUIDE
–4–
www.amplighting.com
–4–
2
1
[email protected] • 813.978.3900
–5–
INSTALLATION & MAINTENANCE GUIDE
4
5
AMP®Deck-DesignPro Classic
ADL-2010-4-B-XX
AMP®Deck-DesignPro Classic
ADL-2010-4-B-XX
Remove Lens Assembly
Install Base
Install Bulb
Install Lens Assembly
Luminaire Lens Assembly
Base Rotate the lens assembly counter
clockwise until it is stops and then
lift the lens assembly straight off.
Note: The rst time it may be
difcult because the luminaire has
a tight o-ring seal and a grease
sealant for moisture protection.
Base
Lock
Screw
Wall Anchor Attach the base onto the desired
location and secure with the lock
screws.
Note: Wall anchors are required for
certain installation conditions (e.g.
Brick wall, Concrete Wall, etc.).
Mark on the wall for wall anchors
from the holes on the base.
Remove the base and drill proper
holes on the wall and then insert
the wall anchors.
3
Wire Connections
Luminaire
Wire Connector
Main Supply Cable
Pigtail
Strip both leads from the luminaire
pigtail. Using two wire connectors
(sold separately), connect the leads
from the luminaire to the main supply
cable leads.
Insert the bulb with correct wattage and
type marked on the luminaire label.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
NOTE: DO NOT touch bulb with bare
hands. Use soft cloth to handle bulb.
Socket
Bulb
Push the lens assembly back onto the
base aligned with the gaps on the
base. Push hard (moisture proof xture
requires force to get air out). Once the
lens assembly is ush with the base,
rotate the lens assembly until it stops
and locks into place.
Inner Shield
Base
Gap
Install/Replace Bulb
Rotate the lens assembly and then remove it to expose the bulb and replace
it with the correct wattage and type marked on the luminaire label. And
then reinstall the lens assembly.
IMPORTANT: Halogen bulbs must be protected from moisture and dust at all
times. Always reinstall lens assembly when moved.

IS-ADL-2010-4-B-XX.pdf
Specications and product details subject to change without notice.
© Copyright 2019, AMP®Lighting, Lutz FL USA 33549 • All rights reserved.
