AMP Lighting VariantPro Spotlight Operating and safety instructions

INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
AMP®Low Voltage Landscape Lighting
AMP®VariantPro Spotlight
AAL-1010-4-B-BZ

AMP®VariantPro Spotlight
AAL-1010-4-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com
–2–
[email protected] • 813.978.3900
Product Dimensions
–3–
Install Stake
1
Board
Stake
Ground Soil
Important Safety Instructions: Read Before Installation
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with wire connectors that are suitable
for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or
tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
7. If additional lengths of low voltage cable are required, please contact
www.amplighting.com or call 1-813-978-3900.
Important Safety Instructions
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may dam-
age lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
Package Contents
A. (1) Fixture
B. (1) Stake
5 1/2”-7 1/2”
3 1/4”
5 1/2”
2 1/4”
3/4”
Determine the desired location for
mounting the luminaire. Hammer the
stake into the ground until ange
of stake is ush to grade. To avoid
damage to the stake, place a board
on top of the stake while hammering.
NOTE: If the ground is hard and the
stake is difcult to install, make a
crosscut in the ground using a at
shovel.

INSTALLATION & MAINTENANCE GUIDE
–4–
www.amplighting.com
–4–
Wire Connections
3
Install Luminaire to Stake
2
[email protected] • 813.978.3900
–5–
INSTALLATION & MAINTENANCE GUIDE
Install Bulb
4
Install Lens
5
AMP®VariantPro Spotlight
AAL-1010-4-B-BZ
Clear away an area in the ground
at the wireway slot on top of the
stake. Lay the luminaire pigtail
into the wireway slot and attach
the luminaire onto the stake.
Tighten until snug.
Wireway Slot
Pigtail
Luminaire
Wire Connectors
Main Low Voltage
Supply Cable
Pigtail
Strip both leads from the luminaire pigtail. Using two wire connectors
(sold separately), connect the leads from the luminaire to the main
supply cable leads.
AMP®VariantPro Spotlight
AAL-1010-4-B-BZ
Insert the bulb with the correct
wattage and type marked on the
luminaire label.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
NOTE: DO NOT touch bulb with bare
hands. Use soft cloth to handle bulb.
Thread the lens onto the luminaire
and hand tighten until snug.
Bulb
Socket
Lens
Luminaire

INSTALLATION & MAINTENANCE GUIDE
–6–
www.amplighting.com
–6–
[email protected] • 813.978.3900
–7–
Install Glare Guard
6
Install/Replace Bulb
Place the glare guard onto the lens
and secure it with the lock screw.
Adjust the luminaire to the desired
angle by using the set screw.
Loosen the lock screw to remove the glare guard. Then remove the lens to
expose the bulb. Replace it with the correct wattage and type marked on
the xture label. Then reinstall the lens and glare guard.
IMPORTANT: Bulbs must be protected from moisture and dust at all times.
Always reinstall lens when removed.
AMP®VariantPro Spotlight
AAL-1010-4-B-BZ
Glare Guard
Lock Screw
Lens
Set Screw

IS-AAL-1010-4-B-BZ-ver1.pdf
Specications and product details subject to change without notice.
© Copyright 2019, AMP®Lighting, Lutz FL USA 33549 • All rights reserved.
