AMP Lighting AWL-710IR-X-BBZ Series Operating and safety instructions

Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
INSTALLATION & MAINTENANCE GUIDE
AMP®Low Voltage Landscape Lighting
AMP®ONE HydroProTM LED In-Grade Light
AWL-710IR-X-BBZ (Dimmable)

AMP ONE HydraPro™ LED In-Grade Light
AWL-710IR-X-BBZ (Dimmable)
Important: Please Read Before Installation
Important: Safety Instructions
INSTALLATION & MAINTENANCE GUIDE
This xture is intended for installation in accordance with local codes and
the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
xture.
2. Warning: this xture is not intended to be installed within 10 feet [3
meters] of a pool, spa or fountain.
3. This xture is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in
order to connect to the main low voltage cable.
5. Wiring connections must be made with UL listed wire connectors that
are suitable for outdoor use.
6. Position the wire connector so that it is located within 6 inches (15.2
cm) from a building structure, a luminaire, or tting.
7. IR dimmability with our Design-Master™ Remote Control.
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.
!
!
[email protected] • 813.978.3900

www.amplighting.com
–3–
Product Dimensions
Package Contents
Parts Required (sold separately)
A. (1) Fixture
B. (1) Stake
A. (1) AMP®ONE Design-Master
Remote ControlTM
2”
4”

[email protected] • 813.978.3900
–4–
INSTALLATION & MAINTENANCE GUIDE
Install Stake
1
Board
Stake
Soil
Ground
Install Fixture to Stake
2
Fixture
Stake
Determine the desired location for mounting
the xture. Hammer the stake into the
ground until ange of stake is ush to grade.
To avoid damage to the stake, place a board
on top of the stake while hammering.
NOTE: If the ground is hard and the stake
is difcult to install, make a crosscut in the
ground using a at shovel before hammering
the stake.
Clear away an area in the ground for the
stake. Lay the luminaire pigtail into the
cleared area and screw the xture onto
the stake. Tighten until snug.
AMP ONE HydraPro™ LED In-Grade Light
AWL-710IR-X-BBZ (Dimmable)

–5–
www.amplighting.com
–5–
Wire Connection
3
Pigtail
Main Supply Cable
Wire Connectors
Strip both leads from the luminaire pigtail. Using two wire connectors
(sold seperately), connect the leads from the luminaire to the main
supply cable.

[email protected] • 813.978.3900
–6–
Remove Faceplate
4
Loosen the screws and remove the
faceplate from the xture.
Screw
Faceplate
Fixture
Install Glare Guard
5
Attach the glare guard onto the
xture and secure it with the
screws previously removed.
Fixture
Install/Replace Glare Guard
Screw
Glare Guard

–7–

is-AWL-710IR-BBZ-ver7.pdf
Specications and product details subject to change without notice.
© Copyright 2019, AMP® Lighting, Lutz FL USA 33549 • All rights reserved.
