AMP AAL-1049 Operating and safety instructions

- 1 -
AMP®LOW VOLTAGE LANDSCAPE LIGHTING
AMP®Nano LED Spotlight
ITEM: AAL-1049
INSTALLATION & MAINTENANCE GUIDE
1-813-978-3900 • Mon-Fri 9am-6pm (EST)

IMPORTANT SAFETY INSTRUCTIONS: READ BEFORE INSTALLATION
INSTALLATION & MAINTENANCE GUIDE
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation, operation
maintenance or mounting situations.
1. Make sure the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M) or
more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL listed wire connectors that
are suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or fitting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
IMPORTANT SAFETY INSTRUCTIONS
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
LIGHTED LAMP IS HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire fitting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
AMP®Nano LED Spotlight - AAL-1049
813.978.3900 • [email protected]om • www.amplighting.com
2

PACKAGE CONTENTS
INSTALL FIXTURE BODY TO STAKE
1
813.978.3900 • [email protected]om • www.amplighting.com
2
813.978.3900 • [email protected]om • www.amplighting.com
3
PRODUCT DIMENSIONS
A. (1) Fixture Body
B. (1) Allen Wrench
C. (1) Stake
2.39”
0.5”
0.45”
Pass the supply wire of the
fixture body through the
wireway slot on the stake.
Thread the fixture body onto
the stake.
Fixture Body
Wireway Slot
Supply Wires
Stake

INSTALL STAKE INTO SOIL
2
WIRE CONNECTIONS
3
INSTALLATION & MAINTENANCE GUIDE
AMP®Nano LED Spotlight - AAL-1049
813.978.3900 • [email protected]om • www.amplighting.com
4
Insert the stake into the soil
until flange of stake is flush
to the ground.
Fixture Body
Supply Wire
Stake
Ground
Soil
Strip both the leads from
the luminaire pigtail.
Using two UL listed wire
connectors (sold separately),
connect the leads from
the luminaire to the main
supply cable leads.
Pigtail
Wire Connectors
Main Supply Cable

ADJUST DIRECTIONS
4
813.978.3900 • [email protected]om • www.amplighting.com
4
813.978.3900 • [email protected]om • www.amplighting.com
5
By using the Allen wrench,
loosen the screw at the joint
and adjust the luminaire to
the desired direction. Once
the desired direction is
achieved, tighten the screw.
ROTATE
Fixture Body
Screw
Allen Wrench

INSTALLATION & MAINTENANCE GUIDE
AMP®Nano LED Spotlight - AAL-1049
813.978.3900 • [email protected]om • www.amplighting.com
6

813.978.3900 • [email protected]om • www.amplighting.com 813.978.3900 • [email protected]om • www.amplighting.com
7

Specifications and product details subject to change without notice.
© Copyright 2023, AMP® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected]om • amplighting.com
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
