AMP Pro Junction Hub Operating and safety instructions

- 1 -
INSTALLATION & MAINTENANCE GUIDE
AMP®LOW VOLTAGE LANDSCAPE LIGHTING
AMP® Pro Junction Hub (Gen. 3)
ITEM: VAC-HUB4-PBK-R1
1-813-978-3900 • Mon-Fri 9am-6pm (EST)

PACKAGE CONTENTS
PRODUCT DIMENSIONS
A. (1) Connection Hub
IMPORTANT SAFETY INSTRUCTIONS: READ BEFORE INSTALLATION
INSTALLATION & MAINTENANCE GUIDE
!
This connection hub is intended for installation in accordance with local
codes and the National Electric Code (NEC). Failure to adhere to these codes
and instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
fixture.
2. Warning: this connection hub is not intended to be installed within 10 feet
[3 meters] of a pool, spa or fountain.
3. This connection hub is for outdoor use only, which must be mounted at
least 1.25” (30 cm) above ground.
4. This connection hub is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (20 AMPS) at 15 volts.
5. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in
order to connect to the main low voltage cable.
AMP®Pro Junction Hub (Gen. 3) - VAC-HUB4-PBK-R1
813.978.3900 • [email protected]om • www.amplighting.com
2
2.75”
4”
5”

INSTALL STAKE
1
Board
813.978.3900 • [email protected]om • www.amplighting.com
2
813.978.3900 • [email protected]om • www.amplighting.com
3
Determine the desired
location for mounting the
hub. Hammer the stake into
the ground until flange of
stake is flush to grade. To
avoid damage to the stake,
place a board on top of the
stake while hammering.
NOTE: If the ground is hard
and the stake is difficult to
install, make a crosscut in the
ground using a flat shovel.
Ground
Stake
Soil
Install Connection Hub to Stake
2
Hand tighten the
connection hub to the stake
until snug.
Connection hub
Stake
3
Remove Top
Remove the top from the
connection hub.
Top
Connection hub

4
Supply Wire Insert
4
813.978.3900 • [email protected]om • www.amplighting.com
4
Connect Wires
Pass the supply wires from the transformer through one of the
holes underneath the hub base. Strip both leads of the supply
wire from the transformer. Open the clamp on the connector
that you are going to insert the wire in, insert one side of the
supply wire into the connector on the terminal block and close
the clamp. Then insert the other side of the wire into the opposite
terminal block.
Use the same methods to connect the supply wires from the
fixtures.
*NOTE: The connectors will hold up to 10 gauge wire.
Open
Clamp
Hub Top
Terminal Block
Supply Wires from
Transformer
Supply Wires from
Fixture
Hub Base
Hole for Wire
Install Top
After the wires are well
connected, place the top
back onto the connection
hub. Leave any access wire
inside of the hub in case
you need to adjust the
placement of the fixtures.
Hub Top
Connection hub
INSTALLATION & MAINTENANCE GUIDE
AMP®Pro Junction Hub (Gen. 3) - VAC-HUB4-PBK-R1
