AMP®LOW VOLTAGE LANDSCAPE LIGHTING
AMP®G2 EcoPro
ITEM: AAL-1052
INSTALLATION & MAINTENANCE GUIDE
1-813-978-3900 • Mon-Fri 9am-6pm (EST)

IMPORTANT SAFETY INSTRUCTIONS: READ BEFORE INSTALLATION
INSTALLATION & MAINTENANCE GUIDE
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation, operation
maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M) or
more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL listed wire connectors that
are suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or fitting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
IMPORTANT SAFETY INSTRUCTIONS
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
LIGHTED LAMP IS HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire fitting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
AMP®G2 EcoPro - AAL-1052
813.978.3900 • [email protected]om • www.amplighting.com
2

PACKAGE CONTENTS
PRODUCT DIMENSIONS
A. (1) Fixture Body
REMOVE GLARE GUARD
1
813.978.3900 • [email protected]om • www.amplighting.com
2
813.978.3900 • [email protected]om • www.amplighting.com
3
PRODUCT DIMENSIONS
A. (1) MR16 Lamp B. Mounting Accessory
4.5”
2”
2.27”
1”
Loosen the set screw and
remove the glare guard
from the fixture body.
Glare Guard
Fixture Body Set Screw

INSTALL MR11 LAMP
2
INSTALL GLARE GUARD
3
INSTALLATION & MAINTENANCE GUIDE
AMP®G2 EcoPro - AAL-1052
813.978.3900 • [email protected]om • www.amplighting.com
4
Insert MR16 lamp with
correct wattage and type
marked on fixture label.
CAUTION: Do not exceed
maximum wattage marked
on luminaire label.
Socket
MR16 Lamp
Install the glare guard back
onto the fixture body and
secure with previously
loosened set screw. Hand
tighten until snug.
Fixture Body
Set Screw
Glare Guard
INSTALL STAKE
4
Determine the desired location
for mounting the fixture.
Hammer the stake into the
ground until flange of stake is
flush to grade. To avoid damage
to the stake, place a board on top
of the stake while hammering.
NOTE: If the ground is hard and
the stake is difficult to install,
make a crosscut in the ground
using a flat shovel.
Stake
Board
Ground

INSTALL FIXTURE BODY TO STAKE
5
WIRE CONNECTION
5
813.978.3900 • [email protected]om • www.amplighting.com
4
813.978.3900 • [email protected]om • www.amplighting.com
5
Clear away an area in the
ground at the wireway slot
on top of the stake. Lay the
luminaire pigtail into the
wireway slot and screw the
fixture body on to the stake.
Tighten the lock ring against
the stake and hand tighten
until snug.
Wireway Slot
Stake
Pigtail Lock Ring
Fixture Body
Strip both the leads from the luminaire pigtail. Using two UL
listed wire connectors (sold separately), connect the leads from
the luminaire to the main supply cable leads.
Wire Connectors
Main Supply Cable
Pigtail

ADJUST LUMINAIRE DIRECTIONS
6
Please reverse Step 2 - Step 3 to expose the MR16 lamp and replace it
with the correct wattage and type marked on the fixture label. Then,
reinstall the glare guard.
IMPORTANT: The MR16 lamp must be protected from moisture and
dust at all times. Always reinstall the glare guard when moved.
INSTALL/REPLACE LAMP
INSTALLATION & MAINTENANCE GUIDE
AMP®G2 EcoPro - AAL-1052
813.978.3900 • [email protected]om • www.amplighting.com
6
Loosen the knuckle screw
at the joint. Rotate the
luminaire to your desired
direction. Tighten the knuckle
screw once your desired
direction is achieved.
Luminaire
Thumb Screw

813.978.3900 • [email protected]om • www.amplighting.com 813.978.3900 • [email protected]om • www.amplighting.com
7

Specifications and product details subject to change without notice.
© Copyright 2023, AMP® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected]om • amplighting.com
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
