AMP®LOW VOLTAGE LANDSCAPE LIGHTING
AMP® Stemless Brass Bronze Directional Path Light
ITEM: APL-3037
INSTALLATION & MAINTENANCE GUIDE
1-813-978-3900 • Mon-Fri 9am-6pm (EST)

IMPORTANT SAFETY INSTRUCTIONS: READ BEFORE INSTALLATION
INSTALLATION & MAINTENANCE GUIDE
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation, operation
maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M) or
more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL listed wire connectors that
are suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or fitting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
IMPORTANT SAFETY INSTRUCTIONS
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
LIGHTED LAMP IS HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire fitting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
AMP®Stemless Brass Bronze Directional Path Light - APL-3037
813.978.3900 • [email protected]om • www.amplighting.com
2

PACKAGE CONTENTS
Parts Required (Sold Separately)
REMOVE SHADE
1
813.978.3900 • [email protected]om • www.amplighting.com
2
813.978.3900 • [email protected]om • www.amplighting.com
3
A. (1) Fixture Body
B. (1) Mounting Bracket
C. (3) Anchors
D. (3) Screws
E. (1) Coupling
PRODUCT DIMENSIONS
A. Mounting Accessory
B. (1) G4 Bulb
2.71”
2.58”
1.96”
Remove the shade from the
fixture body by removing the
screw on the bottom.
Shade
Fixture Body
Screw

INSTALL G4 BULB
2
INSTALL SHADE
3
INSTALLATION & MAINTENANCE GUIDE
AMP®Stemless Brass Bronze Directional Path Light - APL-3037
813.978.3900 • [email protected]om • www.amplighting.com
4
Insert G4 bulb into the socket
properly with the correct
wattage and type marked on
the fixture label.
CAUTION: Do not exceed
maximum wattage marked
on luminaire label.
Socket G4 Bi-Pin Bulb
Two installation methods are available for this product (Mounting
Option A & B). Refer to respective installation instructions and
then continue to Step 4 for wire connections.
Install the shade back onto
the fixture body and secure
with previously removed
screw. Hand tighten until
snug.
Shade
Fixture Body
Screw

INSTALL MOUNTING BRACKET
1
INSTALL FIXTURE BODY TO MOUNTING BRACKET
2
813.978.3900 • [email protected]om • www.amplighting.com
4
813.978.3900 • [email protected]om • www.amplighting.com
5
MOUNTING OPTION A: SURFACE MOUNT
1. Attach the mounting
bracket to your desired
mounting surface. Use a
pencil, mark 3 points on
the mounting surface
from 3 holes on the
mounting bracket.
2. Set the mounting bracket
aside and drill 1/4” holes
on the marks on the
mounting surface.
3. Insert anchors into the
drilled holes completely.
4. Attach the mounting
bracket onto the
mounting surface and
secure with screws. Hand
tighten until snug with
screwdrivers.
WALL
Hole
Mark
Anchor
Mounting
Screw
Lay the supply cable into
the wireway slot on the
mounting bracket. Align
two screw heads on the
bottom of the fixture
body to the keyholes on
the mounting bracket.
Push the fixture body
onto the mounting
bracket and rotate it until
it is locked into place
Go to Step 4 for wire
connections.
ROTATE
WALL Supply Cable
Wireway slot
Fixture Body
Screw Head
Key Hole
Mounting Bracket

INSTALL STAKE TO FIXTURE
1
INSTALL STAKE INTO SOIL
2
INSTALLATION & MAINTENANCE GUIDE
AMP®Stemless Brass Bronze Directional Path Light - APL-3037
813.978.3900 • [email protected]om • www.amplighting.com
6
MOUNTING OPTION B: STAKE MOUNT
Pass supply cables through
the coupling and the stake.
Thread the coupling and the
stake to the fixture body and
hand tighten until snug.
Fixture
Coupling
Stake
Supply Cable
Clear away an area in the
ground at the wireway slot.
Lay the supply cables into
the wireway slot and insert
the stake into the soil until
flange of stake is flush to
ground.
Go to Step 4 for wire
connections.
Ground
Fixture
Supply Cable
Stake
Soil

INSTALL/REPLACE LAMP
813.978.3900 • [email protected]om • www.amplighting.com 813.978.3900 • [email protected]om • www.amplighting.com
7
Remove the fixture body from the mounting bracket or the stake
first. Reverse Step 1 - Step 3 to expose the G4 bulb and replace it
with the correct wattage and type marked on the fixture label.
Then, reinstall the shade and fixture body.
IMPORTANT: G4 Bi-pin bulb must be protected from moisture and
dust at all times. Always reinstall the shade when removed.
WIRE CONNECTIONS
4
Strip both leads from the luminaire pigtail. Using two UL listed
wire connectors (sold separately), connect the leads from the
luminaire to the main supply cable leads.
Supply Cable
Wire Connectors
Main Supply
Cable
Pigtail

Specifications and product details subject to change without notice.
