AMQ ACTIV DT Riser User manual

1
Please contact [email protected] if you are missing any parts, have difficulty with assembly, or have any product related questions.
ACTIV DT Riser Installation GuideACTIV DT Riser Installation Guide
Components
M6X14
x4
Monitor Holder
M6X12
x4
Base
Dual Monitor Mount
Keyboard Tray Assembly
M6X12
x4
Keyboard Bracket
Monitor HolderM6X10 Hand Screw
x4
Power Cord
Primary Worksurface & Handset
Support Plate
M6X25
x4
M4X10
x1
M6X8
x4
Dual Monitor (Optional)
Keyboard Tray (Optional)
Column/Control Box

2
Please contact [email protected] if you are missing any parts, have difficulty with assembly, or have any product related questions.
ACTIV DT Riser Installation Guide
M6X14 M6X8
M6X25
Step 1
Use M6X14 screws (x4) to assemble base to
column. Wire the column to the control box.
Step 3
Slide the primary worksurface over the column
and set column to lowest position.
Step 2
Use M6X8 screws (x4) to assemble the support plate
to pre-drilled holes at the bottom of column.
Step 4
Wire the handset to the control box and plug in the power cord.
Raise the column at least 8 inches. Use M6X25 screws (x4) to
mount te primary worksurface to support plate.
M6X12
M4X10
Step 5
Use M6X12 screws (x4) to attach monitor holder to top of column.
Remove the M4X10 screw under the monitor holder to release the
VESA plate. Attach the VESA plate to the monitor and resecure to
monitor holder with the M4x10 screw.
Steps 1-5

3
Please contact [email protected] if you are missing any parts, have difficulty with assembly, or have any product related questions.
ACTIV DT Riser Installation Guide
Keyboard Tray
Optional
Step 1
Using the M6x12 screws (x4), attach the
keyboard bracket to primary worksurface
via the predrilled holes on the bottom of
primary worksurface.
Step 2
Insert Keyboard Tray Assembly into the
Keyboard Bracket until the pin releases
and keyboard tray is firmly secured.
Installation of your DT Riser is complete.
M6X12

4
Please contact [email protected] if you are missing any parts, have difficulty with assembly, or have any product related questions.
ACTIV DT Riser Installation Guide
Dual Monitor Mount
M6X12 M6X10
hand screw
Optional
Step 1
Use M6X12 screws (x4) to
attach the dual monitor mount
to top of the column.
Step 2
Prior to installing the monitors to
the unit, use the monitor mount
screws from your monitor to
attach the VESA plates to each
respective monitor.
Note: Single monitor holder is
re-used for the dual monitor
mount assembly.
Step 3
Use the M6x10 hand screws
(x4) to fasten monitor holder to
dual monitor mount through the
horizontal cut-outs in the mount.

5
Please contact [email protected] if you are missing any parts, have difficulty with assembly, or have any product related questions.
ACTIV DT Riser Installation Guide
Diagram
Bottom Wiring
