AMTI Products Slice 141 User manual

1. CONNECT AIRLINE, SET AT 80 PSI. 2. TURN ON SWITCH LOC. IN REAR OF
MACHINE.
3. ADJUST TOP INPUT GUIDE (141) WITH
MATERIAL INSERTED. MATERIAL
MUST BE CENTERED.
4. CLOSE WHEELS W/ADJUSTABLE HAND CRANK.
TOO LOOSE: MATERIAL WILL NOT BE INDEXED
AND SLIP. TOO TIGHT: MATERIAL MAY BE
CRUSHED. MAKE NOTE OF WHEEL POSITION
INDICATOR FOR FUTURE REF.
5. BOTTOM GUIDE 6. ADJUST BOTTOM GUIDE WHEEL APPROX.
¼” ON EACH SIDE OF MATERIAL
7. SLICE KEYPAD SAFETY SHIELD TO LEFT. 8. HIT “LOAD” KEY AND SLIDE KEYPAD
SAFETY SHIELD BACK TO RIGHT.
141 QUICK START GUIDE
*SAFETY: ALWAYS TURN OFF POWER AND DISCONNECT THE AIR LINES BEFORE
INVESTIGATING JAMS OR INTERNALS ISSUES. NEVER PLACE FINGERS, HANDS,
OR TOOLS INTO THE MACHINE WHILE IT IS PLUGGED IN OR AIR CONNECTED.
*BE SURE TO INSTALL TOP AND BOTTOM
CLEAR PLASTIC SAFETY SHIELDS.
BOTTOM SAFETY SHIELD
TOP SAFETY SHIELD

9. PRESS LH & RH ACTIVATION BUTTONS.
MATERIAL WILL ADVANCE FOR ONE CUT CYCLE
FOR LOAD SEQUENCE.
10. SEE PIC 9.
11. TO RUN: SLIDE KEYPAD SAFETY SHIELD TO
LEFT. PRESS “RUN” KEY.
12. LCD WILL SHOW “LENGTH”, ENTER LENGTH.
TOO LOOSE: MATERIAL WILL NOT BE INDEXED
AND SLIP TOO TIGHT: MATERIAL MAY BE
CRUSHED. MAKE NOTE OF WHEEL POSITION
INDICATOR FOR FUTURE REF.
13. PRESS “ENTER” KEY 14. LCD WILL SHOW “COUNT” ENTER QTY. THEN
PRESS “ENTER” KEY (PIC 13).
15. PRESS “RUN” KEY. SLIDE KEYPAD
SAFETY SHIELD BACK TO RIGHT.
16. REPEAT PROCEDURE AS IN PIC 9 & 10.
MATERIAL WILL THEN BEGIN “RUN” CYLCE.
NOTES:
1. THE LH & RH ACTIVATION BUTTONS ONLY
NEED TO BE PRESSED ONCE AND NOT HELD IN
PLACE DURING “RUN” CYCLE.
2. KEYPAD SAFETY SHIELD MUST BE SLID BACK
TO RIGHT HAND SIDE OF MACHINE DUE TO
SENSOR LOCATION. IF IT IS NOT, THEN THE SLICE
MACHINE WILL NOT PROCEED WITH EITHER
LOAD OR RUN CYCLES.
www.amtiproducts.com
847.588.7090
*SEE MANUAL FOR ALL SAFETY INFORMATION
