Automotive
Diagnostic Leak Detector
User Manual

Warning
1. Only Authorized operator could use this equipment.
2. Always conrm Fluid level before use, if the  level is low enough to the boom of the 
port, it will need a re
3. Do NOT use the unit on smoke sensive parts. Eg.Lamp housing.
4. Avoid using the equipment on windy environment.
Safety
1. Do not use the equipment while the engine’s running.
2. Wear Protecon Glass.
3. It is always best to test in a drafree area. Always use a bright halogen lamp to enhance the
visibility of the smoke exigthe leak.
Smoke Oil
The equipment is compable with mineral oil based baby oil like
Johnson&Johnson Pink bole.
Pure #5 white oil is the best choice if available.
Specicaon
Model
S1000
S2000
S3000
Pressure Gauge
N/A
Yes
Yes
Flow Indicaon
N/A
N/A
Yes
Flow Control
N/A
N/A
Yes
Flow Rate
<6 L/Min
Power Supply
12V automobile Baery 6Amp
Output Pressure
0.5-8Bar
Length of Power Cord
2.5Meters
Length of Smoke Hose
2.5Meters
Packing List
Main Unit
Power Cord
Smoke Delivery Hose
Funnel
Intake Bladder
Intake Bladder Replacement
Rubber
Adapter Cone
1
*
1
*1 *
1
*1 *1 *1 *

Accessories Explanaon
Power Cord
To oer connecon from the unit to the automobile baery, in order to drive the unit.
Smoke Delivery Hose
For introducon of smoke from the unit to Adapter Cone / Universal Intake Bladder or to the
vacuum pipe directly.
Funnel
Assistance method for smoke oil re, to prevent pour oil to the unit surface.
Intake Bladder
To t the intake and exhaust, seal the system and introduce smoke into the system. Especially
while the inlet posion is not rounded-shape.
1. Clean the inner wall of the intake opening while the Air Filter, and the Throttle connections are removed, so as
not to scratch the adapter.
2. Close the Pressure Relief Valve(A) next to the Hand Pump(B).
3. Put the Rubber Component(C) into the intake opening.
4. Inflate the Rubber Component(C) by pressing the Hand Pump(B)
till the intake opening is tightly sealed.
5. Now the system is ready to test, introduce air/smoke into the
system by plug the smoke nozzle into the Tube Opening(D) .
6. After test,pull off the smoke nozzle, release the inflated air by open the Pressure Relief Valve(A) next to the
Hand Pump(B).
7. Clean the adapter for storage, avoid contact with corrosive liquids.
Intake Bladder Replacement Rubber
The rubber on the Intake Bladder may be easily broken, if not operate it properly with cauon.
The rubber could be replaced with new one without replace the whole Intake Bladder.
Adapter Cone
To t the intake and exhaust, seal the system and introduce smoke into the system. It may fall out
at high pressure and need a second hand to push and hold at operaon.
Product Structure
The following list is designed to familiarize you with the funcon of the operaonal components
of the machine.
A - Oil Refill Port
For oil re while its needed. The funnel is a nice helper to prevent oil from poured to the surface
of the unit.
B - Velcro Strap
For collecon of the smoke delivery hose, and power cord before storage.

C - Smoke Outlet Port
While set up the unit, the Smoke Delivery Hose need to be mounted onto the Smoke Outlet .
D - Power Socket
While set up the unit, the power cords need to plug into the power socket.
E,F - State Indica�on and Air Control
The <E - LED Indicaon> LED has two states.
RED: Power ON.
GREEN: Pressurized air producon.
While power up the unit, the LED would turn RED.
Press <F - Air Control switch>, the <E - LED Indicaon> would turn GREEN, and the unit start
to generate pressurized air.
Press <F - Air Control switch> again anyme, the <E - LED Indicaon> would turn RED, and
the unit stops generag pressurized air.
G,H - State Indica�on and Smoke Control
The <G - LED Indicaon> LED has three states.
OFF: Smoke generaon not started.
GREEN: Smoke generaon.
RED: Overheat.
While not smoke the unit, the LED would be OFF.
Press <H - Smoke Control switch>, the <G - LED Indicaon> would turn GREEN, and the unit
start to generate smoke.
Press <H - Smoke Control switch> again anyme, the <G - LED Indicaon> would turn OFF,
and the unit stops generang smoke.
While the smoke generag chamber is overheat, for protecon, the smoke generaon
would be halted and the <G - LED Indicaon> would turn RED and restart generang smoke while
the smoke generag chamber cooled down, or you can switch it OFF by pressing <H - Smoke
Control switch> .
I - System Pressure Gauge
The Pressure Gauge displays the output pressure of the machine if block the smoke outlet port,
otherwise it shows the real me pressure of the system been tes.
Pressure Decay Test: This gauge can also be used to determine if a leak exists by switching othe
<F - Air Control> while the system is under pressure. If the gauge holds the displayed pressure,
there is no leakage. If the displayed pressure starts drops, there is leakage in the system.
J - Flow Meter
The purpose of the ow meter is to provide a quick visual indicaon of the amount of air/smoke
passing through the system being tested. If the smoke nozzle is in a closed system, and there are
no leaks in that system, the ow meter will read zero (ball at boom of scale). As the system is
lled with air or smoke, the ball in the ow meter will slowly fall to the boom of the scale as the
pressure in the system equalizes to the output pressure of the unit. As the ow decreases, the
output pressure will increase. If the ow meter ball never falls to the boom of the scale, there is
leakage or air passing through the system. It is not necessary to use smoke when using the ow
meter to determine if a leak exists.
K - Flow Dial
In many cases excessive smoke exig a leak may make it dit to determine the exact locaon
of the leak. The purpose of the Flow Control Valve is to decrease the amount of smoke exig a
leak so that its posion may be pinpointed without the masking eect of excessive smoke. Turn
clockwise to decrease ow, counterclockwise to increase ow. This valve is also used to lock out
the system under test and observe any pressure decay on the pressure gauge.

L - Oil Level Gauge
While set up the unit, smoke oil need to be  into the unit, do not exceed the MAX line.
Check and conm proper oil level periodically. If the oil level is lower than the MIN line,the unit
would need a re
Leak Status Indicaon
No Leak Small Leak Massive Leak
Generic Operaon
1. Turn OFF the ignion of the vehicle.
LEAK TEST OF VEHICLE SYSTEMS REQUIRES THE ENGINE TO BE OFF.
2. Dismantle the air ter and the throle connecons.
3. Clean the inner wall of the intake opening to avoid sharp objects and put the Universal Intake
Adapter into the opening.
4. Connect the Power Cord to 12V vehicle baery.
5. Now the Power LED would be ON, if else check the power supply.
6. Introduce the smoke nozzle into the system via the Adapter Cone.
7. Press Air Control Switch, wait for 30 seconds un the system is pressurized, and check the
Pressure Gauge & Flow Meter reading for leak status, if the unit is equipped with Pressure Gauge
& Flow Meter.
9. Press Smoke Control Switch, .unplug and Plug back the smoke nozzle back into the Cone
Adapter when there’s obvious smoke coming out of the smoke nozzle.
10. The system will be ready for leak check in 2 minutes. Use a bright light torch or working lamp
to assist.
11. Aer test, press Smoke Control Switch again to stop the unit from generag smoke and
press Air Control Switch to stop generag pressurized air.
12. Collect the Smoke Hose and the Power Cord with the Velcro Straps for storage. Hang the unit
or make it stand in UPRIGHT posion only. Do NOT lay it down.
Warranty
1. The main unit entled free warranty since the date of purchasing up to 12 months.
2. All accessories entled free warranty since the date of purchasing up to 6 months, except the
Intake Bladders.
3. Any damage to the machine caused by misuse, or improper operaon, is not covered by
warranty.
