1. Overview
Antaira Technologies’ LNP-0802C-SFP industrial PoE+ Gigabit unmanaged Ethernet switch series
is IP30 rated and DIN-Rail mountable. It comes with 6*10/100Tx which support IEEE802.3at with
high power PoE up to 30W/port, and 2*GigE combo ports (2*10/100/1000Tx RJ45, and 2*100/100
SFP slots for fiber), making it ideal for applications that demand a high bandwidth and long
distance communication.
This product series provides a high EFT and ESD protection to prevent any unregulated voltage
and is suitable for harsh environments. It supports the power redundancy feature by having a dual
power input design and a reverse power polarity protection. In addition, the built-in relay warning
function alerts maintainers when power failures occur.
The LNP-0802C-SFP series includes two models: one with an operating temperature range of -10
to 70°C, and the other one with an extended operating temperature range of -40 to 75°C. It is a
perfectly designed product to fulfill any special needs for industrial automation, outdoor
applications and harsh weather environments.
1.1 Key Features
 System Interface/Performance
 All RJ-45 ports support auto MDI/MDI-X function
 Embedded 6*10/100Tx (PSE 30W/Port), 2*Gigabit combo ports (2*10/100/1000Tx
RJ45, and 2* 100/1000 SFP slots)
 Store-and-forward switching architecture
 8K MAC address table
 Power line EFT protection: 2,000VDC; Ethernet ESD protection: 6,000VDC
 Power Input
 DC 48 ~ 55V redundant power
 Operating Temperature
 Standard operating temperature model: -10°C ~ 70°C
 Extended operating temperature model (–T): -40°C ~ 75°C
 Case/Installation
 IP-30 protection
 DIN-Rail and wall mount design

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
2
1.2 Package Contents
 1 - LNP-0802C-SFP (T): 8-port industrial PoE+ unmanaged Ethernet switch, with
6*10/100Tx (30W/port), 2* Gigabit combo ports (2*10/100/1000Tx RJ45, and 2*
100/1000 SFP slots)
 1 - User manual
 1 - Product CD
 2 - Wall mounting brackets and screws
 1 - DC cable –18 AWG & DC jack 5.5x2.1mm
1.3 Safety Precaution
Attention: If the DC voltage is supplied by an external circuit, please use a protection
device on the power supply input. The industrial Ethernet switch’s
hardware specs, ports, cabling information, and wiring installation will be
described within this user manual.

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
3
2. Hardware Description
2.1 Physical Dimensions
Figure 2.1, below, shows the physical dimensions of Antaira Technologies’ LNP-0802C-SFP series:
8-port industrial PoE+ unmanaged switches, with 6*10/100Tx (30W/port), 2* Gigabit combo ports
(2*10/100/1000Tx RJ45, and 2* 100/1000 SFP slots)
(W x D x H) is 46mm x 99mm x 142mm
Figure 2.1
LNP-0802C-SFP Series Physical Dimensions

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
4
2.2 Front Panel
The front panel of the LNP-0802C-SFP series: 8-port industrial PoE+ unmanaged switches, with
6*10/100Tx (30W/Port), 2* Gigabit combo ports (2*10/100/1000Tx RJ45, and 2* 100/1000 SFP
slots) is shown below in Figure 2.2.
2.3 Top View
Figure 2.3, below, shows the top panel of the LNP-0802C-SFP series switch that is equipped
with one 6-pin removal terminal block connector for dual DC power inputs (48~55VDC).
Figure 2.2 - The Front Panel of the LNP-0802C-SFP Series
Figure 2.3
Top Panel View of LNP-0802C-SFP Series

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
5
2.4 LED Indicators
There are LED light indicators located on the front panel of the industrial Ethernet switch that
display the power status and network status. Each LED indicator has a different color and has
its own specific meaning, see below in Table 2.1.
LED Color Description
P1 Green On Power input 1 is active
Off Power input 1 is inactive
P2 Green On Power input 2 is active
Off Power input 2 is inactive
Fault Red
On Power input 1 or 2 is inactive
Off Power input 1 and 2 are both functional, or no power,
inputs/ports link is active/port alarm is disabled
PoE Indicators
(Port 1~6) Green On The port is supplying PoE power
Off No powered-device attached or power supplying fails
LAN Port 1 ~ 6
(Upper LED)
Green
On Connected to network, 100Mbps
Flashing Networking is active
Off Not connected to network
LAN Port 1 ~ 6
(Lower LED)
Green
On Connected to network, 10Mbps
Flashing Networking is active
Off Not connected to network
Gigabit Combo Port LED Indicators
LED Color Description
SFP Port
Combo G1~G2
LNK/ACT
Green
On Connected to network
Flashing Networking is active
Off Not connected to network
LAN Port
Combo G1 ~G2
(Upper LED)
Green
On Connected to network, 1000Mbps
Flashing Networking is active
Off Not connected to network
LAN Port
Combo G1 ~G2
(Lower LED)
Green
On Connected to network, 10/100Mbps
Flashing Networking is active
Off Not connected to network
Table 2.1
LED Indicators for LNP-0802C-SFP Series

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
6
2.5 Ethernet Ports
 RJ-45 Ports
RJ-45 Ports (Auto MDI/MDIX): The RJ-45 ports (LAN 1~6) are auto-sensing for 10Base-T or
100Base-Tx device connections. The Gigabit combo RJ-45 ports (LAN G1~G2) are auto-sensing
for 10Base-T, 100Base-Tx, and 1000Base-T device connections. Auto MDI/MDIX means that the
switch can connect to another switch or workstation without changing the straight-through or
crossover cabling. See the figures below for straight-through and crossover cabling schematics.
 RJ-45 Pin Assignments (Table 2.2)
Pin Number Assignment
1 Rx+
2 Rx-
3 Tx+
6 Tx-
All ports on this industrial Ethernet switch support automatic MDI/MDI-X operation. Users can use
straight-through cables (see figure below) for all network connections to PCs, servers, other
switches or hubs. With straight-through cable, pins 1, 2, 3, and 6 are at one end of the cable, and
are connected straight through to pins 1, 2, 3 and 6 at the other end of the cable. The table below
(Table 2.3) shows the 10BASE-T/100BASE-TX/1000BASE-T MDI and MDI-X port pin outs.
Note
“+” and “-” signs represent the polarity of the wires that make up each wire pair.
Pin MDI-X Signal Name MDI Signal Name
1 Receive Data Plus (RD+) Transmit Data Plus (TD+)
2 Receive Data Minus (RD-) Transmit Data Minus (TD-)
3 Transmit Data Plus (TD+) Receive Data Plus (RD+)
6 Transmit Data Minus (TD-) Receive Data Minus (RD-)
Table 2.2
RJ45 Pin Assignments
Table 2.3
Ethernet Signal Pin Outs

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
7
The following figures show the cabling schematics for straight-through and crossover.
The following figures show the 10 and 100 Ethernet RJ-45 pin outs.
Figure 2.6 - RJ45 Ethernet Port Pin Outs
Figure 2.4 - Straight-Through Cable Schematic Figure 2.5 - Crossover Cable Schematic
Figure 2.7 - Straight-Through Cable Schematic Figure 2.8 - Crossover Cable Schematic

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
8
2.6 Cabling
Use the four twisted-pair, category 5e, or the above cabling for the RJ-45 port connections. The
cable between the switch and the link partner (switch, hub, workstation, etc.) must be less than
100 meters (328 ft.) in length.
2.6.1 Gigabit Combo Port - Copper/SFP (mini-GBIC)
Antaira’s LNP-0802C-SFP series has two
auto-detected Gigabit combo Ports
(2*10/100/1000Tx RJ45, and 2*100/1000
SFP slots for fiber connection).
 The Gigabit copper (10/100/1000T)
ports should use Category 5e or
the above UTP/STP cable for the
connection up to 1000Mbps. The
small form-factor pluggable (SFP)
is a compact optical transceiver
used in optical communications for
both telecommunication and data
communications.
 The SFP slots support dual rate
mode, which can switch the connection speed between 100 and 1000Mbps. They are
used for connecting to the network segment with single or multi-mode fiber. Users must
first choose the appropriate SFP transceiver to plug into the slots, and then choose the
proper multi-mode or single-mode fiber according to the transceiver being used. When
fiber optic is used, it transmits at a speed up to 1000 Mbps and it can prevent noise
interference from the system.
**Note:
The Gigabit combo ports (SFP/Copper) cannot be working at the same time. The SFP port
has the higher priority than the copper port; when inserting a 100M or 1000M SFP transceiver
(which has connected to the remote device via fiber cable) into the SFP port, the connection of
the accompanying copper port will be linked down.

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
9
The small form-factor pluggable (SFP) is a compact optical transceiver used in optical communications
for both telecommunication and data communication applications.
To connect the transceiver and LC cable, please follow the steps below:
First, insert the SFP transceiver module into the SFP slot as shown below in Figure 2.9. Notice
that the triangle mark is at the bottom of the SFP slot. Figure 2.10 shows SFP transceiver module
was inserted.
Second, insert the fiber cable of the LC connector into the transceiver as shown below in Figure
2.11.
Figure 2.9 - Transceiver to the SFP Module
Figure 2.10 - Transceiver Inserted
Figure 2.11 - LC Connector to the Transceiver

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
10
To remove the LC connector from the transceiver, please follow the steps shown below:
1. Press the upper side of the LC connector from the transceiver and pull it out to release as
shown below in Figure 2.12.
2. Push down the metal clasp and pull the transceiver out by the plastic part as shown below in
Figure 2.13.
Figure 2.12
Remove LC Connector
Figure 2.13
Pull Out from the SFP Module

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
11
2.7 Wiring the Power Inputs
Please follow the steps below to insert the power wire.
1. Insert the positive and negative wires into the PWR1 (V1+, V1-) and PWR2 (V2+, V2-)
contacts on the terminal block connector as shown below in Figure 2.14.
2. Tighten the wire-clamp screws to prevent the wires from loosening, as shown below in Figure
2.15.
**Note  Only use copper conductors, 60/75°C, tighten to 5 lbs.
 The wire gauge for the terminal block should range between 18~20 AWG.
Figure 2.15
Power Terminal Block
Figure 2.14
Power Terminal Block

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
12
2.8 Wiring the Fault Alarm Contact
The fault alarm contact is in the middle of the terminal block connector as the picture shows below
in Figure 2.16. By inserting the wires, it will detect the fault status including power failure or port
link failure (managed industrial switch only) and form a normally open circuit. An application
example for the fault alarm contact is shown below in Figure 2.16.
**Note
 The wire gauge for the terminal block should range between 12 ~ 24 AWG.
 If only using one power source, jumper Pin 1 to Pin 5 and Pin 2 to Pin 6 to
eliminate the power fault alarm.
Figure 2.16
Wiring the Fault Alarm Contact

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
13
3. Mounting Installation
3.1 DIN-Rail Mounting
The DIN-Rail is pre-installed on the industrial Ethernet switch from the factory. If the DIN-Rail is
not on the industrial Ethernet switch, please see Figure 3.1 to learn how to install the DIN-Rail on
the switch.
Figure 3.1
The Rear Side of the Switch and DIN-Rail Bracket

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
14
Follow the steps below to learn how to hang the industrial Ethernet switch.
1. Use the screws to install the DIN-Rail bracket on the rear side of the industrial Ethernet switch.
2. To remove the DIN-Rail bracket, do the opposite from step 1.
3. After the DIN-Rail bracket is installed on the rear side of the switch, insert the top of the DIN-
Rail on to the track as shown below in Figure 3.2.
4. Lightly pull down the bracket on to the rail as shown below in Figure 3.3.
5. Check if the bracket is mounted tightly on the rail.
6. To remove the industrial
Ethernet
switch from the rail, do the opposite from the above steps.
Figure 3.3
Stable the Switch on DIN-Rail
Figure 3.2
Insert the Switch on the DIN-Rail

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
15
3.2 Wall Mounting
Follow the steps below to mount the industrial
Ethernet
switch using the wall mounting bracket as
shown below in Figure 3.4.
1. Remove the DIN-Rail bracket from the industrial Ethernet switch by loosening the screws.
2. Place the wall mounting brackets on the top and bottom of the industrial Ethernet switch.
3. Use the screws to screw the wall mounting bracket on the industrial Ethernet switch.
4. Use the hook holes at the corners of the wall mounting bracket to hang the industrial Ethernet
switch on the wall.
5. To remove the wall mount bracket, do the opposite from the steps above.
Below, in Figure 3.5 are the dimensions of the wall mounting bracket.
Figure 3.5
Wall Mounting Bracket Dimensions
Figure 3.4
Remove DIN-Rail Bracket from the Switch

Antaira Technologies - Industrial Ethernet Switches
LNP-0802C-SFP Series User Manual V1.2
16
4. Hardware Installation
4.1 Installation Steps
This section will explain how to install Antaira Technologies’ LNP-0802C-SFP series: 8-port
industrial PoE+ unmanaged Ethernet switches, with 6*10/100Tx (30W/Port), 2* Gigabit combo
ports (2*10/100/1000Tx RJ45, and 2* 100/1000 SFP slots).
Installation Steps
1. Unpack the industrial Ethernet switch from the original packing box.
2. Check if the DIN-Rail bracket is screwed on the industrial Ethernet switch.
 If the DIN-Rail is not screwed on the industrial Ethernet switch, please refer to the
DIN-Rail Mounting section for DIN-Rail installation.
 If you want to wall mount the industrial Ethernet switch, please refer to the Wall
Mounting section for wall mounting installation.
3. To hang the industrial Ethernet switch on a DIN-Rail or wall, please refer to the Mounting
Installation section.
4. Power on the industrial Ethernet switch and then the power LED light will turn on.
 If you need help on how to wire power, please refer to the Wiring the Power Inputs
section.
 Please refer to the LED Indicators section for LED light indication.
5. Prepare the twisted-pair, straight-through category 5 cable for Ethernet connection.
6. Insert one side of the RJ-45 cable into switch’s Ethernet port and on the other side into the
networking device’s Ethernet port, e.g. switch PC or server. The Ethernet port’s (RJ-45) LED
on the industrial Ethernet switch will turn on when the cable is connected to the networking
device.
 Please refer to the LED Indicators section for LED light indication.
7. When all connections are set and the LED lights all show normal, the installation is complete.
