Anthro FCCzz/xx3 Series User manual

R
Questions?
1-800-325-3841
Anthro
Corporation Technology Furniture
®
10450 SW Manhasset Drive Tualatin, Oregon 97062 anthro.com
SAVE THESE INSTRUCTIONS!
Rev. F January 2006
Hello! Thank you for choosing Anthro.
Before beginning assembly of your Console Unit, take a moment to review the parts listed on the next page
to verify that your shipment is complete.
Please review the assembly instructions of all Anthro products you
purchased and are planning to include in this installation, prior to beginning this assembly.
Your Console Unit is heavy!
A second person will be needed for this assembly procedure.
To make the assembly of your Console Unit even easier, we have included all of the required tools. The handy
Hex Driver Bit can be used in your electric drill in place of the Hex Driver.
Hex Driver
5
/
32
”
............................................................
375-5000-00
Hex Driver Bit
5
/
32
”
.....................................................
375-5003-00
Hex Key
5
/
32
”
.................................................................
375-5016-00
Hex Key
1
/
4
”
..................................................................
375-5024-00
3-Way Wrench
.............................................................
225-5196-03
8 oz. Rubber Mallet
.....................................................
375-5022-00
Console Unit
Assembly Instructions
1-800-325-3841
Step 15
Begin by placing the Base Tube Assembly
(Locking Casters
as shown)
onto the Vertical Legs.
Attach the Base Tubes to each Leg by inserting a
fi t
Bolt through a Tube Washer, then insert the
fi t
Bolt
through the Base Tube and carefully thread into
each Vertical Leg.
Tighten all
fi t
Bolts and Cap Screws.
Step 16
(uses the
1
/
8
” Hex Key)
Carefully rotate your Console Unit onto the Casters.
Pop the six Small End Caps into the Leg ends.
Congratulations!
Your assembly is complete.
(
5
/
16
-18 X 3.5”)
fi t
Bolt
325-5194-00
fi t
Tube Washer
225-2050-00 or 225-3522-00
fi t Tube Washer
fi t Tube Washer
Locking Casters
Small End Caps
Adjust the Caddy Shelf height by:
1. Squeezing and holding the Paddle.
2. Reposition the Caddy to the desired location.
3. Release the Paddle.
Rotate Knob to
adjust Caddy
angle.
Squeeze Paddle
to adjust Caddy
height.
angle.
Adjust the Caddy Shelf angle by:
1. Rotating the Knob counterclockwise.
2. Reposition the Caddy to the desired angle.
3. Rotate the Knob clockwise.
Adjusting your Console Caddy

Anthro
Corporation Technology Furniture
®
10450 SW Manhasset Drive Tualatin, Oregon 97062 1-800-325-3841
anthro.com
18– 3” Non-Locking Casters
...........
Qty. 4
...................
150-5052-00
19– Caster Inserts
...............................
Qty. 6
...................
525-5032-00
20– 2.0” Large End Caps
...................
Qty. 4
...................
175-5157-00
21– Insert Screws
.............................
Qty. 6
...................
325-5052-00
22–
fi t
Console Back Trough-Y
......
Qty. 1
...................
225-2368-00
23– Button Head Screws
..................
Qty. 4
...................
325-5003-00
24– 1.5” Small Caps
.............................
Qty. 6
...................
175-5156-00
25– Small Support X
..........................
Qty. 1
...................
225-2014-00
26–
3
/
4
” Wood Screws
........................
Qty. 42
................
325-5106-00
27– Support Screws
............................
Qty. 12
................
325-5010-00
28–
fi t
Corner Connector Support-X
.
Corner Connector Support-X .Corner Connector Support-X
Qty. 1
...................
225-5582-00
29–
fi t
Corner Connector Support-Y
.
Corner Connector Support-Y .Corner Connector Support-Y
Qty. 1
...................
225-5583-00
All Fastener quantities listed here are the minimum needed
for your Console Unit assembly. There may be a few extra
Fasteners included, which are not counted in the Parts List.
Component list for part # FCCzz/xx3
Detailed views of all Hardware is provided with each Assembly Step.
06
08
09
13
15
21
19
Step 12
(uses the
1
/
4
” Hex Key)
Position the 15.27” Base Tube against the Console
Junction, then mate the Keyed Feature to the Keyed Tube
End. Secure the Base Tube using a Cap Screw & the
1
/
4
”
Hex Key.
Place the 15 “ Base Tube against the Base Junction and
secure using a Cap Screw.
NOTE: Do not yet fully tighten the 15” Base Tube Cap Screw.
Step 13
(uses the
1
/
4
” Hex Key)
Place the Console Base Junction-X onto the open ends
of the 15” & 15.27” Base Tubes as shown, then mate the
Keyed Feature to the 15.27” Keyed Tube End.
Secure both Base Tubes to the Console Base Junction
using two Cap Screws & the
1
/
4
” Hex Key.
NOTE: Do not yet fully tighten the 15” Base Tube Cap Screw.
Step 14
(uses the
1
/
4
” Hex Key)
Place the non-coped ends of the two remaining Cross
Tubes against the Base Junction and loosely
secure using
two Cap Screws.
Orient the remaining Base Tube assembly as shown.
Secure to the coped Cross Tube Ends by inserting
a
fi t
Bolt through a Tube Washer, then insert the Bolt
through the Base Tube and carefully
thread into each
Cross Tube, but don’t fully tighten the
fi t
Bolts yet.
Tighten the two Cap Screws installed during
this Step.
(
5
/
16
-18 X 1.5”)
Cap Screw
325-5225-00
(
5
/
16
-18 X 1.5”)
Cap Screw
325-5225-00
Leave these two holes
open on the 15” Base Tube
open on the 15” Base Tube
15.27” Base Tube
Keyed ends
Screw
Leave these two holes open
Leave these two holes open
15.27” Base Tube
Keyed end
Keyed end
Leave these two holes open
fi t Tube Washer
Side
holes
Cross Tubes
Locking Caster
Cap Screw
(
5
/
16
-18 X 3.5”)
fi t
Bolt
325-5194-00
fi t
Tube Washer
225-2050-00 or 225-3522-00
(
5
(5 (
/
16
-18 X 1.5”)
Cap Screw
325-5225-00
25
22
29
Base Tube Assembly
(from Step 11)
(from Step 11)
Console
Base
Junction-Y
Console Base Junction-X
Console
Base Junc-
tion-X
Remaining Base
Tube Assembly (from
Step 9)
Keyed Feature
01–
fi t
01– fi t 01–
Console Large Shelf
.............
Console Large Shelf .............Console Large Shelf
Qty. 1
...................
100-6498-00
02–
fi t
Console Caddy
......................
Qty. 1
...................
100-6499-
00
03–
fi t
03– fi t 03–
Adjusta Mechanism
...............
Qty. 1
...................
225-5547-00
(The Adjusta Mechanism is packaged separately & requires assembly)
04–
fi t
Console Back Trough-X
....
Qty. 1
...................
225-2367-00
05– Small Support Y
...........................
Qty. 1
...................
225-2015-00
06–
fi t
24.875” Vertical Legs
............
Qty. 6
...................
125-5230-00
07–
fi t
21” Base Tubes
.......................
Qty. 2
...................
125-5275-00
08–
fi t
30.5” Console Cross Tubes
...
Qty. 4
...................
125-5248-00
09–
fi t
Console Base Junction-Y
...
Qty. 1
...................
225-5787-00
10– Acorn Nuts
....................................
Qty. 2
...................
325-5023-00
11– Cap Screws
....................................
Qty. 8
...................
325-5225-00
12–
fi t
15.27” Keyed Base Tube
.....
Qty. 1
...................
125-5249-00
13–
fi t
13– fi t 13–
15” Base Tube
.........................
Qty. 1
...................
125-5250-00
14–
fi t
Console Base Junction-X
...
Qty. 1
...................
225-5786-00
15– 3” Locking Casters
......................
Qty. 2
...................
150-5053-00
16–
5
/
16
-18
fi t
Bolts
..............................
Qty. 10
................
325-5194-00
17–
fi t
Tube Washers
.........................
Qty. 10
225-2050-00 or 225-3522-00
Cap
Screw

Step 9
Insert two End Caps into the ends of both 21” Base Tubes.
Install two Caster Inserts into each Base Tube and
secure with one Insert Screw per Insert.
Insert one Locking and one Non-Locking Caster into
each Insert of a Base Tube as shown.
Step 10
Install one Caster Insert into both the 15.27” & 15” Base
Tubes and secure each Insert with one Insert Screw.
Insert one Non-Locking Caster into each Insert of both
Base Tubes as shown.
Anthro
Corporation Technology Furniture
®
10450 SW Manhasset Drive Tualatin, Oregon 97062 1-800-325-3841
anthro.com
Step 2
(uses the 3-Way Wrench)
Unpack the remaining Adjusta Mechanism components
and arrange them as shown at right.
Place one Crossbar end onto the lower Crossbar
Button and Threaded Bolt
(located on each of the Arm
Mechanisms)
. Secure the Crossbar to the Arm Mechanism
using one
5
/
16
” Hex Nut onto the Threaded Bolt.
Repeat for remaining Crossbar end and Arm Mechanism.
5
/
16
” Hex Nut
(included with 225-5547-00)
DETAIL VIEW
Arm Mechanism
Thread-
ed Bolts
5
/
16
” Hex
Nut
Paddle
Brake/Paddle
Assembly
Crossbar
Lower Crossbar
Button
ed Bolts
NOTE
:
it is very important that you attach the Crossbar
: it is very important that you attach the Crossbar :
ONLY
to the Lower Crossbar Button.
ONLY to the Lower Crossbar Button.ONLY
Step 1a
Your Adjusta Mechanism comes unassembled and is
boxed separately inside the Console Unit package.
Begin to assemble the Mechanism by fi rst locating the Adjusta
Crossbar and Brake/Paddle Assembly, position it as shown at
right. Depress the Paddle once to free the Brake Shaft.
Place the Brake Shaft between the two center Crossbar
Flanges. Insert the Post through both center Crossbar
Flanges and Brake Shaft.
NOTE
:
included with Adjusta Mechanism is a small bag of
: included with Adjusta Mechanism is a small bag of :
Hardware containing the (1) Post, (1) Cotter Pin, (2) Hex Nuts,
(2) Wood Screws, & (2) Cable Mounts.
Cotter Pin
(included with 225-5547-00)
Center Crossbar Flanges
Cotter Pin
Step 1b
Install the Cotter Pin through the single opening of the
Post to secure into place.
Post
(included with 225-5547-00)
Brake Shaft
Brake/Paddle Assembly
Crossbar
Post
Step 11
(uses the
1
/
4
” Hex Key)
Place one Base Tube Assembly
(Locking Casters oriented
as shown)
against the Coped Ends of two Cross Tubes.
Attach the Base Tube to the Cross Tubes by inserting
a
fi t
Bolt through a Tube Washer, then insert the Bolt
through the Base Tube and carefully thread into each
Cross Tube, but don’t fully tighten the
fi t
Bolts yet.
Place the Base Junction-Y against the opposite Cross
Tube Ends.
NOTE: Make certain the Keyed feature is oriented as shown.
Secure the Base Junction-Y to the Cross Tubes using
two Cap Screws and the
1
/
4
” Hex Key.
Insert Screw
(with pink threads)
325-5052-00
Locking
Caster
Caster Inserts placed
into the large holes
Leave these four
holes open
Non-Locking
Caster
FCCzz/xx3
Insert Screw
(with pink threads)
325-5052-00
Caster Insert placed
into the large holes
Non-Locking
Caster
15.27” Base Tube
Keyed Ends
Leave these two
holes open
holes open
holes open
(
5
/
16
-18 X 3.5”)
fi t
Bolt
325-5194-00
fi t
Tube Washer
225-2050-00 or 225-3522-00
fi t Bolt
fi t Tube Washer
Side holes
Cross Tube
Coped End
Base Tube
Assembly (from
Step 9)
Console Base
Junction-Y
(
5
/
16
-18 X 1.5”)
Cap Screw
325-5225-00
Cap
Screw
Locking Caster
15” Base Tube
Straight Ends
Keyed
Feature
Cross Tube
Insert Screw
Insert Screw

3
/
4
” Wood Screw
325-5106-00
Support Screw
325-5010-00
Anthro
Corporation Technology Furniture
®
10450 SW Manhasset Drive Tualatin, Oregon 97062 1-800-325-3841
anthro.com
Step 3
Place your Console Large Shelf onto the fl oor with the
predrilled holes facing up.
Position both Small Support Brackets onto the Large
Shelf and align two of the holes on each Support with the
predrilled holes on the Shelf. Loosely secure each Small
Support to the Shelf using two Wood Screws per Support.
Step 5
Place each of the Connector Supports onto the top as
shown.
Align the two holes on each Support with the predrilled
holes on the Shelf, then secure each Support using two
Wood Screws.
Step 4
Place both Back Troughs onto the Console Large Shelf,
between the installed Support Brackets.
Align the two Threaded holes on each Back Trough with
those on the installed Support Brackets. Carefully, thread
one Button Head Screw through the Support Bracket, into
the Back Trough. Repeat for remaining three Button Head
Screws & Threaded Holes.
Insert two Wood Screws through the two remaining
Holes on each of the Back Trough fl anges
(which should
be aligned with two predrilled holes on the Shelf)
and tighten
into place.
3
/
4
” Wood Screw
325-5106-00
3
/
4
” Wood Screw
325-5106-00
(
1
/
4
-20 X .50”) Button Head Screw
325-5003-00
Support Screw
325-5106-00
Step 6
Determine the best height for your Console Large
Shelf. These instructions will place your Shelf 31” from
the fl oor using the standard 3” Casters.
Attach both center Vertical Legs by loosely
installing
two Support Screws through each Connector Support
into Holes 1 & 3 from the top
(non-coped end)
.
Loosely install two Support Screws through each Small
Support into holes 1 & 3 from the top of both front Legs.
Install two Support Screws through holes 1 & 3 from
the top of both rear Legs.
Step 7
(requires Shelf to be 12” from fl oor)
Place the Mechanism onto the Shelf Assembly.
Align the Mechanism Flanges with the predrilled Holes
on the Shelf underside.
Secure the Mechanism to the Shelf using a total of twelve
Wood Screws.
Align the six Holes of the Brake Assembly with those on
the Shelf.
NOTE: It may be necessary to depress the Paddle while
manipulating the Brake over the predrilled Shelf Holes.
Secure the Brake Assembly using a total of six Wood Screws.
(non-coped)
(non-coped)
Bottom (coped) end
(12” high surface shown shaded)
(12” high surface shown shaded)
Paddle
Brake
Mechanism Flanges
FCCzz/xx3
Small Support
Bracket X
Small Support
Bracket Y
Small
Support
Bracket X
FIRST
: Install the But-
FIRST: Install the But-FIRST
ton Head Screws
SECOND:
Install
the Wood
the Wood
Screws
Back
Trough-Y
Back Trough
Flange
NOTE: Make sure the Back Supports
are in front of the Support Brackets.
Threaded
holes
Back
Trough-X
3
/
4
” Wood Screw
325-5106-00
Connector
Support-Y
Support-Y
Connector
Support-X
(12” high surface shown shaded)
(12” high surface shown shaded)
Step 8
(requires Shelf to be 12” from fl oor)
Rotate the Console Caddy so the predrilled holes face up.
Slide the Caddy under the Mechanism and align the three
holes located on each end of the Caddy and Mechanism.
Secure the Caddy using a total of six Wood Screws. Then,
secure the Paddle to the Caddy using four Wood Screws.
NOTE: Make certain the Cable for the Paddle is positioned
underneath the Adjusta Bar.
Paddle
Adjusta Bar
Adjusta Bar
Predrilled Holes
NOTE: For a fi nal Large Shelf height that is lower than 31”,
adjust one hole down for each inch of variance desired.
Connector
Supports
Hole 1
Hole 1
Hole 3
FRONT
Leg
Leg
Leg
REAR
Leg
CENTER
Leg
Cable
Wood Screw
Wood Screw
Support Screw
Wood Screw
Wood Screw
