Anyload OCSM Series User manual

OCSM Series
Light Duty Crane Scale
User’s Guide

2 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
TABLE OF CONTENTS
1. Safety Guides 3
2. Features 3
3. Specifications 4
4. Capacities 4
5. Display & Keys 4
Scale & Remote Controller keys 5
Indicators 5
Messages 5
6. Operations 6
On/Off 6
Zero 6
Tare In / Tare Out 6
Lock / Unlock 7
Accumulate 7
View 7
Delete 8
Clear 8
Unit Switch 8
Tare Set 8
Resolution Switch 9
Battery Power View 9
7. User Setup 9
Resolution 10
Auto-Off time 10
Idle Time 10
Brightness / Backlight 11
Anto-Motion 11
8. Battery Maintenance 11
9. Troubleshooting 12

3 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
1. Safety Guides
For good performance and precise measurement on daily operation, observe
the following safety guides and maintenance recommendations:
oDo NOT overload the scale. This may damage the load cell and will void
the warranty.
oDo NOT leave the load hanged on the scale for too long. This will
decrease scale’s accuracy and shorten the load cell’s life span.
oInspect the shackle and hook before using. Check clips, pins and screws
properly fitted and installed.
oCheck battery frequently. When scale drained its battery, charge the
battery with its dedicated charger or replace it with a new one
oAvoid rotating the scale, this may damage the load cell
oDo NOT use scale under thunder or rain.
oHang the scale on shelf or in dry and well‐ventilated room. Do NOT put
the scale on the ground directly.
oDo NOT attempt to repair the scale by yourself. Contact your local
dealer or to the Technical Support.
2. Features
This scale is a combination of sound and proven mechanical design, with
nowadays’ most advanced electronics to provide a superb feature sets. It is
versatile, reliable, accurate and easy to operate.
oSuperb Quality. Strictly in accordance with OIML R76, Chinese
GB/T11883‐2002 National Standards, and European CE directives.
oGreat Safety. Aluminum‐casting case, high firm hook and ring,
dedicated weighing load cell for safety installation.
oStrong Reliability. Cutting‐edge technology, quality integrated circuit
for high performance and long time stability.
oBroad Applicability. Popular and applicable in storage, textile,
metallurgy industry, and so forth.
oEasy to Use. Infra‐red remote controlling design. Easy to operate on
the scale or in distance.
oComplete Function. Division switch, unit conversion, automatic power
saver, battery inspection, idle mode, tare set, etc.

4 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
3. Specifications
Accuracy Class
Chinese GB/T 11883‐2002 Class III
Equivalent to OIML R76
Tare Range
100% F.S.
Zero Range
4% F.S.
Stable Time
≤10sec
Overload
100% F.S. + 9e
Safety Load
125% F.S.
Ultimate Load
400% F.S.
Battery
6V/5Ah lead acid battery.
Charger
AC220V or 110V input, DC9V/1500mA output
Op. Temp.
‐10℃~ +40℃
Op. Humidity
20℃≤90%
Display
30mm (1.2inch) LED or 35mm(1.38inch) LCD
4. Capacities
model
max. cap.
min. cap.
resolution
division
OCSM‐200lb
200lb
2lb
0.1lb
2,000
OCSM‐400lb
400lb
4lb
0.2lb
2,000
OCSM‐600lb
600lb
4lb
0.2lb
3,000
OCSM‐1000lb
1000lb
10lb
0.5lb
2,500
OCSM‐2000lb
2000lb
20lb
1lb
2,000
5. Display & Keys
Scale & Remote Controller keys
key
name
function
On/Off
press for 1sec, power-on scale.
press for 1sec, power-off scale.
exit without saving
Zero
zero scale
with , unit switch
increase digit
Tare
tare in/out
with , tare set
right scroll digit

5 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
Hold
lock/unlock
with , enter User Setup
confirm
2nd
2nd function
with , enter Password mode
exit and save
Acc
accumulate weight
with , switch resolution
decrease digit
Del
delete last weight
with , clear all weight
left scroll digital
View
view accumulated weight
with , view battery level
F1
NC
Indicators
indicator
name
note
Stable
lit when weight is stable
Zero
lit when weight is at zero
Tare
lit when weight is tared
Hold
lit when weight is locked
lb
lit when weight is in lb
kg
lit when weight is in kg (some models
have no kg label or annunciator)
Messages
Message
Stand for
note
Weight over range
Detect weight
Weight below range
SETUP
User setup
END
Save and exit
OFF
Power off

6 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
6. Operations
On/Off
oPress for 1sec, will power‐on scale.
oScale performs initialization and boot‐up testing then display flashes 3
times, and displays max. cap., battery power, then detects weight and
Auto‐Zero.
For information about Auto‐Zero, refer to Scale Setup in Technical Manual.
oPress or for 1sec, power‐off scale.
Scale displays battery power and off message, then cut off power
Zero
oPress or , will zero the scale.
Indicator lights on.
oScale must not be locked, otherwise displays.
oScale must be stable, otherwise displays.
oScale must not be tared, otherwise displays.
oWeight must be in Manual‐Zero Range, otherwise
displays.
For information about Manual‐Zero Range, refer to Scale’s
Configuration in Technical Manual.
Tare In / Tare Out
oIn gross mode, press or , will store the load as tare.
Indicator lights on
oScale must not be locked, otherwise displays.
oScale must be stable, otherwise displays.
oWeight must more than 0, otherwise displays.
oWeight must be lighter than 100% F.S., otherwise
displays.

7 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
Tare will reduce the apparent overloading range of scale. For example,
if a 5000*2kg scale has a 1000kg container as tare, the scale will
overload at a new weight of 4018kg (5000 –1000 + additional 9
divisions).
oIn net mode, press or , will remove the tare stored.
Indicator lights off.
oScale must not be locked, otherwise displays
Lock / Unlock
oPress , will hold the reading in the scale.
Indicator lights on.
oScale must be stable, otherwise displays.
oPress , unlock scale.
Indicator lights off.
Accumulate
oPress , will accumulate the current weight.
will display indicating weight is accumulated. Scale uses
displayed weight, so gross or net weight is added into the same
accumulator.
oScale must not be locked, otherwise displays.
oScale must be stable, otherwise displays.
oWeight must exceed 0, otherwise displays.
oScale must return zero before new weight can be accumulated
otherwise displays
View
oPress , enter the View mode.
Display flashes accumulated weight.
oScale must not be locked, otherwise displays.
oIf accumulated weight is zero, displays.
oPress , to view high 5‐digital and low 5‐digital.
oPress or to exit View mode.

8 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
Delete
oPress , will delete last accumulated weight.
will display indicating last accumulated weight is deleted.
Delete function only deletes the last weight.
oScale must not be locked, otherwise displays.
oIf last accumulated weight has been deleted, displays
Clear
oPress , then press , will clear all weights registered.
will display indicating all weight are cleared.
Unit Switch
oPress , then press , switching unit between kg, lb, USR.
When unit switches to kg, displays, indicator lights on (some
models do not have kg label or annunciator). When unit switches to lb,
displays, indicator lights on. When unit switches to USR,
displays, indicator and lights off.
oUnit Switch changes unit temporarily. Scale does not save unit unless
System Unit is changed.
For more information about USR, refer to Scale’s Configuration in
Technical Manual
Tare Set
oIn gross mode, press , then press or , will enter Tare Set
mode.
Scale displays 00000, waiting for user input.
oPress or , and or ,input weight. Press , enter
weight.
Indicator lights on.
oScale must be in gross mode, otherwise displays.
oWeight must exceed 0, otherwise displays.
oWeight must be lighter than 100% F.S., otherwise displays

9 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
Resolution Switch
oPress , and then press , switch display resolution
oScale displays new resolution.
oHigh resolution offers better accuracy at the cost of longer
measuring time and stricter requirement of load’s stability.
oDesigned to meet the OIML R76’s directive, the scale has the
best (default) performance at 2000 to 3000 division.
oResolution Switch changes the apparent overloading range of
scale. For example, if a 3000*1kg scale is switched to
3000*0.5kg, it will overload at 3004.5kg (3000 + 9*0.5), while
by default, it overloads at 3009kg (3000 + 9*1).
oDefault resolution will be restored next time when scale is
powered on or enter User Setup. To save changes in
resolution for later, enter User Setup and change Resolution.
For information about Resolution, refer to User Setup.
Battery Power View
oPress , and then press to view battery power.
oScale displays battery voltage, for example , indicating
6.38V.
For information about battery, refer to Battery Maintenance
7. User Setup
oPress , and then press , enter User Setup mode.
oMessage displays.
oPress will enter Resolution.

10 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
Resolution
Scale displays resolution to be set. For example , indicating
resolution is set to 0.5.
oPress or , and , change resolution
oPress or , exit without saving. Press , exit and save.
Designed to meet the OIML R76’s directive, the scale has thebest
(default) performance at 2000 to 3000 division
oPress will enter Auto‐Off.
Auto‐Off Time
oScale displays auto‐off time, e.g., indicating 15min.
oPress or , and , change Auto‐Off time.
oPress or , exit without saving. Press , exit and save.
Auto‐Off function maximizes scale’s battery life against people’s
carelessness not to power off scale when it’s not working.
Auto‐Off starts countdown timer when there’s no action or load is
stable. Any key pressing or motion in load restarts countdown timer.
Auto‐Off time can be set to: 0 (never auto‐off ), 5min, 15min, 30min,
60min.
oPress will enter Idle Mode setting.
Idle Time
oScale displays idle time, e.g., indicating 30sec.
oPress or , and , change idle time.
oPress or , exit without saving. Press , exit and save.
To maximize battery life, scale automatically enters Idle Mode, when
there’s no action or the load is stable. In Idle Mode, scale works in
low‐power consumption status. Any key pressing or motion in load
wakes up scale from Idle Mode.
Idle time can be set to: 0 (never ilde), 5sec, 15sec, 30sec, 60sec.
oPress will enter to Brightness / Backlight setting.

11 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
Brightness / Backlight
Scale displays LED brightness / LCD backlight status.
oPress or , and , change LED brightness / LCD backlight
status.
oPress or , exit without saving. Press , exit and save.
Dim LED brightness or turn off LCD backlight saves battery power
dramatically.
LED brightness can be set to: 1(dim), 2(normal), 3(bright) 。
oPress will enter Anti‐Motion
Anti‐Motion
Scale display Anti‐Motion level to be set, e.g., indicating
level 1.
oPress or , and , change Anti‐Motion level.
oPress or , exit without saving. Press , exit and save.
At the cost of measuring time, Anti‐Motion function intelligently settles
weight reading when scale is in motion. The weaker Anti‐Motion is, the
faster weight reading displays, but the longer it takes to be stable.
Anti‐Motion can be set to: 0 (off), 1 (weakest), 2 (weak), 3 (normal), 4
(strong), 5 (strongest).
oPress will enter Auto‐Off again.
8. Battery Maintenance
To maximize battery life, observe the following battery maintenance
guides:
oThis scale is powered by a 6V rechargeable lead‐acid battery.
oBattery is permanently attached to battery door. To remove battery
pack, remove both screws on the access door, pull battery pack
straight out, and unplug battery cable from scale.
oDepending on LED brightness or LCD backlight setting, battery works
from 40 hours to 100 hours.
oIn order to conserve battery life, enable Auto‐Off and Idle Mode, dim
LED brightness or turn off LCD backlight.

12 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
oCharging time for a completely discharged battery is approximately 8
hours.
oTo obtain maximum service life, battery should be stored between
‐20℃(‐4°F) and +50℃(122°F). Stored batteries should be recharged
every three months.
oWhen charging battery, charging indicator being green indicates lack of
power, being red indicates full.
9. Troubleshooting
Symptom
Possible Cause
Suggested Solution
not power-on after
is depressed
discharged / defective
battery
check battery and
charge
defective key
press harder and keep
pressing 2sec
defective power cable
open front panel, check
power cable
defective mainboard
contact representative
display flashes
discharged battery
charge battery
no action taken after key
pressed
scale is disturbed
re-plug power cable
defective key
contact representative
weight reading not
stable
load in motion
keep load stable
weak Anti-Motion
change Anti-Motion
level
damped loadcell or
mainboard
dry loadcell or
mainboard
defective mainboard
contact representative
weight reading not zero
when no load
discharged battery
charge battery
load-cell stressed too
long
hang scale in storage
drifting loadcell
contact representative
large error in weight
reading
scale not zeroed before
applying load
manual Zero scale
before loading
wrong unit
switch to correct unit
scale requires
calibration
calibrate scale
defective loadcell or
mainboard
contact representative
battery cannot be
recharged
defective charge board
contact representative
defective battery
short remote controlling
distance
discharged / defective
remote battery
replace remote
controller batteries

13 | ANYLOAD OCSM Series Light Duty Crane Scale User’s Guide
10. Notes

ANYLOAD Weigh & Measure Inc.
Website: www.anyload.com
Email: [e-mail]
Fax: [phone]
North America Toll Free: 1-855-ANYLOAD (269 5623)
